D-Link DWC-1000 User manual

Wireless Controller
CLI Reference Guide
DWC-1000
Ver. 1.01
Building Networks for People
Business Wireless Solution

CLI Reference Guide
Wireless Controller
D-LinkCorporation
Copyright © 2011.
http://www.dlink.com

Wireless Controller CLI Reference Guide
1
CLI ReferenceGuide
DWC-1000
Wireless Controller
Version 1.01
Copyright © 2011
Copyright Notice
This publication, including all photographs, illustrations and software, is protected under
international copyright laws, with all rights reserved. Neither this manual, nor any of the
material contained herein, may be reproduced without written consent of the author.
Disclaimer
The information in this document is subject to change without notice. The manufacturer makes
no representations or warranties with respect to the cont ents hereof and specifically disclaim
any implied warranties of merchantability or fitness for any particular purpose. The
manufacturer reserves the right to revise this publication and to make changes from time to
time in the content hereof without obligation of the manufacturer to notify any person of such
revision or changes.
Limitationsof Liability
UNDER NO CIRCUMSTANCES SHALL D-LINK OR ITS SUPPLIERS BE LIABLE FOR
DAMAGES OF ANY CHARACTER (E.G. DAMAGES FOR LOSS OF PROFIT, SOFTWARE
RESTORATION, WORK STOPPAGE, LOSS OF SAVED DATA OR ANY OTHER
COMMERCIAL DAMAGES OR LOSSES) RESULTING FROM THE APPLICATION OR
IMPROPER USE OF THE D-LINK PRODUCT OR FAILURE OF THE PRODUCT, EVEN IF
D-LINK IS INFORMED OF THE POSSIBILITY OF SUCH DAMAGES. FURTHERMORE, D -
LINK WILL NOT BE LIABLE FOR THIRD-PARTY CLAIMS AGAINST CUSTOMER FOR
LOSSES OR DAMAGES. D-LINK WILL IN NO EVENT BE LIABLE FOR ANY DAMAGES
IN EXCESS OF THE AMOUNT D-LINK RECEIVED FROM THE END-USER FOR THE
PRODUCT.

Wireless Controller CLI Reference Guide
2
Table of Contents
Chapter 1. Introduction..........................................................................................................................................10
Chapter 2. Accessing the CLI.............................................................................................................................11
Chapter 3. Basic commands available on the CLI.......................................................................................12
3.1 CONTEXT SENSITIVE HELP........................................................................................12
3.2 AUTO-COMPLETION .......................................................................................................12
3.3 MOVEMENT KEYS............................................................................................................12
3.4 DELETION KEYS ...............................................................................................................12
3.5 ESCAPE SEQUENCES ...................................................................................................13
Chapter 4. Command Hierarchy in CLI ...........................................................................................................14
4.1 CLI commands can be divided into 3 categories:....................................................14
4.2 Configration commands are sub-divided into the following: ................................14
4.3 The wireless controller configuration is sub-divided into following:...................14
Chapter 5. Global commands used in CLI .....................................................................................................16
Chapter 6. Show commands used in CLI.......................................................................................................17
6.1 WLAN Management...........................................................................................................17
6.2 System....................................................................................................................................22
6.3 Net............................................................................................................................................22
6.4 VPN..........................................................................................................................................24
6.5 Security...................................................................................................................................25
6.6 RADIUS..................................................................................................................................26
6.7 Help..........................................................................................................................................26
Chapter 7. Configuration commands................................................................................................................27
7.1 License Activation commands........................................................................................27
7.2 Global configuration commands ....................................................................................27
7.3 System configuration commands ..................................................................................27
7.4 UTIL configuration commands ....................................................................................... 29
7.5 QoS configuration commands ........................................................................................29
7.6 NET configuration commands ........................................................................................31
7.7 VPN configuration commands........................................................................................34
7.8 Security configuration commands.................................................................................35
7.9 History configuration commands ...................................................................................37
Chapter 8. Configuration commands WLAN .................................................................................................38
8.1 wlan ap_management manual configure <macaddr>............................................39
8.2 wlan ap_management ap_database add <macaddr>............................................40
8.3 wlan ap_management ap_database edit <macaddr>............................................ 40
8.4 wlan ap_management ap_database delete <macaddr>.......................................41
8.5 wlan ap_management rf_management configure...................................................41

