Culligan Smart Controller HE DF 12 Operation manual

CULLIGAN®
High Efficiency 1.5
Water Filter
Featuring the
Culligan®Smart Controller™
Models from 2012
©2017 Culligan International Company
Installation,
Operation, and
Service Instructions
with Parts Lists
Cat. No. 01024514
Rev. E 06/15/17
DCO # 017278

Attention Culligan Customer:
Your local independently operated Culligan dealer employs trained service and maintenance personnel who are experienced
in the installation, function and repair of Culligan equipment. This publication is written specifically for these individuals and is
intended for their use.
We encourage Culligan users to learn about Culligan products, but we believe that product knowledge is best obtained by
consulting with your Culligan dealer. Untrained individuals who use this manual assume the risk of any resulting property
damage or personal injury.
NOTICE Please send any suggestions for improving this manual to [email protected]
WARNING! Electrical shock hazard! Prior to servicing equipment, disconnect power supply to prevent
electrical shock.
WARNING! If incorrectly installed, operated, or maintained, this product can cause severe injury.
Those who install, operate, or maintain this product should be trained in its proper use,
warned of its dangers, and should read the entire manual before attempting to install, op-
erate, or maintain this product. Failure to comply with any warning or caution that results
in any damage will void the warranty.
CAUTION! This product is not to be used by children or persons with reduced physical, sensory or
mental capabilities, or lack of experience or knowledge, unless they have been given su-
pervision or instruction.
CAUTION! Children should be instructed not to play with this appliance.
CAUTION! If the power cord from the transformer to the unit looks or becomes damaged, the cord
and transformer should be replaced by a Culligan Service Agent or similarly qualified per-
son in order to avoid a hazard.
WARNING! This device complies with Part 15 of the FCC rules subject to the two following
conditions: 1) This device may not cause harmful interference, and 2) This device must ac-
cept all interference received, including interference that may cause undesired operation.
This equipment complies with Part 15 of the FCC rules. Any changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the equipment. Changes or modifications not expressly approved by
the party responsible for compliance could void the user’s authority to operate the equipment.
CAUTION! To reduce the risk of fire, use only No. 26 AWG or larger telecommunications line cord.
NOTE This system is not intended for use with water that is microbiologically unsafe or of unknown quality
without adequate disinfection either before or after the system.
NOTE Check with your public works department for applicable local plumbing and sanitation codes. Follow local
codes if they differ from the standards used in this manual. To ensure proper and efficient operation of the
Culligan equipment to your full satisfaction, carefully follow the instructions in this manual.
Products manufactured and marketed by Culligan International Company (Culligan) and its affiliates are protected by patents
issued or pending in the United States and other countries. Culligan reserves the right to change the specifications referred to
in this literature at any time without prior notice. Culligan, Aqua-Sensor, Tripl-Hull, and SoftMinder are trademarks of Culligan
International Company or its affiliates.
Culligan International Company
9399 West Higgins Road, Suite 1100
Rosemont, Illinois 60018
1-847-430-2800
www.culligan.com

i
Cat. No. 01024514
Contents
Introduction........................................................................ 1
Basic Principles ................................................................. 3
Performance Specifications............................................... 4
Preparation........................................................................ 6
Controller Features............................................................ 9
Installation ....................................................................... 10
Smart Controller Circuit Board Layout............................. 23
Electrical Schematic ........................................................ 24
Installing Accessories...................................................... 25
Final Startup .................................................................... 44
Preventative Maintenance............................................... 46
Maintenance.................................................................... 47
Troubleshooting............................................................... 51
HE 1.5 Filter Parts List..................................................... 57
Appendix A Data Port Output ....................................... 62
Index................................................................................ 65
Installation,
Operation, and
Service Instructions
with Parts Lists
CULLIGAN®
High Efficiency 1.5
Water Filter
Featuring the
Culligan®Smart Controller™
Models from 2012

