1. Introduction
Thank you for your interest in the FM0+ S6E1C-Series Starter Kit. This kit enables customers to
evaluate and develop projects using the FM0+ device family. FM0+ is a portfolio of ultra-low
power ARM® Cortex®-M0+ MCUs. It is designed for low-power and cost-sensitive applications
such as white goods, sensors, meters, HMI systems, power tools and internet of things (IoT)
battery powered or energy harvesting wearable devices. There are several device series in this
portfolio: the S6E1A-Series, the S6E1B-Series and the S6E1C-Series. This kit uses a device
from the S6E1C-Series.
The S6E1C-Series microcontroller is based on the ARM® Cortex®-M0+ processor with on-chip
flash memory. This series has peripherals such as High Definition Multimedia
Interface-Consumer Electronics Control (HDMI-CEC), A/D converters, Descriptor System Data
Transfer Controller (DTSC) and communication interfaces like USB, UART, CSIO (SPI), I2C and
LIN. The FM0+S6E1C-Series Starter Kit offers footprint compatibility with Arduino™ shields,
which provides options for application development.
1.1 Kit Contents
The FM0+ S6E1C-Series Starter Kit contains the following, as shown in Figure 1-1.
FM0+ S6E1C-Series board
USB Standard-A to Micro-B cable
Quick Start Guide
Figure 1-1: Kit Contents
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Introduction
FM0+ S6E1C-Series Starter Kit Guide, Doc. # 002-10542 Rev. *D 5
Inspect the contents of the kit; if you find any part missing, contact your nearest Cypress sales
office for help: www.cypress.com/support.
1.2 Board Details
Figure 1-2: FM0+ S6E1C-Series Starter Kit Markup
1. Arduino Interface (CN7-CN10)
2. User button
3. MB9AF312K programmer and debugger (CMSIS-DAP)
4. Serial programming mode select (J3)
5. Power supply resource select (J4)
6. USB device connector (CN4)
7. Potentiometer
8. MB9AF312K programming mode jumper (J1)
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Introduction
FM0+ S6E1C-Series Starter Kit Guide, Doc. # 002-10542 Rev. *D 6
9. Headphone and microphone jack (CN1)
10. Reset button
11. Multicon connector (CN12, CN13)
12. Jumper for current measurement (J5)
13. 10-pin JTAG connector
14. Stereo codec
15. Programming mode jumper (J2)
16. Cypress FM0+ MCU S6E1C32D0A
17. RGB LED
18. NOR flash
19. 3.3 V voltage regulator
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Introduction
FM0+ S6E1C-Series Starter Kit Guide, Doc. # 002-10542 Rev. *D 7
1.3 Jumper and Connector
Table 1-1: Jumper Description
Jumper
Function
Setting
J1
Sets the programming mode pin (MD0) of
MB9AF312K (CMSIS-DAP)
Open: run mode
Closed: serial programming mode
J2
Sets the programming mode pin (MD0) of
S6E1C3
Open: run mode
Closed: serial programming mode
J3
Serial programming mode Select for
S6E1C3
Pin 2 to Pin 1: UART programming mode (not supported on this
kit)
Pin 2 to Pin 3: USB programming mode
J4
Power supply resource select
Pin 2 to Pin 1: power from CMSIS-DAP (CN3)
Pin 2 to Pin 3: power from USB port of S6E1C3 (CN4)
J5
Jumper for power measurement
Open jp11 and connect a multi-meter with the terminals of J5 to
measure the current that FM0+ MCU consumes.
Table 1-2: Connector Description
Connector
Description
CN1
Headphone and microphone jack
CN2
10-pin JTAG interface
CN3
USB port of CMSIS-DAP
CN4
USB port of FM0+ MCU
CN7,CN8,CN9,CN10
Arduino compatible headers
CN12,CN13
Multicon connector
1.4 Getting Started
This guide will help you get started with the FM0+S6E1C-Series Starter Kit:
The Installation and Test Operation chapter describes the installation of the kit installer,
and the test procedures for testing the board.
The Hardware chapter describes the major features of the FM0+ S6E1C-Series Starter
Kit and functionalities such as CMSIS-DAP debugger, Ethernet, USB, stereo codec,
memories and sensors.
The Software Development chapter describes how to open and run an example project
in the IAR Embedded Workbench or Keil µVision IDE; it also describes how to use the
example projects and how to program the devices using the USB DIRECT Programmer.
