CYBEX FT-360S Instruction Manual

FT-360S Functional Trainer
Owner’s and Service Manual
Strength Systems
Part Number 9101-999-4 E
www.cybexinternational.com

FT-360S Functional Trainer
Owner’s and Service Manual
Strength Systems
Part Number 9101-999-4 E
Cybex®and the Cybex logo are registered trademarks of Cybex International, Inc.
DISCLAIMER: Cybex International, Inc., makes no representations or warranties regarding the contents of this manual. We reserve the right to
revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such
revisions or changes.
© Copyright 2008, Cybex International, Inc. All rights reserved.
Printed in the United States of America.
10 Trotter Drive Medway, MA 02053 • 508-533-4300 • FAX [phone]
www.cybexinternational.com • [email protected] • 9101-999-4 E • June 2008

iTable of Contents
1 Safety
Safety ......................... 1-1
Warning/Caution Decals .......... 1-2
Regular Maintenance Activities..... 1-6
Using Proper Form .............. 1-6
2 Technical Specifications
General Specifications ............ 2-1
Machine Specifications ........... 2-4
3 General Exercise Guidelines
Training Suggestions ............. 3-1
Glossary ....................... 3-2
Exercise Charts
4 Exercises
FT-360S Overview................ 4-2
Adjustment and Safety ........... 4-2
Weight Stack and Effective
Resistance ..................... 4-2
Exercise Opportunities............ 4-3
Lateral Step .................... 4-4
Overhead Squat ................. 4-4
Single Leg Squat ................ 4-5
Split Squat Press ................ 4-5
Hip Extension ................... 4-6
Hip Flexion ..................... 4-6
Lunge Adduction ................ 4-7
Shoulder Adduction .............. 4-8
Chest Press .................... 4-9
Standing Chest Press ............ 4-9
Back and Shoulder Extension...... 4-10
Shoulder Abduction .............. 4-10
Lat Pulldown ................... 4-11
Row .......................... 4-11
Standing Overhead Press ......... 4-12
Push Pull ...................... 4-12
Tricep Extension................. 4-13
Table of Contents
5 Customer Service
Contacting Service .............. 5-1
Ordering Parts .................. 5-1
RMA .......................... 5-2
Damaged Parts ................. 5-3
6 Assembly
FT-360S Diagram................. 6-1
Tools Required .................. 6-2
Unpacking ..................... 6-2
Installing Foot Pads .............. 6-4
Installing Snap Links ............. 6-5
Installing Weight Stack ........... 6-6
Final Assembly .................. 6-13
7 Maintenance
Daily Procedures ................ 7-2
Weekly Procedures .............. 7-4
Yearly Procedures ............... 7-6
Enviroment. . . . . . . . . . . .......... 7-6
Storage. . . . . . . . . . . . . . . . . . . . . . . 7-7
Weight Stack Cable Adjustment .... 7-7
8 Service
Parts Lists and Diagrams ......... 8-1

Cybex FT-360S Functional Trainer Owner’s Manual
Safety
Page 1-1
1 - Safety
Safety
Read the Owner’s Manual carefully before assembling, servicing or using the equipment.
It is the responsibility of the facility owner and/or owner of the equipment to instruct users on
proper operation of the equipment and review all labels.
WARNING: Serious injury could occur if these safety precautions are not observed:
User Safety Precautions
Obtain a medical exam prior to beginning an exercise program.•
Read all warnings and obtain proper instruction on use of the machine prior to using.•
Keep body and clothing free from and clear of all moving parts.•
Inspect machine prior to use.• DO NOT use if it appears damaged or inoperable.
DO NOT• attempt to fix a broken or jammed machine. Notify floor staff.
Use the machine only for the intended use.• DO NOT modify the machine.
Be sure that the weight pin is completely inserted. Use only the pin provided by the manufacturer.• If unsure seek assistance.
Never pin the weights in an elevated position.• DO NOT use the machine if found in this condition.
Seek assistance from floor staff.
Children must not be allowed near this machine. Teenage rs must be supervised.•
DO NOT• use if guards are missing or damaged.
DO NOT• use dumbbells or other incremental weights, except those provided by the manufacturer.
Inspect all cables and belts and connections prior to use.• DO NOT use if any components are worn,
frayed, or damaged.
DO NOT• remove this label. Replace if damaged.
Stop exercising if you feel faint, dizzy or experience pain at any time while exercising and consult• your physician.

