Daikin FTXG25EV1BW Instruction manual

technical data
FTXG-EV1BW_FTXG-EV1BS
Wall Mounted,
Inverter Controlled Unit
air conditioning systems
Split
Sky Air

• Split Sky Air • Indoor Units 1
• Indoor Units • R-410A • FTXG-EV1BW_FTXG-EV1BS
TABLE OF CONTENTS
FTXG-EV1BW_FTXG-EV1BS
1Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
For indoor units only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Dimensional drawing & centre of gravity . . . . . . . . . . . . . . . . . . . . . . . . 5
Dimensional drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Centre of gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4 Piping diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5 Wiring diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Wiring diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6 Sound data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Sound pressure spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

• Indoor Units • R-410A • FTXG-EV1BW_FTXG-EV1BS
1
• Split Sky Air • Indoor Units
2
1 Features
IndoorUnit SplitSky FTXG-EV1BW_FT R-410A • State of the art design: sleek, compact and stylish outlook
• Superb energy efficiency
• Available in 2 colour variations: mat crystal white and mat crystal
silver
• Newly designed air distribution flap prevents draft feeling by
activating the ’comfort mode’
• The new titanium apatite photocatalytic air purification filter increases
the active surface area for effective purification and deodorisation
• Horizontal and vertical auto-swing + 3D-air flow ensure efficient air
and temperature distribution.
• Powerful mode can be selected for rapid cooling or heating
• The movement sensor saves power consumption in unoccupied
rooms
• Indoor unit silent operation: "Silent" button on the remote control
lowers the operation sound of the indoor unit by 3dB(A).
(optional) (5 steps)
(standard)
(integrated
titanium apatite)

3
2
• Split Sky Air • Indoor Units 3
• Indoor Units • R-410A • FTXG-EV1BW_FTXG-EV1BS
2 Specifications
2-1 FOR INDOOR UNITS ONLY FTXG25EV1BW FTXG25EV1BS FTXG35EV1BW FTXG35EV1BS
Nominal Input Cooling kW 0.030 0.030 0.030 0.030
Heating kW 0.030 0.030 0.030 0.030
2-2 TECHNICAL SPECIFICATIONS FTXG25EV1BW FTXG25EV1BS FTXG35EV1BW FTXG35EV1BS
Casing Colour Mat Crystal White Mat Crystal Silver Mat Crystal White Mat Crystal Silver
Dimensions Packing Height mm 345 345 345 345
Width mm 894 894 894 894
Depth mm 222 222 222 222
Unit Height mm 275 275 275 275
Width mm 840 840 840 840
Depth mm 150 150 150 150
Weight Unit kg 9.0 9.0 9.0 9.0
Packed Unit kg 13.0 13.0 13.0 13.0
Heat
Exchanger
Dimensions Length mm 660 660 660 660
Nr of Rows 1 1 1 1
Fin Pitch mm 1.10 1.10 1.10 1.10
Nr of Stages 4 4 4 4
Tube type Grooved tube (7)
Fin Type Slit fin
Fan Type Cross flow fan
Air Flow Rate Cooling High m³/min 7.7 7.7 8.1 8.1
Medium m³/min 6.1 6.1 6.5 6.5
Low m³/min 4.7 4.7 4.9 4.9
Silent
Operation
m³/min 3.8 3.8 4.1 4.1
Heating High m³/min 9.0 9.0 9.6 9.6
Medium m³/min 7.9 7.9 8.2 8.2
Low m³/min 6.7 6.7 6.7 6.7
Silent
Operation
m³/min 5.4 5.4 5.9 5.9
Fan Motor Quantity 1 1 1 1
Model KFD-280-40-8B
Number of steps 5 steps, silent and auto
Motor Speed
(cooling)
High rpm 1400 1400 1470 1470
Medium rpm 1170 1170 1220 1220
Low rpm 940 940 980 980
Silent
Operation
rpm 810 810 850 850
Speed
(heating)
High rpm 1470 1470 1550 1550
Medium rpm 1310 1310 1350 1350
Low rpm 1150 1150 1150 1150
Silent
Operation
rpm 980 980 1040 1040
Fan Motor Output
(high)
W40 40 40 40
Cooling Sound Power High dBA 56.0 56.0 57.0 57.0
Sound
Pressure
High dBA 38.0 38.0 39.0 39.0
Medium dBA 32.0 32.0 33.0 33.0
Low dBA 25.0 25.0 26.0 26.0
Silent
Operation
dBA 22.0 22.0 23.0 23.0
Heating Sound Power High dBA 56.0 56.0 57.0 57.0
Sound
Pressure
High dBA 38.0 38.0 39.0 39.0
Medium dBA 33.0 33.0 34.0 34.0
Low dBA 28.0 28.0 29.0 29.0
Silent
Operation
dBA 25.0 25.0 29.0 29.0
Refrigerant Type R-410A

