Important user information
CAUTION
The CAUTION! sign is used to call attention to instructions or conditions that
must be followed to avoid damage to the product or other equipment in order
to avoid personal injury. Be sure not to proceed until the instructions are
clearly understood and all stated conditions are met.
Note: The Note sign is used to indicate information important for trouble-free and optimal use
of the product.
WARNING
This is a Class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
All users must read this entire manual to fully understand the safe use of AD-900.
Recycling
This symbol indicates that the waste of electrical and electronic equipment must
not be disposed as unsorted municipal waste and must be collected separately.
Please contact an authorized representative of the manufacturer for information
concerning the decommissioning of equipment.
2 AD-900 Instructions 56314038 AD

1 Introduction
AD-900 is an A/D converter for connecting an external instrument to the UNICORN™
control system in an ÄKTAdesign system.
The module has one high resolution analogue input for monitoring e.g. pressure, UV
monitor signals or other signals available as voltage outputs.
AD-900 communicates with the UNICORN control system via UniNet 2.
A Mini-DIN signal cable to connect to the external device, and a UniNet cable are
supplied with the module.
AD-900 Instructions 56314038 AD 3

2 Installation
2.1 Unpacking
Unpack the module and check the items against the packing list. Inspect the items for
obvious damage which may have occurred during transportation.
CAUTION
Before connecting the AD-900 make sure the power is switched OFF
at the system pump or the complete system.
2.2 Installing AD-900
Step Action
1Connect the Mini-DIN cable connector to socket. Analog In at AD-900.
Note:
The length of the analog cable must not exceed 3 m.
2Remove the protection cover from the wires marked 1 and 2 at the other end
of the Mini-DIN cable.
3Connect wire 1 (brown) to the external device high output.
4 AD-900 Instructions 56314038 AD

Step Action
4Connect wire 2 (red) to the external device low output.
5Connect the module with two UniNet cables as a part of the UniNet 2 chain.
One UniNet cable is supplied with the module.
Note:
The power on-LED on AD-900 flashes for a few seconds when connecting the
UniNet cable. The light gets steady when the communication with UNICORN is
established.
6If more than one AD-900 module will be connected, set the ID switches as
follows:
1 2 1 2
Code 0 Code 1 Code 2 Code 3
1 2 1 2
NO
Code 0 shall be used if only one AD-900 is used.
UniNet 2 cables are used to interconnect the individual modules.
7Attach the module to the mounting slot on the ÄKTAdesign system.
Attach
to slot
Lock
Release
AD-900 Instructions 56314038 AD 5

3 Operation
3.1 On/Off
AD-900 is on when connected to a UniNet 2 connector in a running ÄKTAdesign system.
All interaction with the module is made through the UNICORN control system. A steady
light from the green power on-LED indicates that the communication is established.
6 AD-900 Instructions 56314038 AD

4 Maintenance
No regular maintenance is required.
AD-900 Instructions 56314038 AD 7

5 Troubleshooting
If the suggested actions do not correct the fault, call Cytiva.
Fault Action
No response from AD-900 in UNICORN Check that the cables and connectors
are properly connected.
Noisy signal 1. Remove the protection cover from
the unmarked wire (the thickest one).
2. Connect the wire to ground, or to the
low output (the same terminal as for
wire 2), on the external device.
Other faults Contact Cytiva.
8 AD-900 Instructions 56314038 AD

6 Reference information
6.1 Description
AD-900 is an A/D converter with one analogue input channel. The recommended input
voltage range is ±2 V DC.
The input channel is isolated from the UniNet 2 connection. The Mini-DIN connector has
the following pin configuration:
Pin Signal name
1 Input signal (high)
2 Signal ground (low)
3–6 Not connected
Note: The length of the analog cable must not exceed 3 m.
AD-900 contains no user replaceable items.
6.2 Technical specifications
Operating data
Voltage range ±2 V DC
Resolution 1 mV, 20 bit
Input impedance ≥ 1 MΩ
Accuracy Better than ±0.5% or ±0.05 mV
whichever is greater
Max. input voltage ±5 V
Power requirement 18–36 V DC through the UniNet 2
connection
Power consumption Max. 1.0 W
Physical data
Degree of protection IP 21
Material, box enclosure Aluminum
Dimensions,
H × W × D
incl. attachment
40 × 140 × 80 mm
45 × 175 × 85 mm
AD-900 Instructions 56314038 AD 9

Physical data
Weight 0.4 kg
Environment +4°C to +40°C
20% to 95% relative humidity 84 to 106
kPa (840 to 1060 mbar) atmospheric
pressure
6.3 Accessories and spare parts
Item Quantity per
pack
Code no.
AD-900 including
a UniNet cable 0.7 m,
a Mini-DIN cable 1.5 m 1 18-1148-62
Cable UniNet, 0.3 m 1 18-1109-73
Cable UniNet, 0.7 m 1 18-1109-74
Cable UniNet, 1.5 m 1 18-1117-75
Cable UniNet, 3.0 m 1 18-1109-75
Cable Mini-DIN, 1.5 m, 6-pole 1 18-1110-64
