CYBEX 525AT User manual

525AT Arc Trainer
Owner's Manual
Part Number
1008575-0001 AB

User and Service Documents Link
Operation Manuals and other Product Information available at
https://www.lftechsupport.com/web/document-library/documents
https://www.lftechsupport.com/web/document-library/documents
https://www.lftechsupport.com/web/document-library/documents
https://www.lftechsupport.com/web/document-library/documents
https://www.lftechsupport.com/web/document-library/documents
https://www.lftechsupport.com/web/document-library/documents
Trobareu el manual de funcionament i altra informació de producte a
https://www.lftechsupport.com/web/document-library/documents
Mae Llawlyfrau Gweithredu a Gwybodaeth Arall am Beiriannau ar gael yn
https://www.lftechsupport.com/web/document-library/documents
Die Betriebsanleitung und andere Produktinformationen erhalten Sie unter
https://www.lftechsupport.com/web/document-library/documents
Encontrará el manual de funcionamiento y otra información de producto en
https://www.lftechsupport.com/web/document-library/documents
Erabiltzailearen Eskuliburua eta Beste Produktuei buruzko Informazioa eskuratu
https://www.lftechsupport.com/web/document-library/documents gunean
Käyttöoppaat ja muut tuotetiedot ovat saatavana osoitteessa
https://www.lftechsupport.com/web/document-library/documents
Les manuels d’utilisation, ainsi que d’autres informations sur les Produits, sont disponibles sur
https://www.lftechsupport.com/web/document-library/documents
Felhasználói kézikönyvek és más termékinformációk:
https://www.lftechsupport.com/web/document-library/documents
Manuali di funzionamento e altre informazioni sui prodotti disponibili su
https://www.lftechsupport.com/web/document-library/documents
Instrukcje obsługi i inne informacje o produktach dostępne na stronie
https://www.lftechsupport.com/web/document-library/documents
Manuais de Operação e Informações sobre outros produtos disponíveis em
https://www.lftechsupport.com/web/document-library/documents
https://www.lftechsupport.com/web/document-library/documents
Kullanım Kılavuzları ve Diğer Ürün Bilgileri https://www.lftechsupport.com/web/document-library/documents’da
bulunmaktadır
Page 3 of 53

Table of Contents
Getting Started
Safety Instructions..............................................................5
Consignes de sécurité........................................................7
Warnings and Cautions......................................................9
Label Placement...............................................................10
Setup...................................................................................11
Product Overview
Product Features..............................................................12
Mounting and Dismounting the Arc Trainer................12
How to Use the Arc Trainer.............................................12
Assembly
Assembly Procedure........................................................13
Testing Operation.............................................................22
Time and Date Confirmation..........................................23
Operation
Intended Use.....................................................................24
Individual Human Power Versus Mechanical
Power.............................................................................24
Terms Used........................................................................24
User Control Symbols Used............................................24
Console Display.................................................................26
User Controls.....................................................................26
Mount and Dismount.......................................................27
Range of Motion................................................................27
Quick Operation Guide....................................................28
Detailed Operation Guide...............................................28
Safety Sentry......................................................................30
Workout Selection............................................................30
Data Readouts...................................................................30
Heart Rate Indicator.........................................................31
How Power Input Versus Displayed Value is
Calculated.....................................................................31
Testing Parameters..........................................................31
Service and Technical Data
Preventive Maintenance Tips.........................................32
Maintenance Schedule....................................................32
Approved and Compatible Cleaners............................32
Troubleshooting the Polar®Heart Rate Chest
Strap..............................................................................33
Drive Belts...........................................................................33
How to Obtain Product Service.....................................35
Specifications
Appendix - Workout Overviews
1 - Weight Loss 1................................................................37
2 - Weight Loss 2................................................................39
3 - Weight Loss 3................................................................41
4 - Cardio 1.........................................................................43
5 - Cardio 2.........................................................................45
6 - Cardio 3.........................................................................47
7 - Strength 1......................................................................49
8 - Strength 2......................................................................51
Cybex®and the Cybex logo are registered trademarks of Cybex International, Inc.
DISCLAIMER: Cybex International, Inc. makes no representations or warranties regarding the contents of this manual. We reserve the right to revise this document
at any time or to make changes to the product described within it without notice or obligation to notify any person of such revisions or changes.
©Copyright 2018, Cybex International, Inc.
Columbia Center III - 9525 West Bryn Mawr Ave, Rosemont, IL 60018 • 800-351-3737 • 847-288-3700 • FAX [phone]
www.cybexintl.com • 1008575-0001 AB • 2018
Page 4 of 53

