Cresco 10SW User manual

Thank you for purchasing our
Cresco 10 SW Fertilizer and Salt Spreader
We’re delighted to have you as a customer and are here to help!
First off, let’s get your product assembled!
Scan for video assembly: Table of Contents:
1: Spare Parts
2-4: Assembling your Cresco10SW
5-8: Slide System Explanation
9-10: How to Use the Cresco10
11: Warranty

1
Spare Parts
Empty all contents of the box onto a flat surface and count parts to make sure all are there.
CRESCO 10 PARTS LIST: 1. Wheel (X2) 2. Handle Bar 3. Stand 4. Gear box and Impellor 5. Axle bearing (X2) (One is on the axle, the second one is in the parts pack)
6. Plastic Wheel Caps 7. Wheel Cap Screws 8. Agitator 9. M6x60 (X4) 10. M6 Nuts (X4) 11. M6x35 (X2) 12. M6 x Wing Nut (X2)
13. Plastic Wheel Axle (With part 5 attached) 14. Lower Frame (X2) 15. Control Rod 16. Hopper Body 17. Control Lever 18. Summer Slider
19. Adjustors left/right
20. Pivot Bracket 21. Lower Linkage 22. Winter Slider 23. R-pin Small 24. 4x Screws 25. 4x Washers
Scan to view
spare parts:

2
Slide System Explanation
Your Cresco spreader comes with two different application sliders.
One is for winter and the other is for summer!
Winter Summer
Winter Slider Summer Slider
Please locate and choose your slider.

3
Assembling your Cresco 10
You will need a phillips head
screwdriver, one pair of plyers/
grips and an m6 metric spanner.
If you are using the spreader
for fertiliser or seed, slide
the summer application into
position as shown above.
ASSEMBLING THE SLIDER SYSTEM, LINKAGE & LOWER FRAME:
Locate the lower linkage (21)
and place it through the pivot
bracket (20).
Push the free end of the lower
linkage (21) through the centre
hole of the chosen slider.
Secure the lower linkage (21) in
place using the R pin small as
shown.
Take the two lower frames (14)
and attach them to the hopper
body (16) using the M6x60 bolts
(9). SEE NOTE.
When placing the legs on the
hopper, make sure the two
holes on the side of the lower
frame (Item 14) are on the
outside. There should be one
hole on the inside.
2
4
6 7
5
NOTE
Summer Slider
If you are using the spreader
for winter, slide the winter
application into position as
shown above.
1
Winter Slider
Locate & tighten the 4 screws &
washers to fix the required slider
(winter or summer) into position.
Make sure the screws are not
overly tight and the slider can
slide backward and forward.
3

4
Assembling your Cresco 10
Place the one axle bearing (Item
5) into the hole shown at the
bottom of the lower frame (14).
Feed the axle (13) through the hole
(without bearing) on the lower legs.
Push it through the gearbox and bearing
(Item 5) on the other side. Ensure the
axle bearings are firmly in.
ASSEMBLY CONTINUED:
Place both wheels (Item 1) onto
the ends of the axle (Item 13).
Push the plastic end cap (6)
into the centre hole of the axle.
Use screwdriver and wheel cap
screws (7) to tighten. Complete
on both sides.
Turn the spreader onto its wheels and
ensure they work correctly. Align the
holes at the bottom of the handle bar
(item 2) with the holes at the top of the
lower frame (item 14). You may need to
pull the ends apart slightly to place in
position.
Use M6x35 (11) and M6 wingnuts
to tighten as shown. Repeat on
both sides.
Protruding from the back of
the hopper body (item 16) is
the pivot bracket (20) pictured
above. Clip the L shaped end
of the control rod (item 15) into
the hole on the pivot bracket
(item 20).
BC
10
11
D
9A
ASSEMBLING THE HANDLE BAR
AND CONTROL ROD:
12
Arrow on gearbox must
be facing forwards.
Rotate the hopper body (16) to
the position shown. Place the
gear box and impellor (4) in the
centre hole of the hopper body
(16), let it rest there. Make sure
the arrow on the gearbox faces
forwards.
9
Take the stand (Item 3) and
place it into the protruding
M6x60 bolts (x4) (Item 9).
Tighten with the M6x30 lock
nuts (x4) (Item 10).
8

5
Assembling your Cresco 10
With the hopper aperture fully
open (as in figure 13) and the
gauge lever set at 20, tighten
the screw firmly to secure the
control rod.
Affix the agitator pin (Item 8)
through the impellor shaft inside
the hopper.
15
16
FINAL TOUCHES:
Before tightening the control
rod. Make sure the application
holes in the hopper are fully
open and the control lever is
set at 20.
14
Summer slider pictured
IMPORTANT
Feed the other end of the
control rod (item 15) through the
hole of the control lever (17).
Make sure you push the control
lever all the way to setting 20.
Do not tighten into place.
13

