D-Link DWC-2000 Instruction Manual

Wireless Controller
CLI Reference Guide
DWC-2000
Ver. 1.0
Business Wireless Solution
Building Networks for People

CLI Reference Guide
DWC-2000 Wireless Controller Version 1.0
D-Link.
Copyright © 2014
www.dlink.com

1
Contents
Contents..........................................................................................................................1
1.0 Introduction............................................................................................................6
2.0 Configuration commands under branch WLAN ...................................................35
2.1 wlan ap_management manual configure <macaddr> ......................................................35
2.2 wlan ap_management ap_database add <macaddr>......................................................36
2.3 wlan ap_management ap_database edit <macaddr> ......................................................36
2.4 wlan ap_management ap_database delete <macaddr>...................................................38
2.5 wlan ap_management rf_management configure............................................................38
2.6 wlan ap_management poll_list configure.........................................................................39
2.7 wlan ap_management poll_list delete_ip_address <ipaddr>............................................39
2.8 wlan ap_management poll_list delete_vlan_list <id> .......................................................39
2.9 wlan ap_management poll_list discovery configure.........................................................40
2.10 wlan ap_management oui_database add ......................................................................40
2.11 wlan ap_management oui_database delete <ouival> ....................................................40
2.12 wlan ap_profile add <profileid>......................................................................................40
2.13 wlan ap_profile edit <profileid> ......................................................................................41
2.14 wlan ap_profile delete <profileid> ..................................................................................41
2.15 wlan ap_profile copy <sourceprofileid> <destprofileid>..................................................41
2.16 wlan ap_profile radio configure <profileid> <radio>........................................................41
2.17 wlan ap_profile QoS configure <profileid> <radio> ........................................................42
2.18 wlan network configure <networkid>..............................................................................43
2.19 wlan network delete <networkId>...................................................................................46
2.20 wlan ap_profile ssid configure <profileid> <radio> .........................................................46
2.21 wlan ap_profile apply <profileid>....................................................................................46
2.22 wlan captivePortal ssid configure <ssid> .......................................................................46
2.23 wlan client add <macaddr>............................................................................................47
2.24 wlan client edit <macaddr>............................................................................................47
2.25 wlan client delete <macaddr>........................................................................................47
2.26 wlan peer_controller configure.......................................................................................48
2.27 wlan peer_controller push_configuration <ipaddr>.........................................................48
2.28 wlan wids_security ap configure....................................................................................49

2
2.29 wlan wids_security client configure................................................................................50
2.30 wlan wlan_global_setting ap_validation configure..........................................................51
2.31 wlan wlan_global_setting radius_server configure.........................................................51
2.32 wlan wlan_global_setting country configure...................................................................52
2.33 wlan wlan_global_setting wireless_switch <enable>......................................................52
3.0 Configuration commands under branch LICENSE.........................................52
3.1 license list........................................................................................................................52
3.2 license activate <activationKey>......................................................................................52
4.0 Configuration commands under branch SYSTEM .........................................52
4.1 system NT-Domain-Settings............................................................................................52
4.2 system RADIUS_Settings................................................................................................53
4.3 system LDAP_Settings....................................................................................................53
4.4 system POP3_Settings POP3_Server_Configuration......................................................54
4.5 system POP3_Settings POP3_Trusted_CA.....................................................................55
4.6 system logging ipv4 configure..........................................................................................55
4.7 system logging facility configure <facility> .......................................................................56
4.8 system logging remote configure.....................................................................................56
4.9 system logging ipv6 configure..........................................................................................60
4.10 system Radius-Settings.................................................................................................60
4.11 system remote_management https configure ................................................................62
4.12 system remote_management telnet configure ...............................................................62
4.13 system snmp trap configure <agent_ip>........................................................................63
4.14 system snmp trap delete <agent_ip>.............................................................................63
4.15 system snmp users configure <user>............................................................................63
4.16 system snmp sys configure............................................................................................64
4.17 system snmp access add ..............................................................................................64
4.18 system snmp access edit <rowid>.................................................................................65
4.19 system snmp access delete <rowid>.............................................................................66
4.20 system time configure....................................................................................................66
4.21 system traffic_meter configure.......................................................................................67
4.22 system usb usb1 configure............................................................................................67
4.23 system usb usb2 configure............................................................................................68
4.24 system group add..........................................................................................................68
4.25 system group edit <row_id>...........................................................................................69