Getting Started
Safety Instructions
Read all instructions before using the product.
Please take special note of the following safety instructions and important points prior to choosing a location and
beginning assembly of the product.
Warning: Health-related injuries may result from incorrect or excessive use of exercise equipment. Cybex
International, Inc. STRONGLY recommends seeing a physician for a complete medical exam before undertaking
an exercise program, particularly if the user has a family history of high blood pressure or heart disease, is
over the age of 45, smokes, has high cholesterol, is obese, or has not exercised regularly in the past year. If,
at any time while exercising, the user experiences faintness, dizziness, pain, or shortness of breath, he or she
must stop immediately.
Warning: To reduce the risk of burns, fire, electric shock, or injury, it is imperative to connect each product
to a properly grounded electrical outlet.
Warning: Heart rate monitoring systems may be inaccurate. Over exercising may result in serious injury or
death. If you feel faint, stop exercising immediately.
Warning: Ensure that there is at least 23.6" (0.6 m) of clearance behind the product and at least 12" (30 cm)
on the sides.
Warning: The product is not equipped with a free-wheeling feature. Therefore, it cannot be stopped
immediately.
Warning: Moving parts and fall hazard.
• To avoid serious injury wait until foot plates come to a complete stop before getting off unit.
• The moving parts cannot be stopped immediately, the unit is not equipped with a free wheel.
Danger: To reduce the risk of electrical shock or injury from moving parts, always unplug product before
cleaning or attempting any maintenance activity.
• The individual human power required to perform an exercise may be different than the mechanical power
displayed on the product.
• Use caution when mounting or dismounting the product. Before mounting, use the moving arms to bring the
foot plate nearest to you to the lowest position. Use the stationary handlebars whenever additional stability is
required. While exercising, hold onto the moving arms.
• Never face backward while using the product.
• Do not stand or sit on the rear plastic covers of the product.
• Never operate the product if it has a damaged power cord or electrical plug, or if it has been dropped, damaged,
or even partially immersed in water. Contact Customer Support Services.
• Position the product so that the power cord plug to the wall is accessible to the user. Make sure that the power
cord is not knotted or twisted and that it is not trapped under any equipment or other objects.
• If the electrical supply cord is damaged, it must be replaced by the manufacturer, an authorized service agent,
or a similarly qualified person to avoid a hazard.
• Always follow the console instructions for proper operation.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental
capabilities, or lack of experience or knowledge unless they have supervision or been given instruction concerning
the use of the appliance by a person responsible for their safety.
• Do not use this product outdoors, near swimming pools or in areas of high humidity.
Page 5 of 53

