CY7B9910
CY7B9920
Low Skew Clock Buffer
Cypress Semiconductor Corporation • 198 Champion Court • San Jose,CA 95134-1709 • 408-943-2600
Document Number: 38-07135 Rev. *B Revised August 07, 2007
Features
■All outputs skew <100 ps typical (250 max.)
■15 to 80 MHz output operation
■Zero input to output delay
■50% duty cycle outputs
■Outputs drive 50Ωterminated lines
■Low operating current
■24-pin SOIC package
■Jitter:<200 ps peak to peak, <25 ps RMS
Functional Description
The CY7B9910 and CY7B9920 Low Skew Clock Buffers offer
low skew system clock distribution. These multiple output clock
drivers optimize the timing of high performance computer
systems.Eachoftheeightindividualdriverscandriveterminated
transmission lines with impedances as low as 50Ω. They deliver
minimal and specified output skews and full swing logic levels
(CY7B9910 TTL or CY7B9920 CMOS).
The completely integrated PLL enables “zero delay” capability.
External divide capability, combined with the internal PLL, allows
distribution of a low frequency clock that is multiplied by virtually
any factor at the clock destination. This facility minimizes clock
distribution difficulty while allowing maximum system clock
speed and flexibility.
Block Diagram Description
Phase Frequency Detector and Filter
The Phase Frequency Detector and Filter blocks accept inputs
from the reference frequency (REF) input and the feedback (FB)
input and generate correction information to control the
frequency of the Voltage Controlled Oscillator (VCO). These
blocks, along with the VCO, form a Phase Locked Loop (PLL)
that tracks the incoming REF signal.
VCO
The VCO accepts analog control inputs from the PLL filter block
and generates a frequency. The operational range of the VCO is
determined by the FS control pin.
TEST
FB
REF
VOLTAGE
CONTROLLED
OSCILLATOR
FS Q0
FILTER
PHASE
FREQ
DET
Q1
Q2
Q3
Q4
Q5
Q6
Q7
Logic Block Diagram
[+] Feedback[+] Feedback

CY7B9910
CY7B9920
Document Number: 38-07135 Rev. *B Page 2 of 11
Pin Configuration
Test Mode
The TEST input is a three level input. In normal system operation, this pin is connected to ground, allowing the CY7B9910 and
CY7B9920 to operate as described in Block Diagram Description. For testing purposes, any of the three level inputs can have a
removable jumper to ground or be tied LOW through a 100W resistor. This enables an external tester to change the state of these pins.
If the TEST input is forced to its MID or HIGH state, the device operates with its internal phase locked loop disconnected and input
levels supplied to REF directly control all outputs. Relative output-to-output functions are the same as in normal mode.
Pin Definitions
Signal Name IO Description
REF IReferencefrequencyinput.Thisinputsuppliesthefrequencyandtiming againstwhichallfunctional
variations are measured.
FB IPLL feedback input (typically connected to one of the eight outputs).
FS[1,2,3] IThree level frequency range select.
TEST IThree level select. See TEST MODE.
Q[0..7] OClock outputs.
VCCN PWR Power supply for output drivers.
VCCQ PWR Power supply for internal circuitry.
GND PWR Ground.
Q4
Q2
REF
VCCQ
FS
NC
VCCQ
VCCN
Q0
Q1
GND
Q3
VCCN
GND
TEST
NC
GND
VCCN
Q7
Q6
GND
Q5
VCCN
FB
SOIC
Top View
1
2
3
4
5
6
7
8
9
10
11
12
15
16
17
18
19
20
24
23
22
21
13
14
7B9910
7B9920
Notes
1. For all three state inputs, HIGH indicates a connection to VCC, LOW indicates a connection to GND, and MID indicates an open connection. Internal termination
circuitry holds an unconnected input to VCC/2.
2. The level to be set on FS is determined by the “normal” operating frequency (fNOM) of the VCO (see Logic Block Diagram). The frequency appearing at the REF
and FB inputs are fNOM when the output connected to FB is undivided. The frequency of the REF and FB inputs are fNOM/X when the device is configured for a
frequency multiplication by using external division in the feedback path of value X.