3
4.26 system group delete <row_id>.......................................................................................69
4.27 system users add ..........................................................................................................69
4.28 system users edit <row_id>...........................................................................................70
4.29 system users delete <row_id>.......................................................................................70
4.30 system group groupaccesscontrol configure <group_id>...............................................70
4.31 system group access_control_browser add...................................................................71
4.32 system group access_control_browser delete <row_id>................................................71
4.33 system group access_control_ip add.............................................................................71
4.34 system group access_control_ip delete <row_id>..........................................................72
5.0 Configuration commands under branch UTIL ................................................72
5.1 util system_check ping <ip_address>..............................................................................72
5.2 util system_check dns_lookup <dns> ..............................................................................72
5.3 util system_check traceroute <ip_address>.....................................................................72
5.4 util system_check capturePackets start <interface> ........................................................72
5.5 util system_check capturePackets download <fileName> <ipAddr>.................................73
5.6 util schedule-reboot <enable_reboot>..............................................................................73
5.7 util usb_test <ipAddr> <fileName>...................................................................................73
5.8 util backup_configuration <fileName> <ipAddr>...............................................................73
5.9 util restore_configuration <IpAddr> <FileName>..............................................................73
5.10 util firmware_upgrade <IpAddr> <FileName> ................................................................73
6.0 Configuration commands under branch QOS ................................................73
6.1 qos lan status..................................................................................................................74
6.2 qos lan enable.................................................................................................................75
6.3 qos lan disable ................................................................................................................76
6.4 qos lan trustmode cos enable <lanPort>..........................................................................77
6.5 qos lan trustmode dscp enable <lanPort>........................................................................78
6.6 qos lan cos-map configure <cosValue> <priorityQueue>.................................................79
6.7 qos lan dscp-map configure <dscpValue> <priorityQueue>.............................................80
6.8 qos lan cos-to-dscp-remarking enable.............................................................................82
6.9 qos lan cos-to-dscp-remarking disable ............................................................................83
6.10 qos lan cos-to-dscp-remarking status............................................................................84
6.11 qos lan cos-to-dscp-remarking configure <cosValue> <dscpValue>..............................85
6.12 qos lan queue scheduling-algo set <sched-algo>..........................................................86
7.0 Configuration commands under branch NET ......................................................87

4
7.1 net bandwidth profile enable <enable>............................................................................87
7.2 net bandwidth profile add.................................................................................................87
7.3 net bandwidth profile edit <row_id> .................................................................................88
7.4 net bandwidth profile delete <row_id> .............................................................................88
7.5 net bandwidth traffic_selector add ...................................................................................89
7.6 net bandwidth traffic_selector edit <row_id>....................................................................89
7.7 net bandwidth traffic_selector delete <row_id>................................................................90
7.8 net lan dhcp reserved_ip configure <mac_address>........................................................90
7.9 net lan dhcp reserved_ip delete <mac_address>.............................................................90
7.10 net ethernet configure <interface_name> ......................................................................91
7.11 net lan ipv4 configure.....................................................................................................91
7.12 net lan default_route configure ......................................................................................94
7.13 net lan ipv6 configure.....................................................................................................94
7.14 net lan ipv6 pool configure <ipv6PoolStartAddr> ...........................................................95
7.15 net lan ipv6 pool delete <ipv6PoolStartAddr> ................................................................96
7.16 net mode configure........................................................................................................96
7.17 net port management configure <portName> ................................................................96
7.18 net radvd configure........................................................................................................97
7.19 net radvd pool add.........................................................................................................98
7.20 net radvd pool edit <row_id>..........................................................................................98
7.21 net radvd pool delete <row_id>......................................................................................99
7.22 net routing dynamic configure........................................................................................99
7.23 net routing static ipv4 configure <name> .....................................................................101
7.24 net routing static ipv6 configure <name> .....................................................................102
7.25 net routing static ipv4 delete <name>..........................................................................103
7.26 net routing static ipv6 delete <name>..........................................................................103
7.27 net captivePortal billing_profile add .............................................................................103
7.28 net captivePortal billing_profile edit <row_id>..............................................................105
7.29 net captivePortal billing_profile delete <row_id>..........................................................108
7.30 net port-vlan edit <portname>......................................................................................108
7.31 net vlan-membership edit <port>.................................................................................108
7.32 net multiVlan subnet edit <vlanID> ..............................................................................108
7.33 net vlan config add <vlan_id>......................................................................................110
7.34 net vlan config edit <vlan_Id>......................................................................................110