Wireless Controller CLI Reference Guide
3
8.6 wlan ap_management poll_list configure ...................................................................42
8.7 wlan ap_management poll_list delete_ip_address <ipaddr> ..............................42
8.8 wlan ap_management poll_list delete_vlan_list <id>.............................................42
8.9 wlan ap_management poll_list discovery configure ...............................................42
8.10 wlan ap_management oui_database add ..................................................................42
8.11 wlan ap_management oui_database edit <ouival>.................................................43
8.12 wlan ap_management oui_database delete <ouival>............................................43
8.13 wlan ap_profile add <profileid>......................................................................................43
8.14 wlan ap_profile edit <profileid> ......................................................................................43
8.15 wlan ap_profile delete <profileid> .................................................................................44
8.16 wlan ap_profile copy <sourceprofileid> <destprofileid> ........................................44
8.17 wlan ap_profile radio configure <profileid> <radio>................................................44
8.18 wlan ap_profile QoS configure <profileid> <radio>.................................................45
8.19 wlan network configure <networkid>............................................................................45
8.20 wlan client add <macaddr>..............................................................................................46
8.21 wlan client edit <macaddr>..............................................................................................46
8.22 wlan client delete <macaddr>.........................................................................................47
8.23 wlan global dist_tunnel configure..................................................................................47
8.24 wlan global snmp_trap configure...................................................................................47
8.25 wlan global configure.........................................................................................................47
8.26 wlan peer_controller configure.......................................................................................48
8.27 wlan peer_controller push_configuration <ipaddr> .................................................49
8.28 wlan wids_security ap configure....................................................................................49
8.29 wlan wids_security client configure ..............................................................................49
8.30 wlan wlan_global_setting ap_validation configure ..................................................50
8.31 wlan wlan_global_setting radius_server configure..................................................50
8.32 wlan wlan_global_setting country configure..............................................................51
8.33 wlan wlan_global_setting wireless_switch <enable> .............................................51
8.34 wlan wlan_global_setting wireless_switch <enable> .............................................51
Chapter 9. Configuration commands System................................................................................................52
9.1 system logging ipv4 configure........................................................................................52
9.2 system logging ipv4 configure........................................................................................53
9.3 system logging remote configure ..................................................................................53
9.4 system logging ipv6 configure........................................................................................55
9.5 system remote_management https configure...........................................................55
9.6 system remote_management telnet configure .........................................................56
9.7 system snmp trap configure <ltagent_ip> ..................................................................56
9.8 system snmp trap delete <ltagent_ip>.........................................................................57
9.9 system snmp users configure <ltuser>........................................................................57
9.10 system snmp sys configure.............................................................................................57
9.11 system snmp access add.................................................................................................57
9.12 system snmp access edit <ltrowid>..............................................................................58