ii Culligan® High Efficiency 1.5 Water Filter ii Cat. No. 01024514
Analytical
Laboratory
Services
Water Testing Made Easy.
Culligan’s Analytical Laboratory provides its customers with quality water analysis using EPA approved methods. Our Analytical
Laboratory is certied by the State of Illinois EPA, to be compliant with the National Environmental Laboratory Accreditation
Conference (NELAC) standards. In addition to Illinois chemical certication, our Analytical Laboratory is certied to perform
coliform and E. coli testing.
We strive to provide our customers with the testing they need at the lowest possible cost with the quickest turn-around time.
STANDARD
WATER TESTING
For sizing systems and
general chemical water
characteristics.
WELL
WATER TESTING
•Basic •Realtor
•Drilling Surveilance
•Expanded
•Gold
SPECIAL
WATER TESTING
•Hemodialysis •Scale
•Resin •Organic
•Microbiology
•Membrane
Contact your local Culligan Dealer today to
make sure your water is it’s best it can be.
1-877-889-8195
E-mail: Water[email protected]
www.culligan.com

Introduction 1
Cat. No. 01024514
Introduction
Read this Manual First
Before you operate the Culligan®High Efficiency (HE) water filter systems, read this manual to become familiar with the
device and its capabilities. The system must be supplied with cold water only.
Culligan®High Efficiency water filter systems are designed to meet the needs of applications for high quality water. This
manual contains important information about the unit, including information needed for installation, operating, and mainte-
nance procedures. A troubleshooting section provides a guide for quick and accurate problem solving.
In order for the water treatment system to continue to provide high quality water, you must develop a
thorough understanding of the system and its operation. Review this manual before making any attempt
to install, operate, or service the system. Installation or maintenance done on this system by an un-
trained service person can cause major damage to equipment or property damage.
The Culligan High Efficiency 1.5” Water Filters have been tested and certified by WQA and IAPMO
against NSF/ANSI Standard 372, CSA B483.1, and NSF/ANSI Standard 61 for Materials Safety Re-
quirements only. Not certified for Contaminant Reductions or Structural Integrity by WQA.
The HE 1.5 Water Filter Control Enclosure complies with the UL 50/50E and UL 746C standards for a
NEMA 3R Enclosure Rating.
For installations in Massachusetts, Massachusetts Plumbing Code 248 CMR shall be adhered to. Con-
sult your licensed plumber for installation of this system. This system and its installation must comply
with state and local regulations. The use of saddle valves is not permitted.
The HE 1.5” Water Filter Systems are not intended for household use.
About this Manual
This manual:
• Familiarizes the operator with the equipment
• Explains installation and setup procedures
• Explains the various modes of operation
• Gives specifications and troubleshooting information
This publication is based on information available when approved for printing. Continuing design refinements could cause
changes that may not be included in this publication.
NOTE Refer to the GBE Programming for Commercial Softeners and Filters, except HF xN Manual (P/N
01027295) for programming information. This manual can be obtained from your local dealer, on C-Port
(www.cport.culligan.com) under the Technical Service Tab or on the Service Tech App.
Safe Practices
Throughout this manual there are paragraphs set off by special headings.
Note/Notice
Note or Notice is used to emphasize installation, operation or maintenance information which is important, but does not
present any hazard. For example,
NOTICE The nipple must extend no more than 1 inch above the cover plate.
Caution
Caution is used when failure to follow directions could result in damage to equipment or property. For example,
CAUTION! Disassembly while under water pressure can result in flooding.

2 Culligan® High Efficiency 1.5 Water Filter 2 Cat. No. 01024514
Warning
Warning is used to indicate a hazard which could cause injury or death if ignored. For example,
WARNING! Electrical shock hazard! Unplug the unit before removing the timer mechanism or
cover plates!
The CAUTION and WARNING paragraphs are not meant to cover all possible conditions and situations that may occur. It
must be understood that common sense, caution, and careful attention are conditions which cannot be built into the equip-
ment. These MUST be supplied by the personnel installing, operating, or maintaining the system.
Be sure to check and follow the applicable plumbing codes and ordinances when installing this equipment. Local codes
may prohibit the discharge of acid or caustic solutions to drain. An extra solution tank should be used to neutralize the
solution before discharging to drain.
Use protective clothing and proper face or eye protection equipment when handling chemicals or power tools.
Serial Numbers
The control valve serial number is located on the back of the timer case.
The media tank serial number is located on the top surface of the tank.
This publication is based on information available when approved for printing. Continuing design refinement could cause
changes that may not be included in this publication.
NOTE Do not remove or destroy the serial number. It must be referenced on request for warranty repair or
replacement.