3. When the FS pin is selected HIGH, the REF input must not transition upon power up until VCC reached 4.3V.
[+] Feedback[+] Feedback

CY7B9910
CY7B9920
Document Number: 38-07135 Rev. *B Page 3 of 11
Maximum Ratings
Operating outside these boundaries may affect the performance
and life of the device. These user guidelines are not tested.
Storage Temperature .................................–65°C to +150°C
Ambient Temperature with
Power Applied ............................................–55°C to +125°C
Supply Voltage to Ground Potential................–0.5V to +7.0V
DC Input Voltage ............................................–0.5V to +7.0V
Output Current into Outputs (LOW).............................64 mA
Static Discharge Voltage............................................>2001V
(MIL-STD-883, Method 3015)
Latch Up Current.....................................................>200 mA
Operating Range
Range Ambient Temperature VCC
Commercial 0°C to +70°C 5V ±10%
Industrial –40°C to +85°C 5V ±10%
[+] Feedback[+] Feedback

CY7B9910
CY7B9920
Document Number: 38-07135 Rev. *B Page 4 of 11
Electrical Characteristics Over the Operating Range
CY7B9910 CY7B9920
Parameter Description Test Conditions Min Max Min Max Unit
VOH Output HIGH Voltage VCC = Min, IOH = –16 mA 2.4 V
VCC = Min, IOH =–40 mA VCC–0.75
VOL Output LOW Voltage VCC = Min, IOL = 46 mA 0.45 V
VCC = Min, IOL = 46 mA 0.45
VIH Input HIGH Voltage
(REF and FB inputs only) 2.0 VCC VCC – 1.35 VCC V
VIL Input LOW Voltage
(REF and FB inputs only) –0.5 0.8 –0.5 1.35 V
VIHH Three Level Input HIGH
Voltage (Test, FS)[4] Min ≤VCC ≤Max VCC – 1V VCC VCC – 1V VCC V
VIMM Three Level Input MID
Voltage (Test, FS)[4] Min ≤VCC ≤Max VCC/2 – 500 mV VCC/2 + 500 mV VCC/2 – 500 mV VCC/2 + 500 mV V
VILL Three Level Input LOW
Voltage (Test, FS)[4] Min ≤VCC ≤Max 0.0 1.0 0.0 1.0 V
IIH Input HIGH Leakage Current
(REF and FB inputs only) VCC = Max, VIN = Max 10 10 μA
IIL Input LOW Leakage Current
(REF and FB inputs only) VCC = Max, VIN = 0.4V –500 –500 μA
IIHH Input HIGH Current
(Test, FS) VIN = VCC 200 200 μA
IIMM Input MID Current
(Test, FS) VIN = VCC/2 –50 50 –50 50 μA
IILL Input LOW Current
(Test, FS) VIN = GND –200 –200 μA
IOS Output Short Circuit
Current[5] VCC = Max, VOUT = GND (25°C only) –250 N/A mA
ICCQ Operating Current Used by
Internal Circuitry VCCN = VCCQ = Max All Input
Selects Open
Com’l 85 85 mA
Mil/Ind 90 90
ICCN Output Buffer Current per
Output Pair[6] VCCN = VCCQ = Max IOUT = 0 mA
Input Selects Open, fMAX
14 19 mA
PD Power Dissipation per
Output Pair[7] VCCN = VCCQ = Max IOUT = 0 mA
Input Selects Open, fMAX
78 104[5] mW
Notes
4. These inputs are normally wired to VCC, GND, or left unconnected (actual threshold voltages vary as a percentage of VCC). Internal termination resistors hold
unconnected inputs at VCC/2. If these inputs are switched, the function and timing of the outputs may glitch and the PLL may require an additional tLOCK time
before all data sheet limits are achieved.
