D-Link DWR-720P User manual

Version 1.00 ǀ2018/07 1
WCDMA / 3G Fixed FLLA Phone
DWR-720/P
User Manual

2
Preface
D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify
any person or organization of such revisions or changes.
Trademarks
D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United
States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks
of their respective companies.
Copyright ⓒ2012 by D-Link Systems, Inc.
All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written permission
from D-Link Systems, Inc.
Download electronic copy from telkom.d-link.co.za

3
Table of Contents
Preface............................................................................. 2
Trademarks................................................................... 2
1. Your Phone Overview...................................................6
1.1.Package Contents....................................................6
1.2.System Requirements..............................................6
1.3.Safety and Maintenance...........................................7
1.3.1.Using the phone..............................................7
1.3.2.Using the battery.............................................8
1.3.3.Using the battery charger................................9
2. Hardware Overview.....................................................10
2.1.Appearance
2.1.1.Front..............................................................10
2.1.2.Back...............................................................11
2.1.3.Key Descriptions............................................12
2.1.4.Status Icons...................................................15
2.1.5.Screen Background Light..............................16
2.1.6.Adjust the Volume.........................................16
2.2.Instructions before Use...........................................17
2.2.1.Power on.......................................................19
2.2.2.Power off.......................................................19
2.2.3.Phone Security..............................................19
2.2.4.PIN code........................................................20
2.2.5.PUK code......................................................21
2.3.Basic Functions......................................................21
2.3.1.Direct call.......................................................21
2.3.2.Quick dial from dialled list..............................22
2.3.3.Receive a call................................................22
2.3.4.Terminate call................................................23
2.3.5.Make Emergency call....................................23

4
2.3.6.Make International long-distance call............23
2.4.Talk Options............................................................24
2.4.1.Hold / Release Talk State..............................24
2.4.2.Dial second number.......................................24
2.4.3.Answer second incoming call........................25
2.4.4.Selecting current phone number...................25
3. Messaging...................................................................27
3.1.Write message........................................................27
3.2.Inbox.......................................................................28
3.3.Outbox....................................................................28
3.4.Drafts......................................................................29
3.5.Sent Box.................................................................29
3.6.Templates...............................................................29
3.7.SMS settings...........................................................29
3.8.Message capacity...................................................30
3.9.Voice mail server....................................................30
4. Contacts......................................................................31
5. Call logs......................................................................32
6. Settings.......................................................................33
6.1.Phone Settings.......................................................33
6.1.1.Date & time....................................................33
6.1.2.Language settings.........................................33
6.1.3.Input method..................................................34
6.1.4.Shortcut settings............................................34
6.1.5.Shortcut dial settings.....................................34
6.1.6.Auto power on/off..........................................35
6.1.7.Power management......................................35
6.1.8.Restore factory settings.................................35
6.2.Display....................................................................36
6.3.Call settings............................................................36
6.3.1.Network Selection..........................................36
6.3.2.Network Type................................................37
6.3.3.Call divert.......................................................37
6.3.4.Call waiting....................................................38
6.3.5.Call barring....................................................39
6.3.6.Hide ID...........................................................39
6.3.7.Call time minute reminder..............................40

5
6.3.8.Auto redial.....................................................40
6.3.9.Answer/Reject mode.....................................40
6.3.10.Post-dialling delay.........................................40
6.4.Security...................................................................41
6.5.Profile......................................................................42
6.6.Phone Info..............................................................42
6.7.Calculator................................................................43
6.8.Alarm......................................................................44
6.9.Operator Menu (STK) ............................................44
7. Frequently Asked Questions.......................................45
8. Technical Specifications..............................................48

Version 1.00 ǀ2018/06/25 6
1.1 Package Contents
D-Link DWR-720P WCDMA / 3G Fixed FLLA Phone
Battery
Handset Cord
Handset Receiver
Antenna
Power Supply
Note: Using a power supply with a different voltage rating than the one included with the DWR-720P will cause damage
and void the warranty for this product.
1.2 System Requirements
A compatible (U)SIM card with service1
1Subject to services and service terms available from your carrier.