• Never operate the product with the air openings blocked. Keep air openings free of lint, hair, or any other
obstructing material.
• Never insert objects into any opening in these products. If an object should drop inside, turn off the power,
unplug the power cord from the outlet, and carefully retrieve it. If the item cannot be reached, contact Customer
Support Services.
• Never place liquids of any type directly on the unit, except in an accessory tray or holder. Containers with lids
are recommended.
• Do not use these products in bare feet. Always wear shoes. Wear shoes with rubber or high-traction soles. Do
not use shoes with heels, leather soles, cleats or spikes. Make sure no stones are embedded in the soles.
• Keep all loose clothing, shoelaces, and towels away from moving parts.
• Do not reach into, or underneath, the unit or tip it on its side during operation.
• This equipment is not intended for use by children. Keep children under the age of 14 away from the machine.
• Do not allow other people to interfere in any way with the user or equipment during a workout.
• Use these products for their intended use as described in this manual. Do not use attachments that have not
been recommended by the manufacturer.
• Read all warnings on each product prior to starting a workout.
• If warnings are missing or damaged, please contact Customer Support Services immediately for replacement
warning labels. Warning labels are shipped with every product and should be installed before product is used.
Cybex International, Inc. is not responsible for missing or damaged warning labels.
• Health and Environmental Regulations Warning - This product may contain chemicals known to the State of
California to cause cancer, birth defects, or other reproductive harm. For more information related to the
European Commission Regulation (EC) No. 1907/2006 (REACH) and the California Safe Drinking Water and Toxic
Enforcement Act of 1986 (Proposition 65), please visit
https://www.lftechsupport.com/web/guest/environmental-regulations-information.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Testing Parameters
Displayed power (Wattage) and speed (Strides Per Minute), were found to meet class A accuracy when compared
with measured power and speed, with adjustable braking positioned in its maximum position, at the following
accuracy test points:
• 150 W, 86 SPM• 25 W, 37 SPM
• 50 W, 52 SPM • 175 W, 92 SPM
• 100 W, 72 SPM • 200 W, 97 SPM
Page 6 of 53

Consignes de sécurité
Lire toutes les instructions avant usage.
Prêtez une attention toute particulière aux instructions de sécurité ci-dessous avant de choisir un emplacement
et de commencer à assembler votre CYBEX INTERNATIONAL INC. .
AVERTISSEMENT: Une utilisation incorrecte ou excessive de l'appareil peut entraîner des blessures. CYBEX
INTERNATIONAL INC. recommande VIVEMENT aux utilisateurs de passer un examen médical complet avant
d'entamer un programme d'entraînement, et tout particulièrement dans les cas suivants : antécédents
familiaux d'hypertension (pression sanguine trop élevée) ou de pathologies cardiaques, utilisateurs de 45
ans ou plus, tabagisme, hypercholestérolémie (taux de cholestérol sanguin trop élevé), obésité, absence
d'exercice physique depuis un an ou plus. Arrêtez immédiatement votre entraînement si vous ressentez l'un
des signes suivants lors de l'utilisation de votre appareil : étourdissements, vertiges, douleur ou essoufflement.
AVERTISSEMENT: Pour réduire les risques de brûlures, d'incendies, de chocs électriques ou de blessures,
il est essentiel de brancher chaque appareil sur une prise électrique correctement mise à la terre.
AVERTISSEMENT: Les systèmes de surveillance de la fréquence cardiaque peuvent être inexacts. Un exercice
trop intensif peut entraîner des blessures graves, voire mortelles. Si vous ressentez une sensation de malaise,
arrêtez immédiatement l’exercice.
AVERTISSEMENT: Veillez à laisser un dégagement d’au moins 60 cm (23,6 in) derrière l'appareil et d'au
moins 30 cm (12 in.) sur les côtés.
AVERTISSEMENT: L'appareil n'est pas équipé d'une option roue libre. et ne peut donc pas être arrêté
instantanément.
AVERTISSEMENT: Pièces mobiles et risque de chute.
• Afin d'éviter des blessures sérieuses, attendez l'arrêt complet des repose-pieds avant de descendre de
l'appareil.
• Les pièces mobiles ne peuvent pas être arrêtées immédiatement, l'unité n'est pas équipée d'une roue
libre.
Danger.: Pour réduire les risques de chocs électriques ou de blessures en raison des pièces mobiles,
débranchez toujours les produits avant de les nettoyer ou de procéder aux tâches d’entretien.
•La puissance nécessaire à chaque utilisateur pour effectuer un exercice peut différer de la puissance mécanique
affichée sur l'appareil.
• Montez et descendez avec précaution du produit. Avant de monter, placez le repose-pied situé de votre côté
en position basse, en vous aidant des bras mobiles. Utilisez les poignées fixes lorsque vous avez besoin de
renforcer votre équilibre. Pendant les exercices, tenez les bras mobiles.
• Ne montez jamais à l'envers sur le produit.
• Ne faites jamais fonctionner le produit dont la fiche ou le cordon d'alimentation sont altérés, ni aucun appareil
qui serait tombé, aurait été endommagé ou même partiellement plongé dans l'eau. Contactez le Service clients.
• Placez l'appareil de façon à ce que l'utilisateur ait accès à la fiche du cordon d'alimentation. Assurez-vous que
le cordon d'alimentation n'est pas noué ou tordu et qu'il n'est pas coincé sous un autre appareil ou sous tout
autre objet.
• Si le cordon d'alimentation électrique est endommagé, il doit être remplacé par le fabricant, par un réparateur
agréé ou par une personne qualifiée afin d'éviter tout danger.
• Suivez toujours les instructions s'affichant sur la console.
•Cet appareil n'est pas destiné à être utilisé par des personnes ou des enfants présentant des capacités physiques,
sensorielles ou mentales réduites, ou un manque d'expérience et de connaissances, sauf en cas de supervision
ou d'instructions relatives à son utilisation par une personne responsable de leur sécurité.
• N'utilisez pas ce produit à l'extérieur, près d'une piscine ou dans des endroits très humides.
Page 7 of 53