5. Tested one output at a time, output shorted for less than one second, less than 10% duty cycle. Room temperature only. CY7B9920 outputs are not short circuit
protected.
6. Total output current per output pair is approximated by the following expression that includes device current plus load current:
CY7B9910:
ICCN = [(4 + 0.11F) + [((835 – 3F)/Z) + (.0022FC)]N] x 1.1
CY7B9920:
ICCN = [(3.5+.17F) + [((1160 – 2.8F)/Z) + (.0025FC)]N] x 1.1
Where
F = frequency in MHz
C = capacitive load in pF
Z = line impedance in ohms
N = number of loaded outputs; 0, 1, or 2
FC = F < C.
7. Totalpowerdissipationperoutputpairis approximatedbythefollowingexpression thatincludesdevice powerdissipationpluspowerdissipationduetotheloadcircuit:
CY7B9910:
PD = [(22 + 0.61F) + [((1550 – 2.7F)/Z) + (.0125FC)]N] x 1.1
CY7B9920:
PD = [(19.25+ 0.94F) + [((700 + 6F)/Z) + (.017FC)]N] x 1.1.See note 3 for variable definition.
[+] Feedback[+] Feedback

CY7B9910
CY7B9920
Document Number: 38-07135 Rev. *B Page 5 of 11
AC Test Loads and Waveforms
Capacitance
Tested initially and after any design or process changes that may affect these parameters.
Parameter Description Test Conditions Max Unit
CIN Input Capacitance TA= 25°C, f = 1 MHz, VCC = 5.0V 10 pF
7B9910–3 7B9910–4
TTL AC Test Load (CY7B9910) TTL Input Test Waveform (Cy7B9910)
5V
R1
R2
CL
R1
R2
CL
7B9910–5
CMOS AC Test Load (CY7B9920)
3.0V
2.0V
Vth =1.5V
0.8V
0.0V
≤1ns ≤1ns
2.0V
0.8V
Vth =1.5V
80%
Vth =V
CC/2
20%
0.0V
≤ 3ns ≤3ns
80%
20%
Vth =V
CC/2
7B9910–6
CMOS Input Test Waveform (CY7B9920)
VCC
R1=130
R2=91
CL=50pF(C
L= 30pF for –5 and – 2 devices)
(Includes fixture and probe capacitance)
R1=100
R2=100
CL=50pF(C
L=30 pF for –5 and – 2devices)
(Includes fixture and probe capacitance)
VCC
Switching Characteristics
Over the Operating Range [11]
CY7B9910–2[8] CY7B9920–2[8]
Parameter Description Min Typ Max Min Typ Max Unit
fNOM Operating Clock
Frequency in MHz FS = LOW[1, 2] 15 30 15 30 MHz
FS = MID[1, 2] 25 50 25 50
FS = HIGH[1, 2, 3] 40 80 40 80[12]
tRPWH REF Pulse Width HIGH 5.0 5.0 ns
tRPWL REF Pulse Width LOW 5.0 5.0 ns
tSKEW Zero Output Skew (All Outputs)[13, 14] 0.1 0.25 0.1 0.25 ns
tDEV Device-to-Device Skew[14, 15] 0.75 0.75 ns
tPD Propagation Delay, REF Rise to FB Rise –0.25 0.0 +0.25 –0.25 0.0 +0.25 ns
tODCV Output Duty Cycle Variation[16] –0.65 0.0 +0.65 –0.65 0.0 +0.65 ns
tORISE Output Rise Time[17, 18] 0.15 1.0 1.2 0.5 2.0 2.5 ns
tOFALL Output Fall Time[17, 18] 0.15 1.0 1.2 0.5 2.0 2.5 ns
tLOCK PLL Lock Time[19] 0.5 0.5 ms
tJR Cycle-to-Cycle Output Jitter Peak to Peak 200 200 ps
RMS 25 25 ps
[+] Feedback[+] Feedback