7
1.3 Safety and Maintenance
1.3.1 Using the Phone
Please observe the following points:
Before use, please read the instruction manual carefully.
Do not power on the phone when the use of a cellular phone is prohibited as it may cause interruptions or danger.
Please keep your phone switched off when you are on a plane. If functions that will automatically power on your phone, such as alarm
clock or calendar, are setup, please check and cancel the configuration before boarding the plane.
While using the phone, please keep away from heat source and high voltage environments, such as electric appliances or electric
cooking devices. Please use the phone under normal operating temperatures.
Do not operate the phone whilst driving.
Only the original supplied battery, charger and accessories should be used.
Phone may cause interference to nearby electronic devices, therefore keep it away from electronic devices such as radios, PC’s,
pacemakers, hearing aids, etc. Do not place the phone near credit cards or any magnetic fields.
Do not disassemble the phone –Any unauthorized work performed on the phone will void the warranty.
Do not use benzene, thinners, alcohol, or corrosive chemicals such as detergent to clean the cover of your phone.
Your phone is not water-proof, so please keep it dry. Do not use it in damp environment, such as a bathroom. Keep it away from rain and
moisture.

8
1.3.2 Using the Battery
Please observe the following points:
Before use, please read instructions for use as well as label on the surface of the battery.
Please charge the battery in a cool and well-ventilated room as high temperatures may lead to overheating.
Do not attempt open the battery as it may lead to short circuit or electrolyte leakage.
If electrolytes get in contact with your eyes, there is danger of blindness.
In such case, immediately wash your eyes with clean water and seek medical attention immediately (Do not rub your eyes)
Keep the battery away from mechanical vibration and shaking. Do not short connect the battery as this may damage the battery and
components connected to it.
Keep the metal contact points and battery clean.
Do not use damaged or depleted batteries.
The battery should be replaced when it cannot meet the requirement for performance. Battery can be charged hundreds of times before
it should be replaced.
Though it can be charged hundreds of times, its quantity of electric charge may decrease gradually. When service time (talk time and
standby time) is found to have decreased, the battery needs to be replaced.
Prevent the battery from exposure to the skin or places with excessive smoke or dust. Do not use it in damp environments, such as a
bathroom. The battery is not waterproof; so keep it away from rain and moisture.
Do not put the battery in places that are too hot or too cold. Temperature above 55 degrees Celsius or below -10 degrees Celsius may
affect performance of the battery.

9
Do not put the battery in an open fire as this could lead to an explosion.
Do not put the battery in water to avoid short circuit inside, resulting in battery overheat, smoking, distortion, damage or even explosion.
Treat battery according to local regulations (for example, recycling). Do not treat battery as domestic garbage.
Only the original charger supplied with the phone should be used for charging the battery.
Keep battery out of reach of children to avoid danger.
Using another type of battery, charger or generic accessories may violate the certification or warranty terms of equipment and may result
in damage.
1.3.3 Using the Battery Charger
Please observe the following points:
Before use, please read the user instructions as well as the label on the surface of the charger.
Do not disassemble or modify the charger or use it when power cable is damaged.
Do not touch the charger with wet hands. If the charger connects with water or other liquid, immediately cut off the power supply.
Do not short connect the charger and keep it away from mechanical vibration or shaking and direct sun shine.
Do not use it in damp environments, such as a bathroom.
The battery charger is not waterproof; therefore keep it away from rain and moisture.
Keep the charger out of reach of children to avoid danger.

