Crowcon Gas-Pro User manual

Gas-Pro
User & Operator Manual
M07995/Eng
Issue 15 January 2023
Multi-gas monitor

2
© 2023 Crowcon Detection Instruments Limited
Gas-Pro Multi-gas monitor
Contents
Prologue 5
Gas-Pro Overview 5
Safety Information 6
Unpacking 8
1. Set-up 9
1.1 Prior to use 9
1.2 Gas-Pro orientation 9
1.3 Charging 10
1.4 Fittingaowplate 11
1.5 Quick view 12
2. Operation 13
2.1 General 13
2.2 Turn on 13
2.3 Pump test 15
2.4 Detecting gas 16
2.4.1 Diffusion monitoring 16
2.4.2 Pumped mode 16
2.4.3 Manual sampling 17
2.4.3.1 Using the Hand Aspirator 17
2.5 Alarms 18
2.5.1 Low battery alarm 18
2.5.2 Instantaneous alarm 18
2.5.3 Time weighted average alarm (TWA) 18
2.5.3.1 TWA Resume function* 18
2.5.4 Accepting and clearing alarms 19
2.5.5 Sensor types 19
2.5.5.1 Oxygen sensors 19
2.5.5.2 Electro-chemical sensors 19
2.5.5.3 Infra red sensors 19
2.5.5.4 Pellistor sensors 20
2.5.5.5 Pellistor saver mode 20
2.5.5.6 PID 20
2.6 Gas-Pro functions 21
2.6.1 Accessing the user menus 21
2.6.2 Home screen 21
2.6.3 Manual zero 21
2.6.4 Time weighted average 21
2.6.5 Pre-entry check (PEC) 21
2.6.5.1 Starting a Pre-entry check 22
2.6.5.2 Carrying out a Pre-entry check 22
2.6.6 Peak review 23
Prologue
Maintenance
Operation
Set-up
PC software
Gas testing
Accessories
Specications
Appendices
Trouble
shooting
Warranty
Contents

3
© 2023 Crowcon Detection Instruments Limited
Gas-Pro Multi-gas monitor
2.6.7 Pellistor Correction Factor 23
2.6.8 Settings 23
2.6.8.1 User setting 23
2.6.8.2 Pump setting 23
2.6.8.3 Sounder volume 23
2.7 Shut down 24
2.8 Additional Features 24
2.8.1 2.8.1 +ve Safety™ 24
2.8.1.1 +ve Safety™ indicator meanings 24
2.8.2 Data and event logging 24
2.8.3 Bump/Pump functionality 25
2.9 Tank Check Mode 25
2.9.1 Dual-Range Operation 26
2.9.2 Differences with Home Screen 26
2.9.2.1 Instantaneous Alarms 26
2.9.2.2 TWA 26
2.9.2.3 Pre-Entry Check (PEC) 26
2.9.2.4CondenceTone 26
2.9.2.5 Display Backlight 26
3. Gas testing and calibration 27
3.1 Introduction 27
3.2 Bump Test Functionality 28
3.2.1 Speedy bump 28
3.2.1.1 Procedure 28
3.2.2 Smart bump 29
3.2.2.1 Procedure 29
3.2.3 Calibration after bump fail 29
3.2.3.1 Procedure 29
3.3 New sensor calibration/service 29
3.4 Gastestscreenow 30
4. Icon overview 31
5. Service and maintenance 32
6. PC interface and Portables Pro 33
6.1 General 33
6.2 PC interface cable 33
7. Accessories 34
8. Specication 35
Prologue
Maintenance
Operation
Set-up
PC software
Gas testing
Accessories
Specications
Appendices
Trouble
shooting
Warranty
Contents

4
© 2023 Crowcon Detection Instruments Limited
Gas-Pro Multi-gas monitor
9. Troubleshooting 36
9.1 Pump test failure 36
9.2 Fault screens 36
9.2.1 Fault Descriptions 37
9.2.2 Fault codes 38
10. Appendices 39
10.1 Sensors 39
10.1.1 Toxic 39
10.1.2 Flammable Pellistor Sensors 39
10.1.3 Flammable IR Sensors 40
10.1.4 Oxygen 40
10.1.5 IR 40
10.1.6 PID 40
10.2 Sensor Limitations 40
10.3 Charging and run times 41
Warranty 42
Contacts 43
Prologue
Maintenance
Operation
Set-up
PC software
Gas testing
Accessories
Specications
Appendices
Trouble
shooting
Warranty
Contents

