CYBEX Arc Trainer 770A User manual

Cybex 770A/770AT Arc Trainer®
Owner’s Manual
Cardiovascular Systems
Part Number 5770-4 C
www.cybexintl.com

2
Cybex Owner’s Manual
Cybex® and the Cybex logo are registered trademarks of Cybex International, Inc. Polar®is a registered trademark of Polar Electro Inc. iPOD®is
registered trademark of Apple.
DISCLAIMER: Cybex International, Inc., makes no representations or warranties regarding the contents of this manual. We reserve the right to revise
this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such revisions or
changes.
© Copyright 2012, Cybex International, Inc. All rights reserved. Printed in the United States of America.
10 Trotter Drive Medway, MA 02053 • 508-533-4300 • FAX [phone] • www.cybexintl.com • 5770-4 C • June 2012
FCC Compliance Information .............3
Safety
Ground and Voltage Information...........4
Important Safety Instructions .............5
Warnings and Cautions .................8
Label Placement.......................9
Assembly
Specications - 770A ..................10
Specications - 770AT ................. 11
Environment and Storage...............12
Choosing and Preparing Site . . . . . . . . . . . . 12
Electrical Power Requirements ..........12
770AAssembly Procedure ..............13
Tools Required......................13
770AT Assembly Procedure.............26
Tools Required......................26
Setup ..............................43
A/V Conguration and FM Radio Presets...45
E3 View Monitor Controls...............50
E3 View Monitor Setup.................51
Testing Operation .....................60
Operation
Intended Use ........................61
Terms Used .........................61
User Control Symbols Used.............62
CardioTouch Symbols Used.............63
CardioTouch Symbols Used (continued) ...64
Console Display . . . . . . . . . . . . . . . . . . . . . . 65
Muscle Map and Incline Meter . . . . . . . . . . . 66
CardioTouch Screen and User Controls....67
Mount and Dismount ..................68
Emergency Dismount..................68
Range of Motion......................69
Quick Operation Guide.................70
Detailed Operation Guide...............70
Workout Selection ....................72
Data Readouts - LED display............73
E3 View Monitor Screen Options .........74
Heart Rate Indicator ...................74
Fan Control..........................75
iPod Functions .......................75
Maintenance
Warnings ...........................76
Cleaning Unit ........................77
Preventive Maintenance Activities ........77
Remove Access Cover.................78
Drive Belts ..........................79
Rechargeable Battery..................79
Attach Access Cover ..................80
E3 View Monitor ......................80
Recommended Service Schedule ........81
Statistics............................82
Customer Service
Product Registration...................83
Contacting Service ....................83
Ordering Parts .......................83
Serial Number........................84
Return Material Authorization (RMA) ......84
Damaged Parts.......................85
Appendix - Workout Overviews
Weight Loss - Hill Climb ................86
Weight Loss - Speed Bump .............87
Strength - High Low ...................88
Strength - Bursts......................89
Strength - Interval.....................90
Fitness (Mens) , Shaping (Womens) -
Total Leg ..........................91
Fitness (Mens) - Target: Hip, Shaping
(Womens) - Glute Camp ..............92
Cardio - Wave........................93
Cardio - Interval ......................94
Cardio - Heart Rate Control .............95
Power - Constant Power................95
Power - Adaptive Power................95
Table of Contents

3
Cybex Owner’s Manual
FCC Compliance Information
Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment!
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.

Cybex Owner’s Manual
4
Safety
Read all instructions and warnings before using.
Ground and Voltage Information
DANGER: Death or serious injury can occur. To avoid death or serious injury the
following precautions must be observed. Equipment must be properly
grounded. Check with a qualied electrician or service provider to verify the
unit is properly grounded. Improper connection of equipment grounding can
result in electric shock.
For E3 View Monitor or Optional Power Supply
• Unit must be grounded. This unit is equipped with an optional equipment-grounding conductor cord
and a grounding plug.
• Do not use a ground plug adapter to adapt the power cord to a non-grounded outlet.
• Plug must be plugged into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
• If unit malfunctions, grounding provides path of least resistance for electric current to reduce risk of
electric shock.
Cybexisnotresponsibleforinjuriesordamagesasaresultofcordorplugmodication.
• Verify voltage requirements of unit match local voltage requirements.
• Verify unit outlet is the same conguration as the plug.
Power
Adapter Power Cord
UseCybexsuppliedpoweradapterandpowercordsonly.
Connector
Varies by
Country

