DAIKIN ROOM AIR CONDITIONER
Operation Manual
Türkçe
MODELS FTXS20G2V1B FTXS25G2V1B
FTXS35G2V1B FTXS42G2V1B
FTXS50G2V1B
00_CV_3P207037-1.fm Page 1 Tuesday, June 5, 2007 10:38 AM

1
CONTENTS
READ BEFORE OPERATION
Safety precautions ......................................... 2
Names of parts............................................... 4
Preparation before Operation......................... 7
OPERATION
AUTO · DRY · COOL · HEAT · FAN
Operation ..................................................... 10
Adjusting the Airflow Direction ..................... 12
COMFORT AIRFLOW and
INTELLIGENT EYE Operation ..................... 14
POWERFUL Operation ................................ 17
OUTDOOR UNIT QUIET Operation............. 18
ECONO Operation ....................................... 19
TIMER Operation ......................................... 20
WEEKLY TIMER Operation ......................... 22
Note for Multi System................................... 27
CARE
Care and Cleaning ....................................... 29
TROUBLE SHOOTING
Trouble Shooting.......................................... 32
01_EN_3P207037-1.fm Page 1 Monday, September 10, 2007 5:16 PM

2
READ BEFORE OPERATION
Safety precautions
• Keep this manual where the operator can easily find them.
• Read this manual attentively before starting up the unit.
• For safety reason the operator must read the following cautions carefully.
• This manual classifies precautions into WARNINGS and CAUTIONS. Be sure to follow all precau-
tions below: they are all important for ensuring safety.
WARNING
• In order to avoid fire, explosion or injury, do not operate the unit when harmful, among
which flammable or corrosive gases, are detected near the unit.
• It is not good for health to expose your body to the airflow for a long time.
• Do not put a finger, a rod or other objects into the air outlet or inlet. As the fan is rotating at
a high speed, it will cause injury.
• Do not attempt to repair, relocate, modify or reinstall the air conditioner by yourself. Incorrect work
will cause electric shocks, fire etc.
For repairs and reinstallation, consult your Daikin dealer for advice and information.
• The refrigerant used in the air conditioner is safe. Although leaks should not occur, if for
some reason any refrigerant happens to leak into the room, make sure it does not come in
contact with any flame as of gas heaters, kerosene heaters or gas range.
• If the air conditioner is not cooling (heating) properly, the refrigerant may be leaking, so call your dealer.
When carrying out repairs accompanying adding refrigerant, check the content of the repairs with our service staff.
• Do not attempt to install the air conditioner by your self. Incorrect work will result in water leakage,
electric shocks or fire. For installation, consult the dealer or a qualified technician.
• In order to avoid electric shock, fire or injury, if you detect any abnormally such as smell of fire, stop
the operation and turn off the breaker. And call your dealer for instructions.
• Depending on the environment, an earth leakage breaker must be installed. Lack of an earth
leakage breaker may result in electric shocks or fire.
• The air conditioner must be earthed. Incomplete earthing may result in electric shocks. Do
not connect the earth line to a gas pipe, water pipe, lightning rod, or a telephone earth line.
CAUTION
•
In order to avoid any quality deterioration, do not use the unit for cooling precision instru-
ments, food, plants, animals or works of art.
• Never expose little children, plants or animals directly to the airflow.
•
Do not place appliances which produce open fire in places exposed to the airflow from the unit or
under the indoor unit. It may cause incomplete combustion or deformation of the unit due to the heat.
WARNING
If you do not follow these instructions exactly, the unit may
cause property damage, personal injury or loss of life.
CAUTION
If you do not follow these instructions exactly, the unit may
cause minor or moderate property damage or personal injury.
Never do. Be sure to follow the instructions.
Be sure to earth the air conditioner. Never cause the air conditioner (including the
remote controller) to get wet.
Never touch the air conditioner (including the
remote controller) with a wet hand.
01_EN_3P207037-1.fm Page 2 Monday, September 10, 2007 5:16 PM

