Crestron SmartPresenter SPC-122 User manual

Crestron SPC-122 SmartPresenter™ Cable
Crestron Electronics, Inc. Operations Guide - DOC. 5780
15 Volvo Drive SmartPresenter™ Cable: SPC-122
Rockleigh, NJ 07647 07.99
Tel: 888.CRESTRON Specificationssubject to change without notice.
Fax: [phone] www.crestron.com
SmartPresenter™ Cable: SPC-122
The SPC-122 is designed for the SmartPresenter™ and used to control specific
serially-controlled devices. The entire length of the cable is approximately 15 feet
(4.572 meters) with a RJ11 (6-position, 6-pin) connector at one end and a DB9M
connector at the other end.
Physical View of the SPC-122
UNMARKED PINS
ARE NOT CONNECTED
AS VIEWED FROM
SOLDER CUP SIDE 15 FEET
(4.572 METERS)
BLK #5 (GND)
RED #3 (TX)
GRN #2 (RX)
WHT
PIN #1
NOTE: Alteration of the SPC-122
in any manner may affect its
performance within the control
system. Crestron cannot
guarantee its behavior if altered.
A serially-controlled device can be controlled with the SmartPresenter™ only if the
appropriate Q-Code is assigned to OUTPUT 4 on the SP-1. The SP-1 recognizes the
Q-Code as an RS-232 switching device and outputs commands for that device to the
PC port (rather than the OUTPUT 4 port). Use the SPC-122 to connect the SP-1 to
the serially-controlled device (refer to illustration below). Only those devices with a
cable code “c” designation in the Crestron Q-Codes table (latest version of the
SmartPresenter Quick Guide, Doc. 5742) require the SPC-122.
Hookup Connection for Controlling a Serially-Controlled Device
SPC-122
SERIALLY-CONTROLLED
DEVICE