10
2 Hardware Overview
2.1.1 Front

11
2.1.2 Back

12
2.1.3 Key Descriptions

13
1
Left Soft Key
Press to go into the main menu in idle screen; Select/Ok in submenus
2
Direction Key
Up Key
Scroll through the menu; Default shortcut to Contact List in idle screen
Down Key
Scroll through the menu; Default shortcut to Call Logs in idle screen
Left Key
Default shortcut to Messaging in idle screen
Right Key
Default shortcut to Profiles in idle screen
3
Right Soft Key
In any menu you can go back to the last menu
4
Shortcut Dial Keys
Set M1 –M4 as quick dial contacts
5
End Call/
Power On/Off Key
Hold down for a few seconds to power on/off the phone; Press the end key to end
phone call or return back to idle screen
6
SMS Key
Shortcut access to SMS menu in idle screen
7
Redial Key
Press to call the last dialled phone number
8
Hands Free key
Press to activate or deactivate hands free/ speaker mode
9
Numeric Keypad
To enter numbers and characters

14
10
Answer Key
Enter the phone number and press Dial key; Press to see last dialled numbers
11
Star Key
In idle screen, press to enter either ✲, +, P or W; Press to enter the special
symbol mode, i.e. ? ! : ; . , ’# $ % etc.
12
Hash Key
In idle screen, press to enter #; In message editing screen, press to switch input
method, i.e. Abc, ABC, abc, 123.

15
2.1.4 Status Icons
Icons on the screen:
Signal strength indicator
3G Network Service available
2G Network Service available
No Network Service available
Network Roaming
AC adapter Plugged in and Powered
Battery Life Indicator
Phone set to Silent Mode
Missed Call
New Message Received
Alarm has been set

16
2.1.5 Screen Background Light
Background light illuminates the screen.
When you power on your phone, the background light will turn on for a predefined period.
If no key is pressed within the period, the background light will turn off automatically to save battery life.
To adjust background light brightness and period:
For Time (sec): [Menu] [Settings] [2.Display] [2.Backlight].
You can now select between: Always on, 30, 20, 15, 10, 5 secs
For Brightness: [Menu] [Settings] [2.Display] [3.Contrast].
You can now press the left or right arrow keys to adjust the brightness down or up.
2.1.6 Adjust the Volume
During a call:
Press [Up Key] to increase the volume of the handset or hands free (HF)
Press [Down Key] to decrease the volume of the handset or hands free (HF)

17
2.2 Instructions before Use
Before using the phone, make sure the plug or battery is correctly connected and the SIM card has been inserted
correctly. Follow the instructions below on how to install the phone:

18
Warning: Before pulling out the SIM card, the phone should be powered off. Inserting or pulling out SIM cards is not
permitted when the external power is connected as it can damage the SIM card.

19
2.2.1 Power on
The device can work on both single battery mode and single charger mode.
Press and hold [Power Key] button until boot screen appears.
If there is a prompt for PIN code, please enter your PIN code and press [OK] key.
Note: Please contact your service provider for the default SIM PIN code if unavailable.
After power on, if the SIM card inserted is valid, your phone will automatically search available network.
If the SIM card is invalid or inactive, it will prompt you to Insert SIM or indicate Invalid SIM.
2.2.2 Power off
To power off, press and hold the [Power key] until power off screen appears.
Note: In this state, all reminders and alarms will still sound if set. Power off the phone and disconnect the external power whenever
inserting the battery or SIM card.
2.2.3 Phone Security
You can set an access password to avoid unauthorized use of your phone.
The default phone password is 1234.
To activate or deactivate this feature, please follow these steps:

20
In the idle screen [Menu] [Settings] [4.Security] [Power-on password].
You now have the option to Activate, Modify or switch Off the Phone Lock feature.
In order to Activate, Modify or switch Off, you will be required to enter the phone password.
Note: It is highly recommended to change the default password to a 4-8 digit code only you will know
and remember.
To change the phone password, please follow these steps:
In the idle screen [Menu] [Settings] [4.Security] [Power-on password] [2.Modify].
You will be required to enter the current password before you can create a new one.
[Please input password] [OK] [Input new password] [OK] [Confirm new password] [OK].
2.2.4 PIN code
PIN code is used to prevent illegal use of user’s SIM card.
If your phone has enabled PIN code protection, you will be prompted to enter your PIN code.
If the wrong PIN code is entered three times consecutively the SIM card will be automatically soft locked.
You will be required to enter the PUK code to unlock it.
The PIN code is related to SIM card, not the telephone and is provided by your Network Service Provider.