3
• Do not block air inlets nor outlets. Impaired airflow may result in insufficient performance or trouble.
• Do not stand or sit on the outdoor unit. Do not place any object on the unit to avoid injury, do not
remove the fan guard.
• Do not place anything under the indoor or outdoor unit that must be kept away from moisture. In
certain conditions, moisture in the air may condense and drip.
• After a long use, check the unit stand and fittings for damage.
• Do not touch the air inlet and alminum fins of outdoor unit. It may cause injury.
• The appliance is not intended for use by young children or infirm persons without supervision.
• Young children should be supervised to ensure that they do not play with the appliance.
• To avoid oxygen deficiency, ventilate the room sufficiently if equipment with burner is used
together with the air conditioner.
•
Before cleaning, be sure to stop the operation, turn the breaker off or pull out the supply cord.
• Do not connect the air conditioner to a power supply different from the one as specified. It
may cause trouble or fire.
• Arrange the drain hose to ensure smooth drainage. Incomplete draining may cause wetting of the
building, furniture etc.
• Do not place objects in direct proximity of the outdoor unit and do not let leaves and other debris
accumulate around the unit.
Leaves are a hotbed for small animals which can enter the unit. Once in the unit, such animals can
cause malfunctions, smoke or fire when making contact with electrical parts.
• Do not operate the air conditioner with wet hands.
• Do not wash the indoor unit with excessive water, only use a slightly wet cloth.
•
Do not place things such as vessels containing water or anything else on top of the unit. Water
may penetrate into the unit and degrade electrical insulations, resulting in an electric shock.
■To install the air conditioner in the following types of environments, consult the dealer.
• Places with an oily ambient or where steam or soot occurs.
• Salty environment such as coastal areas.
• Places where sulfide gas occurs such as hot springs.
• Places where snow may block the outdoor unit.
The drain from the outdoor unit must be discharged to a place of good drainage.
■For installation, choose a place as described below.
•
A place solid enough to bear the weight of the unit which does not amplify the operation noise or vibration.
• A place from where the air discharged from the outdoor unit or the operation noise will not annoy
your neighbours.
• For power supply, be sure to use a separate power circuit dedicated to the air conditioner.
• Relocating the air conditioner requires specialized knowledge and skills. Please consult the
dealer if relocation is necessary for moving or remodeling.
Installation site.
Consider nuisance to your neighbours from noises.
Electrical work.
System relocation.
01_EN_3P207037-1.fm Page 3 Monday, September 10, 2007 5:16 PM

4
Names of parts
■Indoor Unit
16 14
13
15
12
134
5
7
91110
8
6
2
01_EN_3P207037-1.fm Page 4 Monday, September 10, 2007 5:16 PM

5
■Outdoor Unit
■
Indoor Unit
1. Air filter
2. Titanium Apatite Photocatalytic
Air-Purifying Filter:
• These filters are attached to the inside of
the air filters.
3. Air inlet
4. Front panel
5. Panel tab
6. Room temperature sensor:
• It senses the air temperature around the
unit.
7. INTELLIGENT EYE sensor: (page 14.)
8. Display
9. Air outlet
10. Horizontal blades (flaps): (page 12.)
11. Vertical blades (louvers):
• The louvers are inside of the air outlet.
(page 12.)
12. Indoor Unit ON/OFF switch: (page 10.)
• Push this switch once to start operation.
Push once again to stop it.
• The operation mode refers to the following
table.
• This switch is useful when the remote
controller is missing.
13. Operation lamp (green)
14. TIMER lamp (yellow): (page 20.)
15.
INTELLIGENT EYE lamp (green): (page 14.)
16. Signal receiver:
•
It receives signals from the remote controller.
• When the unit receives a signal, you will
hear a short beep.
• Operation start ........ beep-beep
• Settings changed ..... beep
• Operation stop.......... beeeeep
■
Outdoor Unit
17. Air inlet: (Back and side)
18. Refrigerant piping and inter-unit cable
19. Drain hose
20. Earth terminal:
• It is inside of this cover.
21. Air outlet
20/25/35/42 class 50 class
18
19
20
21
17
18
19
20
21
17
Model
Mode Temperature
setting
Airflow
rate
COOLING
ONLY
COOL
22°C AUTO
HEAT
PUMP
AUTO
25°C AUTO
01_EN_3P207037-1.fm Page 5 Monday, September 10, 2007 5:16 PM

6
■Remote Controller
1. Signal transmitter:
• It sends signals to the indoor unit.
2. Display:
• It displays the current settings.
(In this illustration, each section is shown
with all its displays ON for the purpose of
explanation.)
3. FAN setting button:
• It selects the airflow rate setting.
4. POWERFUL button:
POWERFUL operation (page 17.)
5. ON/OFF button:
• Press this button once to start operation.
Press once again to stop it.
6. TEMPERATURE adjustment buttons:
• It changes the temperature setting.
7. MODE selector button:
• It selects the operation mode.
(AUTO/DRY/COOL/HEAT/FAN) (page 10.)
8. QUIET button:
OUTDOOR UNIT QUIET operation (page 18.)
9. ECONO button:
ECONO operation (page 19.)
10. SWING button:
• Horizontal blades (flaps) (page 12.)
11. SWING button:
• Vertical blades (louvers) (page 12.)
12. COMFORT/SENSOR button:
• COMFORT AIRFLOW and INTELLIGENT
EYE operation (page 14.)
13. WEEKLY/PROGRAM/COPY/BACK/NEXT
button:
• WEEKLY TIMER operation (page 22.)
14. SELECT button:
• It changes the ON/OFF TIMER and
WEEKLY TIMER settings. (page 20, 22.)
15. OFF TIMER button: (page 20.)
16. ON TIMER button: (page 21.)
17. TIMER CANCEL button:
• It cancels the timer setting. (page 20, 21.)
• It cannot be used for the WEEKLY TIMER
operation.
18. CLOCK button: (page 8.)
1
5
6
2
3
4
<ARC452A3>
7
8
13
14
15
17
<Open the front cover>
109
11
12
16
18
01_EN_3P207037-1.fm Page 6 Monday, September 10, 2007 5:16 PM