CY7B9910
CY7B9920
Document Number: 38-07135 Rev. *B Page 6 of 11
CY7B9910–5 CY7B9920–5
Parameter Description Min Typ Max Min Typ Max Unit
fNOM Operating Clock
Frequency in MHz FS = LOW[1, 2] 15 30 15 30 MHz
FS = MID[1, 2] 25 50 25 50
FS = HIGH[1, 2, 3] 40 80 40 80[12]
tRPWH REF Pulse Width HIGH 5.0 5.0 ns
tRPWL REF Pulse Width LOW 5.0 5.0 ns
tSKEW Zero Output Skew (All Outputs)[13, 14] 0.25 0.5 0.25 0.5 ns
tDEV Device-to-Device Skew[8,15] 1.0 1.0 ns
tPD Propagation Delay, REF Rise to FB Rise –0.5 0.0 +0.5 –0.5 0.0 +0.5 ns
tODCV Output Duty Cycle Variation[16] –1.0 0.0 +1.0 –1.0 0.0 +1.0 ns
tORISE Output Rise Time[17, 18 0.15 1.0 1.5 0.5 2.0 3.0 ns
tOFALL Output Fall Time[17, 18] 0.15 1.0 1.5 0.5 2.0 3.0 ns
tLOCK PLL Lock Time[19] 0.5 0.5 ms
tJR Cycle-to-Cycle Output Jitter Peak to Peak[8] 200 200 ps
RMS[8] 25 25 ps
Notes
8. Guaranteed by statistical correlation. Tested initially and after any design or process changes that may affect these parameters.
9. CMOS output buffer current and power dissipation specified at 50 MHz reference frequency.
10.Applies to REF and FB inputs only.
11. Test measurement levels for the CY7B9910 are TTL levels (1.5V to 1.5V). Test measurement levels for the CY7B9920 are CMOS levels (VCC/2 to VCC/2). Test
conditions assume signal transition times of 2ns or less and output loading as shown in the AC Test Loads and Waveforms unless otherwise specified.
12.Except as noted, all CY7B9920–2 and –5 timing parameters are specified to 80 MHz with a 30 pF load.
13.tSKEW is defined as the time between the earliest and the latest output transition among all outputs when all are loaded with 50 pF and terminated with 50Ωto
2.06V (CY7B9910) or VCC/2 (CY7B9920).
14.tSKEW is defined as the skew between outputs.
15.tDEV is the output-to-output skew between any two outputs on separate devices operating under the same conditions (VCC, ambient temperature, air flow, and
so on).
16.tODCV is the deviation of the output from a 50% duty cycle.
17.Specified with outputs loaded with 30 pF for the CY7B99X0–2 and –5 devices and 50 pF for the CY7B99X0–7 devices. Devices are terminated through 50Ωto
2.06V (CY7B9910) or VCC/2 (CY7B9920).
18.tORISE and tOFALL measured between 0.8V and 2.0V for the CY7B9910 or 0.8VCC and 0.2VCC for the CY7B9920.
19.tLOCK is the time that is required before synchronization is achieved. This specification is valid only after VCC is stable and within normal operating limits. This
parameter is measured from the application of a new signal or frequency at REF or FB until tPD is within specified limits.
