Product Registration and Warranty
CURT stands behind our products with industry-leading warranties. To get copies of the product
warranties, register your purchase or provide feedback, visit: warranty.curtgroup.com/surveys
NOTICE
Visit www.curtmfg.com for a full-color copy of this
instruction manual, as well as helpful videos, guides and much more!
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
This installation requires the front fascia panel to be temporarily
removed and reinstalled. Some drilling and trimming are required.
To help prevent damage to the product or vehicle, refer to the specified
torque specifications when securing hardware during the installation process.
If equipped, we recommend removing the base plate attachment tabs when not in use.
INSTALLATION MANUAL 70118
WARNING
Never exceed the vehicle manufacturer's recommended gross vehicle weight rating (GVWR).
Parts List
Item Qty Description
1 1 Tow bar base plate
2 2 Tow bar mounting tab
3 2 Safety cable, 7,500 lbs.
4 4 Square hole spacer,
1/4" x 1" x 2"
5 4 Carriage bolt,
3/8"-16 x 1-1/2", grade 8
6 4 Hex head bolt,
3/8"-16 x 1-1/4", grade 8
7 4 Lock washer, 3/8"
8 4 Nylock nut, 3/8"-16, grade 8
9 4 Flange nut, 3/8"-16, grade 8
10 2Quick link, 1/2"
11 2Socket plug
CAUTION
Take care when cutting any plastic or metal as injury may occur if done improperly.
Installed Attachment Tabs
Height 16"
Width 20"
Product Photo
Not pictured: Safety cables, quick links and socket plugs
Tools Required
Torque wrench Drill
Socket, 7mm Drill bit, 3/8"
Socket, 7/16" Nut driver, 5/16"
Socket, 9/16" T15 Torx
Wrench, 7/16" Tape measure
Wrench, 9/16" Phillips screwdriver
Utility knife Flat head screwdriver
Paint pen Aviator shears
Large vise grip Fishwire, 3/8"
(includes four)
Level of Difficulty
Difficult
Installation difficulty levels are based on time
and effort involved and may vary depending on
the installer level of expertise, condition of the
vehicle and proper tools and equipment.
SAFETY INSTRUCTIONS
Safety glasses should be worn at all times while installing this product.

CURTMFG.COM •PRODUCT SUPPORT: 877.287.8634 •70118-INS-RC •04/14/2020 •ECN6926 •PAGE 2
Included
fishwire
1
3
2
A SSEMBLY
5
6
10
11
7
8
9
4
Parts List
Item Qty Description
1 1 Tow bar base plate
2 2 Tow bar mounting tab
3 2 Safety cable, 7,500 lbs.
4 4 Square hole spacer,
1/4" x 1" x 2"
5 4 Carriage bolt,
3/8"-16 x 1-1/2", grade 8
6 4 Hex head bolt,
3/8"-16 x 1-1/4", grade 8
7 4 Lock washer, 3/8"
8 4 Nylock nut, 3/8"-16, grade 8
9 4 Flange nut, 3/8"-16, grade 8
10 2Quick link, 1/2"
11 2Socket plug

CURTMFG.COM •PRODUCT SUPPORT: 877.287.8634 •70118-INS-RC •04/14/2020 •ECN6926 •PAGE 3
Step 1
Open the hood and use a T-15 Torx
bit to remove the seven screws
along the top edge of the grill.
BUMPER FASCIA REMOVAL
Step 2
Use a T-15 Torx bit to remove the four screws
along the inside edge of the wheel well liner.
Repeat on the other side of the vehicle.
Step 3
Carefully pull the plastic wheel edge
trim piece in front of the tire to allow
access to the bumper cover.
Repeat on the other side of the vehicle.

CURTMFG.COM •PRODUCT SUPPORT: 877.287.8634 •70118-INS-RC •04/14/2020 •ECN6926 •PAGE 4
Step 5
Use a 7mm socket to remove the ten bolts
along the underside of the vehicle – three
on each side and four in the center.
Step 4
Pull the wheel well liner back and
use a 7mm socket to remove the
bolt at the bumper fascia joint.
Repeat on the other side of the vehicle.