Basic Principles 3
Cat. No. 01024514
Basic Principles
Activated Carbon Filter
Filters reduce unpleasant taste and odors from the water supply. In normal operation, the water passes through the multi-
port valve into the top of the media tank. As it flow down through the mineral bed, sediment in the water is filtered out and
objectionable dissolved gases are absorbed into the mineral. The clear water that leaves the bottom of the media tank and
goes into the service lines is free from many disagreeable taste and odors.
Depth Filter
Depth filters filter both heavy sediment and suspended matter from the water supply. In normal operation, the water pass-
es through the multi-port valve and into the top of the media tank. As the water flows down through the mineral bed, sed-
iment in the water is filtered out. The clear water that leaves the bottom of the media tank and flows through the service
lines is free from most sediment and suspended matter.
Greensand Filter*
Culligan’s standard Greensand Filters operate as a continuous feed system similiar to a depth filter and not as a batch
style system. Greensand can remove manganese and both oxidized and soluble iron using a chlorine-injection feed
system ahead of the filter. Reconditioning frequency is dependent on filter loading, but a maximum chlorine demand of
10 mg/L is recommended. Desludging tanks or alternative methods of reducing the chlorine dosing may be required. This
system is not recommended for removing high levels of sulfur.
Filtering Process
To keep the filter operating properly, it is necessary to periodically remove the accumulated sediment from the mineral
bed. This done by a three-step process:
Backwash
The direction of flow through the tank is reversed, and the mineral bed is backwashed. This action expands and agitates
the bed, releasing the sediment that is then carried up and out to the drain.
Settle
The tank is allowed to be in an idle state to tallow the different types of media to stratisfy and settle. Water flow to the
drain will be present during this step.
Fast Rinse
A rapid downflow flush repacks the mineral bed and washes out traces of sediment not removed by backwash.
Backwash Frequency
Generally, backwash the HE 1.5 filter once per week. However, more frequent cleaning is recommended for water with
high turbidity. On filters with pressure gauges, the differential pressure across the filter can be monitored.
Carbon, depth and greensand filters should be cleaned when the differential pressure across the filter increases by 8–10
psi over the pressure differential across a clean filter bed.
*Greensand filters are not WQA or IAMPO certified.

4 Culligan® High Efficiency 1.5 Water Filter 4 Cat. No. 01024514
Performance Specifications
In order to function properly, some operational parameters must be followed. They include:
1. An operating water pressure between 20 and 125 psi (138-862 kPa). If water pressure is greater than 80 psi, Culligan
recommends following the IAPMO Uniform Plumbing code section 806.2 by installing a Pressure Regulating Valve
before the system. Operating on high presure for extended periods of time can increase the service frequency of re-
placement parts. If water pressure can drop below the minimum water pressure, add a booster pump to maintain a
25 psi (172 kPa) minimum operating pressure.
2. Operating temperature between 33° and 120°F or 1°–49°C.
3. Clear (non-turbid) water supplies (Less than 5 NTU).
Culligan HE 1.5 Depth Filter & Progressive Flow Depth Filter
HE DF 12 HE DF 14 HE DF 16 HE DF 21
Tank Size, in. [mm] 12x52 [305x1321] 14x47 [356x1194] 16x53 [406x1346] 21x62 [533x1575]
Pipe Size, in. [mm] 1.5 [38.1]
Temperature 33–120°F
Water Pressure 20–125 psi
Water Pressure (Canada Only) 20–90 psi
Electrical 24V/60 Hz/21.6 W
Installed Size (HxDxW, in.) 62x24x14 57x24x14 63x24x16 72x24x21
Clear height required above unit 52" 47" 53" 62"
Media Quantity, lb. [kg] 180 [82] 205 [93] 280 [127] 615 [280]
Normal Service Flow, gpm@psi 8@3 11@3 14@4 24@8
lpm@kPa [email protected] [email protected] [email protected] [email protected]
Peak Service Flow, gpm@psi 12@5 16@6 21@6 36@13
lpm@kPa [email protected] [email protected] [email protected] [email protected]
Backwash Flow, gpm [lpm] 10 [38.1] 15 [56.8] 20 [75.7] 30 [113.6]
pH limitation 6–9.5
Regeneration Time 30 minutes