[+] Feedback[+] Feedback

CY7B9910
CY7B9920
Document Number: 38-07135 Rev. *B Page 7 of 11
Switching Characteristics
Over the Operating Range[11] (continued)
CY7B9910–7 CY7B9920–7
Parameter Description Min Typ Max Min Typ Max Unit
fNOM Operating Clock
Frequency in MHz FS = LOW[1, 2] 15 30 15 30 MHz
FS = MID[1, 2] 25 50 25 50
FS = HIGH1, 2, 3] 40 80 40 80[12]
tRPWH REF Pulse Width HIGH 5.0 5.0 ns
tRPWL REF Pulse Width LOW 5.0 5.0 ns
tSKEW Zero Output Skew (All Outputs)[13, 14] 0.3 0.75 0.3 0.75 ns
tDEV Device-to-Device Skew[8, 15] 1.5 1.5 ns
tPD Propagation Delay, REF Rise to FB Rise –0.7 0.0 +0.7 –0.7 0.0 +0.7 ns
tODCV Output Duty Cycle Variation[16] –1.2 0.0 +1.2 –1.2 0.0 +1.2 ns
tORISE Output Rise Time[17, 18] 0.15 1.5 2.5 0.5 3.0 5.0 ns
tOFALL Output Fall Time17, 18] 0.15 1.5 2.5 0.5 3.0 5.0 ns
tLOCK PLL Lock Time[19] 0.5 0.5 ms
tJR Cycle-to-Cycle Output
Jitter Peak to Peak[8] 200 200 ps
tJR RMS[8] 25 25 ps
[+] Feedback[+] Feedback

CY7B9910
CY7B9920
Document Number: 38-07135 Rev. *B Page 8 of 11
AC Timing Diagrams
Figure 1. AC Timing Diagrams
Figure 2. Zero Skew and Zero Delay Clock Driver
tODCV
tODCV
tREF
REF
FB
Q
OTHER Q
tRPWH
tRPWL
tPD
tSKEW tSKEW tJR
SYSTEM
CLOCK
FB
REF
FS
Q0
Q1
Q2
Q3
Q4
Q5
Q6
Q7
TEST
Z0
LOAD
LOAD
LOAD
LOAD
REF
Z0
Z0
Z0
[+] Feedback[+] Feedback

CY7B9910
CY7B9920
Document Number: 38-07135 Rev. *B Page 9 of 11
Operational Mode Descriptions
Figure 2 shows the device configured as a zero skew clock
buffer. In this mode the 7B9910/9920 is used as the basis for a
lowskew clock distribution tree. The outputsarealigned andmay
each drive a terminated transmission line to an independent
load. The FB input is tied to any output and the operating
frequency range is selected with the FS pin. The low skew speci-
fication, coupled with the ability to drive terminated transmission
lines (with impedances as low as 50 ohms), enables efficient
printed circuit board design.
Figure 1 shows the CY7B9910/9920 connected in series to
construct a zero skew clock distribution tree between boards.
Cascaded clock buffers accumulates low frequency jitter
because of the non-ideal filtering characteristics of the PLL filter.
Do not connect more than two clock buffers in series.
Figure 3. Board-to-Board Clock Distribution
SYSTEM
CLOCK
Z
0
FB
REF
FS
TEST
REF
REF
FS
FB
LOAD
LOAD
LOAD
LOAD
LOAD
TEST
Z
0
Z
0
Z
0
Q0
Q1
Q2
Q3
Q4
Q5
Q6
Q7
Q0
Q1
Q2
Q3
Q4
Q5
Q6
Q7
[+] Feedback[+] Feedback

CY7B9910
CY7B9920
Document Number: 38-07135 Rev. *B Page 10 of 11
Ordering Information
Accuracy
(ps) Ordering Code Package Type Operating Range
250 CY7B9910–2SC 24-Pb Small Outline IC Commercial
CY7B9910–2SCT 24-Pb Small Outline IC - Tape and Reel Commercial
CY7B9920–2SC[20] 24-Pb Small Outline IC Commercial
500 CY7B9910–5SC 24-Pb Small Outline IC Commercial
CY7B9910–5SCT 24-Pb Small Outline IC - Tape and Reel Commercial
CY7B9910–5SI 24-Pb Small Outline IC Industrial
CY7B9910–5SIT 24-Pb Small Outline IC - Tape and Reel Industrial
CY7B9920–5SC 24-Pb Small Outline IC Commercial
CY7B9920–5SCT 24-Pb Small Outline IC - Tape and Reel Commercial
CY7B9920–5SI 24-Pb Small Outline IC Industrial
750 CY7B9910–7SC 24-Pb Small Outline IC Commercial
CY7B9910–7SI[20] 24-Pb Small Outline IC Industrial
CY7B9920–7SC[20] 24-Pb Small Outline IC Commercial
CY7B9920–7SI[20] 24-Pb Small Outline IC Industrial
Pb-Free
250 CY7B9910–2SXC 24-Pb Small Outline IC Commercial
CY7B9910–2SXCT 24-Pb Small Outline IC - Tape and Reel Commercial
500 CY7B9910–5SXC 24-Pb Small Outline IC Commercial
CY7B9910–5SXCT 24-Pb Small Outline IC - Tape and Reel Commercial
CY7B9910–5SXI 24-Pb Small Outline IC Industrial
CY7B9910–5SXIT 24-Pb Small Outline IC - Tape and Reel Industrial
750 CY7B9910–7SXC 24-Pb Small Outline IC Commercial
CY7B9910–7SXCT 24-Pb Small Outline IC - Tape and Reel Commercial
Package Diagram
Figure 4. 24-Pin (300 Mil) Molded SOIC S13
51-85025-*C
Note
20.Not recommended for new design.