Cybex Owner’s Manual
4 5
Important Safety Instructions
(Save These Instructions)
DANGER: Death or serious injury can occur. To avoid death or injury the following
procedure must be followed. Always unplug this unit from the electrical outlet
before cleaning. Unplugging equipment reduces risk for shock.
User Safety Precautions
• KEEPALL CHILDREN 12 AND UNDER AWAY! Teenagers or disabled must be supervised.
• Obtain a medical exam before beginning any exercise program.
• Stop exercising if feeling faint, dizzy, or experiencing pain and consult your physician.
• Obtain instruction before using.
• Read and understand all warnings posted on the unit before using.
• Use the handrails for support and to maintain balance.
• Wait until foot plates come to a complete stop before dismounting.
• Keep foot plate surface clean and dry.
• DO NOT wear loose or dangling clothing while using.
• Keep all body parts and other items free and clear of moving parts.
• DO NOT use unit if user exceeds 400 lbs. (180 kg). This is the rated maximum user weight.
• Report any malfunctions, damage or repairs to the facility.
• Replace any warning labels if damaged, worn or illegible.
Facility Safety Precautions
It is the sole responsibility of the user/owner or facility operator to ensure that regular maintenance is
performed.
• Enforce all user and safety precautions.
• Read and understand the Owner’s Manual completely before assembling, servicing or using unit.
• Verify all users are properly trained on using the equipment.
• Do not use unit outdoors.
• Verify that each unit is setup, leveled and operated on a solid level surface. Do not install equipment
on an uneven surface.
• Verify there is enough room for safe access and operation of unit.
• Use Cybex AC power adapters only.
• Do not use the optional power adapter in damp or wet locations.
• Do not use the unit if: (1) the unit is plugged into an optional power adapter that has a damaged
cord; (2) the unit is not working properly or (3) if the unit has been dropped or damaged. Seek
service from a qualied technician.
• EQUIPMENT is not suitable for use in the presence of aerosol (spray), FLAMMABLE
ANAESTHETIC MIXTURE WITH AIR or WITH OXYGEN or NITROUS OXIDE.
• Perform regular maintenance checks on unit. Performance level can be maintained only if
examined regularly. Pay close attention to all areas most susceptible to wear, including (but not
limited to) cables, pulleys, belts and grips.
• Replace any warning labels if damaged, worn, or illegible.
• Immediately replace worn or damaged components. If unable to immediately replace worn or
damaged components, then remove unit from service until repair is made.

Cybex Owner’s Manual
6
• Do not attempt electrical or mechanical repairs. Seek qualied repair personnel when servicing. If
you live in the USA, contact Cybex Customer Service at 888-462-9239. If you live outside the USA,
contact Cybex Customer Service at 508-533-4300.
• Use only Cybex supplied components to maintain/repair unit.
• Keep a repair log of all maintenance activities.
• Disconnect the optional power adapter before servicing unit.
• Do not use attachments unless recommended for the unit by Cybex.
• The unit may generate electromagnetic or other forms of interference, or it may be affected by
interference from other equipment nearby. If this is suspected, take precautions by separating the
equipment or otherwise shielding it to avoid such interference.
Unit with E3 View Monitor option
WARNING: Serious injury or death can occur. To avoid injury or death the following
procedure must be followed. Monitor must be connected to a mains socket
outlet with a protective earthing connection. Failure to connect monitor
correctly could result in electrical shock. Do not alter the mains plug or
coupler. Both are used as a disconnection device. It must remain operable or
the safety of the equipment is at risk. Do not expose this monitor to rain or
moisture. Exposing monitor to moisture could result in electrical shock.
• The product is supplied with electricity. Rain or moisture increases the risk of electric shock.
• Do not interfere with the enclosure. The lightning ash with arrowhead symbol within an equilateral
triangle, is intended to alert the user to the presence of non-insulated “dangerous voltage“ within
the product’s enclosure that may be of sufcient magnitude to constitute a risk of electric shock to
persons.
• The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
product.
• Ensure that used batteries are disposed of safely. Do not dispose of electrical products in the
general waste. When your monitor has reached the end of its life, contact your local city council
regarding available recycling or disposal options.
• Electricity is used to perform many useful functions, but it can also cause personal injuries and
property damage if improperly handled. This product has been engineered and manufactured with
safety being the highest priority. However, improper use can result in personal injury and/or property
damage.
• Read and keep these instructions.
• Heed all warnings and follow all instructions.
• Do not use this monitor near water.
• Dust off the panel with a soft dry cloth as needed. The screen can be cleaned with computer screen
wipes or other non abrasive, moist, disposable wipes.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including ampliers) that produce heat.
• No naked ame sources, such as lighted candles, should be placed on the monitor.
• Do not expose batteries to excessive heat sources.