Wireless Controller CLI Reference Guide
4
9.13 system snmp access delete <ltrowid>.........................................................................58
9.14 system switch_settings power_saving configure.....................................................58
9.15 system switch_settings jumbo_frame configure ......................................................59
9.16 system time configure .......................................................................................................59
9.17 system traffic_meter configure.......................................................................................59
9.18 system usb usb1 configure.............................................................................................. 60
9.19 system usb usb2 configure..............................................................................................60
9.20 system groups configure ..................................................................................................60
9.21 system group add ...............................................................................................................61
9.22 system group edit <ltrow_id>.......................................................................................... 61
9.23 system group delete <ltrow_id>.....................................................................................61
9.24 system users add................................................................................................................61
9.25 system users edit <ltrow_id> ..........................................................................................62
9.26 system users delete <ltrow_id> .....................................................................................62
9.27 system users password <ltuser> ...................................................................................62
9.28 system users idle_timeout <lttimeout>........................................................................62
9.29 system group groupaccesscontrol configure <ltgroup_id>...................................63
9.30 system group access_control_browser add..............................................................63
9.31 system group access_control_browser delete <ltrow_id>....................................63
9.32 system group access_control_ip add ..........................................................................64
9.33 system group access_control_ip delete <ltrow_id> ................................................64
Chapter 10. Configuration commands UTIL.....................................................................................................65
10.1 util system_check ping <ltip_address>........................................................................65
10.2 util system_check dns_lookup <ltdns>........................................................................65
10.3 util system_check traceroute <ltip_address>............................................................65
10.4 util system_check capturePackets start <ltinterface> ............................................65
10.5 util system_check capturePackets download <ltfileName> <ltipAddr>............65
10.6 util cat <ltfileName>............................................................................................................65
10.7 util md5sum <ltfileName> ................................................................................................66
10.8 util copy <ltfileName1> <ltfileName2> .........................................................................66
10.9 util usb_test <ltipAddr> <ltfileName> ...........................................................................66
Chapter 11. Configure commands QOS............................................................................................................67
11.1 qos lan status .......................................................................................................................67
11.2 qos lan trustmode cos enable <ltlanPort>..................................................................67
11.3 qos lan trustmode dscp enable <ltlanPort> ...............................................................68
11.4 qos lan cos-map configure <ltcosValue> <ltpriorityQueue> ................................68
11.5 qos lan dscp-map configure <ltdscpValue> <ltpriorityQueue> ...........................68
11.6 qos lan cos-to-dscp-remarking enable ........................................................................68
11.7 qos lan cos-to-dscp-remarking configure <ltcosValue> <ltdscpValue> ...........69
11.8 qos option bandwidth set <ltwanInterface> <ltupStreamBW>
<ltdownStreamBW> .........................................................................................................................69

Wireless Controller CLI Reference Guide
5
11.9 16 qos option bandwidth profile add <ltwanInterface> <ltbwProfileName>
<ltpriority> <ltmaxBW> <ltminBW>.............................................................................................69
11.10 qos option bandwidth profile del <ltbwProfileName> .............................................69
11.11 qos option traffic-selector add ip <ltipAddress> <ltservice> <ltbwProfile>......70
11.12 qos option traffic-selector add mac <ltmacAddress> <ltservice> <ltbwProfile>
70
11.13 qos option traffic-selector add port <ltlanPort> <ltservice> <ltbwProfile> .......70
11.14 qos option traffic-selector add vlan <ltvlanId> <ltservice> <ltbwProfile>.........70
11.15 qos option traffic-selector add dscp <ltdscpId> <ltservice> <ltbwProfile> ......70
11.16 qos option traffic-selector del <lttrafficSelectorId> ..................................................71
11.17 qos lan queue scheduling-algo set <ltsched-algo>.................................................71
Chapter 12. Configuration commands NET .....................................................................................................72
12.1 net ipv6_tunnel six_to_four configure..........................................................................72
12.2 net ddns Option1 configure .............................................................................................72
12.3 net ddns Option2 configure .............................................................................................72
12.4 net lan dhcp reserved_ip configure <ltmac_address>...........................................73
12.5 net lan dhcp reserved_ip delete <ltmac_address> .................................................73
12.6 net Option dhcpc configure..............................................................................................73
12.7 net dmz configure ...............................................................................................................73
12.8 net dmz dhcp reserved_ip configure <ltmac_address>.........................................74
12.9 net dmz dhcp reserved_ip delete <ltmac_address>...............................................74
12.10 net ethernet configure <ltinterface_name> ................................................................75
12.11 net lan ipv4 configure ........................................................................................................75
12.12 net lan ipv6 configure ........................................................................................................77
12.13 net lan ipv6 pool configure <ltipv6PoolStartAddr> ..................................................77
12.14 net lan ipv6 pool delete <ltipv6PoolStartAddr> ........................................................78
12.15 net intel_Amt server configure........................................................................................78
12.16 net intel_Amt_Reflector configure.................................................................................78
12.17 net ip_Aliasing server add................................................................................................79
12.18 net ip_Aliasing server edit <ltrow_id> ..........................................................................79
12.19 net ip_Aliasing server delete <ltrow_id> .....................................................................79
12.20 net mode configure.............................................................................................................80
12.21 net ipv6_tunnel isatap add............................................................................................... 80
12.22 net ipv6_tunnel isatap edit <ltrow_id> .........................................................................80
12.23 net ipv6_tunnel isatap delete <ltrow_id> ....................................................................81
12.24 net routing mode configure..............................................................................................81
12.25 net Option Option1 ipv4 configure ................................................................................81
12.26 net Option Option2 ipv4 configure ................................................................................87
12.27 net Option mode configure ..............................................................................................94
12.28 net Option port_setup configure ....................................................................................95
12.29 net Option configurable_port configure.......................................................................96
12.30 net Option Option1 ipv6 configure ................................................................................96
12.31 net Optionn Option2 ipv6 configure..............................................................................97