• Indoor Units • R-410A • FTXG-EV1BW_FTXG-EV1BS
2
• Split Sky Air • Indoor Units
4
2 Specifications
Piping
connections
Liquid (OD) Diameter
(OD)
mm 6.4 6.4 6.4 6.4
Gas Diameter
(OD)
mm 9.5 9.5 9.5 9.5
Drain Diameter
(OD)
mm 18 18 18 18
Heat Insulation Both liquid and gas pipes
Air Filter Removable/washable/Mildew proof
Air direction control Left, right, up and downwards
Temperature control Microcomputer control
Standard
Accessories
Item Installation manual
Quantity 1111
Item Operationmanual Operation manual Operation manual Operation manual
Quantity 1111
Item Infrared remote control
Quantity 1111
Item Batteries
Quantity 2222
Item Remote control holder
Quantity 1111
Item Titanium apatite photocatalytic air purification filter
Quantity 2222
Item Indoor unit fixing screws
Quantity 1111
Item Mounting plate
Quantity 1111
Notes Sound values are measured in an anechoic room.
Sound pressure level is a relative value, depending on the distance and acoustic environment. For more details,
please refer to sound level drawings of this chapter.
The sound power level is an absolute value indicating the power which a sound source generates.
2-3 ELECTRICAL SPECIFICATIONS FTXG25EV1BW FTXG25EV1BS FTXG35EV1BW FTXG35EV1BS
Power Supply Name V1
Phase 1111
Frequency Hz 50 50 50 50
Voltage V 220-240
Current Nominal
running current
(RLA)
Cooling A 0.14 0.14 0.14 0.14
Heating A 0.14 0.14 0.14 0.14
Wiring
connections
For Power
Supply
Quantity 3333
Remark 4 for interunit wiring (included earth wiring)
Voltage range Minimum -10%
Maximum +10%
Power Supply Intake Outdoor unit only
2-2 TECHNICAL SPECIFICATIONS FTXG25EV1BW FTXG25EV1BS FTXG35EV1BW FTXG35EV1BS

3
3
• Split Sky Air • Indoor Units 5
• Indoor Units • R-410A • FTXG-EV1BW_FTXG-EV1BS
3 Dimensional drawing & centre of gravity
3 - 1 Dimensional drawing
3D050494
FTXG25,35E unit (mm)
Left
Rear
Right
The mark (Y) shows piping direction
Intelligent eye lamp
Signal receiver
Bottom Front grille fixing screws
(Inside)
Timer lamp
Operation lamp
Signal transmitter
Infrared remote control
Blade angle
Right/Left
(Automatic)
Air flow (indoor)
(Space for
operation)
Including mounting plate
Name plate
Terminal block with
earth terminal
(Inside)
(space for performance)
(Space for operation)
Liquid pipe 6.4CuT (The length of pipe
outside the unit: about 390).
Gas pipe 9.5Cut (The length of
pipe outside the unit: about 340) Drain hose (connecting part I.D.
J14.0, O.D. J18.0)
(The hose length on the
outside of the unit is
approx. 440)
Wall hole for embedded piping
J65 hole. Wall hole J65 hole
Standard locations of wall holes
Cooling
Up/down (automatic)
Dry
Intelligent eye sensor
Room temp. thermistor (inner)
(ARC433A41)
Rear
Heating
Room temperature thermistor (bottom view)
Earth terminal
(M4 Inside panel)
Operating
state
Indoor unit ON/OFF switch
Up and down wind
direction control blade
movable range
Reduction gear unit fixed screws (inside panel)
(198)
Required space for
installation

• Indoor Units • R-410A • FTXG-EV1BW_FTXG-EV1BS
3
• Split Sky Air • Indoor Units
6
3 Dimensional drawing & centre of gravity
3 - 2 Centre of gravity
4D050964
FTXG25,35E