5
7.35 net vlan config delete <VlanId>....................................................................................111

6
1.0 Introduction
The command “show Radius-Settings ?”at the CLI prompt, gives a
description of all the show commands in the branch Radius-Settings , these
are as follows:
1
show
Radius-
Settings
Display radius configuration. A RADIUS server
maintains a database of user accounts used in
larger environments. If a RADIUS server already
exists, it can be used for authenticating users that
want to connect to the wireless network provided
by this device. When multiple RADIUS servers
are configured they are accessed in the same
order as in the table. If first RADIUS server is not
accessible, then system tries to contact the next
RADIUS server. Configured Radius Servers This
table displays the list of all configured RADIUS
servers. If the optional argument ServerIP is
specified, detailed configuration of the RADIUS
server is displayed. Server IP: IP address of
RADIUS authentication server Server Port:
RADIUS authentication server port to send the
RADIUS messages. Timeout: The time (in
seconds) the device waits for a response from the
RADIUS server Retries: The number of tries the
router will make to the RADIUS server before
giving up. Secret: RADIUS server secret. This
field is only displayed if the argument ServerIP is
specified.
The command “show wlan ?”at the CLI prompt, gives a description of all the
show commands in the branch wlan , these are as follows:
1
show wlan ap_management
Display the
parameters
related to ap
management.
2
show wlan ap_management channel_plan
Display the
configured
channel plan
parameters.
3
show wlan ap_management power_plan
Display the
configured power
plan parameters.
4
show wlan ap_management oui
Local OUI
Database Entries.

7
5
show wlan ap_management discovery
Display AP and
peer
controllerdiscovery
parameters.
6
show wlan ap_management channel_plan status <radio>
Display the
configured
channel plan
parameters.
7
show wlan ap_management channel_plan history <radio>
Display the
channel plan
history.
8
show wlan ap_management channel_plan
proposed <radio>
Display the
proposed channel
adjustments.
9
show wlan ap_management power_plan status
Display the
configured power
plan parameters.
10
show wlan ap_management power_plan proposed
Display the
proposed power
adjustments.
11
show wlan ap_management oui database
Display Local OUI
Database.
12
show wlan ap_management discovery status
Display Discovery
parameters.
13
show wlan ap_management discovery ip_list
Display IP Poll
discovery list.
14
show wlan ap_management discovery vlan_list
Display VLAN ID
discovery list.
15
show wlan ap_management oui status <ouival>
Display Local OUI
Database for a
ouival.
16
show wlan ap_conf
Display AP
configuration and
status.
17
show wlan ap_conf capability
Display AP
hardware
capability.
18
show wlan ap_conf macaddr
Display AP
configuration and
status for specific
AP.
19
show wlan ap_conf database
Display AP
configuration and
status.
20
show wlan network
Display network

8
configuration
parameters.
21
show wlan ap_conf download
Display AP code
download
configuration and
status.
22
show wlan network status
Display network
configuration
parameters.
23
show wlan network networkid <id>
Display network
configuration
parameters for
specific network.
24
show wlan ap_conf failure_status
Display AP
association and
authentication
failure status.
25
show wlan ap_conf image_availability
Display WS stored
AP image
information.
26
show wlan ap_conf profile
Display AP profile
parameters.
27
show wlan ap_conf provisioning_status
Display AP
Provisioning
parameteres.
28
show wlan ap_conf radio_status
Display Radio
configuration.
29
show wlan ap_conf rf-scan_status
Display WS
managed APs RF
Scan data.
30
show wlan ap_conf status
Display WS
managed AP
status parameters.
31
show wlan ap_conf capability status
Display AP
hardware
capability.
32
show wlan ap_conf capability image_table
Display AP image
capability table.
33
show wlan ap_conf capability
hardware<hw_dwl8600|hw_dwl3600|hw_dwl6600> <radio>
Display AP
hardware
capability for
specific hardware.
34
show wlan ap_conf database status
Display AP
configuration and
status.