Wireless Controller CLI Reference Guide
6
12.32 net routing ospfv2 configure <ltinterface>..................................................................98
12.33 net routing ospfv3 configure <ltinterface> ..................................................................99
12.34 net port management configure <ltportName>.........................................................99
12.35 net Option pppoe configure...........................................................................................100
12.36 net routing protocol_binding add.................................................................................100
12.37 net routing protocol_binding edit <ltrow_id>............................................................101
12.38 net routing protocol_binding enable <ltrow_id> .....................................................101
12.39 net routing protocol_binding disable <ltrow_id>.....................................................102
12.40 net routing protocol_binding delete <ltrow_id>.......................................................103
12.41 net radvd configure...........................................................................................................103
12.42 net radvd pool add............................................................................................................104
12.43 net radvd pool edit <ltrow_id> ......................................................................................104
12.44 net radvd pool delete <ltrow_id> .................................................................................104
12.45 net routing dynamic configure ......................................................................................105
12.46 net routing static ipv4 configure <ltname> ...............................................................106
12.47 net routing static ipv6 configure <ltname> ...............................................................106
12.48 net routing static ipv4 delete <ltname>......................................................................107
12.49 net routing static ipv6 delete <ltname>......................................................................107
12.50 net tahi add-default-route <ltip_address>.................................................................107
12.51 net tahi add-route <ltip_address> <ltgw>.................................................................107
12.52 net tahi del-route <ltip_address> <ltgw>...................................................................108
12.53 net tahi ipv6-Alias-Add(LAN) <ltip6_address>........................................................108
12.54 net tahi ipv6-Alias-Del(LAN) <ltip6_address>.........................................................108
12.55 net tahi ipv6-Alias-Add(OPTION) <ltip6_address> ...............................................108
12.56 net tahi ipv6-Alias-Del(OPTION) <ltip6_address>.................................................108
12.57 net tahi reachable-time <lttime>..................................................................................108
12.58 net tahi ping6 <ltip> <ltsize>......................................................................................... 109
12.59 net tahi pmtu-route-add <ltipAdd> ..............................................................................109
12.60 net upnp configure............................................................................................................109
Chapter 13. Configuration commands VPN...................................................................................................110
13.1 vpn l2tp server configure................................................................................................110
13.2 vpn pptp client configure ................................................................................................110
13.3 vpn pptp client_action <ltaction>.................................................................................111
13.4 vpn pptp server configure ..............................................................................................111
13.5 vpn sslvpn portal-layouts add.......................................................................................111
13.6 vpn sslvpn portal-layouts edit <ltrow_id>..................................................................112
13.7 vpn sslvpn portal-layouts delete <ltrow_id>.............................................................112
13.8 vpn sslvpn portal-layouts set-default <ltrow_id> ....................................................113
13.9 vpn sslvpn portforwarding appconfig add.................................................................113
13.10 vpn sslvpn portforwarding appconfig delete <ltrow_id> ......................................113
13.11 vpn sslvpn portforwarding hostconfig add................................................................113
13.12 vpn sslvpn portforwarding hostconfig delete <ltrow_id> .....................................113