Performance Specifications 5
Cat. No. 01024514
Culligan HE 1.5 Carbon Filter & Progressive Flow Carbon Filter
HE CF 12 HE CF 14 HE CF 16 HE CF 21
Tank Size, in. [mm] 12x52 [305x1321] 14x47 [356x1194] 16x53 [406x1346] 21x62 [533x1575]
Pipe Size, in. [mm] 1.5 [38.1]
Temperature 33–120°F
Water Pressure 20–125 psi
Water Pressure (Canada Only) 20–90 psi
Electrical 24V/60 Hz/21.6 W
Installed Size (HxDxW, in.) 62x24x14 57x24x14 63x24x16 72x24x21
Clear height required above unit 52" 47" 53" 62"
Media Quantity, ft3[L] 2 [57] 3 [85] 3 [85] 6 [170]
Taste & Odor Removal, gpm@psi 4@1 5@1 7@1 12@2
lpm@kPa [email protected] [email protected] [email protected] [email protected]
Dechlorination, gpm@psi 8@1 11@2 14@2 24@8
lpm@kPa [email protected] [email protected] [email protected] [email protected]
Backwash Flow, gpm [lpm] 8 [30.3] 10 [37.9] 15 [56.8] 25 [94.6]
pH limitation 5–11
Regeneration Time 30 minutes
Culligan HE 1.5 Greensand Filter* & Progressive Flow Greensand Filter*
HE GF 12 HE GF 14 HE GF 16 HE GF 21
Tank Size, in. [mm] 12x52 [305x1321] 14x47 [356x1194] 16x53 [406x1346] 21x62 [533x1575]
Pipe Size, in. [mm] 1.5 [38.1]
Temperature 33–120°F
Water Pressure 20–125 psi
Water Pressure (Canada Only) 20–90 psi
Electrical 24V/60 Hz/21.6 W
Installed Size (HxDxW, in.) 62x24x14 57x24x14 63x24x16 72x24x21
Clear height required above unit 52" 47" 53" 62"
Media Quantity, lb. [kg] 180 [82] 205 [93] 280 [127] 615 [280]
Normal Service Flow, gpm@psi 8@3 11@3 14@4 24@8
lpm@kPa [email protected] [email protected] [email protected] [email protected]
Peak Service Flow, gpm@psi 12@5 16@6 21@6 36@13
lpm@kPa [email protected] [email protected] [email protected] [email protected]
Backwash Flow, gpm [lpm] 10 [38.1] 15 [56.8] 20 [75.7] 30 [113.6]
pH limitation 6–9.5
Regeneration Time 30 minutes
*Greensand filters are not WQA or IAMPO certified.

