WiseSpin® CF-10
Personal Centrifuge
Operation Manual
(Version 1.4.2)
written for
Model CF-10

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 2/37
Contents
Page
1. Safety Instructions ........................................................................…….....….. 3
2. Before Use …......................................................................................……..... 5
3. Introduction ....................................................................................... 6
4. Package Contents ......................................................................................... 7
5. Appearance and Naming .................................................................................. 8
6. Controller Details .......................................................................................... 9
7. Installation ..................………………............................................................ 10
8. Cautions in Use ………………....................................................................... 12
9. Operation ........................................................................................... 14
10. Specifications …………........................................................................ 18
11. Maintenance …………………..................................................................... 19
12. Certificate ........................……….............................................................. 20

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 3/37
SafetyInstructions 1
Please read this carefully for the safety before using the device. The indicated cautions are
related to the safety and you should observe all safety and warning instructions.
Symbols (Pictograms) and the meaning
This symbol indicates caution
(Including warning). There will be
concrete descriptions.
This symbol indicates inhibition.
There will be concrete
description.
This symbol indicates inhibition
regarding modification.
This symbol indicates caution
regarding heat.
This symbol indicates the risk of
explosion or fire.
This symbol indicates the user
must be kept away while
operation.
Please read following warning for safety and proper use.
WARNING
Do not use a power source other than which the unit is designed to operate on.
Inappropriate power supply may result in damage to the equipment. Adhere to all
electrical codes.
Please do not touch with wet hands. It may be caused an electric shock.
Do not handle the power cord harshly. Disconnection or short may cause if you
bend or put a heavy thing on the device.
When you take a plug out in a wall socket, turn the power off and then take the plug
out carefully.

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 4/37
Insert the plug securely into a wall socket.
Loose connections result in excessive heat generation to the device and may cause
arcing to occur at the connection.
Avoid using multi-point extension power cords. It may cause excessive heat
generation and be the cause of a fire.
If you extend the power cord, use the cord to have sufficient electric capacity.
Be sure to operate the device only with the specified power supply.
When you connect the product specified by 100V to 200V, it may be caused to
over-heat, electric shock or a short circuit to each part.
Do not connect wrong electricity since it is the cause of a fire.
Disconnect the power supply plug if the unit is not going to be used for an extended
period of time.
Refer to the Warnings regarding Installation stated in the Section 7.
Refer to the Warning and Cautions regarding use of the device
stated in the Section 8.

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 5/37
BeforeUse 2
Thank you very much for purchase of WiseSpin®CF-10 Centrifuge.
This operation manual describes performance, proper usage, cautions and notices for use of the
purchased product. Before use, please confirm this manual and use properly.
Please read carefully and thoroughly all the safety instructions described in the Section 1 again.
And also, please keep this manual.
Modifications of exterior, interior, mechanism, electric/electronics or any other specifications
could be made without notice to improve the quality and performance of the product.

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 6/37
Introduction 3
WiseSpin®Digital Personal Table-top Centrifuges has very low noise level (≤57dB at Max.
RPM) even though it has high performance (max. 13,500rpm (rcf: 12,225 x g)) and extremely
compact with small footprint
Key features are as follows;
■Unbelievably quiet operation with maintenance-free drive (Brushless DC motor)
■Very low noise level: ≤57dB at max. rpm
■High performance - Max. 13,500rpm (rcf: 12,225 x g) by digital feedback speed control
■Extremely compact design with small footprint
■Simplest user interface by Jog-Shuttle Switch - Patented user interface
■Exclusive ‘Spin Down’ button: Two types of simple operation for repetitive use of a certain
RPM & time. (Timer operating & Return operating)
■Acceleration and braking times lower than 15 sec (for max. Speed)
■Digital Back-Light LCD, with Power bar graph
■Digital timer function with continuous running mode (99hr 59min)
■Storage function for the set values of RPM and Timer
■Locking mode supported for experimental Safety
■Safety system for motor error and automatic stop when opening door
■Capacity: 12 x 1.5/2.0 ml tubes

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 7/37
PackageContents 4
CF-10 Personal table top Centrifuges ……………….……….................................................... [ 1 ]
CFAR1512 Angle Rotor, 12 x 1.5/2.0 ml tubes ....................................................................... [ 1 ]
Power Code ………………………………………………………..……………………………... [ 1 ]
Operation Manual .................................................................................................................... [ 1 ]

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 8/37
Appearance and Naming 5
Control Panel
Lid Clamp
Lid
Lid Shover
Lid Open Sensor
Rotor - CFAR1512 (12 x 1.5/2.0 ml tubes)
3
1
4
2
5
6
Air hole
closed by a rubber cap in the factory
setting.