Wireless Controller CLI Reference Guide
7
13.13 vpn sslvpn resource add ................................................................................................114
13.14 vpn sslvpn resource configure add <ltresource_name> .....................................114
13.15 vpn sslvpn resource configure delete <ltrow_id> ..................................................114
13.16 vpn sslvpn resource delete <ltrow_id> ......................................................................114
13.17 vpn sslvpn policy add ......................................................................................................115
13.18 vpn sslvpn policy edit <ltrow_id>.................................................................................115
13.19 vpn sslvpn policy delete <ltrow_id> ............................................................................116
13.20 vpn sslvpn client................................................................................................................116
13.21 vpn sslvpn route add........................................................................................................116
13.22 vpn sslvpn route delete <ltrow_id> .............................................................................117
13.23 vpn sslvpn users domains add.....................................................................................117
13.24 vpn sslvpn users domains edit <ltrow_id> ............................................................... 117
13.25 vpn sslvpn users domains delete <ltrow_id> ..........................................................118
13.26 vpn sslvpn users groups add........................................................................................118
13.27 vpn sslvpn users groups edit <ltrow_id>...................................................................119
13.28 vpn sslvpn users groups delete <ltrow_id>.............................................................. 119
13.29 vpn sslvpn users users add...........................................................................................119
13.30 vpn sslvpn users users edit <ltrow_id> .....................................................................120
13.31 vpn sslvpn users users login_policies <ltrow_id>..................................................120
13.32 vpn sslvpn users users browser_policies <ltrow_id> ...........................................120
13.33 vpn sslvpn users users ip_policies configure <ltrow_id> ....................................121
13.34 vpn sslvpn users users ip_policies delete <ltrow_id> ..........................................121
13.35 vpn sslvpn users users delete <ltrow_id> ................................................................121
13.36 vpn ipsec policy configure <ltname>..........................................................................121
13.37 vpn ipsec policy enable <ltname>...............................................................................124
13.38 vpn ipsec policy disable <ltname> ..............................................................................124
13.39 vpn ipsec policy delete <ltname> ................................................................................124
13.40 vpn ipsec policy connect <ltname>.............................................................................125
13.41 vpn ipsec policy drop <ltname> ...................................................................................125
Chapter 14. Configuration commands Security ............................................................................................126
14.1 security advanced_network attack_checks configure..........................................126
14.2 security advanced_network igmp setup....................................................................126
14.3 security application_rules add......................................................................................126
14.4 security application_rules edit <ltrow_id>.................................................................127
14.5 security application_rules delete <ltrow_id>............................................................127
14.6 security firewall custom_service add .........................................................................127
14.7 security firewall custom_service edit <ltrow_id> ....................................................128
14.8 security firewall custom_service delete <ltrow_id> ...............................................128
14.9 security firewall ipv4 configure .....................................................................................128
14.10 security firewall ipv4 default_outbound_policy <ltdefault_outbound_policy>
130
14.11 security firewall ipv4 edit <ltrow_id>...........................................................................130
14.12 security firewall ipv4 enable <ltrow_id>.....................................................................131