Cybex FT-360S Functional Trainer Owner’s Manual
Safety
Page 1-2
Facility Safety Precautions
Read the Owner’s Manual carefully before assembling, servicing or using the equipment.•
Securely anchor each machine to the floor using the anchor holes provided in each machine.•
NOTE: Cybex is not responsible for the actual anchoring of equipment. Consult with a
professional contractor.
NOTE: Use fasteners having a minimum of 500 lbs. tensile capacity (3/8” grade 2 bolts
or better).
NOTE: If legs/frame does not contact surface, DO NOT pull down with anchors. Shim any
leg or frame not in contact with surface using flat washers.
Make sure that each machine is set up and operated on a solid level surface.• Do not install
equipment on an uneven surface.
Make sure that all users are properly trained on how to use the equipment.•
Make sure there is enough room for safe access and operation of the equipment.•
Perform regular maintenance checks on the equipment. Also pay close attention to all areas• most susceptible to wear, including (but not limited to) cables, pulleys, belts and grips.
Immediately replace worn or damaged components. If unable to immediately replace worn or• damaged components then remove from service until the repair is made.
Use only Cybex supplied components to maintain/repair the equipment.•
Keep a repair log of all maintenance activities.•
Inspect all cables and belts and connections prior to use.• DO NOT use if any components are worn,
frayed, or damaged.
NOTE: It is the sole responsibility of the user/owner or facility operator to ensure that regular
maintenance is performed.
Warning/Caution Decals
Warning decals indicate a potentially hazardous situation, which, if not avoided, could result in death
or serious injury.
Caution decals indicate a potentially hazardous situation, which, if not avoided, could result in minor
or moderate injury.
The warning and caution decals are shown on the following page. The diagrams following the decals
show where each decal is located.

Cybex FT-360S Functional Trainer Owner’s Manual
Safety
Page 1-3
4605-381-4 A
8500-311-4 A
Arm will drop when
knob is pulled.
Support arm while
adjusting arm position.
Be sure detent pin
is fully engaged
before use. Return
arm to storage position
when not in use.
Failure to do so could
result in personal injury.
WARNING
AB
C

Cybex FT-360S Functional Trainer Owner’s Manual
Safety
Page 1-4
Warning DecalA. ...................4605-381-4
Warning DecalB. ...................8500-311-4
DESCRIPTION PART NO.
B
A
B
(Both Sides)
(Both Sides)

Cybex FT-360S Functional Trainer Owner’s Manual
Safety
Page 1-5
C
Caution DecalC. ....................9100-348-4
DESCRIPTION PART NO.

Cybex FT-360S Functional Trainer Owner’s Manual
Safety
Page 1-6
Regular Maintenance Activities
Preventative maintenance activities must be performed to maintain normal operation of your equipment.
Keeping a log sheet of all maintenance actions will assist you in staying current with all preventative
maintenance activities. The preventative maintenance actions are described in detail in Chapter 5.
Briefly, they include:
Weekly
1. Inspect all nuts and bolts for looseness. Tighten as required.
2. Inspect all cables for damage or wear (see Chapter 7). Immediately discontinue use if a cable is
worn or damaged.
3. Check for worn handles, worn snap links, and worn warning labeling. Replace all worn parts
immediately.
4. Inspect for loose or worn grips. Replace all loose or worn grips immediately.
5. Inspect weight stacks for proper alignment and operation. Correct all improper alignment and
operation issues immediately.
6. Lubricate guide rods using automotive engine oil only.
Yearly
1. Replace all cables at least annually.
Using Proper Form
Before working out, read and understand the training suggestions listed in Chapter 3. See Chapter 4
for proper form during exercise.