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 9/37
Controller Details
6
(NOTE) SV : Set Value, PV : Present Value
Operation Status
SV of rotation speed (set rpm : x 10) or Timer
PV of rotation speed (measured rpm : x 10) or Timer
Power bar graph indicating the power of the motor operating
ROTATION (operating) lamp : indication of rotation setting and status.
TIMER lamp : indication of Timer setting and status.
MODE button : Selection of main operation mode. (Set Rotation Speed mode, Set Timer
mode and Safety Locking mode)
SPIN-DOWN button : Go to ‘SPIN DOWN’ mode.
○
15 Jog-shuttle knob : Turn + Push
- Setting the value of Rotation Speed or Timer by Turing.
- Start and stop by Pushing
7
9
10
15
8
11 12
13 14

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 10/37
Installation 7
1. After receiving the unit and putting it on the specified place of use remove the wrapping.
2. Check the unit whether there are eventual transport damages or not. In case there are some
transport damages found please inform the forwarder and your contractor. If there is no
damage, please go to next point 3.
3. Push the Lid Clamp and open the lid. You can find the rotor, CFAR1512 (12 x 1.5/2.0 ml
tubes) equipped in the centrifuging room. Please check carefully if there is anything wrong
including loose fixing of the rotor or leaning of the rotor. In case there is any kind of damage
found, please inform the forwarder and your contractor. If you cannot find anything wrong,
please go to next point 4.
4. Connect the main power cord to the socket.

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 11/37
WARNING
Place the device on a level, horizontal surface to support the capacity of the device
without vibration.
Do not install at a dangerous place. Do not operate the device where there are
flammables. It could be caused serious accidents like explosion or fire.
Do not operate the device outside. Avoid areas where the sun shines or rain directly
on the device. It is very dangerous as cause over-heat or a short circuit.
Do not tilt or lay down the device, and do not impact the body of the device. The
device includes shock-sensitive motor and structures, which could be damaged by
the tilt or impact.
Do not install the device where it can get damp or dust. It may be caused
overheating, a short circuit or a fire by damp or dust inside of the device.
Do not use this device when temperature falls below 10°C and rise above 40 °C.
In door use only.
Do not use the device at a place with high temperature. Do not operate the device
near a heater, blowing an air-conditioner. It may be caused an accident by over-
heating of the motor.
The device should be set at a well ventilated place. Be sure the holes on the side or
bottom surface of the body are not blocked by some obstacles.
Do not operate the device at a poor ventilated place or use closed. It may cause a fire
or damage of the device as not to release heat or insufficient ventilation may result.
Set the device a lightening place.
When you set the device at a dark place, it may cause an unexpected accident by
mistake in operation.
If you want to run the machine for a long time, the rubber cap for the air hole in the lid
should be removed before operation.
If you run the machine for too long time with the air hole in the lid closed by rubber
cap, it may cause damage to temperature sensitive samples.

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 12/37
CautionsinUse 8
WARNING
Be careful to operate the device.
You MUST read this manual carefully and completely before using.
The device should only be operated by laboratory personnel especially trained for
this purpose and familiar with all precautionary measures required for working in a
laboratory.
If unexpected sound, smell or smog is generated after connecting electric power, pull
out the main plug and contact manufacturer or a supplier.
Do not put any objects insides.
When an object that is easy to be combustible is like a stone, a metal or paper goes
insides, it may cause a fire, an electric shock or a break down.
If do, pull out the mains plug from a socket and contact a manufacturer or a supplier.
Do not disassemble or remodeling by yourself.
It may cause damage to the designed safety.
We do not have any duties for an accident, quality deterioration or a defect caused
by a customer.
All the mechanisms and electric/electronic devices in this machine are designed and
developed by the manufacturer. The devices could be disassembled and serviced
only by the engineers of manufacturer or by engineers approved by manufacturer.
Do not touch the device with wet hand while operation.
Do not turn on and off frequently. It could damage the electronic part.
This device must be connected to an earthed power supply.

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 13/37
CAUTION
Before every centrifugation operation, check that the rotor is completely and tightly
fixed at the motor axis.
Before every centrifugation operation, check that the lid is completely closed by the
lid clamp.
Do not open the door during rotation.
Rotor will stop by safety system. But it needs 12 to 15 seconds. If you touch angle
rotor before stop, may result serious injury.
Basically, you MUST make the balance of angle rotor in loading sample to rotor.
If you want to use the maximum rotor speed (13,500 rpm) for centrifugation, you
SHOULD make the sample weight to fill up to two decimal places (i.e., 0.00g
precision).
If you don’t keep this basic instruction, you can have a serious problem of the
machine, and so it leads to an accident as well.
Allow the rotation speed to slow zero before opening the lid when the centrifugation is
finished.
Please be careful that liquid should not penetrate into the part of control panel or
back plane.
Do not use flammable material.
Flammable materials or Chemicals must not be used in order to avoid an explosion or
a fire.
Please avoid ultrasonic lamps.
The unit could be cracked or faded.
Disconnect the power supply plug if the unit is not going to be used for an extended
period of time.