7
Preparation before Operation
■To set the batteries
1. Slide the front cover to take it off.
2. Set two dry batteries (LR03·AAA).
3. Set the front cover as before.
■To operate the remote controller
• To use the remote controller, aim the transmitter at the indoor
unit. If there is anything to block signals between the unit and
the remote controller, such as a curtain, the unit will not
operate.
• Do not drop the remote controller. Do not get it wet.
• The maximum distance for communication is about 7m.
■To fix the remote controller holder
on the wall
1.
Choose a place from where the signals reach the unit.
2. Fix the holder to a wall, a pillar, or similar
location with the screws procured locally.
3. Place the remote controller in the remote
controller holder.
ATTENTION
■
About batteries
• When replacing the batteries, use batteries of the same type, and replace the two old batteries together.
• When the system is not used for a long time, take the batteries out.
• The batteries will last for approximately one year. If the remote controller display begins to
fade and the degradation of reception performance occurs within a year, however, replace
both two batteries with new size AAA alkaline batteries.
• The attached batteries are provided for the initial use of the system.
The usable period of the batteries may be short depending on the manufactured date of the air conditioner.
■
About remote controller
• Never expose the remote controller to direct sunlight.
• Dust on the signal transmitter or receiver will reduce the sensitivity. Wipe off dust with soft cloth.
• Signal communication may be disabled if an electronic-starter-type fluorescent lamp (such
as inverter-type lamps) is in the room. Consult the shop if that is the case.
• If the remote controller signals happen to operate another appliance, move that appliance
to somewhere else, or consult the shop.
2
3
1
Position +and
– correctly!
Receiver
Remote
controller
holder
Set.
• To remove, pull it
upwards.
01_EN_3P207037-1.fm Page 7 Monday, September 10, 2007 5:16 PM

8
Preparation before Operation
■To set the clock
1. Press “CLOCK button”.
is displayed.
and blinks.
2. Press “SELECT button” to set
the current day of the week.
3. Press “CLOCK button”.
blinks.
4. Press “SELECT button” to set
the clock to the present time.
Holding down “ ” or “ ” button
rapidly increases or decreases the time
display.
5. Press “CLOCK button”.
Always point the remote controller at the
indoor unit when pushing the buttons
when setting the indoor unit’s internal
clock.
blinks.
NOTE
• If the indoor unit’s internal clock is not set to the correct time, the WEEKLY TIMER will not
operate punctually.
1, 3, 5
2, 4
01_EN_3P207037-1.fm Page 8 Monday, September 10, 2007 5:16 PM

9
■Turn the breaker ON
• Turning ON the breaker opens once and closes the flaps. (This is a normal procedure.)
■Checks on Remote Controller Settings
• This remote controller is common to the heat pump model
and cooling only model. Use the dipswitches on the remote
controller to set the heat pump model or cooling only model.
• Refer to the following explanation and make the setting as
shown in the illustration.
• For customers of Heat pump model: Set to H/P
• For customers of Cooling-only model: Set to C/O
NOTE
■
Tips for saving energy
• Be careful not to cool (heat) the room too much.
Keeping the temperature setting at a moderate level helps save energy.
• Cover windows with a blind or a curtain.
Blocking sunlight and air from outdoors increases the cooling (heating) effect.
• Clogged air filters cause inefficient operation and waste energy.
Clean them once in about every two weeks.
■
Please note
• The air conditioner always consumes 15-35 watts of electricity even while it is not operating.
•
If you are not going to use the air conditioner for a long period, for example in spring or autumn, turn the breaker OFF.
• Use the air conditioner in the following conditions.
•The operation of the system outside the above humidity or temperature range may cause a
safety device to disable the system.
H/P C/O
Dipswitches
Recommended temperature setting
For cooling:26°C – 28°C
For heating:20°C – 24°C
Mode Operating conditions If operation is continued out of this range
COOL Outdoor temperature: 〈 2MK(X)S 〉 10 to 46°C
〈3/4/5MK(X)S〉 –10 to 46°C
〈RK(X)S〉 –10 to 46°C
Indoor temperature: 18 to 32°C
Indoor humidity: 80% max.
• A safety device may work to stop the operation.
(In multi system, it may work to stop the operation of
the outdoor unit only.)
• Condensation may occur on the indoor unit and drip.
HEAT Outdoor temperature: 〈2/3/4/5MXS〉 –15 to 20°C
〈RXS〉 –15 to 20°C
Indoor temperature: 10 to 30°C
• A safety device may work to stop the operation.
DRY Outdoor temperature: 〈 2MK(X)S 〉 10 to 46°C
〈3/4/5MK(X)S〉 –10 to 46°C
〈RK(X)S〉 –10 to 46°C
Indoor temperature: 18 to 32°C
Indoor humidity: 80% max.
• A safety device may work to stop the operation.
• Condensation may occur on the indoor unit and drip.
01_EN_3P207037-1.fm Page 9 Monday, September 10, 2007 5:16 PM