The Appendix provides the kit schematics, and the bill of materials (BOM).
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Introduction
FM0+ S6E1C-Series Starter Kit Guide, Doc. # 002-10542 Rev. *D 8
1.5 Additional Learning Resources
Cypress provides a wealth of data at www.cypress.com to help you to select the right MCU device
for your design, and to quickly and effectively integrate the device into your design.
Visit the FM0+ product page for links to multiple resources, such as:
Microcontroller Selector Guide
Getting Started information
Datasheets
FM0+ Peripheral Manuals
1.6 Technical Support
For assistance, visit Cypress Support or contact customer support at [phone] Ext. 2
(in the USA) or [phone] Ext. 2 (International).
1.7 Acronyms
Table 1-3. Acronyms Used in this Document
Acronym
Description
ADC
Analog-to-Digital Converter
CMSIS-DAP
Debug Access Port
DTSC
Descriptor System Data Transfer Controller
GPIO
General Purpose Input/output
HDMI-CEC
HighDefinition Multimedia Interface-Consumer Electronics Control
IDE
Integrated Development Environment
I2C
Inter-Integrated Circuit
I2S
Inter-IC Sound
JTAG
Joint Test Action Group
LDO
Low Drop Out (voltage regulator)
LED
Light-Emitting Diode
PDL
Peripheral Driver Library
PWM
Pulse Width Modulation
RGB
Red Green Blue
SWD
Serial Wire Debug
SPI
Serial Peripheral Interface
UART
Universal Asynchronous Receiver Transmitter
USB
Universal Serial Bus
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

FM0+ S6E1C-Series Starter Kit Guide, Doc. # 002-10542 Rev. *D 9
2. Installation and Test Operation
This chapter describes the steps to install the software tools and drivers on a PC for using the
FM0+ S6E1C-Series Starter Kit. After a successful installation, user can run the test code which
is pre-programmed in the device.
2.1 Install Software
Follow the steps below to install the FM0+ S6E1C-Series Starter Kit software:
1. Download the FM0+ S6E1C-Series Starter Kit installer from the webpage:
www.cypress.com/FM0-64L-S6E1C3.The Kit software is available for download in three
formats.
FM0+ S6E1C-Series Starter Kit Complete Setup: This installation package contains
the files related to the kit, including the Documentation, Hardware, Firmware, Software
tools and drivers. However, it does not include the Windows Installer or Microsoft .NET
framework packages. If these packages are not on your computer, the installer directs
you to download and install them from the Internet.
FM0+ S6E1C-Series Starter Kit Only Package: This executable file installs only the kit
contents, which include kit code examples, hardware files, and user documents. This
package can be used if all the software prerequisites (listed in step 5) are installed on
your PC.
FM0+ S6E1C-Series Starter Kit DVD ISO: This file is a complete package, stored in a
DVD-ROM image format, which you can use to create a DVD or extract using an ISO
extraction program such as WinZip® or WinRAR. The file can also be mounted like a
virtual CD/DVD using virtual drive programs such as Virtual CloneDrive and MagicISO.
This file includes all the required software, utilities, drivers, hardware files, and user
documents.
2. If you have downloaded the ISO file, mount it in a virtual drive. Extract the ISO contents if
you do not have a virtual drive to mount. Double-click cyautorun.exe in the root directory of
the extracted content or the mounted ISO if “Autorun from CD/DVD” is not enabled on the
PC. The installation window will appear automatically.
Note: If you are using the “Kit Complete Setup” and “Kit Only Package”, then go to step 4
for installation.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Installation and Test Operation
FM0+ S6E1C-Series Starter Kit Guide, Doc. # 002-10542 Rev. *D 10
3. Click Install FM0-64L-S6E1C3 to start the kit installation, shown as Figure 2-1.
Figure 2-1: Kit Installation Window
4. Select the folder in which you want to install this package or use the default folder.
5. When you click Next, the FM0+ S6E1C-Series Starter Kit installer automatically installs the
required software, if it is not present on your PC. Following are the required softwares and
drivers:
FM Universal Peripheral Driver Library (PDL)
Serial Port Viewer
FLASH USB DIRECT Programmer
FLASH MCU Programmer
CMSIS-DAP driver
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.