• Ne jamais utiliser le produit en ayant les ouvertures d'air bloquées. Le système d'aération doit être propre et
ne contenir aucun résidu de tissus, cheveux ou autres matériaux.
•N'insérez jamais d'objet dans les ouvertures de cet appareil. Si un objet tombe dans l'appareil, mettez ce dernier
hors tension, débranchez le cordon d'alimentation et récupérez l'objet avec précaution. Si vous ne pouvez pas
l'atteindre, contactez le Service clients.
• Ne placez jamais de liquides d'aucune sorte directement sur l'appareil, sauf si vous disposez d'un support ou
d'un plateau pour accessoires. Nous vous recommandons de n'utiliser que des récipients pourvus d'un bouchon.
• N'utilisez pas ce produit pieds nus. Portez toujours des chaussures. Portez des chaussures avec semelles en
caoutchouc ou antidérapantes. N'utilisez pas de chaussures à talon, à semelle en cuir, à crampons ou à pointes.
Vérifiez qu'aucun gravier n'est coincé dans vos semelles.
• Éloignez les vêtements amples, les lacets de chaussure et les serviettes des parties mobiles de l'appareil.
• Ne placez pas les mains à l'intérieur ou sous l'appareil ; ne le faites pas basculer sur le côté durant son
fonctionnement.
• Cet équipement n'est pas destiné à être utilisé par les enfants. Tenez les enfants âgés de moins de 14 ans à
l'écart de la machine.
• Ne laissez personne gêner l'utilisateur ou le fonctionnement de l'appareil pendant un exercice.
• Utilisez cet équipement uniquement aux fins auxquelles il est destiné et de la manière décrite dans le présent
manuel. N'utilisez pas d'accessoires non recommandés par le fabricant.
• Lisez les avertissements avant de commencer à vous entraîner.
• Si certaines étiquettes d'avertissement sont manquantes ou endommagées, contactez immédiatement le
Service à la clientèle. Nous vous en fournirons de nouvelles. Les étiquettes d'avertissement sont expédiées
avec les appareils et doivent être installées avant utilisation de ces derniers. Cybex International, Inc. n'est pas
responsable des étiquettes manquantes ou endommagées.
• Réglementation en matière de santé et d'environnement : avertissement – Cet appareil peut contenir des
produits chimiques considérés par l'État de Californie comme étant cancérigènes et causant des malformations
congénitales et d'autres troubles de l'appareil reproducteur. Pour plus d'informations sur le règlement de la
Commission européenne (CE) n°1907/2006 (REACH) et sur le California Safe Drinking Water and Toxic Enforcement
Act de 1986 (Proposition 65), consultez la page
https://www.lftechsupport.com/web/guest/environmental-regulations-information.
Remarque: cet équipement a été testé et jugé conforme aux limites des dispositifs numériques de classe
A, définies dans l’article 15 du règlement de la FCC. Ces limites sont conçues pour assurer une protection
raisonnable contre le brouillage préjudiciable lorsque l'appareil fonctionne dans un environnement
commercial. Cet équipement génère, utilise et peut émettre des fréquences radio. Il peut causer des
interférences nuisibles aux communications radio s'il n'est pas installé et utilisé conformément aux
instructions du présent manuel d'installation. Le fonctionnement de cet appareil dans une zone résidentielle
pourrait provoquer un brouillage préjudiciable, auquel cas l'utilisateur sera tenu de corriger ce brouillage
à ses propres frais.
CONSERVEZ PRÉCIEUSEMENT CES INSTRUCTIONS POUR UNE CONSULTATION ULTÉRIEURE..
Paramètres de test
La puissance affichée (puissance) et la vitesse (foulées par minute), se sont avérées répondre à la précision de la
classe A par rapport à la puissance et la vitesse mesurées, avec le freinage réglable placé en position maximale,
au niveau des points d'essai de précision suivants :
• 150 W, 86 SPM• 25 W, 37 SPM
• 50 W, 52 SPM • 175 W, 92 SPM
• 100 W, 72 SPM • 200 W, 97 SPM
Page 8 of 53