Cybex Owner’s Manual
6 7
• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for safety. If the provided plug does not t into
outlet, consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the monitor.
• Only use attachments/accessories specied by the manufacturer.
• Unplug this monitor during lightning storms or when unused for long periods of time.
• Refer all servicing to qualied service personnel. Servicing is required when the monitor has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the monitor, has been exposed to rain or moisture, does not operate
normally, or has been dropped.
• Do not expose this monitor to dripping or splashing and ensure that no objects lled with liquids,
such as vases, are placed on the monitor.
• To completely disconnect this monitor from the AC Mains, disconnect the power supply cord plug
from the AC receptacle.
• The mains plug of the power supply cord shall remain readily operable.
• Overloading – Do not overload the AC outlets or extension cords.
• Replacement Parts – In case the product needs replacement parts, make sure that the service
person uses replacement parts specied by the manufacturer.
• Safety Check – Upon completion of service or repair work, request the service technician to perform
a safety check to ensure that the monitor is in proper operating condition.
• Consult dealer if in doubt about the installation, operation, or safety of this monitor.

Cybex Owner’s Manual
8
Warnings and Cautions
To replace any worn or damaged decals do one of the following: Visit www.cybexintl.com to shop
for parts online, fax orders to 508-533-5183 or contact Cybex Customer Service at 888-462-9239. If
you are located outside of the USA, call 508-533-4300. For location or part number of labels, see the
parts list and exploded-view diagram on the Cybex web site at www.cybexintl.com.
Warning decals indicate a potentially hazardous situation that could result in death or serious injury if
the precautions are not observed.
Caution decals indicate a potentially hazardous situation, which, if not avoided, could result in minor
or moderate injury.
The diagram following the decals show where each decal is located.
DECAL, DISCONNECT POWER
ENGLISH
REL 7-24-08
750A-372-4
125
1:1
OWATONNA
MFG. APPR.
TECH. PUBS. APPR. DATE
DATE
REV.
DWG. NO.
SCALE
SIZE
CHECKED BY
DWG. BY
TITLE:
FINISH:
MATERIAL:
B
SHEET
OF
EXCEPT AS NOTED
GENERAL
TOLERANCES:
2 DECIMALS ± .03
3 DECIMALS ± .015
ANGLES ± 1°
FEATURES SHOWN
PERPENDICULAR OR
PARALLEL SHALL BE
SO WITHIN ± 1°
REMOVE ALL BURRS
BREAK SHARP EDGES
.005/.010 R
SURFACE FINISH
INDICATED PER
ANSI B46.1-1985
GENERAL
MACHINING
DIMENSIONS
IN INCHES
DATE
DATE
REMOVE CARBURIZATION
AND SCALE FROM LASER
AND PLASMA CUT EDGES
ALL MATERIAL MUST COMPLY TO
EUROPEAN UNION DIRECTIVE
2002/95/EC RoHS (RESTRICTION
OF HAZARDOUS SUBSTANCES)
1 1 B
NOTE: SEE ENGINEERING DRAWING 750A-372-X FOR SPECIFICATIONS.
BB 8-13-08
EML 8-13-08
750A-372-4 B
WARNING
DISCONNECT POWER