Cybex FT-360S Functional Trainer Owner’s Manual
Technical
Specifications
Page 2-1
2 - Technical Specifications
General Specifications
Frame Finish
Shall be made of mechanical quality 11 gauge and 16 gauge steel purchased in mill run quantities• to assure the best consistency.
Prior to applying finish, each part shall be put through a multi-stage wash to remove all oils and to• chemically prepare the surface for maximum adhesion. After the wash, the frames shall be dried and
coated with an Electrostatically applied powdercoat finish that shall be applied in powder form and
then baked until cured.
The finish shall be textured and very hard, assuring a scratch and chip resistant finish.•
Weight Selection
Weights are to be selected by using a high quality selector pin that completely penetrates the weight• plate and locks in place to eliminate any chance of disengaging during use. The pin shall be attached
to the weightstack with a plastic lanyard in order that the pin stays with the appropriate machine.
Weight Stacks Configuration
All weight stacks shall have 4” x 18” x 1”, 20 pound weights.•
Weight Plates
Shall be made of solid cold-rolled steel with wrinkle black powder coat finish.•
Guide rod holes shall be machined to a tolerance of .006 inches.•
Low-friction bushings shall surround the guide rods for smooth gliding motion.•

Cybex FT-360S Functional Trainer Owner’s Manual
Technical
Specifications
Page 2-2
Pulleys
Shall use Dupont Corp. fiberglass-reinforced nylon 70G33 material, tensile strength rated at• 22,500 PSI with 6203ZZ double sealed bearings dynamic load rated at 1600 lbs.
Pulleys shall be 4.50 inches in diameter with a cable groove with a depth of .250 inches.•
Swivel Pulley
Shall be molded from glass reinforced nylon, with a tensile breaking strength of at least 14,000 PSI.•
Weight Transport
Shall be lubricated, 7 x 19, 1/8” galvanized steel, nylon coated aircraft cable with breaking strength• rated at 2000 pounds.
All cable ends shall be finished off with a swaged fitting with a breaking strength equal to the• cable itself.
Weight Stack Guide Rods
Shall be solid ground and polished cold-drawn steel with minimum yield strength of 100,000 PSI• with a hard chrome plated piston steel finish with an overall minimum accuracy of .010.
Weight Stack Suspension
Shall have heavy-duty neoprene bumpers with an 80-durometer rating under the weight stacks• to reduce shock and vibration stresses to the frame and facility.
Frame Construction
Primarily 1 1/2 x 2” tubing with 11 gauge wall thickness, but different tubing sizes and wall thickness• shall be used as required through engineering stress analysis.
Shielding shall be 16 gauge wall thickness sheet metal.•
Fully welded frames for maximum structural integrity and minimum maintenance.•
All machining and welding will be done utilizing jigs and fixtures to insure highest quality and• interchangabiliity of parts.
Pivot Adjustment
Shall be cast from 1020 steel and black powder coated.•
Clevis
Shall be cast from 1020 steel and black powder coated.•

Cybex FT-360S Functional Trainer Owner’s Manual
Technical
Specifications
Page 2-3
Adjustment Plate
Shall be laser and plasma cut hot-rolled steel and nickel chromium electroplated.•
Hardware
All 3/8” socket head cap screws shall be of grade 8 (or equivalent). All bolts shall be either chromed• or zinc plated for additional corrosion resistance.
Adjustment Decals
High contrast Lexan decals shall be used for adjustment arms and weight stack to ensure maximum• readability.
Instructional Placard
Shall provide step-by-step instructions and a picture to illustrate use.•
Placard shall indicate proper positioning, and clearly describe the correct use of machines.•
Counter Balancing
Rotational counter balancing shall be accomplished by the use of a class 2 extension spring.•
Reach counterbalancing shall be accomplished by the use of a 13.35 inch, cylinder dampner.•
Front panel shall be made of clear frosted shatter resistant PETG material.•

Cybex FT-360S Functional Trainer Owner’s Manual
Technical
Specifications
Page 2-4
Machine Specifications
FT-360 S - Product No. 9101
Total Weight
(includes weight stack)
787 lbs.
358 kg
Weight Stack
300 lbs.
136 kg
Size
inches - 113 W x 54 L x 90 H (maximum in use)
cm - 287 cm W x 137 cm L x 229 cm H
NOTE: A minimum of three feet clearance is required around the machine during exercise.
113
54