9
35
show wlan ap_conf database macaddr <macaddr>
Display AP
configuration and
status for specific
AP.
36
show wlan ap_conf profile status
Display AP profile
parameters.
37
show wlan ap_conf profile radio
Display AP profile
radio parameters.
38
show wlan ap_conf profile radio status <id> <radio>
Display AP profile
radio parameters.
39
show wlan ap_conf profile radio auto_eligible <id> <radio>
Display supported
and enabled
channels for AP
profile radio
parameters.
40
show wlan ap_conf profile radio mcs_indices <id> <radio>
Display supported
MCS indices for
the AP profile
radio.
41
show wlan ap_conf profile radio qos <id> <radio>
Display QoS
parameters for the
AP profile radio.
42
show wlan ap_conf profile radio rates <id> <radio>
Display advertised
and supported
rates for AP
profile.
43
show wlan ap_conf profile radio tspec <id> <radio>
Display TSPEC
parameters for the
AP profile radio.
44
show wlan ap_conf profile radio vap <id> <radio>
Display AP profile
VAP parameters.
45
show wlan ap_conf profile profileid <profileid>
Display AP profile
parameters for
specific profile.
46
show wlan ap_conf macaddr
dist_tunnel_statistics <macaddr>
Display L2
Distributed Tunnel
statistics for AP.
47
show wlan ap_conf macaddr
dist_tunnel_status <macaddr>
Display L2
Distributed Tunnel
status for AP.
48
show wlan ap_conf macaddr failure_status <macaddr>
Display WS
managed AP
failure status
parameters.
49
show wlan ap_conf macaddr
Display AP

10
provisioning_status <macaddr>
Provisioning
status parameters.
50
show wlan ap_conf macaddr radio_status <macaddr>
Display WS
managed AP radio
status parameters.
51
show wlan ap_conf macaddr
rf_scan_rogue_classification<macaddr>
Display the WIDS
AP rogue
classification test
results.
52
show wlan ap_conf macaddr rf_scan_status <macaddr>
Display RF Scan
AP status
parameters.
53
show wlan ap_conf macaddr
rf_scan_triangulation <macaddr>
Display signal
triangulation
status.
54
show wlan ap_conf macaddr statistics <macaddr>
Display WS
managed AP
statistics.
55
show wlan ap_conf macaddr status <macaddr>
Display WS
managed AP
status parameters.
56
show wlan ap_conf macaddr tspec_statistics <macaddr>
Display WS
managed AP
TSPEC statistics.
57
show wlan ap_conf macaddr tspec_status <macaddr>
Display WS
managed AP
TSPEC status.
58
show wlan client
Display AP
associated client
configuration and
status.
59
show wlan known_client
Display the
wireless Known
Client(s).
60
show wlan client adhoc
Display Ad Hoc
network
information.
61
show wlan client detected-client
Display detected
client’s
information.
62
show wlan client rrm
Display Radio
Resource
Measurement
(RRM)
information.

11
63
show wlan client summary
Display associated
client summary
parameters.
64
show wlan client adhoc status
Display WS
detected clients
on an ad-hoc
network.
65
show wlan client rrm status
Show associated
client Radio
Resource
Measurement
status parameters.
66
show wlan client status
Display associated
client status
parameters.
67
show wlan client detected-client preauth-history
Display detected
client pre-auth
history status.
68
show wlan client detected-client roam-history
Display detected
client roam history
status.
69
show wlan client detected-client status
Display detected
client status
parameters.
70
show wlan client macaddr
Show associated
client MAC
address for
specific client.
71
show wlan client macaddr detected_client
Display associated
detected clients
information.
72
show wlan client macaddr adhoc <macaddr>
Display Ad Hoc
network
information.
73
show wlan client macaddr client-qos
Display associated
client QoS
information.
74
show wlan client macaddr client-qos radius <macaddr>
Display associated
client QoS
RADIUS
configuration.
75
show wlan client macaddr client-qos status <macaddr>
Display associated
client QoS status
parameters.
76
show wlan client macaddr detected_client preauth-
Display detected