Wireless Controller CLI Reference Guide
8
14.13 security firewall ipv4 disable <ltrow_id>....................................................................131
14.14 security firewall ipv4 delete <ltrow_id>......................................................................131
14.15 security firewall ipv4 move <ltrow_id> .......................................................................131
14.16 security firewall algs.........................................................................................................131
14.17 security firewall ipv6 edit <ltrow_id>...........................................................................132
14.18 security firewall ipv6 configure .....................................................................................133
14.19 security firewall ipv6 enable <ltrow_id>.....................................................................133
14.20 security firewall ipv6 disable <ltrow_id>....................................................................134
14.21 security firewall ipv6 delete <ltrow_id>......................................................................134
14.22 security firewall ipv6 move <ltrow_id> .......................................................................134
14.23 security firewall ipv6 default_outbound_policy <ltdefault_outbound_policy>
134
14.24 security ids configure.......................................................................................................134
14.25 security session_settings configure............................................................................134
14.26 security schedules add ...................................................................................................135
14.27 security schedules edit <ltrow_id> ..............................................................................136
14.28 security schedules delete <ltrow_id> .........................................................................136
14.29 security mac_filter configure .........................................................................................136
14.30 security mac_filter source add...................................................................................... 137
14.31 security mac_filter source edit <ltrow_id> ................................................................137
14.32 security mac_filter source delete <ltrow_id> ...........................................................137
14.33 security ip_or_mac_binding add..................................................................................137
14.34 security ip_or_mac_binding edit <ltrow_id> ............................................................ 138
14.35 security ip_or_mac_binding delete <ltrow_id> .......................................................138
14.36 security firewall vpn_passthrough configure ...........................................................138
14.37 security website_filter content_filtering configure..................................................139
14.38 security website_filter approved_urls add................................................................139
14.39 security website_filter approved_urls edit <ltrow_id>...........................................139
14.40 security website_filter approved_urls delete <ltrow_id>......................................139
14.41 security website_filter blocked_keywords add........................................................ 140
14.42 security website_filter blocked_keywords edit <ltrow_id> ..................................140
14.43 security website_filter blocked_keywords delete <ltrow_id> .............................140
14.44 security website_filter blocked_keywords enable <ltrow_id>............................140
14.45 security website_filter blocked_keywords disable <ltrow_id> ...........................140
Chapter 15. Configuration commands RADIUS............................................................................................141
15.1 radius configure <ltradius_server> .............................................................................141
15.2 radius delete <ltradius_server>....................................................................................141
Chapter 16. Configuration commands HISTORY.........................................................................................142
16.1 history <ltlimit>...................................................................................................................142
Chapter 17. Configuration commands License activate ............................................................................143
17.1 License list...........................................................................................................................143

Wireless Controller CLI Reference Guide
9
17.2 License activate <ltactivationKey>..............................................................................143

Wireless Controller CLI Reference Guide
10
Chapter 1. Introduction
This document describes the command line interface (CLI) for managing DWC-1000 (WLAN)
wireless contorller.
The CLI user requires advanced knowledge about the configuration of the system and should be
used only by those users who are familiar with CLI-based configuration.
Note that the following features in the DWC-1000 wireless controller cannot be
managed by the CLI: Firmware Upgrade
Configuration Backup / Restore
Certificate Generate / Upload
Power Savings mode configuration
System Dashboard / Resource Utilization
Please access the web browser based UI of the DWC-1000 controller for managing these
features.

Wireless Controller CLI Reference Guide
11
Chapter 2. Accessing the CLI
The CLI can be accessed by logging in with the same user credentials as used to
access the web browser based UI.
********************************************
Welcome to the DWC-1000 Command Line Interface
********************************************
D-Link DWC-1000>
Note: DWC-1000> is the CLI prompt.

Wireless Controller CLI Reference Guide
12
Chapter 3. Basic commands
available on the CLI
3.1 CONTEXT SENSITIVE HELP
[] - Display context sensitive help. This is either a list of possible command
completions with summaries, or the full syntax of the current command. A subsequent
repeat of this key, when a command has been resolved, will display a detailed
reference.
3.2 AUTO-COMPLETION
The following keys both perform auto-completion for the current command line. If the
command prefix is not unique a subsequent repeat of the key will display possible
completions.
[enter] - Auto-completes, syntax-checks then executes a command. If there is a syntax
error then offending part of the command line will be highlighted and explained.
[space] - Auto-completes, or if the command is already resolved, inserts a space.
3.3 MOVEMENT KEYS
[CTRL-A] - Move to the start of the line.
[CTRL-E] - Move to the end of the line.
[up] - Move to the previous command line held in history.
[down] - Move to the next command line held in history.
[left] - Move the insertion point left one character.
[right] - Move the insertion point right one character.
3.4 DELETION KEYS
[CTRL-C] - Delete the whole line.
[CTRL-D] - Delete the character to the right on the insertion point.
[CTRL-K] - Delete all the characters to the right of the insertion point.
[Backspace] - Delete the character to the left of the insertion point.