BEFORE SERVICING.
Voltage: 100-240 VAC~
50/60Hz 1.8 Amps 1-Phase
2.00
1.25
R .10
4 PLACES
SAFETY ORANGE PMS 152
BLACK TRIANGLE W/ ORANGE
EXCLAMATION POINT, BLACK LETTERS
18 PTARIAL BOLD FONT
PART NUMBER
6 PT ARIAL TEXT
WHITE BACKGROUND WITH
BLACK 10 PTARIAL TEXT
WHITE BACKGROUND WITH
BLACK 10 PTARIAL BOLD TEXT
770A-331-4
SERIOUS INJURY COULD OCCUR IF
THESE PRECAUTIONS ARE NOT OBSERVED
WARNING
WARNING
KEEP ALL CHILDREN 12 AND UNDER AWAY! Teenagers or
disabled must be supervised.
Obtain a medical exam before beginning any exercise program.
Stop exercising if feeling faint, dizzy, or experiencing pain and
consult your physician.
Obtain instruction before using.
Read and understand the Owner's Manual and all warnings
posted on the unit before using.
Use the handrails for support and to maintain balance.
WARNING! Heart rate monitoring systems may be
inaccurate. Over exercise may result in serious injury or
death. If you feel faint stop exercising immediately.
125
1:1
OWATONNA
MFG. APPR.
TECH. PUBS. APPR. DATE
DATE
REV.
DWG. NO.
SCALE
SIZE
CHECKED BY
DWG. BY
TITLE:
FINISH:
MATERIAL:
B
SHEET
OF
EXCEPTAS NOTED
GENERAL
TOLERANCES:
2 DECIMALS ± .03
3 DECIMALS ± .015
ANGLES ± 1°
FEATURES SHOWN
PERPENDICULAR OR
PARALLEL SHALL BE
SO WITHIN ± 1°
REMOVE ALL BURRS
BREAK SHARP EDGES
.005/.010 R
SURFACE FINISH
INDICATED PER
ANSI B46.1-1985
GENERAL
MACHINING
DIMENSIONS
IN INCHES
DATE
DATE
REMOVE CARBURIZATION
AND SCALE FROM LASER
AND PLASMA CUT EDGES
ALL MATERIAL MUST COMPLY TO
EUROPEAN UNION DIRECTIVE
2002/95/EC RoHS (RESTRICTION
OF HAZARDOUS SUBSTANCES)
DE-17155-4
DECAL, WARNING
ENGLISH
1 1 B
JT 7-22-03
WARNING
DE-17155-4 B
Hot flywheel! Wait until it
cools before servicing.
SAFETY ORANGE PMS 152
BLACK TRIANGLE W/ ORANGE
EXCLAMATION POINT, BLACK LETTERS
17.54 PTARIAL BLACK FONT
WHITE BACKGROUND WITH
BLACK 10.5 PTARIAL TEXT
PART NUMBER
6.5 PT ARIAL TEXT
125
1:1
OWATONNA
MFG. APPR.
TECH. PUBS. APPR. DATE
DATE
REV.
DWG. NO.
SCALE
SIZE
CHECKED BY
DWG. BY
TITLE:
FINISH:
MATERIAL:
B
SHEET
OF
EXCEPTAS NOTED
GENERAL
TOLERANCES:
2 DECIMALS ± .03
3 DECIMALS ± .015
ANGLES ± 1°
FEATURES SHOWN
PERPENDICULAR OR
PARALLEL SHALL BE
SO WITHIN ± 1°
REMOVE ALL BURRS
BREAK SHARP EDGES
.005/.010 R
SURFACE FINISH
INDICATED PER
ANSI B46.1-1985
GENERAL
MACHINING
DIMENSIONS
IN INCHES
DATE
DATE
REMOVE CARBURIZATION
AND SCALE FROM LASER
AND PLASMA CUT EDGES
ALL MATERIAL MUST COMPLY TO
EUROPEAN UNION DIRECTIVE
2002/95/EC RoHS (RESTRICTION
OF HAZARDOUS SUBSTANCES)
DECAL, CAUTION MOVING PARTS
DE-17219-4 B
1 1
JT 7-22-03
1.80
1.25
R .12
4 PLACES
SAFETY YELLOW PMS 108
BACKGROUND BLACK TRIANGLE
W/ YELLOW EXCLAMATION POINT,
BLACK LETTERS 18.9 PTARIAL BLACK FONT
WHITE BACKGROUND WITH
BLACK 12 PTARIAL TEXT
PART NUMBER
6.5 PT ARIAL TEXT
DE-17219-4 B
CAUTION
Moving parts.
Keep hands away
when in use.
DE-17219-4 B
CAUTION
Moving parts.
Keep hands away
when in use.
(SPECS)
MASTER
ARTWORK
DE-17219-4 A
CAUTION
Moving parts.
Keep hands away
when in use.