6 Culligan® High Efficiency 1.5 Water Filter 6 Cat. No. 01024514
Preparation
Component Description
The water filter is shipped from the factory in a minimum of three cartons. Remove all components from their cartons and
inspect them before starting installation.
Control Valve Assembly Includes the High Efficiency control valve, meter, and the bypass valve. Small
parts packages will contain additional installation hardware, and the filter Own-
er’s Guide.
Media Tank Includes Quadra-Hull™ media tank complete with outlet manifold and inlet
strainer.
Filter Media Includes the filter media. See the filling procedure in the installation section for
proper filling instructions.
Tools and Materials
The following tools and supplies will be needed, depending on installation method. Observe all applicable codes.
NOTE Check and comply with your state and local codes. You must follow these guidelines.
For installations in Massachusetts, the Commonwealth of Massachusetts Plumbing Code 248 CMR
shall be adhered to. Consult your licensed plumber for installation of the system. This system and its
installation must comply with state and local regulations. The use of saddle valves is not permitted.
All Installations
• Safety glasses
• Phillips screwdrivers, small and medium tip.
• Gauge assembly
• Silicone lubricant (P/N 00471507 or equivalent)—DO NOT USE PETROLEUM-BASED LUBRICANTS
• A bucket, preferably light-colored
• Towels
Special Tools
• Torch, solder and flux for sweat copper connections
• Use only lead-free solder and flux for all sweat-solder connections, as required by state and local codes.
• Threading tools, pipe wrenches and thread sealer for threaded connections.
• Saw, solvent and cement for plastic pipe connections.
Materials
• Drain line, 1/2” (P/N 00303082, gray, semi-flexible; or P/N 00331946, black, semi-rigid; or equivalent)
• Thread sealing tape
• Pressure reducing valve (if pressure exceeds 125 psi [860 kPa])
• Pipe and fittings suited to the type of installation

Preparation 7
Cat. No. 01024514
Application
Water Quality
Verify that raw water and flow rate are within limits as outlined in the specifications.
CAUTION! Do not use where the water is microbiologically unsafe or with water of unknown
quality without adequate disinfection before or after the unit.
Pressure
If pressure exceeds 125 psi (860 kPa), install a pressure reducing valve (see materials checklist). On private water sys-
tems, make sure the minimum pressure (the pressure at which the pump starts) is greater than 20 psi (140 kPa). Adjust
the pressure switch if necessary.
CAUTION! The use of a pressure reducing valve may limit the flow of water in the household.
Temperature
Do not install the unit where it might freeze, or next to a water heater or furnace or in direct sunlight. Outdoor installation is
not recommended and voids the warranty. Use the Culligan Outdoor HE filter for outdoor installations. The Culligan Out-
door HE filter has been certified by Underwriter’s Laboratories for outdoor installation. If installing in an outside location,
you must take the steps necessary to assure the filter, installation plumbing, wiring, etc. are as well protected from the
elements (sunlight, rain, wind, heat, cold), contamination, vandalism, etc. as when installed indoors.
Location
Space Requirements
Allow 6–12 inches (15–30 cm) behind the unit for plumbing and drain lines and 4 feet (1.3 meters) above the unit for
service access.
Floor Surface
Choose an area with solid, level floor free of bumps or irregularities. Bumps, cracks, stones and other irregularities can
cause the salt storage tank bottom to crack when filled with salt and water.
Drain Facilities
Choose a nearby drain that can handle the rated drain flow (floor drain, sink or stand pipe). Refer to the Drain Line Chart,
Table 3 on page 18, for maximum drain line length.
NOTE Most codes require an anti-siphon device or airgap. Observe all local plumbing codes and drain
restrictions. The system and installation must comply with all state and local laws and regulations.
Electrical Facilities
A 10-foot cord and wall mount plug-in transformer are provided. The customer should provide a receptacle, preferably one
not controlled by a switch that can be turned off accidentally. Observe local electrical codes.
NOTE P/N 01012956 and P/N 01018133 plug-in transformer are rated for indoor installations only.
NOTE The filter works on 24 Volt/60 Hz power only. Be sure to use the included transformer. Be sure the
electrical outlet and transformer are in an inside location to protect from moisture. Properly ground to
conform with all governing codes and ordinances.

8 Culligan® High Efficiency 1.5 Water Filter 8 Cat. No. 01024514
Terms
Distributor—A pipe with slits that allows the water to enter and leave inside the media tank.
Media Tank—The underbedding and resin the media tank holds.
Recondition—A process where the media is revitalized to filter again.
Media—The actual material that filters water.
Underbedding—A gravel mixture that keeps the filter media from entering the distributors.
Manifold
Freeboard (C)
Media
Distributor
Gravel
Underbedding
Figure 1. Media tank.