Wireless Controller CLI Reference Guide
13
3.5 ESCAPE SEQUENCES
!! - Substitute the last command line.
!N - Substitute the Nth command line (absolute as per 'history' command).
!-N - Substitute the command line entered N lines before (relative).

Wireless Controller CLI Reference Guide
14
Chapter 4. Command
Hierarchy in CLI
4.1 CLI commands can be divided into 3
categories:
Global commands
Show commands
Configuration commands
4.2 Configration commands are sub-divided
into the following:
WLAN
System
Utilities (UTIL)
QoS
Networking (net)
Virtual Private Area Network (VPN)
Security
History
RADUIS
License Activation
4.3 The wireless controller configuration is
sub-divided into following:
AP Management
AP profile configuration
Distributed Tunnel Configuration

Wireless Controller CLI Reference Guide
15
SNMP configration
Peer Controller configuration
WIDS configuration
AP Validation Configuration
Country Configuration
Wireless switch configuration

Wireless Controller CLI Reference Guide
16
Chapter 5. Global commands used in
CLI
.exit: Exit this session
.help: Display an overview of the CLI syntax
.top: Return to the default mode
.reboot: Reboot the system.
.history: Display the current session's command line history. Number of commands in
history list can be controlled by setting limit argument; by default it is unbounded.

Wireless Controller CLI Reference Guide
17
Chapter 6. Show commands used in
CLI
The show commands for all the above mentioned branches are outlined in this section.
6.1 WLAN Management
The command show wlan at theCLI prompt would give the description of all the show commands in the
branch wlan , which is as follows:
Sl No
Command Name
Purpose
1
show wlanap_management
Display the parameters relatedto ap
management
2
show wlanap_managementchannel_plan
Display the configuredchannelplan
parameters.
3
show wlanap_managementpower_plan
Display the configured power plan
parameters.
4
show wlanap_managementoui
LocalOUI Database Entries
5
show wlanap_managementdiscovery
Display APand peer sw itch discovery
parameters.
6
show wlanap_managementchannel_planstatus <ltradio>
Display the configuredchannelplan
parameters.
7
show wlanap_managementchannel_planhistory <ltradio>
Display the channelplan history.
8
show wlan ap_management channel_planproposed <ltradio>
Display the proposedchannel
adjustments.
9
show wlanap_managementpower_planstatus
Display the configured power plan
parameters.
10
show wlanap_managementpower_planproposed
Display the proposedpoweradjustments.
11
show wlanap_managementoui database
Display LocalOUI Database
12
show wlanap_management discovery status
Display Discovery parameters
13
show wlanap_management discovery ip_list
Display IP Poll discovery list.
14
show wlanap_management discovery vlan_list
Display VLANID discovery list.
15
show wlanap_managementoui status <ltouival>
Display LocalOUI Database for aouival
16
show wlanap_conf
Display APconfigurationandstatus
17
show wlanap_confcapability
Display APhardwarecapability.
18
show wlanap_confmacaddr
Display APconfigurationandstatus for
specific AP
19
show wlanap_confdatabase
Display APconfigurationandstatus.
20
show wlannetwork
Display networkconfigurationparameters.
21
show wlanap_confdownload
Display APcodedownloadconfiguration
and status.
22
show wlannetworkstatus
Display networkconfigurationparameters
23
show wlannetworknetworkid<ltid>
Display networkconfigurationparameters
for specific network
24
show wlanap_conffailure_status
Display APassociationandauthentication
failurestatus.
25
show wlanap_confimage_availability
Display WS storedAPimage information.
26
show wlanap_confprofile
Display APprofileparameters.
27
show wlanap_confprovisioning_status
Display APProvisioning parameteres.
28
show wlanap_confradio_status
Display Radio configuration.
29
show wlanap_confrf-scan_status
Display WS managed APs RF Scan data.
30
show wlanap_confstatus
Display WS managed APstatus