12
history<macaddr>
client pre-auth
history status.
77
show wlan client macaddr detected_client roam-
history <macaddr>
Display detected
client roam history
status
78
show wlan client macaddr detected_client rogue-
classification<macaddr>
Display the WIDS
Client rogue
classification test
results.
79
show wlan client macaddr detected_client
status <macaddr>
Display detected
client status
parameters.
80
show wlan client macaddr detected_client
triangulation <macaddr>
Display detected
client signal
triangulation
status.
81
show wlan client macaddr dist-tunnel <macaddr>
Display associated
client L2
Distributed Tunnel
information.
82
show wlan client macaddr neighbor_ap <macaddr>
Display status
parameters of
neighbor AP seen
by client
83
show wlan client macaddr rrm <macaddr>
Display Radio
Resource
Measurement
(RRM)
information.
84
show wlan client macaddr statistics status <macaddr>
Display WS
managed AP
client statistics.
85
show wlan client macaddr statistics
Display WS
managed AP
client statistics.
86
show wlan client macaddr statistics association <macaddr>
Display client
association
statistics.
87
show wlan client macaddr statistics session <macaddr>
Display session
statistics.
88
show wlan client macaddr status <macaddr>
Display associated
client status
parameters.
89
show wlan client macaddr tspec_statistics <macaddr>
Display WS
managed AP

13
client TSPEC
statistics.
90
show wlan client macaddr tspec_status <macaddr>
Display associated
client TSPEC
status parameters.
91
show wlan peer_switch
Display status for
peer wireless
controllers and
configuration
push.
92
show wlan peer_switch configuration
Display status for
configuration
push.
93
show wlan peer_switch peer_controller
Display status for
peer wireless
controllers.
94
show wlan peer_switch peer_controller status
Display status for
peer wireless
controllers.
95
show wlan peer_switch peer_controller
configuration_status
Display
configuration for
peer controller
configuration push
groups.
96
show wlan peer_switch peer_controller configure_status
Display status for
peer controller
configuration
push.
97
show wlan peer_switch peer_controller ip
Display status for
peer wireless
controller for an
IP.
98
show wlan peer_switch peer_controller ap_status
Display status for
peer controller
managed APs.
99
show wlan peer_switch peer_controller ip status <ipaddr>
Display status for
peer controller .
100
show wlan peer_switch peer_controller ip
ap_status <ipaddr>
Display status for
peer
controllermanaged
APs.
101
show wlan peer_switch peer_controller ip
configure_status <ipaddr>
Display status for
peer controller
configuration
push.

14
102
show wlan peer_switch configuration receive_status
Display status for
configuration
received from a
peer controller.
103
show wlan peer_switch configuration request_status
Display status for
a peer controller
configuration push
request.
104
show wlan wids_security
Display the
wireless WIDS
security settings.
105
show wlan wids_security client
Display the WIDS
Client security
configuration.
106
show wlan wids_security ap
Display the WIDS
AP security
configuration.
107
show wlan wids_security de_authentication
Display the AP de-
authentication
attack status.
108
show wlan wids_security rogue_test_descriptions
Display the WIDS
AP rogue
classification test
descriptions.
109
show wlan multicast
Display the valid
multicast transmit
rates.
110
show wlan multicast txrate <radio>
Display the valid
multicast transmit
rates.
111
show wlan rates <radio>
Display the valid
rates.
112
show wlan ssid
Display client
network
association
information.
113
show wlan ssid status <ssid>
Display AP
associated client
configuration and
status.
114
show wlan ssid client_status
Display AP
associated client
configuration and
status.
115
show wlan switch
Display controller