Controller Features 9
Cat. No. 01024514
Culligan Smart Controller™
The Culligan Smart Controller is designed to operate a wide range of existing and new High
Efficiency softener and filtration valves. The Smart Controller is designed to be both reliable and
easy to use. The Smart Controller features a bright and easy to read display.
New Smart Controller features:
• Optional wireless remote control.
• Optional telephone modem—calls for service.
• Upgrade to the latest firmware when it becomes available (requires GBE Updater).
• Automatically sets time and date.
• Five-year battery backup with real-time-clock.
• Support for auxiliary outputs.
The Smart Controller uses a circuit board designed to mount onto the control valve attached to a water softener or filter.
There are four other, optional, add-on modules in the Smart Controller family. These modules include:
Wireless Remote Control
This remote control displays the current status of the water softener or filters and allows for remote control. It can be
located up to 200 feet away from the Smart Controller (depending upon building construction materials).
Modem Board
This module can be installed into either the Smart Controller or the Wireless Remote. It allows for the system to be re-
motely monitored detecting problems before they occur.
NOTE Modem kit requires a one-year subscription to either Level 1 or Level 2 Telecom package. See on
C-Port (www.cport.culligan.com) under the Telemetry Tab for details.
RF Transmitter
This module is installed into BOTH the Smart Controller and the Wireless Remote to allow them to communicate via
Radio Frequency (RF) communications. In North America, these modules communicate at 915 MHz and are designed to
work without interference with other 915
MHz devices such as cordless telephones
and baby monitors. Other frequencies are
used in other countries.
Auxiliary Board
This module can be installed into the
Smart Controller to provide a variety of
add-on capabilities such as operation of
external solenoid valves and relays(typi-
cally used in commercial applications).
Flow Meter
The High Efficiency filter can monitor any
hall-effect type flow meter signal and use
it as the basis of monitoring the amount of
water flowing through the valve.
The connectors used with these add-on
modules, as well as connectors for the HE
Sensor Products, are shown in Figure 2.
AQUA SENSOR
24V
2.5V
FLOW METER
PHONE
MODEM BOARD
RF BOARD 915MHz
AUXILIARY BOARD
POWER
POSITION SENSOR
CONNECTION
MOTOR CONNECTOR
Figure 2. Smart Controller circuit board for HE filter.
Controller Features

10 Culligan® High Efficiency 1.5 Water Filter 10 Cat. No. 01024514
Install Distribution System
CAUTION! Do not attempt to use any distribution part that is damaged. Doing so may create
operational problems and/or create a substantial risk of consequential damage not
covered by the product warranty.
Figure 3. Install Distribution System
Mark flush with tank opening
Media Tank
Remove distributor and cut square on mark
Deburr distributor pipe
Media Tank
Rest flat on the bottom
Distributor
Installation