Wireless Controller CLI Reference Guide
18
parameters.
31
show wlanap_confcapability status
Display APhardwarecapability.
32
show wlanap_confcapability image_table
Display APimage capability table
33
show wlanap_confcapability hardware
<lthw_dwl8600|hw_dwl3600|hw_dwl6600> <ltradio>
Display APhardwarecapability for
specific hardware
34
show wlanap_confdatabasestatus
Display APconfigurationandstatus.
35
show wlanap_confdatabasemacaddr <ltmacaddr>
Display APconfigurationandstatus for
specific AP
36
show wlanap_confprofilestatus
Display APprofileparameters.
37
show wlanap_confprofileradio
Display APprofileradio parameters.
38
show wlanap_confprofileradiostatus <ltid><ltradio>
Display APprofileradio parameters.
39
show wlanap_confprofileradioauto_eligible <ltid><ltradio>
Display supportedandenabled channels
for APprofileradioparameters.
40
show wlanap_confprofileradiomcs_indices <ltid><ltradio>
Display supportedMCS indices for theAP
profileradio
41
show wlanap_confprofileradioqos <ltid><ltradio>
Display QoS parameters for theAP profile
radio.
42
show wlanap_confprofileradiorates <ltid><ltradio>
Display advertisedandsupportedrates for
APprofile
43
show wlanap_confprofileradiotspec <ltid><ltradio>
Display TSPEC parameters for theAP
profileradio
44
show wlanap_confprofileradiovap<ltid><ltradio>
Display APprofileVAPparameters.
45
show wlanap_confprofileprofileid<ltprofileid>
Display APprofileparameters for specific
profile
46
show wlan ap_confmacaddr dist_tunnel_statistics
<ltmacaddr>
Display L2 Distributed Tunnel statistics for
AP.
47
show wlan ap_confmacaddr dist_tunnel_status<ltmacaddr>
Display L2 Distributed Tunnel statusfor
AP.
48
show wlan ap_confmacaddr failure_status <ltmacaddr>
Display WS managed APfailurestatus
parameters.
49
show wlanap_confmacaddr provisioning_status <ltmacaddr>
Display APProvisioning status
parameters.
50
show wlan ap_confmacaddr radio_status <ltmacaddr>
Display WS managed APradiostatus
parameters.
51
show wlan ap_confmacaddr rf_scan_rogue_classification
<ltmacaddr>
Display the WIDS AProgueclassification
testresults.
52
show wlan ap_confmacaddr rf_scan_status <ltmacaddr>
Display RF ScanAP status parameters.
53
show wlan ap_confmacaddr rf_scan_triangulation
<ltmacaddr>
Display signal triangulation status.
54
show wlan ap_confmacaddr statistics <ltmacaddr>
Display WS managed APstatistics.
55
show wlan ap_confmacaddr status <ltmacaddr>
Display WS managed APstatus
parameters.
56
show wlan ap_confmacaddr tspec_statistics <ltmacaddr>
Display WS managed APTSPEC
statistics.
57
show wlan ap_confmacaddr tspec_status<ltmacaddr>
Display WS managed APTSPEC status.
58
show wlanclient
Display APassociatedclientconfiguration
and status.
59
show wlanknown_client
Display the wirelessKnownClient(s)
60
show wlanclientadhoc
Display AdHoc networkinformation.
61
show wlanclientdetected-client
Display detectedclients information
62
show wlanclientrrm
Display Radio ResourceMeasurement
(RRM) information.
63
show wlanclientsummary
Display associatedclientsummary
parameters.
64
show wlanclientadhoc status
Display WS detectedclients on an ad-hoc
network
65
show wlanclientrrmstatus
Show associatedclientRadioResource
Measurement status parameters.
66
show wlanclientstatus
Display associatedclientstatus
