Daewoo AVS1322 User manual

1
Compact Wooden DAB/FM Radio
AVS1322
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Compact Wooden DAB/FM Radio
AVS1322
User Manual

2
Compact Wooden DAB/FM Radio
AVS1322
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed. These instructions should be saved for future
reference:
•Read and familiarise yourself with all operating instructions before
using this DAB Radio.
•Before plugging your unit into the mains, visually check that the unit is
intact and has not suffered any transit damage.
•Check that the voltage indicated on the data plate corresponds with
that of the local network before connecting the appliance to the mains
power supply.
•Always use this appliance on a solid, level, non-flammable surface.
•Ensure that there is clearance of at least 100mm (4 Inches) minimum
around the Radio for sufficient ventilation.
•Ensure that the ventilation openings are not covered with items, such
as newspapers, table-cloths, curtains, etc.
•No naked flame sources, such as lighted candles, should be placed on
the Radio.
•Do not position the Radio close to sources of heat such as radiators,
heaters, other electronic equipment, etc.
•The Radio shall not be exposed to dripping or splashing and that no
objects filled with liquids, such as vases, shall be placed on the
apparatus.
•Do not immerse this appliance or its supply in water or any other
liquids.
•Do not leave the appliance unattended during use.
•Do not leave the appliance unattended whilst connected to the mains
supply.
•Always remove the mains supply from the mains socket when the Radio
is not in use, the mains supply must be accessible at all times.
•Close supervision is required when using this appliance near children.
•Never leave this appliance within reach of children.
•This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.

3
Compact Wooden DAB/FM Radio
AVS1322
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
•Children of less than 3 years should be kept away unless continuously
supervised.
•Do not use this appliance outdoors.
•It is imperative to unplug the power supply after the appliance has
been used, before it is cleaned and whilst being repaired.
•Unplug after each use. Grasp the supply, not the cord.
•Repairs to electrical appliances should only be performed by qualified
personnel. Improper repairs may place the user at serious risk.
•Do not operate this appliance with a damaged plug or cord, after a
malfunction or after being dropped or damaged in any way.
•Regular, periodic checks should be carried out on the mains supply to
ensure no damage is evident. Should there be any signs of damage the
product should not be used.
•If the power cable is damaged, it should only be replaced by the
manufacturer or a suitable qualified after-sales-service in order to
avoid a hazard
•Do not allow the power cable to hang over sharp edges or come in
contact with hot surfaces.
•Do not run the power cable under carpets, rugs, etc.
•This product is intended for household use only and should not be used
for industrial purposes.
•Do not use any accessories or attachments with this appliance other
than those supplied or recommended by supplier.
•Do not use this product for anything other than its intended use.
•Do not push objects into any openings as damage to the product
and/or electric shock may occur.

4
Compact Wooden DAB/FM Radio
AVS1322
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts –Front Panel
1. Standby/Mode –Press to turn the radio on. Press and hold to put the radio into standby.
Quickly press to select between DAB and FM radio modes.
2. Scan –Press Once to Scan the Radio Band.
3. LCD Display.
4. Preset/Dimmer –Press to Select Radio Presets. Whilst in standby, quickly press to select
three brightness levels for the display.
5. Alarm –Press to enter alarm settings.
6. Wooden Outer Case.
7. Sleep/Snooze –Press and hold to enter the Sleep timer. After the alarm sounds, pressed to
snooze the alarm.
8. Volume/Enter control.
9. Next button.
10. Previous button.
11. Info/Menu button –Press and hold to enter the Menu. Quick press to select the radio
information on the display.
12. Loudspeaker.
13. Feet.
1
2
7
8
3
4
9
5
6
10
11
12
13

5
Compact Wooden DAB/FM Radio
AVS1322
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts –Rear Panel
Before the first time you use your DAB Radio
Please read these operating instructions thoroughly and keep them in a safe place for future
reference.
Remove all packing materials and discard responsibly.
Using the Radio with Batteries
•Open the Battery Compartment (15) and push the tab on the Battery Compartment Cover
(16) to the right and remove (arrowed below)
•Insert four 1.5V AA Batteries (not supplied) into the battery compartment being careful to
observe the polarity markings inside:
•Replace the Battery Compartment Cover.
14.Telescopic Aerial
15.Battery Compartment
16.Battery Compartment Catch
17.Micro USB DC Power Socket
18.Headphone Jack Socket
19.On/Off Switch
20.Bass Port
21.Mains Adaptor
22.Micro USB DC Power Plug
14
17
15
16
18
19
20
21
22

