72-Mbit (2M x 36/4M x 18/1M x 72)
Pipelined SRAM with NoBL™ Architecture
CY7C1470BV33
CY7C1472BV33, CY7C1474BV33
Cypress Semiconductor Corporation • 198 Champion Court • San Jose,CA 95134-1709 • 408-943-2600
Document #: 001-15031 Rev. *C Revised February 29, 2008
Features
■Pin-compatible and functionally equivalent to ZBT™
■Supports 250 MHz bus operations with zero wait states
❐Available speed grades are 250, 200, and 167 MHz
■Internally self-timed output buffer control to eliminate the need
to use asynchronous OE
■Fully registered (inputs and outputs) for pipelined operation
■Byte Write capability
■Single 3.3V power supply
■3.3V/2.5V IO power supply
■Fast clock-to-output time
❐3.0 ns (for 250-MHz device)
■Clock Enable (CEN) pin to suspend operation
■Synchronous self-timed writes
■CY7C1470BV33, CY7C1472BV33 available in
JEDEC-standard Pb-free 100-pin TQFP, Pb-free and
non-Pb-free 165-ball FBGA package. CY7C1474BV33
available in Pb-free and non-Pb-free 209-ball FBGA package
■IEEE 1149.1 JTAG Boundary Scan compatible
■Burst capability—linear or interleaved burst order
■“ZZ” Sleep Mode option and Stop Clock option
Functional Description
The CY7C1470BV33, CY7C1472BV33, and CY7C1474BV33
are 3.3V, 2M x 36/4M x 18/1M x 72 Synchronous pipelined burst
SRAMs with No Bus Latency™ (NoBL™) logic, respectively.
They are designed to support unlimited true back-to-back read
or write operations with no wait states. The CY7C1470BV33,
CY7C1472BV33, and CY7C1474BV33 are equipped with the
advanced (NoBL) logic required to enable consecutive read or
write operations with data beingtransferred on everyclock cycle.
This feature dramatically improves the throughput of data in
systems that require frequent read or write transitions. The
CY7C1470BV33, CY7C1472BV33, andCY7C1474BV33 arepin
compatible and functionally equivalent to ZBT devices.
All synchronous inputs pass through input registers controlled by
the rising edge of the clock. All data outputs pass through output
registers controlled by the rising edge of the clock. The clock
input is qualified by the Clock Enable (CEN) signal, which when
deasserted suspends operation and extends the previous clock
cycle.
Write operations are controlled by the Byte Write Selects
(BWa–BWdfor CY7C1470BV33, BWa–BWb for
CY7C1472BV33, and BWa–BWhfor CY7C1474BV33) and a
Write Enable (WE) input. All writes are conducted with on-chip
synchronous self-timed write circuitry.
Three synchronous Chip Enables (CE1, CE2, CE3) and an
asynchronous Output Enable (OE) provide for easy bank
selection and output tri-state control. To avoid bus contention,
the output drivers are synchronously tri-stated during the data
portion of a write sequence.
Selection Guide
Description 250 MHz 200 MHz 167 MHz Unit
Maximum Access Time 3.0 3.0 3.4 ns
Maximum Operating Current 500 500 450 mA
Maximum CMOS Standby Current 120 120 120 mA