Cybex FT-360S Functional Trainer Owner’s Manual
General Exercise
Guidelines
Page 3-1
3 - General Exercise Guidelines
Training Suggestions
Before you workout
Prior to starting a training program, get a complete physical exam to make sure your physician agrees
that you are ready. Always warm-up your muscles before a workout. A 5-10 minute cardio warm-up
followed by slow stretching (no bouncing) is recommended. Continue with a lighter set (50% of normal of
intended exercises. Proper breathing is very important. Exhale during muscle exertion, and inhale while
returning to the start position. Start your program conservatively. Choose weights you can easily lift in the
first weeks. Always perform the full range of motion-unless you have an injury, then consult a professional
trainer. Your Cybex dealer can help you find one. Know the terms? A “repetition” (rep) is defined as one
complete movement through an exercise, returning to the start position. A “set” is a continuous series of
reps. usually between 6-15.
During your workout
The number of reps. you perform in a set depends on your goal. To build muscle and strength, do fewer
reps. (6-8) with heavier weight. To firm your muscles and build endurance, do more reps. (12-15) with
lighter weight. Never “cheat” by shortening the range of motion, bouncing the weight, or shifting your
posture. This may allow you to lift more weight, but it is dangerous and less effective. Catch your breath
between sets, then continue. When “circuit training” move briskly to the next exercise; when doing
multiple sets on one exercise, rest 45-90 seconds before the next set. Work up to three sets per exercise.
When you can perform the desired reps and sets for any exercise, increase the weight by a half or full
plate. Circuit training is a good way to start. This involves doing one set per exercise, then moving to the
next exercise, pausing only briefly between them (to keep your heart and breath rate up) until completing
a balanced “circuit” of 8-10 exercises for your entire body. Then repeat the circuit. After several weeks,
you can move into multiple sets (3 in a row) per exercise if you choose. For both circuit and multiple set
training, exercise the complete body every other day, up to three times a week NOTE : A full day’s rest,
plus proper nutrition and hydration are required for optimum muscle-building or toning. Alternatively, work
out half your body one day (e.g., the upper body) and the other half the following day (e.g. the lower
body). To reduce muscle soreness, end each series of sets for a given muscle with a set of increased
reps and lighter weights. At the end of your workout, cool down in a similar way to your warm-up.

Cybex FT-360S Functional Trainer Owner’s Manual
General Exercise
Guidelines
Page 3-2
Glossary
Abduction - movement away from the mid-line of the body.
Acceleration - the rate at which an object’s velocity changes with time; that is the change of velocity
divided by the time interval.
Accuracy - freedom from error. Degree of conformity of a measure to a standard or a true value.
Action Line - the direction of pull created by the fibers or tendons of the muscle at the point of
application.
Active Insufficiency - a two joint muscle loses the ability to cross-bridge (generate force) due to full
shortening over its greatest anatomical length and tension created in an opposing muscle (antagonist).
Active Range of Motion - the degree of motion that occurs between two adjacent segments through
voluntary contraction of the agonist.
Active Stabilization - provided by an internal force. Static stabilization is provided through an isometric
contraction where dynamic stabilization is a series of motions. Dynamic stabilizers maintain the relative
positions of the segments, preventing undesirable or unnecessary motions due to external forces as well
as artifacts of internal forces. May also refer to the concentric/eccentric contractions of a muscle acting in
a force couple to produce motion while maintaining a relatively fixed axis of rotation.
Adipose tissue - fat tissue.
Adduction - movement towards the mid-line of the body.
Agonist - (prime mover) the muscle most involved in producing a movement.
Aerobic - utilizing oxygen.
Aerobic endurance - the ability to persist in physical activities that rely heavily upon oxygen for energy
production.
Anabolic - pertaining to the synthesis of complex substances from simpler substances, especially to the
synthesis of body proteins from amino acids.
Anaerobic - without oxygen.
Anaerobic Endurance - the ability to persist in physical activities of short duration that require high
rates of energy expenditure. These high rates of energy expenditure cannot be met solely by aerobic
metabolism.

