Croydex QM361941 User manual

Thank you for purchasing this Croydex product. Please follow the fixing and care instructions to
ensure that your Wire storage product is fitted safely and that it retains its high quality finish.
Please retain this leaflet for future reference.
This instruction leaflet applies to the following Wire storage products:
QM361941 SOAP BASKET
QM360941 CORNER SOAP BASKET
QM360641 COSMETIC BASKET
QM360541 TWO TIER COSMETIC BASKET
QM365941 CORNER BASKET
QM360841 SMALL TWO TIER CORNER BASKET
QM363841 LARGE TWO TIER CORNER BASKET
QM362841 THREE TIER CORNER BASKET
QM364341 HOOK OVER THREE TIER BASKET
Fixing Pack Contents
Fixing Screws x 2 (4 for Three tier corner basket)
Wall Plugs x 2 (4 for Three tier corner basket)
Please note, QM364341 HOOK OVER THREE TIER BASKET does not contain fixing screws and wall
plugs. This item is for use hooked over shower screens and enclosures.
Only use the fixings supplied.
Tools Required
Drill; 6mm masonry drill bit (6mm ceramic drill bit optional); Cross head screwdriver; Pencil; Spirit
level.
KEEP DIY TOOLS OUT OF THE REACH OF CHILDREN
Home Safety Advice
Always take care when using an electric drill, particularly in the bathroom. Always check for
hidden cables and pipe work before drilling and take extreme care if there is any water in the
working area.
It is advisable to use a residual current circuit breaker (RCCB).
Always wear suitable eye protection when drilling.
If the product is to be fitted on a ceramic tiled wall, a ceramic drill bit should be used. Always
ensure that the drill hole passes through the central tiled area rather than through the grouted
area. To prevent unnecessary damage to the tile, mask the area around the hole with tape
before drilling.
Do not strike the product with hard or sharp objects.

Fitting Instructions
1. Select position of the product on the wall and mark through the fixing holes, ensuring that
where applicable the product is level.
2. Remove the product. Using a 6mm masonry drill, drill the holes in the marked positions to a
depth of 30mm. If drilling through tiles, please pre-drill using a ceramic drill bit. Insert the wall
plugs to the surface of the wall. If fitting to a tiled surface, the wall plugs should be inserted
below the surface of the tile to avoid cracking.
3. Insert the screw(s) through the holes on the product and screw into the wall plug(s). Do not
over tighten as cracking of the tiles could occur.
Product Care
To retain the best quality finish, clean product regularly with a soft cloth and mild detergents. Do
not use abrasive or chemical cleaners, as these will damage the product.
Please retain this leaflet for future reference.
Croydex Limited, Central Way, Andover, Hants, SP10 5AW, UK
Tel: [phone]. Fax: [phone]
Website: www.croydex.co.uk. E-mail: [email protected].
WMA 027 R01