6
Compact Wooden DAB/FM Radio
AVS1322
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Battery Warnings
•Do not mix old and new batteries together.
•It is recommended that batteries are removed from the radio if it is not to be used for a long
period of time.
•CAUTION: There is a danger of explosion if the batteries are incorrectly fitted.
•Replace only with the same or equivalent battery type.
•Do not expose the radio to sunshine, fire, heat or similar.
WARNING
•Keep new and used batteries away from children.
•If the battery compartment does not latch securely, stop using the product and keep it
away from children.
Using the Radio with the Mains Adaptor
•Insert the Small Micro USB DC Power Plug (22) of the Mains Adaptor (21) into Micro USB
DC Power Socket (17) on the rear of the Radio.
•Insert the Mains Adaptor (21) into the nearest mains socket.
NB if the mains adaptor is being used, it is recommended that the batteries (if fitted) are
removed.
Operating Instructions –Using the DAB Radio
Listening to the DAB Radio
1. Ensure that the On/Off Switch (19) on the rear of the radio is in the on position and the
Telescopic Aerial (14) is fully extended.
2. Ensure the radio has batteries inserted or has the Mains Adaptor (21) connected as
described above.
3. Press Standby/Mode button (1) on the front panel until the radio powers up.
NB If the radio is being used for the first time it will automatically scan the airwaves for DAB
stations. The LCD Display (3) will show ‘Scanning’ and a bar to indicate the progress of the
scan, and the total number of stations found so far. Once the scan has finished the radio will
play the first alphanumerically found station.
4. The Date and Time will also automatically update on the LCD Display (3).
5. Adjust the volume using the Volume/Enter control (8).

7
Compact Wooden DAB/FM Radio
AVS1322
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Tuning in and Selecting DAB stations
Press the Previous (10) or Next (9) buttons to scroll through the available stations. Once the
desired station is found, press the Volume/Enter control (8) to select the station.
Saving up to 10 DAB radio stations using the preset function
1. First tune the radio to the desired radio station as described above.
2. Press and hold the Preset/Dimmer button (4) to enter Preset save mode.
3. Press the Previous (10) or Next (9) buttons to scroll through the presets.
NB if a preset is empty and there is no station saved the preset will show as ‘Preset Store
<x:(Empty)>’.
4. After selecting the desired preset press the Volume/Enter control (8) to save the tuned
station into the preset selected –the LCD Display (3) will show ‘Preset x stored’to confirm.
NB x = preset number chosen.
5. Repeat the above steps to save more stations in the presets.
NB the preset number is shown at the bottom of the main screen on the LCD Display (3).
Recalling a preset DAB radio station using the preset function
•To recall a preset Radio Station, briefly press the Preset/Dimmer button (4) to enter the
preset recall mode.
•Press the Previous (10) or Next (9) buttons to scroll through the presets.
NB if a preset is empty and there is no station saved the preset will show as ‘Preset Recall
<x:(Empty)>’.
•After selecting the desired preset press the Volume/Enter control (8) to tune into the
saved radio station.
NB the preset number is shown at the bottom of the main screen on the LCD Display (3).
Selecting DAB Radio Information on the LCD Display
Briefly press the Info/Menu (11) button to select the various DAB radio station related
information such as:
•Dynamic Label Segment (DLS) - Displays scrolling text information supplied by the broadcaster.
•Signal Strength - Displays a signal bar with the current station strength and signal error count.
•Signal error - Provides details of the signal error rate.
•Channel Frequency –Displays the radio station transmission frequency.
•Program Type (PTY) –Displays the program type and description: Pop Music, Rock Music, Talk, Jazz & Blues,
etc.
•Time and Date - Displays the time and date information provided by the broadcaster.
•Audio Bit Rate –Displays the audio bit rate of the transmission.
Updating the DAB stations using the scan button.
It may be necessary to retune your DAB radio in order to receive new stations being broadcast
in your area or if a broadcaster has made any changes to an existing station and you can no
longer receive it.
To update your DAB stations, press the Scan button (2) on the front panel and the DAB radio
band will be updated. Any stations saved in the presets may need to be re-programmed after
re-scanning.
NB Re-scanning may be required if the radio is moved to a new location i.e. after moving
house.