5
© 2023 Crowcon Detection Instruments Limited
Gas-Pro Multi-gas monitor
Prologue
Gas-Pro Overview
Thank you for purchasing the new Gas-Pro. At Crowcon we recognise the need for reliable and robust personal monitors
which are sized to be worn and simple to use.
Gas-Pro is a portable monitor capable of detecting up to 5 gases in a compact and wearable design featuring an optional
internalpump.Focusedonusersandeetmanagersalike,Gas-Pro offers application focused solutions giving greater
operating time and reduced set up time.
Gas-Proisclassiedforuseinhazardousareasandgivesloudandbrightaudibleandvisualalarmindicationsaswellasa
vibratealert.Thetopmountdisplayisbacklitforeaseofuse,andthesimplesinglebuttonsolutionmakesusingandtraining
quick and easy.
Prologue
Maintenance
Operation
Set-up
PC software
Gas testing
Accessories
Specications
Appendices
Trouble
shooting
Warranty
Contents

6
© 2023 Crowcon Detection Instruments Limited
Gas-Pro Multi-gas monitor
Safety Information
• Gas-Proisahazardousareacertiedgasdetectorandassuchmustbeoperatedandmaintainedinstrict
accordancewiththeinstructions,warningsandlabelinformationincludedinthemanual.Gas-Pro must be
operated within the limitations stated.
• Read and understand all instructions in the operation section of the manual prior to use.
• Beforeuseensurethattheequipmentisingoodcondition,theenclosureisintacthasnotbeendamagedinany
way.
• Ifthereisanydamagetotheequipmentdonotuse,contactyourlocalofceoragentforrepair/replacement.
• Donotdisassembleorsubstitutecomponentsasthismayimpairintrinsicsafetyandinvalidatesafetycertication.
• Onlygenuinereplacementpartsmustbeused;substitutecomponentsmayinvalidatecerticationandwarrantyof
the Gas-Proandaccessories,reference“ServiceandMaintenance”sectionofthemanualfordetails.
• No live maintenance is permissible.
• Observe all warnings and instructions marked on the unit and within the manual.
• Observe site health and safety procedures for gases being monitored and evacuation procedures.
• Understand the screen display and alarm warnings prior to use.
• Ifthisproductisnotworkingproperly,readthetroubleshootingguideand/orcontactyourlocalofceoragent,for
details reference the ‘Contacts’ section of the manual (see page 58).
• Ensuremaintenance,serviceandcalibrationiscarriedoutinaccordancewiththeproceduresinthemanualand
only by trained personnel.
• Gas-Promustnotbechargedorhavecommunicationtothedevice,atambienttemperaturesoutsideofthe
temperature range 0°C to 40°C.
• Only connect to Gas-Pro in a safe area for charging or communications.
• Chargingcableassemblies,whilstnominallyprovidingavoltageof6.5V,mustnotexceedavoltageof9.1Vasthis
mayimpairintrinsicsafetyandinvalidatesafetycertication(Um=9.1V).
• Communicationcableassemblies,whilstnominallyoperatingatavoltageof3.0VTTL,mustnotexceedavoltageof
9.1Vasthismayimpairintrinsicsafetyandinvalidatesafetycertication(Um=9.1V).
• The devices are intended for use in normal atmospheric conditions of temperature –20 °C to +55 °C; pressure 80
kPa(0,8bar)to110kPa(1,1bar);andairwithnormaloxygencontent,typically21%v/v(volume/volume).
• Gas-PromaybeusedinZones1and2,forGroupllA,llBandllCgasesandvapoursandforTemperatureClasses
T1,T2,T3andT4.(SeeCerticationlabelsbelow).
Prologue
Maintenance
Operation
Set-up
PC software
Gas testing
Accessories
Specications
Appendices
Trouble
shooting
Warranty
Contents