Installation 11
Cat. No. 01024514
Loading the Media
NOTE Do NOT attempt to load the media without having the tank in its final position. Moving the tank once
the media has been loaded will be difficult at best.
1. Cover the top of the distributor pipe with tape that will prevent media from entering the distributor.
2. Use a funnel in the opening to add 6” of water to protect the distributor.
3. Load Media per Table 1 and Figure 4 and Figure 5.
4. Clean tank threads, remove tape and check for any foriegn materials
NOTE Minimize the amount of water added until final positioning of the tank with the control valve mounted.
NOTE For Carbon Filters, the recommended soaking time for Cullar D media is 12 hours minimum with a sub-
sequent backwash for 30 minutes to remove fine particles.
Table 1. Loading Quantities
Model 12 14 16 21
Carbon Filter
Bottom Layer: Cullsan Medium Gravel (lbs) 30 50 70 200
Top Layer: Cullar D Plus (ft3) 2336
Freeboard (inches) 15 12 18 15
Depth Filter
Bottom Layer: Cullsan U (lbs) 25 50 75 200
Second Layer: Cullsan G50 (lbs) 50 50 50 100
Third Layer: Cullsan A (lbs) 55 55 55 165
Top Layer: Cullcite (lbs) 50 50 100 150
Freeboard (inches) 16 17 19 13
Greensand Filter*
Sub-Bottom Layer: Cullsan Medium Gravel (lbs) 100
Bottom Layer: Cullsan U (lbs) 50 50 50 50
Second Layer: Cullsan G50 (lbs) 50 50 50 100
Third Layer: Cullsorb (lbs) 45 90 180 270
Top Layer: Cullcite (lbs) 25 25 25 25
Freeboard (inches) 15 15 15 15
Notes for preparing Greensand filters* for service:
1. Before adding the last Cullcite (anthracite) layer backwash the existing media including the Cullsorb for 10
minutes or until the water is clear at the drain. Then stop the backwash, depressurize the system and drain the
water down to within 3 - 4 inches above the media.
2. For every cubic foot of Culsorb media to be treated mix 0.5 gallons of 5.75% Chlorine Bleach or 0.2 gallons of
12% Sodium Hypochlorite into 6.5 gallons of water. Pour the chlorine mixture into the tank and allow it to soad
for a minimum of 4 hours.
3. Re-pressurize the unit, fill with water and rinse the media until the free chlorine residual at the drain is less than
0.2 mg/L.
4. Depressurize the unit and drain down the water and add the final Cullcite (anthracite layer. Fill with water and
initiate a complete backwash and rinse cycle.
5. The unit is now ready for operation.
*Greensand filters are not WQA or IAMPO certified.

12 Culligan® High Efficiency 1.5 Water Filter 12 Cat. No. 01024514
Figure 4. Carbon Filter Figure 5. Depth/Greensand Filter
Mount the Control Valve
Figure 6. Mounting the control valve.
Freeboard
Cullar D Plus
Cullsan U
Cullsan Medium Gravel
Freeboard
Cullcite
Cullsan A/ Cullsorb
Cullsan G50
Cullsan U
Cullsan Medium Gravel
1. Lubricate the outlet distributor O-ring with a
silicone-based lubricant.
2. Install the inlet disperser to the
bottom of the control valve.
3. Install the tank adapter o-ring above the
valve’s threads. Do not lubricate, but can
be wetted with water.
4. Lower the control valve slowly onto
the tank so that the distributor tube fits
into the center of the control valve and
then screw the control onto the tank.

Installation 13
Cat. No. 01024514
Suggested Piping Installations
The piping layouts below depict a traditional three-valve bypass. Culligan also offers an optional bypass valve that con-
nects directly to the inlet and outlet of the water filter.
NOTE Interconnecting pipe and fittings, bypass valves, and isolation valves are not supplied.
CAUTION! DO NOT make a direct connection to the drain. Provide an air gap of at least four times
the diameter of the drain pipe or conform to local sanitation codes and to permit the
observation of drain flow.
NOTE Figure 8 displays externally blocking valves for alternating or progressive flow. Internally blocked pro-
gressive flow is plumbed similarly but without the blocking valves.
FILTERED WATER
MANUAL
OUTLET VALVE
BYPASS VALVE(NORMALLY CLOSED)
UNFILTERED WATER
MANUAL
INLET VALVE
VACUUM BREAKER
SMART
CONTROLLER
Figure 7. HE 1.5 single tank piping.
SMART
CONTROLLER
FIL
TERED
WATER UNFILTERED
WATER
BLOCKING
VALVE
BYPASS VALVE(NORMALLY CLOSED)
MANUAL
INLET VALVE
VACUUM BREAKER
High Eciency Twin
BLOCKING
VALVE
Figure 8.HE 1.5 duplex alternating tank piping.