Warnings and Cautions
Warning labels indicate a potentially hazardous situation that could result in serious injury or death if the precautions
are not observed.
Caution labels indicate a potentially hazardous situation that could result in serious injury or damage to machine
if the precautions are not observed.
Contact Customer Support Services to replace any worn or damaged labels.
CanadianCanadian
Page 9 of 53

Label Placement
Label, Warning, Access Tray, Left770A-331-X1
Label, Warning, Access Tray, Left, Canadian770A-331-E1
Label, Warning, Access Tray, Right770A-332-X2
Label, Warning, Access Tray, Right, Canadian770A-332-E2
Label, Warning, Disconnect Power525AT-4003
Label, Warning, Disconnect Power525AT-4013
Label, Warning, Disconnect Power525AT-4023
Label, Warning, Hot FlywheelDE-17155-X4
Label, Caution, Moving PartsDE000004-X5
Page 10 of 53

Setup
Read the entire manual before setting up the unit.
Electrical Power Requirements
CYBEX INTERNATIONAL INC. require an AC power supply according to the electrical configurations listed in the
chart below.
Equipment Rated Current (Amps)Frequency (Hz)Supply Voltage
3.050 / 60100
3.050 / 60110
3.050 / 60120
2.550 / 60200
2.550 / 60220
2.550 / 60230
2.550 / 60240+
Note: Do not modify the plug provided with this product. If the plug does not fit into an available electrical
outlet, have a proper outlet installed by a qualified electrician.
Choosing and Preparing Site
Before assembling the unit, verify the chosen site meets the following criteria:
• Area is well lit and well ventilated.
• Surface is structurally sound and properly leveled.
• Free area for access to unit and emergency dismount. Minimum clearance is 23.6 inches (0.6 meters).
• Adjacent units may share the free area.
Free Area
23.6”, 0.6m
1
It is the responsibility of the facility owner/owner of the equipment to ensure that there is appropriate clearance
around each machine to allow for safe use and passage.
In compliance with the ADA (American Disabilities Act) there must be clear floor space of at least 30 by 48 inches
and be served by an accessible route for at least one of each type of exercise equipment. If the clear space is
enclosed on three sides (e.g., by walls or the equipment itself), the clear space must be 36 by 48 inches.
All other machines must have a clear floor space of 23" for all access point on the machine.
The dimensions stated in the assembly instructions of this manual include the maximum foot print (in use)
dimensions.
Minimum clearance of 12” (30 cm) between units for proper wireless heart rate signal operation.
Page 11 of 53