CURTMFG.COM •PRODUCT SUPPORT: 877.287.8634 •70118-INS-RC •04/14/2020 •ECN6926 •PAGE 5
Step 6
Remove the bumper fascia by pulling up
and out at the edges, near the wheel wells.
Make sure to disconnect any electrical
harnesses. Remove the bumper fascia
entirely and set it aside.
For All-Terrain Models (as shown): Use a
paint pen to mark the areas on the bumper that
need to be trimmed, as shown. Use a tin snips
or aviator shears to cut off the marked areas.
For Denali Models (not pictured): Hold the
base plate in position and use a paint pen to
mark the areas on the radiator air dam that
need to be trimmed, as needed. Use a tin snips
or aviator shears to cut off the marked areas.

CURTMFG.COM •PRODUCT SUPPORT: 877.287.8634 •70118-INS-RC •04/14/2020 •ECN6926 •PAGE 6
Step 8
Using the side plate holes as a guide, drill the
remaining 3/8" holes into the lower frame pinch
seam. Insert a 3/8" hex head bolt (#6) and 3/8"
lock washer (#7) into each hole. Secure them
with 3/8" nylock nuts (#8).
Step 7
Position the tow bar base plate (#1) on
the vehicle frame and clamp it into place.
Fishwire a 3/8" carriage bolt and square
hole spacer (#4) into the front-most hole
on each side of the vehicle. Secure with
3/8" flange nuts (#9).
Using the rear hole as a guide, drill a 3/8"
hole into the frame. Install a 3/8" carriage
bolt (#5) and square hole spacer (#4) into
each of the rear holes. Secure with
3/8" flange nuts (#9).
TOW BAR BASE PLATE INSTALLATION

CURTMFG.COM •PRODUCT SUPPORT: 877.287.8634 •70118-INS-RC •04/14/2020 •ECN6926 •PAGE 7
Step 9
Install the permanent safety cables (#3) and
quick links (#10), looping them around the
vehicle frame and linking them to the tow bar
base plate (#1). There must be one cable on
each side of the vehicle.
Make sure the cables do not pinch or interfere
with any hoses, wiring or other components.
See 'Installing the Permanent Base Plate
Safety Cables' for additional information.
Step 10
Hold up the front fascia in its original position
and mark where it will need to be trimmed
to make space for the safety cable loops and
attachment tabs. Trim out the marked areas.
Reinstall the panel, making sure to
reconnect the electrical harnesses.
When ready to tow, install the tow bar
mounting tabs (#2). When not towing,
insert the socket plugs (#11) into the
ends of the tow bar base plate (#1).
Final Installed Image

CURTMFG.COM •PRODUCT SUPPORT: 877.287.8634 •70118-INS-RC •04/14/2020 •ECN6926 •PAGE 8
SAFETY CABLE INSTALLATION
ADDITIONAL INFORMATION
Towing Tips
Check your equipment Periodically check the condition of all towing equipment. Ensure all fasteners are tight and
that all structural components are sound. Do not tow with worn or damaged parts.
Towing vehicle and trailer
manufacturer's recommendations
Review the owner's manual for your towing vehicle and trailer
for specific recommendations, capacities and requirements.
Installing the Permanent Base Plate Safety Cables
When dinghy towing a vehicle with a tow bar, base plate safety cables should be used at all times.
In the event of a disconnect, the safety cables are designed to help prevent complete vehicle separation.
When installing the safety cables, use the illustrations below as a guide.
Installation guidelines
1. The cables must be connected to
the base plate and the vehicle frame.
2. Two cables must be installed.
3. Each cable must meet or exceed the
gross weight of the towed vehicle.
4. Make sure cables do not pinch or interfere
with hoses, wiring or other components.
Note: Base plate safety cables are not a replacement for safety chains connecting the tow vehicle to the towed vehicle.
BaseplateBaseplate
Quick link Quick link
Permanent baseplate
safety cable
Permanent baseplate
safety cable
Convenience link No convenience link