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 14/37
Operation 9
1. Power-On
Turn on the power, and then get into its default mode.
Install sample to rotor and close door completely.
2. Mode Selection
You can change the mode by the combination of MODE button ○
13, SPIN button ○ 14 and Jog-
shuttle knob ○
15 push.

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 15/37
SV ○
8and PV ○ 9have different meanings for each operation mode. It is shown in the following
<Table 1>.
Setting Mode SV (Set Value) PV (Present Value) Control target
Set Rotation Speed
mode
Set(Saved) Rotation
Speed (rpm) Current Speed (rpm) Rotational Speed (rpm)
Set Timer mode Set(Saved) Time Time remained Operation time
Set SPIN Rotation
Speed Mode
Set(Saved) Rotation
Speed (rpm) for SPIN
operation
Current Speed (rpm) for
SPIN operation
Rotation Speed (rpm) for
SPIN operation
Set SPIN Timer Mode Set(Saved) Time for
SPIN operation
Time remained for SPIN
operation
Operation time for SPIN
operation
Locking Mode Current Speed Current Time Display only
<Table 1> the meaning of display by mode
3. Set Rotation Speed Mode
After you turn on the power, the default mode of the unit is Set Rotation Speed mode.
(NOTE) Please check carefully if the lid is completely closed before running. If the lid is not
closed completely, the unit will not run by safety system.
You can find zero or non-zero value of the SV rpm on LCD and ROTATION lamp ○
11 is blinking.
zIf the SV is non-zero, it means that someone had saved a value previously by storage
function. You can use this saved value or you can modify the value by turning the jog-
shuttle knob ○
15. Simply by clicking jog-shuttle, the unit begins to revolve at the set rpm.
zIf the SV is 0, it means there is not the value saved previously. You can adjust the set
rpm by turning jog-shuttle knob ○
15.
RPM adjustment and Running: When you turn the jog-shuttle knob ○
15 for adjustment of rpm
SV, the set value is changed. Click (push shortly) the jog-shuttle knob ○
15 to start rotational
operation (centrifugation), then ROTATION lamp ○
11 is ON. Rotation rpm (PV) will goes up to set
rpm (SV). Once the rpm PV reaches to rpm SV (within a few seconds), timer starts with its set

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 16/37
value and TIMER lamp ○
12 is ON. (rpm SV on the upper line of LCD changes to the value of
remaining time). If you set timer SV to “0” before running the rotation, rotation will operate
continuously without stopping unless you stop the rotation operation by clicking jog-shuttle knob
in Set Rotation Speed mode.
If you want to change the rpm SV, you have to stop the centrifugation by clicking jog-shuttle
knob again. (Remaining time display changes to rpm SV. ROTATION lamp ○
11 is blinking and
TIMER lamp ○
12 is OFF). Once stopping, you can adjust rpm again, and then click the jog-shuttle
again to restart. In this case, timer will be reset to its SV, and the timer restarts from the
beginning as well after reaching to target RPM.
(NOTE) Control resolution is 100 rpm and maximum rpm is 13,500.
Stop and Restart : If you click the jog-shuttle knob during rotation operation in Set Rotation
Speed mode, the unit stops rotation and it completely stops after approximately 15 seconds
(When you set SV to maximum specification – 13,500 rpm). If you click again in this stop status,
the unit will restart to operate.
Saving current SV : You could save the current rpm SV for re-use in the next time by pushing
jog-shuttle knob for one second. The unit stores the set value in nonvolatile memory, so you
could re-use it afterwards.
4. Set Timer Mode
You can use internal digital timer to make the operation preserved for a certain period of time. If
you push MODE button ○
13 in Set Rotation Speed mode, you can enter into the Set Timer mode.
You can find zero or non-zero value of the timer SV on LCD and TIMER lamp ○
12 is blinking.
zIf the SV is non-zero, it means that someone had saved a value previously by storage
function. You can use this saved value or you can modify the value by turning the jog-
shuttle knob ○
15.
zIf the SV is 0, it means there is not value saved previously. You can adjust the timer SV
by turning jog-shuttle knob ○
15.
Timer adjustment and running Timer : When you turn the jog-shuttle knob ○
15 for adjustment

