Daikin BRP069A71 User manual

Installation manual
WLAN adapter heating English
Installation manual
WLAN adapter heating
BRP069A71

Table of contents
Installation manual
2
BRP069A71
WLAN adapter heating
4P595892-1A – 2019.12
Table of contents
1 About this document 2
2 About the adapter 2
2.1 Components .............................................................................. 2
2.2 Basic parameters ...................................................................... 2
2.3 Compatibility.............................................................................. 2
3 About the box 2
3.1 To unpack the adapter .............................................................. 2
4 Preparation 3
4.1 Installation site requirements..................................................... 3
4.2 Overview of electrical connections ............................................ 3
5 Installation 3
5.1 Precautions when installing the adapter.................................... 3
5.2 Connecting the electrical wiring................................................. 3
5.2.1 To connect the adapter with the unit........................... 3
5.3 Closing the adapter ................................................................... 4
5.3.1 To close the adapter ................................................... 4
5.4 Mounting the adapter ................................................................ 4
5.4.1 To mount the adapter to the unit................................. 4
6 Starting up the system 4
7 Hand-over to the user 5
1 About this document
Target audience
Authorised installers
Documentation set
This document is part of a documentation set. The complete set
consists of:
▪General safety precautions
▪ Safety instructions that you must read before installing
▪ Format: Paper (in the box of the indoor unit)
▪Installation manual:
▪ Installation instructions
▪ Format: Paper (supplied in the kit)
▪Installer reference guide:
▪ Installation instructions, configuration, application guidelines,…
▪ Format: Digital files on http://www.daikineurope.com/support-
and-manuals/product-information/
▪Declaration of conformity
INFORMATION: Declaration of conformity
Hereby, Daikin Europe N.V. declares that the radio
equipment type BRP069A71 is in compliance with the
Directive 2014/53/EU. The original declaration of
conformity is available from http://www.daikineurope.com/
support-and-manuals/product-information/.
Latest revisions of the supplied documentation may be available on
the regional Daikin website or via your dealer.
The original documentation is written in English. All other languages
are translations.
2 About the adapter
Wireless LAN adapter to connect the heat pump system to the
internet, allowing for control of the heat pump system with the Daikin
Residential Controller app.
2.1 Components
Component Description
RUN ▪ LED ON: adapter active as
station, and connected to a
network.
▪ LED flashing: adapter active
as station and not yet
connected to a network.
AP ▪ LED ON: adapter active as
access point, and mobile
device associated.
▪ LED flashing: adapter active
as access point, but no mobile
device associated yet.
SETUP Press to connect the adapter to a
router.
MODE Hold to toggle AP mode on and
off.
POWER Press to reset the adapter.
2.2 Basic parameters
Parameter Value
Frequency range 2400MHz~2483.5MHz
Radio protocol IEEE 802.11b/g/n
Radio frequency channel 1~13
Output power 0dBm~18dBm
Effective radiated power 17dBm (11b) / 14dBm (11g) /
13dBm (11n)
Power supply DC 14 V / 100 mA
2.3 Compatibility
Make sure the heat pump system is compatible for use with the
adapter. For more information, see the installer reference guide of
the heat pump system.
3 About the box
3.1 To unpack the adapter
1Open the box.
2Take out the adapter.

