Crosley CO7275 User manual

Outdoor Wicker Side Table
CO7275

2
PART LIST
A B C
HARDWARE LIST
#1 #2 #3
Bolt
12 PCS (Extra 1)
Flat Washer
12 PCS (Extra 1)
M6*30mm M6mm
2 PCS
Side
2 PCS
Panel End Panel
Top Panel
1 PC
Allen Wrench
1 PC
M6mm
D
1 PC
Glass Top

and allen wrench (part #3).
A
B
#1
#2
#3
A
C
B
#1
#2
#3
NOTE: Please do not fully tighten bolts until unit is fully assembled.
Step 1. Lay side panel (part B) down on a soft flat surface, such as carpet, as shown below.
Attach top panel (part A) to side panel (part B) using bolts (part #1), flat washers (part #2)
Step 2. Attach end panels (part C) to top panel (part A) and side panel (part B) using bolts (part #1),
flat washers (part #2) and allen wrench (part #3).
NOTE: Please do not fully tighten bolts until unit is fully assembled.
3
#1
#2
#3
x2
x2
x1
#2
#3
x4
x1
#1 x4

Step 3. Attach side panel (part B) to top panel (part A) and end panels (part C) using bolts (part #1),
flat washers (part #2) and allen wrench (part #3).
NOTE: Please fully tighten all bolts at this time.
#2
#3
x6
x1
#1 x6
Step 4. Carefully turn assembled unit upright. Place glass top (part D) on the table.
B
B
#1
#1
#2
#3 #3
#2
A
C
C
D
4
