DESCRIPTION:
TheST-CBLisCRESTRON'sprogrammingcablethatenablescommunicationbetweentheSeriesST-
1500TouchpanelandtheCRESNETIIremotecontrolsystem.Theprogrammingcableissixfeetinlength.
Oneend of the ST-CBL has a RA, 3.5 mm stereo connector that inserts into right side of the touchpanel
(whenviewingthetouchscreen).TheotherendoftheST-CBLhasafour-positionfemaleconnectorthat
inserts into the control system port labeled NET. Refer to the illustration below for proper connection.
NOTE The ST-CBL only needs to be connected when loading a program.
NET G
YZ
24
CNRACK OR
CNRACK-D
OR CNMS
SERIES ST-1500
TOUCHPANEL
ST-CBL