14 Culligan® High Efficiency 1.5 Water Filter 14 Cat. No. 01024514
Drain Line Flow Control
Refer to Table 2 for the recommended drain line flow control to be used for various size tanks.
Refer to Figure 9 through Figure 11 and instructions below for changing the drain line flow control.
Table 2. Flow Restrictors
Target Flow Rate (gpm) Depth Filter & Greensand Filter**
Flow Control Carbon Filter Flow Control
Tank Depth
Filter
Carbon
Filter
Greensand
Filter**
Feed Pressure
<45 psi
Normal
Pressure
Feed Pressure
<45 psi
Normal
Pressure
12" 10 8 4 10 gpm 10 gpm 8 gpm* 8 gpm*
14" 15 10 5 J J 10 gpm 10 gpm
16" 20 15 7 K K J E
21" 30 25 12 L L L K
*Shipped assembled in control from factory.
**Greensand filters are not WQA or IAMPO certified.
Drain Line Flow Control Replacement
Refer to Table 2, Figure 9 through Figure 11, and the instructions below to replace the drain line flow control.
1. Remove the cover by releasing the cover fastener from the control valve. See Figure 9 and Figure 10.
2. Remove the drain clip and pull off the drain connector.
3. Remove the drain line flow control located behind the connector.
4. Install the correct backwash flow control
5. Reverse the procedure to reassemble.
NOTE The number on the flow control should face into the valve body.
NOTE Do not re-install the cover until the drain line tubing is connected.
Figure 9. HE 1.5 filter cover fastener clip. Figure 10. Removing the HE 1.5 filter cover.
Figure 11. Replacing drain line flow control.
Clips
Spacer
Flow Control
Drain Connector
Elbow Plug

Installation 15
Cat. No. 01024514
Attaching the Cover
Once the drain and brine line is connected re-attach the cover. Refer to the below instructions and Figure 12 through
Figure 14.
1. Insert the two pins on the top of the cover into the two holes on top of the frame; the cover should be slightly
angled. See Figure 12.
2. Rotate the cover downward inserting the two pins on the side of the cover into the two holes on side of the
frame. See Figure 13.
3. Attach the cover fastener onto the control valve. See Figure 14.
Figure 12. Cover fastener clip. Figure 13. Reattaching the HE 1.5 filter cover.
Figure 14. Reattaching the cover fastener.
Cover Fastener
Push down into place

16 Culligan® High Efficiency 1.5 Water Filter 16 Cat. No. 01024514
Straight-Through Adapter
Each filter is shipped with a Culligan® straight-through adapter to connect the filter to the plumbing system.
CAUTION! Close the inlet supply line and relieve the system pressure before cutting into
the plumbing! Flooding could result if not done!
Straight-Through Adapter Installation
Refer to Figure 15 and the instructions below to connect the
meter, straight-through adapter, and interconnecting pipe.
1. All HE 1.5 units are equipped with a meter. The
meter is installed on the outlet side of the control
valve. The meter body fits in the same space as the
coupling between the control valve and the straight
through adapter. Make sure the arrow on the flow
meter is pointing in the direction of the flow.
2. The straight-through adapter connects directly to
the control valve with the meter and coupling and
two assembly pins. Lubricate all O-rings on the cou-
plings/meter with silicone lubricant. See Figure 15.
NOTE The Low Flow Meter has a white dot on the
connection for the wire harness.
Figure 15. Straight-Through Adapter assembly.
NOTE If the ground from the electrical panel or breaker box to the water meter or underground copper pipe
is tied to the copper water lines and these lines are cut during installation of the straight-through
adapter, an approved grounding strap must be used between the two lines that have been cut in order
to maintain continuity. The length of the grounding strap will depend upon the number of units being
installed. In all cases where metal pipe was originally used and is later interrupted by the straight-
through adapter to maintain proper metallic pipe bonding, an approved ground clamp c/w not less
than #6 copper conductor must be used for continuity. Check your local electrical code for the correct
clamp and cable size.
CAUTION! Close the inlet supply line and relieve the system pressure before cutting into the
plumbing! Flooding could result if not done!
CAUTION! When making sweat connections, use care to keep heat away from the plastic nuts
used to connect the plumbing to the bypass. Damage to these components may result
otherwise.
Flow Meter
Coupling
Straight-Through Adapter
Assembly Pins