Cybex FT-360S Functional Trainer Owner’s Manual
General Exercise
Guidelines
Page 3-3
Anthropometrics - measurements and relationships of length and girth of body parts.
Antagonist - the muscle in opposition to the agonist.
Anatomical Position - standing erect, with feet and palms facing forward.
Anatomical Pulley - a bone or skeletal prominence that alters the direction of the pull of a muscle to
increase the muscle’s mechanical advantage.
Anatomy - geography, naming by orientation and/or apparent capability (non-functional).
Anchor Points - the points at which a load enters and exits the body and/or limb.
Anterior - anatomical term meaning towards the front. Same as ventral.
Assistant Mover - a muscle that is less effective at performing a specified motion, but does have
a small degree of mechanical ability to help the prime mover. There are many borderline cases.
Atrophy - reduction in size of cells and tissues.
Axis of Rotation - imaginary line or point which an object rotates.
Bilateral - refers to both sides.
Biolocomotion - a perspective/description of the human body and its mechanics based upon
locomotion. All animals with legs (regardless of numbers) move with the same mechanics. Gravity is
the common denominator.
Biomechanics - analysis of the load placed on a joint by both the muscle and resistance. Anatomy,
Kinesiology, and Physics = Engineering.
Body composition - the component parts of the body - mainly fat and fat-free weight.
Calorie - a unit of work or energy equal to the amount of heat required to raise the temperature of
1 g of water to 1 degree C.
Cam - a mechanical device used to vary leverage.
Carbohydrate - a chemical compound consisting of carbon, hydrogen and oxygen atoms in specified
arrangements. Carbohydrates are major components of food such as bread, potatoes and rice.
Cardiovascular - pertaining to the heart and blood vessels.
Cartilage - there are several types. Hyaline cartilage is a relatively thin covering on the ends of many
bones. It forms a smooth, resilient, low friction surface for the movement of one bone on another.
Wedges of cartilage (fibrocartilage) called menisci, disks and labrums are to increase stability,
provide shock absorption, and to facilitate motion in some joints.

Cybex FT-360S Functional Trainer Owner’s Manual
General Exercise
Guidelines
Page 3-4
Center of Gravity - the center of a body’s mass. In the human body, it is the point which all parts are
in balance with one another. The COG may be within the body, altered by the position of the body even
to the point of being outside the body (pike position), or altered by the addiction of load to specific body
areas.
Circumduction - a circular movement permitted at ball and socket, condylar and saddle joints.Consists
of flexion, abduction, extension and adduction in sequence.
Circuit Training - a conditioning program consisting of a number of exercises performed at “stations”.
Usually, a given exercise is performed at a station within a specified time; then the athlete moves to the
next station, with its own particular exercise and specified time, then to the next station, and so on.
Closed Chain Kinetic Exercise - a series of rigid links interconnected by a series of pincentered joints.
These are constructed so that motion at one joint will produce motion at all the joints in the system.
Produces greater mechanical efficiency at the risk of increased joint loading. Leg press, bench press.
Close-Packed Position - all synovial joints have a position where joint surfaces are maximally congruent
and the ligaments and capsule are maximally taut.
Collagen - a fibrous protein that serves as the major component of ligaments and tendons.
Compression - two forces acting along the same line towards each other that constitute a compressive
load or compressive stress.
Concentric Action - contraction of a muscle resulting in shortening of the muscle.
Connective Tissue - comprised of mostly the proteins collagen and elastin with water; includes tendons,
ligaments, bursae, cartilage, disks, menisci, fascia and bone.
Cross-bridge - the connection and intertwining of the actin and myosin filaments in a myofibril relative to
a muscular contraction.
Curvilinear Motion - the frequently occurring combination of rotatory and translatory motions.
Distraction - two forces acting along the same line and in opposite directions, they constitute a
distractive, tensile load or tensile stress.
Diathrodial Joint - ball and socket joint.
Distal - furthest from the attached end of the limb; away from the body.
Dorsal - pertaining to the back; opposite of ventral, palmar or plantar.
Dorsiflexioni - movement of the foot up in the sagittal plane; movement toward the leg.
Eccentric - muscle action in which tension is developed in the muscle while it is lengthening.
Negative work is performed.