4 Preparation
Installation manual
3
BRP069A71
WLAN adapter heating
4P595892-1A – 2019.12
3Separate the accessories.
ab
i
c
e
gf
h
d
aAdapter
bAdapter holder with double-sided tape
cCable tie mounting
dCable tie
eConnection cable
fInstallation manual
gTape for adapter holder
hLabel for manual
iScrews
4 Preparation
4.1 Installation site requirements
▪ The adapter is designed to be mounted to the indoor unit, in dry,
indoor locations only.
▪ The exact location of the adapter depends on the type of indoor
unit. For more information, see the addendum book for optional
equipment of the indoor unit.
▪ The adapter is designed to operate in ambient temperatures
ranging from 5~35°C.
4.2 Overview of electrical connections
a
aTo indoor unit
5 Installation
5.1 Precautions when installing the
adapter
DANGER: RISK OF ELECTROCUTION
▪ Turn off the power supply before installing the adapter.
▪ Do NOT handle the adapter with wet hands.
▪ Do NOT let the adapter get wet.
▪ Do NOT disassemble, modify or repair the adapter.
▪ Grip the connector when disconnecting the connection
cable.
▪ Turn off the power supply in case the adapter gets
damaged.
Symbol Explanation
The protection of appliances marked with this symbol
is ensured by double insulation and does not require a
safety connection to electrical earth (ground).
5.2 Connecting the electrical wiring
DANGER: RISK OF ELECTROCUTION
Do NOT turn on the power supply before you have
connected the electrical wiring, closed the adapter, and
mounted it to the indoor unit.
5.2.1 To connect the adapter with the unit
1Separate the upper casing from the lower casing.
a
c
b
aUpper casing
bAdapter PCB
cLower casing
2Connect the forked end of the connection cable to the indoor
unit.
3Connect the other end of the connection cable to the connector
on the adapter PCB.
4Fasten the cable and ensure strain relief.
a

6 Starting up the system
Installation manual
4
BRP069A71
WLAN adapter heating
4P595892-1A – 2019.12
aConnector
INFORMATION
Where to connect the electrical wiring on the indoor unit
depends on the type of indoor unit. For more information,
see the addendum book for optional equipment of the
indoor unit.
INFORMATION
Provide strain relief at indoor unit side by using the cable
tie and cable tie mounting that are included as accessory.
5.3 Closing the adapter
5.3.1 To close the adapter
1Hook the front casing into the rear casing.
2Insert the two screws from the accessory bag.
2×
NOTICE
After closing the adapter, check that the connection cable
is securely fastened.
5.4 Mounting the adapter
Mount the adapter to the indoor unit by making use of the holder and
tape that are included in the accessory bag.
NOTICE
▪ Make sure that the part of the indoor unit to which you
mount the holder is clean.
▪ Make sure to mount the holder to the indoor unit firmly,
so that it can bear the weight of the adapter.
5.4.1 To mount the adapter to the unit
1Attach the double-sided tape to the adapter holder.
a
b
aTape
bAdapter holder
2With the tape, mount the holder to the indoor unit.
3Slide the adapter into the holder.
INFORMATION
The exact location of the holder depends on the type of
indoor unit. For more information, see the addendum book
for optional equipment of the indoor unit.
6 Starting up the system
The adapter gets its power from the indoor unit. For the adapter to
function, make sure it is connected to the indoor unit, and the indoor
unit is powered on.
After powering on the system, the RUN and AP LEDs light up and go
out again after the adapter is operational. Depending on the system
layout, it can take up to 1 minute before the adapter is operational.
INFORMATION
Before starting up the system, make sure that the adapter
is closed and properly mounted to the indoor unit.
INFORMATION
For information on how to configure the system for use
with the adapter, and troubleshoot it in case of problems,
see the installer and user reference guide.

7 Hand-over to the user
Installation manual
5
BRP069A71
WLAN adapter heating
4P595892-1A – 2019.12
7 Hand-over to the user
After having installed and configured the adapter, hand over this
installation manual to the user and make him/her aware of the
following safety precautions.
DANGER
▪ Do not disassemble, modify, or repair the adapter. This
can cause fire, electric shock, or injury.
▪ Do not allow the adapter to get wet or use it when
bathing or doing similar activities with water. This can
cause electric shock or fire.
▪ Do not use the adapter near medical equipment, or
persons using cardiac pacemakers or defibrillators.
This can cause life-threatening electromagnetic
interference.
▪ Do not use the adapter near auto-control equipment
such as automatic doors or fire alarm equipment. This
can cause accidents due to erroneous equipment
behaviour.
▪ In case of abnormal odour or sound, overheating, or
smoke coming out of the adapter, immediately
disconnect the indoor unit from its power supply.
Otherwise, this can lead to fire or malfunction. If this
happens, consult your dealer.
▪ In case you drop or damage the adapter, disconnect
the indoor unit from its power supply. Otherwise, this
can lead to fire or malfunction. If this happens, consult
your dealer.
NOTICE
Do not use the adapter near microwave ovens. This can
affect wireless LAN communications.