15
status information.
116
show wlan switch ipaddr
Display controller
status information
for an IP address.
117
show wlan switch certificate_request_status
Display the
controller
certificate request
information.
118
show wlan switch client_status
Display controller
to associated
client status
parameters.
119
show wlan switch local
Display Local
wireless controller
status parameters.
120
show wlan switch local client_status
Display AP
associated client
configuration and
status.
121
show wlan switch local statistics
Display wireless
controller
Statistics.
122
show wlan switch local status
Display wireless
controller status
parameters
123
show wlan switch local tspec_statistics
Display wireless
controller TSPEC
statistics
124
show wlan switch local tspec_status
Display wireless
controller TSPEC
status parameters.
125
show wlan switch ipaddr client_status <ipaddr>
Display AP
associated client
configuration and
status.
126
show wlan switch ipaddr statistics <ipaddr>
Display wireless
controller
Statistics.
127
show wlan switch ipaddr status <ipaddr>
Display wireless
controller status
parameters.
128
show wlan switch ipaddr tspec_statistics <ipaddr>
Display wireless
controller TSPEC
statistics.
129
show wlan switch ipaddr tspec_status <ipaddr>
Display wireless

16
controller TSPEC
status parameters.
130
show wlan switch provision_status
Display the
controller
provisioning
information.
131
show wlan rrm
Display radio
resource
measurement
(RRM) controller
data.
132
show wlan rrm channel_load
Display channel
load information.
133
show wlan rrm neighbors
Display neighbor
information.
134
show wlan rrm neighbors status
Display neighbor
information.
135
show wlan rrm neighbors ap_status <macaddr>
Display RRM
information for a
managed AP.
136
show wlan rrm channel_load current_request
Show the current
channel load
request, if any.
137
show wlan rrm channel_load history_status
Display channel
load report history
information.
138
show wlan rrm channel_load history_detail
Display
information for
every known
report.
139
show wlan rrm channel_load request_data
Show data to use
for new channel
load requests.
140
show wlan device_location
Display all device
location
parameters.
141
show wlan device_location status
Display all device
location
parameters.
142
show wlan device_location ap
Display all AP
Triangulation
Location Table
parameteres.
143
show wlan device_location ap macaadr <macaddr>
Display all
Triangulation

17
Location Table
parameters for an
AP.
144
show wlan device_location ap triangulation
Display all
Triangulation
Location Table
parameters.
145
show wlan device_location ap triangulation status_all
Display
Triangulation
Location status
parameters for all
device entries in
the triangulation
table database.
146
show wlan device_location ap triangulation status_located
Display
Triangulation
Location status
parameters for
located device
entries in the
triangulation table
database.
147
show wlan device_location building
Display device
location building
parameters.
148
show wlan device_location building number <1-8>
Enter a valid
Building number.
149
show wlan device_location building status
Display device
location building
parameters.
150
show wlan device_location building floor_ap_status
Display device
location AP
parameters.
151
show wlan device_location building floor_status
Display device
location building
floor parameters.
152
show wlan device_location client
Display all
Triangulation
Location Table
parameters.
153
show wlan device_location client triangulation
Display all
Triangulation
Location Table
parameters.
154
show wlan device_location client triangulation status_all
Display

18
Triangulation
Location status
parameters for all
device entries in
the triangulation
table database.
155
show wlan device_location client triangulation
status_located
Display
Triangulation
Location status
parameters for
located device
entries in the
triangulation table
database.
156
show wlan device_location client macaadr <macaadr>
Display all
Triangulation
Location Table
parameters for
specific MAC
Address.
157
show wlan device_location floor_status
Display On-
demand location
search floor
status.
158
show wlan device_location global_status
Display On-
demand location
search global
status.
159
show wlan device_location floor_status building <building>
Building Number.
160
show wlan device_location floor_status
building_floor <building><floor>
Floor number to
search for the
device.
161
show wlan device_location floor_status all
Display On-
demand location
search floor
status.
The command “show LDAP-Settings ?”at the CLI prompt, gives a
description of all the show commands in the branch LDAP-Settings , these are
as follows:
1
show LDAP-Settings
Display LDAP configuration.