Product Overview
Product Features
DescriptionItem
Console1
Accessory Trays2
Cup Holder3
Contact Heart Rate Sensors4
Leg Levelers5
Mounting and Dismounting the Arc Trainer
To mount, step one foot at a time atop each of the foot plates. If necessary, stabilize your body by grasping the
frame, the stationary handles (if available), or the moving handles (if available). Be aware that the pedals will begin
to move as soon as you put weight on them. The pedals are large enough to accommodate different foot positions,
however the most common position is with the user’s toes forward underneath the plastic toe cup.
To begin exercise, push down and back into the pedals. Since the Arc Trainer pedals travel back and forth along
an arc (not in a circle or ellipse), there is no ‘forward’ or ‘backward’ motion.
To dismount, slowly bring the pedals to a stop. Grasp the stationary handles or part of the frame to assist in
stepping off the foot plate, back and away from the machine. When stepping back, ensure that you are beyond
and behind the path of motion of the foot plates. Never stand inside of the machine’s footprint, unless standing
atop the foot plates.
How to Use the Arc Trainer
Once standing on the foot plates, begin exercise by pushing down and back on the foot plates. The user has several
options for hand placement, not all of which are available on each Arc Trainer variant: 1. Stationary handles along
the side of the frame, 2. Stationary handles around the console, 3. Moving handles, or 4. Not holding anything.
These different postures have an influence on the muscles that are utilized and thus, the calories burned during
the exercise. Always be aware of the position of the moving handles, especially if you are not actively grasping
them. These handles move in synchrony with the pedals, so pull on the handle as you are pushing down and back
with your foot. Speed on the Arc Trainer is measured in cadence as steps per minute. The most common cadences
during use are 100-160 steps per minute, although users performing high intensity intervals may routinely exceed
this range.
Page 12 of 53

Assembly
Assembly Procedure
Two people will be required for this procedure.
Tip: Read and understand all instructions thoroughly before assembling this unit. Check all items carefully.
If there is damage, see the Customer Service section of this manual for proper procedure to return, replace,
or reorder parts.
The words "left" and "right" denote the user's orientation.
Verify you have received the correct package
1. Read box label to verify the model number and voltage (optional) match what was ordered.
2. Verify paint color matches what was ordered.
Verify Parts List Shown Below
Qty.DescriptionItem
1Base Assembly1
1Console Assembly2
1Base, Accessory Tray3
1Cover, Top, Accessory Tray4
1Cover, Bottom, Accessory Tray5
2Foot Pad6
1Owner’s Manual7
1Hardware Pack8
Page 13 of 53

Hardware
Qty.DescriptionItem
2Flange Spacer9
13/16” Allen Wrench10
27/32” Allen Wrench11
4BHSCS .375-16 × 2.25”12
1Grommet, Nylon13
4Locknut, .375-16 Nylon14
2Washer, Flat .281 ID × .500 OD × .062”15
2Screw, Pan Head Phillips, #6 x .50”16
3Screw, Pan Head Phillips, 8-16 × .50”17
4Tap Sc 10-12 × 2.00 Pn Hd Phil18
2SHCS .250-20 UNC-3A SS19
3Linkage Rod Cap 2.00 OD (1 extra)20
1Loctite21
Page 14 of 53

Tools Required
• Stubby Phillips screwdriver
• 3/16” Allen wrench (included)
• 7/32” Allen wrench (2) (included)
• 9/16” Open end wrench
Lift and Move Unit
1. Remove lag bolts and shipping supports. Keep package material on linkage arms at this time. This will protect
the paint from scratching during assembly.
2. Grasp each rear support leg firmly and lift with one person on each side.
3. Lift the lower rear support legs so the front transport wheels are able to roll on floor.
Use proper lifting methods.
4. Move unit to intended location.
5. Lower rear support legs.
Page 15 of 53

Install Console Assembly
1. Place the console into position on the frame. Do not pinch cables while lowering the console.
Qty.DescriptionItem
4Locknuts1
1Console2
1Frame3
4Bolts4
1Upper Heart Rate Cable5
1Lower Heart Rate Cable6
1Upper Display Cable7
1Lower Display Cable8
2. Insert (from underneath) the four bolts into the frame and console.
3. Thread the four locknuts onto the bolts by hand.
4. Tighten the four bolts and locknuts with a 7/32” Allen wrench and a 9/16” open-end wrench.
5. Plug the upper heart rate cable into the lower heart rate cable.
6. Plug the upper display cable into the lower display cable.
Install Accessory Tray Base
1. Place the accessory tray base in position on the base assembly.
Qty.DescriptionItem
1Accessory Tray Base1
1Base Assembly2
4Screws3
2. Install the four screws using a stubby Phillips screwdriver.
Install Accessory Tray Top
Install screws securing accessory tray top to accessory tray base using a stubby Phillips screwdriver.
Page 16 of 53