Cybex Owner’s Manual
8 9
Label Placement
DE-17155-4
DE-17219-4 (2)
770A-332-4
770A-331-4
125
1:1
OWATONNA
MFG.APPR.
TECH.PUBS. APPR. DATE
DATE
REV.
DWG.NO.
SCALE
SIZE
CHECKEDBY
DWG.BY
TITLE:
FINISH:
MATERIAL:
BSHEET
OF
EXCEPTAS NOTED
GENERAL
TOLERANCES:
2DECIMALS ± .03
3DECIMALS ± .015
ANGLES ± 1°
FEATURESSHOWN
PERPENDICULAROR
PARALLELSHALL BE
SOWITHIN ± 1°
REMOVEALL BURRS
BREAKSHARP EDGES
.005/.010R
SURFACEFINISH
INDICATEDPER
ANSIB46.1-1985
GENERAL
MACHINING
DIMENSIONS
ININCHES
DATE
DATE
REMOVECARBURIZATION
ANDSCALE FROM LASER
ANDPLASMA CUT EDGES
ALLMATERIAL MUST COMPLY TO
EUROPEANUNION DIRECTIVE
2002/95/ECRoHS (RESTRICTION
OFHAZARDOUS SUBSTANCES)
DECAL, CAUTION MOVING PARTS
DE-17219-4 B
1 1
JT 7-22-03
1.80
1.25
R .12
4 PLACES
SAFETYYELLOW PMS 108
BACKGROUND BLACK TRIANGLE
W/ YELLOW EXCLAMATIONPOINT,
BLACK LETTERS 18.9 PTARIAL BLACK FONT
WHITE BACKGROUND WITH
BLACK 12 PTARIAL TEXT
PARTNUMBER
6.5 PT ARIAL TEXT
DE-17219-4B
CAUTION
Moving parts.
Keep hands away
when in use.
DE-17219-4B
CAUTION
Moving parts.
Keep hands away
when in use.
(SPECS)
MASTER
ARTWORK
DE-17219-4A
CAUTION
Moving parts.
Keep hands away
when in use.
750A-372-4

10
Cybex Owner’s Manual
Assembly
Specifications - 770A
Classification S (Studio)
Accuracy A
Length 76.25” (194 cm)
Width 32” (81 cm)
Height: 62.5” (159 cm)
Weight of
Product 404 lbs (183 kg)
Shipping
Weight 429 lbs (195 kg)
Incline Levels 0-20
Resistance
Levels 0-100
Stride Length 24” (61 cm) xed length.
Workouts Quick Start, ve workout groups, seven workouts, three heart rate workouts, and
two power workouts
Console
Features
Upper console: LED or E3 View Monitor. Displays Cal/Hr, Distance, Strides per
Minute, Calories, Watts, METs and BPM.
Lower console: Two numeric displays for incline, time, resistance and level.
Fan, iPod connector, CardioTouch screen, accessory trays and water bottle holder
Heart Rate
Features
Built-in wireless heart rate receiver (transmitter not included) and contact heart rate
monitoring.
Frame Colors
Standard: White Texture, Black Texture, Metaltone Gold, Black Chrome, Platinum
Sparkle.
Custom: Unlimited colors available.
Resistance
Range 0-900 watt.
Maximum
User Weight 400 lbs. (181 kg).
Power Rating Self powered or 100 - 240 VAC~, 50/60 Hz, 1.8A, 1-phase.
Options AC Power Adapter, E3 View Monitor.
The dimensions stated in the installation instructions are the recommended minimum dimensions as
set forth by the manufacturer. The actual area for access and passage shall be the responsibility of
the facility and should take into account any required local codes or regulations.