8
Compact Wooden DAB/FM Radio
AVS1322
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
DAB Radio Menu
Whilst listening to the DAB radio press and hold the Info/Menu button (11) to enter the DAB
radio menu.
Use the Previous (10) or Next (9) buttons to scroll through the various menu options, press
the Volume/Enter control (8) to select the desired option:
a. Time & Date –Manually set the Date and Time.
b. System Version –Shows the latest software version the radio has installed.
c. Factory Reset –Allows a full reset of the radio back to the original factory settings.
WARNING any radio stations previously saved in the presets and any personal settings will
be lost after a Factory Reset.
Operating Instructions –Using the FM Radio
Listening to the FM Radio
1. Ensure the On/Off Switch (19) on the rear of the radio is in the on position and the
Telescopic Aerial (14) is fully extended.
2. Ensure the radio has batteries inserted or has the Mains Adaptor (21) connected as
described above.
3. Press Standby/Mode button (1) on the front panel until the radio powers up.
4. Briefly press the Standby/Mode button (1) to enter the FM radio mode.
5. Press the Previous (10) or Next (9) buttons to tune up and down the FM radio band.
Holding either of the buttons down will search and stop at the next FM radio station.
NB the radio tunes in 0.05MHz steps.
6. Adjust the volume using the Volume/Enter control (8).
Saving up to 10 FM radio stations using the preset function
1. First tune the radio to the desired radio station as described above.
2. Press and hold the Preset button (4) to enter Preset save mode.
3. Press the Previous (10) or Next (9) buttons to scroll through the presets.
NB if a preset is empty and there is no station saved the preset will show as ‘Preset Store
<x:(Empty)>’.
4. After selecting the desired preset press the Volume/Enter control (8) to save the tuned
station into the preset selected –the LCD Display (3) will show ‘Preset x stored’ to confirm.
NB x = preset number chosen.
5. Repeat the above steps to save more stations in the presets.
NB the preset number is shown at the bottom of the main screen on the LCD Display (3).
Recalling a preset FM radio station using the preset function
1. To recall a preset Radio Station, briefly press the Preset/Dimmer button (4) to enter the
preset recall mode.
2. Press the Previous (10) or Next (9) buttons to scroll through the presets. NB if a preset is
empty and there is no station saved the preset will show as ‘Preset Recall <x:(Empty)>’.
3. After selecting the desired preset press the Volume/Enter control (8) to tune into the
saved radio station.
NB the preset number is shown at the bottom of the main screen on the LCD Display (3).

9
Compact Wooden DAB/FM Radio
AVS1322
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Selecting FM Radio Information on the LCD Display
Briefly press the Info/Menu (11) button to select the various FM radio station related
information such as:
•Radio Text - Displays scrolling text information supplied by the broadcaster.
•Program Type –Displays the description of the program provided by the broadcaster.
•Signal Strength –Displays a signal bar showing the strength of the current radio station.
•Time and Date –Displays the current time and date provided by the broadcaster.
•Frequency –Displays the radio station transmission frequency.
•Audio Type –Displays whether the audio is in Mono or Stereo.
FM Radio Menu
Whilst listening to the FM radio press and hold the Info/Menu button (11) to enter the
FM radio menu.
Use the Previous (10) or Next (8) buttons to scroll through the various menu options, press
the Volume/Enter control (9) to select the desired option:
a. Time & Date –Manually set the Date and Time.
b. System Version –Shows the latest software version the radio has installed.
c. Factory Reset –Allows a full reset of the radio back to the original factory settings.
NB any radio stations previously saved in the presets will be lost after a Factory Reset.
d. FM Scanning –Select from scanning strong stations ‘Only’ or scan all stations by selecting ‘All’.
Operating Instructions –Setting and Using the Alarm Function
1. Press the Alarm button (5) and then press the Volume/Enter control (8) until the “Alarm 1
OFF”flashes on the LCD Display (3).
2. Press the Previous (10) or Next (9) controls to select “Alarm 1 ON”, press the Volume/Enter
control (8) to confirm selection.
3. The hours will flash, press the Previous (10) or Next (9) controls to select the current hour,
press the Volume/Enter control (8) to confirm selection.
4. The minutes will flash, press the Previous (10) or Next (9) controls to select the current
minute, press the Volume/Enter control (8) to confirm selection.
5. “Vol” will flash on the LCD Display (3), press the Previous (10) or Next (9) controls to select
the alarm volume (select from 0 –15 zero being the lowest and 15 the highest volume),
press the Volume/Enter control (8) to confirm selection.
6. The alarm sound source “SRC”will flash on the LCD Display (3), press the Previous (10) or
Next (9) controls to select the alarm source to wake up to: Alarm/DAB/FM, press the
Volume/Enter control (8) to confirm selection.
7. The alarm “Mode” will flash on the LCD Display (3), press the Previous (10) or Next (9)
controls to select when the alarm will go off: Once/Daily/Weekends/Weekdays, press the
Volume/Enter control (8) to confirm selection.
NB to set alarm 2:
1. With the radio on, press the Alarm button (5) twice and then press the Volume/Enter
control (8) until the “Alarm 2 OFF”flashes on the LCD Display (3).
2. Press the Previous (10) or Next (9) controls to select “Alarm 2 ON”, press the Volume/Enter
control (8) to confirm selection. Continue from Step 3 above to set alarm2.
NOTE: You can press the Info/Menu button (11) to skip back one step while the setting the
alarm.