[+] Feedback[+] Feedback

Document Number: 38-07135 Rev. *B Revised August 07, 2007 Page 11 of 11
PSoC Designer™, Programmable System-on-Chip™, and PSoC Express™ are trademarks and PSoC® is a registered trademark of Cypress Semiconductor Corp. All other trademarks or registered
trademarks referenced herein are property of the respective corporations. Purchase of I2C components from Cypress or one of its sublicensed Associated Companies conveys a license under the
Philips I2C Patent Rights to use these components in an I2C system, provided that the system conforms to the I2C Standard Specification as defined by Philips. All products and company names
mentioned in this document may be the trademarks of their respective holders.
CY7B9910
CY7B9920
© Cypress Semiconductor Corporation, 2001-2007.The information contained herein is subject to change without notice. Cypress Semiconductor Corporation assumes no responsibility for the use of
any circuitry other than circuitry embodied in a Cypress product. Nor does it convey or imply any license under patent or other rights. Cypress products are not warranted nor intended to be used for
medical, life support, life saving, critical control or safety applications, unless pursuant to an express written agreement with Cypress. Furthermore, Cypress does not authorize its products for use as
critical components in life-support systems where a malfunction or failure may reasonably be expected to result in significant injury to the user. The inclusion ofCypress productsin life-support systems
application implies that the manufacturer assumes all risk of such use and in doing so indemnifies Cypress against all charges.
Any Source Code (software and/or firmware) is owned by Cypress Semiconductor Corporation (Cypress) and is protected by and subject to worldwide patent protection (United States and foreign),
United States copyright laws and international treaty provisions. Cypress hereby grants to licensee a personal, non-exclusive, non-transferable license to copy, use, modify, create derivative works of,
and compile the Cypress Source Code and derivative works for the sole purpose of creating custom software and or firmware in support of licensee product to be used only inconjunction with a Cypress
integrated circuit as specified inthe applicable agreement.Any reproduction, modification, translation, compilation, or representation of this Source Code except as specified above is prohibited without
the express written permission of Cypress.
Disclaimer: CYPRESS MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARD TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Cypress reserves the right to make changes without further notice to the materials described herein. Cypress does not
assume any liability arising out of the application or use of any product or circuit described herein. Cypress does not authorize its products for use as critical components in life-support systems where
a malfunction or failure may reasonably be expected to result in significant injury to the user. The inclusion of Cypress’ product in a life-support systems application implies that the manufacturer
assumes all risk of such use and in doing so indemnifies Cypress against all charges.
Use may be limited by and subject to the applicable Cypress software license agreement.
Document History
Document Title: CY7B9910/CY7B9920 Low Skew Clock Buffer
Document Number: 38-07135
REV. ECN NO. Issue Date Orig. of
Change Description of Change
** 110244 10/28/01 SZV Change from Specification number: 38-00437 to 38-07135
*A 1199925 See ECN DPF/AESA Added Pb-free parts in Ordering Information
Added Note 20: Not recommended for the new design
*B 1353343 See ECN AESA Change status to final
[+] Feedback[+] Feedback