11
Cybex Owner’s Manual
Specifications - 770AT
Classification S (Studio)
Accuracy A
Length 76.25” (194 cm)
Width 36.28” (92 cm)
Height: 62.5”(159 cm)
Weight of
Product 412 lbs. (187 kg.)
Shipping
Weight 437 lbs. (198 kg.)
Incline Levels 0-20
Resistance
Levels 0-100
Stride Length 24” (61 cm) xed length.
Workouts Quick Start, ve workout groups, seven workouts, three heart rate workouts, and
two power workouts
Console
Features
Upper console: LED or E3 View Monitor. Displays Cal/Hr, Distance, Strides per
Minute, Calories, Watts, METs and BPM.
Lower console: Two numeric displays for incline, time, resistance and level.
Fan, iPod connector, CardioTouch screen, accessory trays and water bottle holder.
Heart Rate
Features
Built-in wireless heart rate receiver (transmitter not included) and contact heart rate
monitoring.
Frame Colors
Standard: White Texture, Black Texture, Metaltone Gold, Black Chrome, Platinum
Sparkle.
Custom: Unlimited colors available.
Resistance
Range 0-900 watt.
Maximum
User Weight 400 lbs. (181 kg).
Power Rating Self powered or 100 - 240 VAC~, 50/60 Hz, 1.8A, 1-phase.
Options AC Power Adapter, E3 View Monitor.
The dimensions stated in the installation instructions are the recommended minimum dimensions as
set forth by the manufacturer. The actual area for access and passage shall be the responsibility of
the facility and should take into account any required local codes or regulations.

12
Cybex Owner’s Manual
Environment and Storage
Humidity and Static Electricity
The unit is designed to function normally in an environment with a relative humidity range of 30% to
75%. The unit can be shipped and stored in a relative humidity range of 10% to 90%.
Dry air may cause static electricity. During workout, user may experience a shock due to build-up
of static electricity on the body and the discharge path of the unit. If static electricity is experienced,
increase humidity to a comfortable level through the use of a humidier.
Do not install, use, or store the unit in an area of high humidity, such as in the vicinity of a steam
room, sauna, indoor pool or outdoors. Exposure to extensive water vapor, chlorine and/or bromine
could adversely affect the electronics as well as other parts of the unit.
Temperature
The unit is designed to function normally in an environment with an ambient temperature range of 50°
F (10° C) to 104° F (40° C). The unit can be shipped and stored in an environment with an ambient
temperature range of 32° F (0° C) to 140° F (60° C).
Choosing and Preparing Site
Before assembling the unit, verify chosen site meets the following criteria:
• Area is well lit and well ventilated.
• Surface is structurally sound and properly leveled.
Place a 3/4” (1.9 cm) thick wood base under unit to protect carpeting.
Area allows for ample access and passage clearance around unit or for emergency dismount.
Minimum clearance is 19.7 inches (0.5 meters) on at least one side of unit and also behind unit.
Minimum clearance fo 12” (30 cm) between units for proper wireless heart rate signal operation.
Electrical Power Requirements
The E3 View Monitor is supplied with a power cord, The AC power kit is optional.
• Verify unit is connected to an outlet having the same conguration as the plug.
• Verify connection is a grounded circuit.
• Do not use a ground-plug adapter to adapt the 3-prong power cord to a non-grounded electrical
outlet.
• Use Cybex supplied optional AC power kit only. Consult an electrician with any questions.
• Ensure outlets used by this product meet all local and federal building codes.

13
Cybex Owner’s Manual
770A Assembly Procedure
Tools Required
• Phillips screwdriver
• Stubby Phillips screwdriver
• 3/16” Allen wrench (supplied)
• 7/32” Allen wrench (supplied)
• 9/16” Open end wrench (2)
The words “left” and “right” denote the user’s orientation.
Two people will be required for this procedure.
Read and understand all instructions thoroughly before assembling this unit. Check all items
carefully. If there is damage, see the Customer Service section of this manual for proper procedure to
return, replace, or reorder parts.
Item Quantity Part Number Description
1 1 Varies Base assembly
2 1 Varies Console assembly
3 2 12090-322 Foot pad
4 1 NA Handle, Right
5 1 NA Handle, Left
6 1 770A-316 Base, Accessory tray
7 1 770A-317 Cover, Top, Accessory tray
81770A-318 Cover, Bottom, Accessory tray
9 1 770A-322 Cover, Rear, Top, Right
10 1 770A-323 Cover, Rear, Outer, Right
11 1 770A-324 Cover, Rear, Inner, Right
12 1 770A-319 Cover, Rear, Top, Left
13 1 770A-321 Cover, Rear, Inner, Left
14 1 770A-320 Cover, Rear, Outer, Left
15 1 770A-341 Collar, Outer, Right
16 1 770A-340 Collar, Inner, Right
17 1 770A-334 Collar, Inner, Left
18 1 770A-335 Collar, Outer, Left
19 1 NA Hardware pack
20 1 5770-X Owner’s Manual
21 1 770A-404 Assembly poster
22 1 770A-415 Commercial Arc warranty sheet
23 1 770A-416 Consumer Arc warranty sheet
24 1 770A-310 Bracket, Lower, Display mount
25 1 770A-427 Cable, 6’, Coax (E3 View Monitor option)