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 17/37
of timer SV, the set values is changed. Timer will automatically begin to run, at the moment that
the rpm PV reaches to rpm SV by the Rotation operation.
Saving current SV : You could save the current timer SV for the re-use in next time by pushing
the jog-shuttle knob for one second. The unit stores the set value in nonvolatile memory, so you
could re-use it afterwards.
If you finish setting timer, push MODE button. you can enter into the Locking mode.
(NOTE) Timer resolution is 1 second and maximum timer value is 99min 59sec. If you set timer
to “0”, rotation will be continued without stopping.
5. Locking Mode
If you push MODE button in Set Timer mode, the unit enters into Safety Locking mode. In this
mode, the PVs of rpm and timer are shown on LCD. And any action (turn or push) to jog-shuttle
knob is disabled and pushing SPIN button is also disabled. So, the operator can prevent the unit
from change of the operation by mistake and can monitor the operation safely. If you push the
MODE button ○
13 again in this mode, the unit enters into the Set Rotation Speed mode.
6. SPIN mode
This mode is very convenient for repetitive use of a certain combination of rotation speed & time.
If you push SPIN button ○
14 in Set Rotation Speed mode or in Set Timer mode, the unit enters
into the SPIN mode. By simply clicking the jog-shuttle knob at this moment, the unit starts
operation promptly with the rotation speed and timer SVs saved previously.
If you want to change the SVs of rotation speed and timer, push the jog-shuttle knob for one
second. Then the unit enters into the Set SPIN Rotation Speed mode. Like in the Set Rotation
Speed mode, you can change the rpm by turning jog-shuttle knob. After setup the rotation speed,
push the SPIN button again (Save & go to next set up), then the current set rpm is saved and
the unit enters into the Set SPIN Timer mode. Like in the Set Timer mode, you can change the
timer SV by turning jog-shuttle knob. After setup the timer, push the SPIN button once again
(Save & go to next set up), then the current timer SV is saved and the unit enters into the Set
SPIN Rotation Speed mode again.
When you finished setup of the rotation speed and timer for SPIN operation, push the jog-shuttle

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 18/37
knob for one second for returning to SPIN mode. By clicking the jog-shuttle knob, the unit starts
operation promptly with the rotation speed and timer SVs saved just before.
WiseSpin®CF-10 Centrifuge offers two different types of SPIN mode operation. The one is
Timer-based operation (with non-zero value of SPIN timer SV) and the other is One Shot
operation (with zero-value of SPIN timer SV). If you set SPIN Timer to “0”, the unit operates to
reach SPIN rpm SV and then stops rotation immediately after the SPIN rpm PV reaches to SPIN
rpm SV. This operation is very convenient for simple Spin-Down purpose.
(It takes approximately 15 seconds to start, run and stop for spin-down operation, when your
SPIN rpm SV is 6,000)
If you want to return to normal operation mode, push the MODE button.
7. Power off
After you complete to use the unit, you must turn off the power switch for your safety.
(NOTE) If you open the lid during rotation, the unit will automatically stop the operation
for user safety. Do not open the door during rotation !! If you don’t keep this note, you
can have a serious problem of the machine, and so it leads to an accident as well.

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 19/37
Specifications 10
CF-10 (with Angle rotor CFAR1512)
Max. RPM 13,500 RPM
Max. RCF 12,225 x g
Max. Capacity 1.5ml(2.0ml) x 12 Tubes
Control Digital Feedback Control with Jog Shuttle Switch
(Turn+Push)
Display Digital Back-light LCD, with Power bar graph
Timer 99min. 59sec. (Can running continuous mode)
Cooling Device Air Cooling
Drive System Brushless DC motor, Direct drive
Acceleration Time ≤15 sec (for max. speed)
Brakin
g
Time ≤15 sec (for max. speed)
Safety System Motor Error Detection,
Auto Stop when opening door
Noise Level ≤57dB
Dimension 170 W x 226 D x 183 H (mm)
Weight 2.3 kg
Power Consumption 90W
Power AC 110V, 50/60Hz or 230V, 50/60Hz

DAIHAN-Sci.com / ALL
for LAB.com
WiseSpin
®
CF-10 Personal Table-top Centrifuge 20/37
Maintenance 11
1. If you don’t use the device for a long time, please plug out, dry up the machine and
keep with packing.
2. When you need exchange of a component for repair, you MUST use an original
component provided by manufacturer.
3. In the warranty period specified on the warranty sheet included in this operation manual,
breakdown of the machine in spite of normal/proper use will be treated by manufacturer
or by an official agent of manufacturer.
4. The manufacturer or its agent is not in charge of breakdown caused by abnormal use or
by ignoring the warnings and cautions described in this manual.
5. Before cleaning the machine, please be sure to pull the power cord off.
6. For cleaning of the machine, we recommend you to use neutral detergent and soft cloth.
Do not use coarse cloth, strong chemicals or organic solution.
