CBL-USB-RS232KM-6
RS-232 to USB Keyboard/Mouse Cable
Installation Guide
Description
The CBL-USB-RS232KM-6 RS-232 to USB
Keyboard/Mouse Cable allows RS-232 serial
communication from a Crestron®control system to
produce keystroke and mouse actions on a target
computer.
NOTE: This product can be used only with 3-Series®
control systems.
Additional Resources
Visit the product page on the
Crestron website
(www.crestron.com) for additional
information and the latest rmware
updates. Use a QR reader
application on your mobile device
to scan the QR image.
Installation
Connect the CBL-USB-RS232KM-6 to the target
computer’s USB port and the control system’s serial
port. If the control system does not use a DB9
connector for RS-232 communication, wire a cable
between the included adapter and the control system to
create a connection to the control system’s RS-232
port. Refer to the adapter’s installation notes to connect
the pins shown in the following table.
Serial Conguration
The control system’s RS-232 port should be congured
to operate at 9600 baud, 8 data bits, and 1 stop bit.
When programming a control system with Crestron’s
programming software, use the two-way serial driver
programming module to send mouse and keyboard
commands from the control system’s RS-232 port.
Custom serial commands can be sent as well. Refer to
the CBL-USB-RS232KM-6 Reference Guide (Doc. 7854)
at www.crestron.com/manuals for details.
PIN
DESCRIPTION
2
Serial data, connected to Receive on control
system
3
Serial data, connected to Transmit on control
system
5
Logic ground

As of the date of manufacture, the CBL-USB-KM232-6 has
been tested and found to comply with specications for CE
marking.
Federal Communications Commission (FCC) Compliance
Statement
This device complies with part 15 of the FCC Rules.
Operation is subject to the following conditions:(1) This device
may not cause harmful interference and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
CAUTION: Changes or modications not expressly approved
by the manufacturer responsible for compliance could void
the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Industry Canada (IC) Compliance Statement
CAN ICES-3 (B)/NMB-3(B)
Product warranty can be found at
www.crestron.com/warranty.
The specic patents that cover Crestron products are listed at
patents.crestron.com.
Certain Crestron products contain open source software. For
specic information, please visit
www.crestron.com/opensource.
Crestron, the Crestron logo, and 3-Series are either
trademarks or registered trademarks of Crestron Electronics,
Inc. in the United States and/or other countries. Other
trademarks, registered trademarks, and trade names may be
used in this document to refer to either the entities claiming
the marks and names or their products. Crestron disclaims
any proprietary interest in the marks and names of others.
Crestron is not responsible for errors in typography or
photography.
This document was written by the Technical Publications
department at Crestron.
©2016 Crestron Electronics, Inc
Crestron Electronics, Inc. Installation Guide
15 Volvo Drive DOC. 7853B
Rockleigh, NJ 07647 (2045790)
Tel: 888.CRESTRON 12.16
Fax: [phone] Specications subject to
www.crestron.com change without notice.