Qty.DescriptionItem
1Accessory Tray Top1
1Accessory Tray Base2
2
Screw, Pan Head Phillips, 8-16 x
.50"
3
Install Accessory Tray Bottom
1. Install the grommet to the frame.
Qty.DescriptionItem
1Grommet, Nylon, Long1
1Frame2
2. Install screws securing the accessory tray bottom to the accessory tray top using a Phillips screwdriver.
3. Install screw securing the accessory tray bottom to the frame using a Phillips screwdriver.
Qty.DescriptionItem
1Accessory Tray Bottom1
1Accessory Tray Top2
2Screw, Pan Head Phillips, 6 x .50"3
1
Screw, Pan Head Phillips, 8-16 x
.50"
4
Page 17 of 53

Remove Left and Right Handle Assembly
The left and right handle assemblies are shipped in rotated positions. The handle assemblies must be removed
and rotated 180 degrees for proper setup and assembly.
Qty.DescriptionItem
1Left Handle Assembly1
1Right Handle Assembly2
1. Remove a screw and washer from the left handle assembly using two 7/32” Allen wrenches.
Qty.DescriptionItem
1Screw1
1Washer2
1Left Handle3
1Pivot Pin Assembly4
2. Slide pivot pin assembly out and remove left handle assembly.
3. Rotate left handle assembly 180 degrees.
4. Apply Loctite to threads inside the pivot pin and screw.
5. Place left handle assembly in position and slide pivot pin assembly back in place.
6. Install the screw and washer to the left handle assembly using two 7/32” Allen wrenches.
Page 18 of 53

7. Remove a screw and washer from the right handle assembly using two 7/32” Allen wrenches.
Qty.DescriptionItem
1Washer1
1Screw2
1Right Handle3
1Pivot Pin Assembly4
8. Slide pivot pin assembly out and remove right handle assembly.
9. Rotate right handle assembly 180 degrees.
10. Apply Loctite to threads inside the pivot pin and screw.
11. Place right handle assembly in position and slide pivot pin assembly back in place.
12. Install the screw and washer to the right handle assembly using two 7/32” Allen wrenches.
Install Left Linkage Rod
1. Pivot left handle assembly up and slide left linkage rod onto left arm.
Qty.DescriptionItem
1Screw1
1Loctite2
1Washer3
1Linkage Rod Cap4
1Flange Spacer5
1Left Arm6
1Left Linkage Rod7
2. Place a drop of Loctite onto the screw.
3. Install the screw, washer, linkage rod cap, and flange spacer using a 3/16” Allen wrench.
4. Tighten screw to a minimum of 90 in-lbs.
Install Right Linkage Rod
1. Pivot right handle assembly up and slide left linkage rod onto left arm.
Page 19 of 53

Qty.DescriptionItem
1Right Linkage Rod1
1Right Arm2
1Flange Spacer3
1Linkage Rod Cap4
1Washer5
1Loctite6
1Screw7
2. Place a drop of Loctite onto the screw.
3. Install the screw, washer, linkage rod cap, and flange spacer using a 3/16” Allen wrench.
4. Tighten screw to a minimum of 90 in-lbs.
Verify handle assemblies are now installed in the correct position.
Qty.DescriptionItem
1Left Handle Assembly1
1Right Handle Assembly2
Install Contact Heart Rate Cable
1. Connect handle heart rate cable to frame heart rate cable.
Qty.DescriptionItem
1Heart Rate Cable, Handle1
1Heart Rate Cable, Frame2
2. Press ends of handle heart rate cable into frame.
Page 20 of 53