7
© 2023 Crowcon Detection Instruments Limited
Gas-Pro Multi-gas monitor
CerticationLabels
ULcerticationlabel ATEX/IECExcerticationlabel MEDcerticationlabel
UKCAcerticationlabel UKCAMEDcerticationlabel
• Gas-proiscertiedforuseinambienttemperaturesintherange-20°Cto+55°C(-4to131°F).
• ApplicableStandardsRefertoequipmentmarkingforconrmationofapplicablecerticationbeforeuse.
IECEx
IEC60079-0:2017,7thEdition
Explosive atmospheres – Part 0: Equipment – General requirements
IEC 60079-1:2014 7th Edition
Explosiveatmospheres–Part1:Equipmentprotectionbyameproofenclosures“d”
IEC60079-11:2014,6thEdition
Explosiveatmospheres–Part11:Equipmentprotectionbyintrinsicsafety“i”
Ex II 1 G Ex ia IIC T4 Ga Tamb -20°C to +55°C
EX 2 G Ex db ia IIC T4 Gb Tamb -20°C to +55°C
IECEx ULD 11.0004X
ATEX & UKCA
EN 60079-0: 2018
Explosive atmospheres – Part 0: Equipment – General requirements
EN 60079-1:2014
Explosiveatmospheres–Part1:Equipmentprotectionbyameproofenclosures“d”
EN 60079-11: 2012
Explosiveatmospheres–Part11:Equipmentprotectionbyintrinsicsafety“i”
II 1 G Ex ia IIC T4 Ga Tamb -20°C to +55°C
II 2 G Ex db ia IIC T4 Gb Tamb -20°C to +55°C
DEMKO 11 ATEX 1031772X
UL22UKEX2405X
UL
GasdetectoruseinhazardouslocationsClass1Division1,GroupsA,B,CandDonlyastointrinsicsafety.
UL 913 Applicable Edition of the UL standard UL60079-0
Applicable Edition of the UL standard UL60079-11
Applicable Edition of the UL standard
Prologue
Maintenance
Operation
Set-up
PC software
Gas testing
Accessories
Specications
Appendices
Trouble
shooting
Warranty
Contents

8
© 2023 Crowcon Detection Instruments Limited
Gas-Pro Multi-gas monitor
Unpacking
Remove the Gas-Pro from the packaging. The standard accessories are under the supporting trays. The following items will
be included as standard:
Box contents
• Gas-Pro
• Quick Start Guide
• Calibration report
The following items are optional:
Optional items
• Charger cradle
• Charger lead (see Power & Communication Cables Technical Data)
• Flow plate (standard for pumped units)
If you have ordered a charger and/or cradle this will also be included in the box. Further accessories are
available but will not be contained in the box (Accessories).
Should the unit be deep discharged, the charging indication will not be shown until the unit has been
charging for 1 hour and the operator button has been pressed.
When on and charging a warning will advise the user to turn the Gas-Pro off after 12 hours or remove
from charge.
Store the battery in a full state and recharge at least once every 3 months.
Prologue
Maintenance
Operation
Set-up
PC software
Gas testing
Accessories
Specications
Appendices
Trouble
shooting
Warranty
Contents

9
© 2023 Crowcon Detection Instruments Limited
Gas-Pro Multi-gas monitor
1. Set-up
1.1 Prior to use
Gas-ProusesaLithiumIon(Li-ion)batterypackandshouldarrivewithsufcientchargetobeusedstraightoutthebox.
However,ifthisisthersttimeofuse,youmayneedtochargethebatterytoattainthefulloperatingtime(seeCharging)
For battery charging and run times see section 10.3
The actual operating time will depend on the types of sensor installed.
1.2 Gas-Pro orientation
Figure 1: Gas-Pro
D-ring
* Blanked for non-pumped unit
Alarm bars
+ve SafetyTM indicator
Charging cable
Certicationlabel
Sounder
Operation button
Pump inlet/outlet*
Sensor apertures
Dual colour LCD display
Alligator clip
Prologue
Maintenance
Operation
Set-up
PC software
Gas testing
Accessories
Specications
Appendices
Trouble
shooting
Warranty
Contents

10
© 2023 Crowcon Detection Instruments Limited
Gas-Pro Multi-gas monitor
1.3 Charging
Chargingshouldonlytakeplaceinnon-hazardous(safe)areas.Tocharge,simplyplugthecable into the charging socket
on the Gas-Proandturnonthemainssupply(seeFigure2below).Ifachargingcradleorvehiclecradleisbeingused,
ensure the Gas-Protsrmlyontothepowerconnector.
Thechargermustbeabletosupply6.5V@450mAwithanoutputvoltagethatdoesnotexceed9.1V(Um).
Figure 2: Charger connection
Whenoff,toshowtheGas-Proischarging,bothLEDswithinthealarmbarswillashredandwillchangetogreenonce
fully charged. This state will continue until the trickle charge is complete. Charging will then terminate showing no indication.
ThescreenwillalsoshowthebatteryiconllinginthemiddleofthescreenwhentheGas-Proisoff,andinthebottomleft-
hand corner when it is on. The battery icon contains a maximum of six segments to indicate the battery’s state of charge. For
example,withthreesegmentsshownandafourthashing,thebatteryis50%charged ,andwhenallsixareshown,the
battery is fully charged (see Figure 3 below).
Figure 3: Charging indications
Prologue
Maintenance
Operation
Set-up
PC software
Gas testing
Accessories
Specications
Appendices
Trouble
shooting
Warranty
Contents