6
Slide System Explanation
Ice Melts
Winter
For spread width 6 meters. Pavement setting (2 meters).

7
Border Control
To protect your borders simply slide the border control into position to cut off
the left hand side of the spread pattern.
Slide System Explanation
Summer
The summer slide system comes with 20 different settings and a border
control. This provides control over the accuracy of your spreading.
Large/Heavy Materials Small/Light Materials

8
Slide System Explanation

9
How to use the Cresco 10
How to Apply Fertilizer to your lawn like a pro in four steps!
Step 1: Understanding the application rate and settings
Step 2: Preparing the Spreader
Step 3: Walking Patterns for the optimum application
Step 4: Cleaning & Maintenance
Step 1: Understand the application rate and
settings
Application Rate Settings
Check the back of the fertilizer bag
to find out the recommended G/m²
and spreader application setting.
If the spreader setting is not on the back
of the bag, please get in touch with your
fertilizer bag provider.
Set the handle to the correct setting.
If you are unable to find the required Cresco volume setting, please visit,
www.crescospreaders.com

10
How to use the Cresco 10
Spread Pattern Settings
Once you have the correct application rate, you will need to check that the
spread of material is even on both sides of the spread pattern.
To balance the spread pattern for your material, check online or with your
fertilizer or seed provider.
For a quick reference, please refer to our guide on the previous page
Step 2: Preparing the Spreader
Check the material to be applied is dry and free flowing to ensure it will flow
freely through the hopper. Make sure your application rate and spread pattern
settings are correct, close the application hole fully and then pour in your
material.

11
How to use the Cresco 10
WARNING **Do not pour material in the hopper when the application holes are
open as it can lead to spillages or leaks that can damage the area. Do not open
the gauge until you are over the area you want to spread and are moving at a
brisk walk***
Step 3: Walking Patterns for the optimum
application (For Fertilizer Only)
There are two methods of effective spreading, longitudinal fertilizer spreading
and cross sectional fertilizer spreading.
When applying fertilizer please make sure you walk at 3mph and keep the
hopper in a stable, upright position.

12
Longitudinal Fertilizer Spreading
½ the application rate suggested on
the back of your fertilizer bag
Cover the area as shown by going
over your tire marks left on the pre-
vious pass
Cross Sectional Fertilizer Spreading
½ the application rate suggested on
the back of your fertilizer bag
Cover the area as shown making
the second pass at the edge of your
spread pattern or where the fertilizer
thrown begins to feather.
How to use the Cresco 10
Step 4: Cleaning and Maintenance

13
This chart should be used as a guide only.
Application guide for fertilisers.
LHS (Left hand slider adjuster) is recommended to be engaged when spreading large sized granular materials to provide a more uniform distribution on the left and right side of the spread pattern. Conversely with very light materials (e.g. grass seed) engaging the RHS (Right hand slider adjuster) will be similarly beneficial. *Do not spread Fertiliser or seed materials with the winter slider* The manufacturer cannot be held responsible for any variations in sq. metre application volumes, or spread width differences, due to possible variations in materials, application conditions at the time and different operator application techniques.

14
2-Year Limited Warranty
DMMP Ltd. warrants this product free of defects in original workmanship and
materials for a period of 2-Years to the end user with the original dated purchase
receipt.
If a manufacturing non-conformance is found, DMMP Ltd. will repair or replace
the part(s) or product at it’s discretion at no charge provided the failure is not
the result of incorrect installation, mishandling, misuse, tampering, or normal
wear and tear as determined by DMMP ltd.
DMMP Ltd. at its discretion may require that the part(s) or product be returned
along with the original purchase receipt at owners’ expense for examination and
compliance with the terms of this warranty.
Do not return any product without first receiving authorization
from DMMP Ltd. To seek remedy under this warranty, contact
DMMP Ltd. at [phone] or email us at info@
dmmp.co.uk and describe the nature of the manufacturing
defect.
SPECIFIC LIMITATIONS:
This warranty covers only the
part(s) or product; any labour
charges associated with repair or
replacement of nonconformances
are specifically excluded.
Due to the corrosive nature of most fertilizers
and ice melt products, DMMP Ltd makes no warranty
against and specifically excludes part(s) or product
degradation or failure due to corrosion or its effects.
To negate the effects of corrosive materials on
your product, clean and dry your spreader or seeder
thoroughly after each use. As a further preventative
measure, coat all metal parts with a light oil or silicon
spray.