14
Cybex Owner’s Manual
#9
#10
#15
#13
#17
#11
#16
#14
#18
#12
#7
#2
#3
#6
#4 #5
#19
#20 #21 #22 #23
#24
#25
#1
#8

15
Cybex Owner’s Manual
Verify contents of hardware pack
See hardware pack listings and hardware pack contents. See Customer Service for contact
information if any parts are missing.
Item Quantity Part Number Description
26 1 BK030204 7/32” Allen Wrench
27 4 HC700430 BHSCS .375-16 x 2.50”
28 1HF540200 Grommet, Nylon
29 4 HN704901 Locknut, .375-16 Nylon
30 4 HT592526 Tap Sc 10-12 x 2.00 Pn Hd Phil
31 6 HT532512 Screw, Pan Head Phillips, #6 x .50”
32 19 HT552512 Screw, Pan Head Phillips, 8-16 x .50”
33 8HT572515 Screw, Pan Head Phillips, 10-24 x .75”
770A Hardware
#26
#30
#27
#31
#28
1:1
#32
#29 #33

16
Cybex Owner’s Manual
#9 #10
#15
#13
#17
#11
#16
#14
#18
#31
#30
#27
#24
#32
#33 #32 #33
#32
#32
#32
#31
#29
#28 #33
#12
#7
#2
#3
#6
#4 #32
#33 #32
#33
#5
#1
#8

17
Cybex Owner’s Manual
Lift and move unit
1. Remove large bolts and shipping supports. Keep package material on linkage arms at this
time. This will protect the paint from scratching during assembly.
2. Grasp each rear support leg rmly and lift with one person on each side.
3. Lift the lower rear support legs using proper lifting methods so the front transport wheels are
able to roll on floor.
4. Move unit to intended location.
5. Lower rear support legs.
Attach 770A console assembly.
1. Place the console into position on the frame. Do not pinch cables while lowering the console.
Upper Display
Cable
Console
Locknuts (4)
Bolts (4)
Lower
Bracket
iPod
Cable
Frame
Lower Display
Cable
Coax Cable
(E3 View Monitor option)
2. Insert (from underneath) the lower bracket and four bolts into the frame and console.
3. Thread the four locknuts onto the bolts by hand.
4. Tighten the four bolts and locknuts with a 7/32” Allen wrench and a 9/16” open-end wrench.
5. Plug the upper display cable into the lower display cable.

18
Cybex Owner’s Manual
Install coax cable (E3 View Monitor option)
1. Remove four screws securing back cover to the console using a Phillips screwdriver.
Screws (4)
Back
Cover
2. Route coax cable up through console support tube.
E3 View Monitor
Coax Connection
Coax
Cable
Console
Support
Tube
3. Install coax cable into the E3 View Monitor coax connector and tighten threaded connector.
4. Install four screws securing back cover to console using a Phillips screwdriver.

19
Cybex Owner’s Manual
Install accessory tray base
1. Place the accessory tray in position on the frame and route the iPod cable towards the back of
the unit. Do not pinch optional coax cable.
Coax Cable
(E3 View Monitor option)
Frame
Screws
(4)
iPod Cable
Accessory
Tray Base
2. Install the four screws using a stubby Phillips screwdriver.
Install accessory tray top
1. Place the accessory tray top in position on the accessory tray base and route the iPod cable
through the notch in the accessory tray. Place the iPod cable strain relief on the inside edge of
the notch in the accessory tray.
Screws (2)
iPod Cable
Strain Relief
Notch
Accessory
Tray Top
Accessory
Tray Base
2. Install the two screws using a stubby Phillips screwdriver.

20
Cybex Owner’s Manual
Install accessory tray bottom
Install the grommet to the frame.
Frame
Grommet
Install the accessory tray bottom to the accessory tray base with three screws using a Phillips
screwdriver.
Screws (2) Screw
Accessory
Tray Base
Accessory
Tray Bottom