10
Compact Wooden DAB/FM Radio
AVS1322
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Display Dimming
With the radio off, press the Preset/Dimmer button (4) to vary the brightness of the LCD
display (3).
Silencing the alarm
Press the Standby/Mode button (1) on the front panel to silence the alarm.
Snooze Mode
After the alarm sounds, the Sleep/Snooze button (7) can be pressed to snooze the alarm. The
alarm will be silent for a further 9 minutes before sounding again. Press the Standby/Mode
button (1) to cancel the snooze mode and alarm.
Switching off the alarm
Press the Alarm button (5) (once for alarm 1 twice for alarm 2) and then press the
Volume/Enter control (8) until the “Alarm 1 (or 2) ON”flashes on the LCD Display (3).
Press the Previous (10) or Next (9) controls to select “Alarm 1 (or 2) OFF”, press the
Volume/Enter control (8) to confirm selection.
Sleep Timer
The sleep timer allows you to listen to music for a set time before the radio turns itself
off automatically.
a. Switch the radio on using the Standby/Mode button (1).
b. Ensure the radio is tuned into the desired station.
c. Press and hold the Sleep/Snooze button (7) to enter sleep mode.
d. Press the Previous (10) or Next (9) controls to select the sleep time duration:
OFF, 120, 90, 60, 45, 30, 15 or 5 minutes. Press the Volume/Enter control (8) to confirm selection.
e. The radio will now play for the selected time which will be shown counting down on the LCD
Display (3) in the top right-hand corner, then go into standby (off) mode.
f. To cancel the sleep timer, repeat the above steps and select Sleep Timer “OFF”.
Operating Instructions –Using the Headphone Output
Insert the Headphones 3.5mm jack plug into the Headphone Jack Socket (18) on the rear
panel.
Adjust the volume level as desired using the Volume/Enter control (8).
Care and Use of your DAB Radio
•Always disconnect the DAB Radio from the mains power supply before cleaning.
•Clean outside of the DAB Radio with a clean damp cloth. Never clean with harsh or
abrasive cleaners.
•Do not submerge the DAB Radio or its Power Supply in water or any other liquids.

11
Compact Wooden DAB/FM Radio
AVS1322
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Technical Specification
Model Number
AVS1322
Power Supply
4x 1.5V AA Batteries or DC 5.0V @1.0A 5.0W
Mains Adaptor
Input: AC 100-240V ~ 50/60Hz 0.15A
Output: DC 5.0V @1.0A 5.0W
Audio Output Power
2.0W
No of Speaker Units
1
Unpacked Weight
Approx. 425g (without batteries)
Dimensions (Approx.)
Approx. 170 (w) x 90 (d) x 100 (h) mm
Operating Temperature Range
0°C to + 40°C
FM Frequency Range
87.5 - 108MHz
DAB Frequency Range
174.928 - 239.2MHZ
This product conforms to Radio Equipment Directive 2014/53/EU
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer for recycling
advice.
Waste batteries should not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local Authority or retailer for recycling
advice.

12
Compact Wooden DAB/FM Radio
AVS1322
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
GUARANTEE
This product is guaranteed for twenty-four months from the date of original
purchase. If any defect should occur due to faulty materials or workmanship, please
return it to the store it was purchased from.
You will need to have your receipt of purchase to hand. The guarantee is subject to
the following provisions:
• It is only valid within the boundaries of the country of purchase.
• The product must be correctly installed and operated in accordance with the
instructions contained in the User Manual.
• The product must be used solely for domestic purposes.
• The guarantee will berendered invalid if the product is re-sold or has been
damaged by inexpert repair.
• The manufacturer disclaims any liability for incidental or consequential damages.
• The guarantee is in addition to, anddoes not diminish, your statutory or legal
rights.
Daewoo Electricals is a registered trademark.
Produced and imported under licence by ESG Ltd
Manchester M3 1JS www.esgltd.com
