Crowcon Detective Net User manual

Detective Net
Quick Reference Guide
LED Indications
LED 1 - Powered/In learn mode
LED 2 - Network Status
LED 3 - Alarm/Alert
LED 4 - Master/Slave status
Battery LED - Low battery
Connection
M070007/ENG
Issue 2 Jan 2015

Setting Up a Simple Wireless Network
Turn On Devices
XPress and hold left button until all LED’s scroll from left to
right.
Reset Devices
XOnce powered, press and hold left button for 3 seconds.
XIf device previously congured as a slave, LED 1 will ash 3
times to indicate a successful reset.
XIf device previously congured as a master, LED 1 and LED 4
will ash 3 times to indicate a successful reset.
Toggle Devices (Slave to Master/Master to Slave)
A network requires just one master device, to toggle between
master and slave, proceed as follows:
XHold right button for 3 seconds.
XIf toggling from slave to master LED 4 will ash 3 times.
XIf toggling from master to slave LED 1 will ash 3 times.
Place Master Device In Learn Mode
XOnce devices are powered and reset, select the master
device.
XDouble click right button to enter learn mode.
XLED 1 will continuously ash red and LED 4 will ash green.
Learn Slave Device to Master
XSelect the slave device place 1m apart from master device.
XDouble click right button to enter learn mode.
XLED 1 will continuously ash red and device will learn
automatically.
XOnce complete LED 1 turns off.
XLED 2 will ash green to indicate the slave is connected to
the master.
XRepeat this process for all other slaves to be connected to
the network.

Exit Learn Mode - Master Device
XIf no further slaves are required, return to the master and
double click the right button.
XLED 1 will turn off, LED 4 will continue to ash green and LED
2 will now ash green.
XNetwork is now congured.
Turn Off Devices
XTo turn off devices, hold both buttons until all LED’s scroll
from right to left.
Setting Up Previously Congured Network
Power up master device
XPress and hold left button until all LED’s scroll from left to
right.
Power up slave devices
XPress and hold left button until all LED’s scroll from left to
right.
XLED 2 will ash green when network connected.
XIf necessary press any button establish communications -
LED2 will ash amber continuously then ash green when
connected.
XRepeat this process with all slave units ensuring LED 2
ashes green.
Perform Network Connection test
XPress & hold both buttons for 1 second on any device.
XAll devices will initiate an alert for 10 seconds.
