AP2300 Wall Mounted Fold Away Shower Seat - Fitting Instructions
Thank you for purchasing this Croydex product. Please follow the fixing and care
instructions to ensure that your Fold Away Shower Seat is fitted safely and that it
retains its high quality finish.
Tools Required
Pencil
Drill
12mm masonry drill bit
12mm ceramic drill bit (optional)
Spirit Level
13mm Spanner or Socket
Fixing Pack Contents
Fixing Bolt x 3
Wall Plug x 3
Washer x 3
Please ensure that fixings are compatible with wall construction materials
KEEP DIY TOOLS OUT OF THE REACH OF CHILDREN
Safety and Care Advice
1. Always take care when using a drill, particularly in the bathroom. Always
check for hidden cables and pipework before drilling and take extreme care if
there is any water in the working area.
2. It is advisable to use a residual current circuit breaker (RCCB). Always wear
suitable eye protection when drilling.
3. If the product is to be fitted on a ceramic tiled wall, a ceramic drill bit should
be used. Always ensure that the drill hole passes through the central tiled
area rather than through the grouted area. To prevent damage to the tile,
mask the area around the hole with tape before drilling.
4. It is recommended that two people fit this product to ensure that it is fitted
safely.
Product Location
Grab and support bars are only as strong as the wall to which they are fixed and the
fixings that are used.
For solid brick and concrete block walls please use the fixings supplied.
For other wall types you will need to ensure that you are using the correct type of
fixing for the material of the wall.
The addition of backboards on the outside of the wall or appropriate strengthening of
internal structures may be required to provide adequate wall strength.
If the wall is made of lightweight thermal blocks, aerated hollow
brickwork or prefabricated partitions even the most appropriate fixings
may not be able to withstand the loads which can be suddenly applied
to grab bars, hinged support bars and seats.

S&H 007 R01
1. Identify the most appropriate position for the Fold Away Shower Seat ring.
Away Shower Seat in position on the wall and using the hole
using a 12mm all,
face of the wall. If fitting to a tiled surface,
crews provided through the washers and the holes of the Fold
ll before
dditional Information only be fitted to solid brick, concrete block walls or
g load for the Fold Away Shower Seat is 90kg. This load
oduct Care Advice quality finish, dry the Fold Away Shower Seat after use.
ese will damage the product.
Please retain this leaflet for future reference.
Croyd
Fitting Instruction
Fig.1 Fig.2
ensuring the product is at a comfortable height and distance for showe
2. The Fold Away Shower Seat can be folded upwards for more convenient
storage so please ensure there is sufficient space above the fixing position to
allow for this.
3. Place the Fold
centres of the wall plate as a template mark the screw fixing positions on the
wall surface. (See Fig.2)
4. Drill the holes to a depth of 65mm in the marked positions
masonry drill. (See Fig.2) If the product is to be fitted onto a ceramic tiled w
a ceramic drill bit should be used.
5. Insert the wall plugs flush to the sur
the wall plugs should be inserted below the surface of the tile to avoid
cracking.
6. Insert the s
Away Shower Seat wall plate and screw to the wall. (See Fig.1)
7. Check the Fold Away Shower Seat is securely fastened to the wa
use.
A
• This product must
similarly strong materials offering appropriate support for the maximum
safe working load.
• Maximum safe workin
must be evenly distributed.
Pr
• To retain the best
• Clean product regularly with a soft damp cloth.
• Do not use abrasive or chemical cleaners, as th
ex Limited, Central Way, ndover, Hants, SP10 5AW, UKA
Tel: [phone]. Fax: [phone]
Website: www.croydex.co.uk. E-mail: [email protected].