3
4
• Split Sky Air • Indoor Units 7
• Indoor Units • R-410A • FTXG-EV1BW_FTXG-EV1BS
4 Piping diagram
4D045301B
FTXG25,35E
Indoor unit
Heat exchanger
Cross flow fan
Fan motor
Field piping
Field piping
Refrigerant flow
Thermistor on heat
exchanger
Cooling
Heating

• Indoor Units • R-410A • FTXG-EV1BW_FTXG-EV1BS
5
• Split Sky Air • Indoor Units
8
5 Wiring diagram
5 - 1 Wiring diagram
3D050493
FTXG25,35E
g
Field wiring
Outdoor
Indoor
Infrared remote
control
R: Protective earth
FG : Frame ground
F1U : Fuse
H2P∼H4P : Pilot lamp
M1F : Fan motor
M1S,M2S,M3S : Swing motor
PCB1,PCB2,PCB3 : Printed circuit board
R1T, R2T : Thermistor
S1∼S51 : Connector
S1W : Operation switch
S2W : Panel limit switch
X1M : Terminal strip
E1 : Earth terminal (shield plate)
E2 : Earth terminal (heat. ex)
Signal
receiver
CAUTION
Note that operation will restart
automatically if the main power
supply is turned off and then
back on again.
Intelligent eye
sensor
Rectifier
Transmission
circuit

3
6
• Split Sky Air • Indoor Units 9
• Indoor Units • R-410A • FTXG-EV1BW_FTXG-EV1BS
6 Sound data
6 - 1 Sound pressure spectrum
3D050970
Octave band sound pressure level
dB:(0dB = 0.0002 µbar)
Octave band center frequency (Hz)
FTXG25E (Cooling)
approximate threshold
hearing for continuous
noise
Legend
50/60Hz 220-240/220-230V(H)
50/60Hz 220-240/220-230V(L)
NOTE
1 Operation noise differs with operation and ambient
conditions.
3D050970
Octave band sound pressure level
dB:(0dB = 0.0002 µbar)
Octave band center frequency (Hz)
FTXG25E (Heating)
approximate threshold
hearing for continuous
noise
Legend
50/60Hz 220-240/220-230V(H)
50/60Hz 220-240/220-230V(L)
NOTE
1 Operation noise differs with operation and ambient
conditions.
3D050971
FTXG35E (Cooling)
Octave band sound pressure level
dB:(0dB = 0.0002 µbar)
approximate threshold
hearing for continuous
noise
Octave band center frequency (Hz)
Legend
50/60Hz 220-240/220-230V(H)
50/60Hz 220-240/220-230V(L)
NOTE
1 Operation noise differs with operation and ambient
conditions.
3D050971
FTXG35E (Heating)
Octave band sound pressure level
dB:(0dB = 0.0002 µbar)
approximate threshold
hearing for continuous
noise
Octave band center frequency (Hz)
Legend
50/60Hz 220-240/220-230V(H)
50/60Hz 220-240/220-230V(L)
NOTE
1 Operation noise differs with operation and ambient
conditions.

ISO14001 assures an effective environmental
management system in order to help protect
human•health•and the environment from the potential
impact of our activities, products and services and to
assist in maintaining and improving the quality of
the•environment.
Daikin Europe N.V. is approved by LRQA for its Quality
Management System in accordance with the ISO9001
standard. ISO9001 pertains to quality assurance regarding
design, development, manufacturing as well as to services
related to the product.
Daikin units comply with the European
regulations that guarantee the safety of
the product.
Zandvoordestraat 300
B-8400 Ostend - Belgium
www.daikineurope.com
EEDE06-1/3 • 05/2006 Prepared in Belgium by Lannoo
The present publication is drawn up by way of
information only and does not constitute an offer
binding upon Daikin Europe N.V.. Daikin Europe N.V.
has compiled the content of this publication to the
best of its knowledge. No express or implied warranty
is given for the completeness, accuracy, reliability or
fitness for particular purpose of its content and the
products and services presented therein. Specifications
are subject to change without prior notice. Daikin
Europe N.V. explicitly rejects any liability for any direct
or indirect damage, In the broadest sense, arising from
or related to the use and/or interpretation of this
publication. All content is copyrighted by Daikin
Europe N.V..
ÉEEDE06-1/3ÇËÍ
Split - Sky Air
Daikin Europe N.V. is participating in the
EUROVENT Certification Programme.
Products are as listed in the EUROVENT
Directory of Certified Products.
