Cypress UNIVERSAL CAPSENSE CY3280-BMM User manual

CY3280-BMM UNIVERSAL CAPSENSE®MATRIX BUTTON MODULE KIT
QUICK START GUIDE
1. Insert the kit CD in the CD drive.
2. Install kit content, PSoC Designer, PSoC
Programmer, and Bridge Control Panel.
Note The hardware prerequisites for this kit are
the CY3280-20x34 Universal CapSense
Controller (UCC) board and MiniProg1
1. Connect the CY3280-BMM board to the
CY3280-20x34 UCC board’s P2 connector.
2. In the CY3280-20x34 board, place the
jumper on header J1 to short pins 2 and 3.
3. In the CY3280-BMM board, place the
jumper on header J2 to short pins 2 and 3.
1. Connect MiniProg1 to the CY3280-
20x34 UCC board’s ISSP connector (J1).
Connect it to your PC using a USB cable.
2. Open PSoC Programmer and click
File > File Load. Browse and load the
CY3280_20x34_PD_Project1.hex file.*
3. Click Connect; connect MiniProg1 to PC.
4. Click the Program button to program the
device.
5. Click the Toggle button to power the
board.
* Note These files are located at:
<Install directory> \Cypress\CY3280
BMM\<version>\Firmware
1. Touch one button at a time. The
corresponding row and column LED
lights up with each touch, indicating
the button you touched.
2. If you touch more than one button,
all the LEDs are turned off because
multi touch is not supported.
1 2
3 4

© 2009-2011 Cypress Semiconductor Corporation. All rights reserved. All trademarks or registered trademarks referenced herein are the
properties of their respective owners. DOC#: 001-51788 REV *B
www.cypress.com/go/CY3280-BMM
For the latest information about this kit visit
CY3280-BMM UNIVERSAL CAPSENSE®MATRIX BUTTON MODULE KIT
QUICK START GUIDE
CY3280-BMM Kit Details
Note For more details on code examples, refer to the Readme file.