10
OPERATION
AUTO · DRY · COOL · HEAT · FAN Operation
The air conditioner operates with the operation
mode of your choice.
From the next time on, the air conditioner will
operate with the same operation mode.
■To start operation
1. Press “MODE selector button”
and select a operation mode.
• Each pressing of the button advances
the mode setting in sequence.
:AUTO
:DRY
: COOL
:HEAT
:FAN
2. Press “ON/OFF button”.
• The OPERATION lamp lights up.
■To stop operation
3. Press “ON/OFF button” again.
• Then OPERATION lamp goes off.
■To change the temperature setting
4. Press “TEMPERATURE adjustment button”.
DRY or FAN mode AUTO or COOL or HEAT mode
The temperature setting is not variable.
Press “ ” to raise the temperature and press
“ ” to lower the temperature.
Set to the temperature you like.
1
5
2, 3
4
Cooling only
model
Heat pump
model
01_EN_3P207037-1.fm Page 10 Monday, September 10, 2007 5:16 PM

11
■To change the airflow rate setting
5. Press “FAN setting button”.
• Indoor unit quiet operation
When the airflow is set to “ ”, the noise from the indoor unit will become quieter.
Use this when making the noise quieter.
NOTE
DRY mode AUTO or COOL or HEAT or FAN mode
The airflow rate setting is not variable.
Five levels of airflow rate setting from “ ” to “ ”
plus “ ” “ ” are available.
■
Note on HEAT operation
• Since this air conditioner heats the room by taking heat from outdoor air to indoors, the heating
capacity becomes smaller in lower outdoor temperatures. If the heating effect is insufficient, it
is recommended to use another heating appliance in combination with the air conditioner.
• The heat pump system heats the room by circulating hot air around all parts of the room.
After the start of heating operation, it takes some time before the room gets warmer.
• In heating operation, frost may occur on the outdoor unit and lower the heating capacity. In
that case, the system switches into defrosting operation to take away the frost.
• During defrosting operation, hot air does not flow out of indoor unit.
• A pinging sound may be heard during defrosting operation, which, however does not mean
that the air conditioner has failures.
■
Note on COOL operation
• This air conditioner cools the room by blowing the hot air in the room outside, so if the
outside temperature is high, the performance of the air conditioner drops.
■
Note on DRY operation
• The computer chip works to rid the room of humidity while maintaining the temperature as
much as possible. It automatically controls temperature and airflow rate, so manual
adjustment of these functions is unavailable.
■
Note on AUTO operation
• In AUTO operation, the system selects a temperature setting and an appropriate operation
mode (COOL or HEAT) based on the room temperature at the start of the operation.
• The system automatically reselects setting at a regular interval to bring the room
temperature to user-setting level.
• If you do not like AUTO operation, manually change the set temperature.
■
Note on airflow rate setting
• At smaller airflow rates, the cooling (heating) effect is also smaller.
01_EN_3P207037-1.fm Page 11 Monday, September 10, 2007 5:16 PM

12
Adjusting the Airflow Direction
You can adjust the airflow direction to increase
your comfort.
■To adjust the horizontal
blades (flaps)
1. Press “SWING button ”.
• “ ” is displayed on the LCD and the
flaps will begin to swing.
2. When the flaps have reached
the desired position,
press “SWING button ”
once more.
• The flaps will stop moving.
• “ ” disappears from the LCD.
■To adjust the vertical
blades (louvers)
3. Press “SWING button ”.
• “ ” is displayed on the LCD.
4. When the louvers have reached the desired position, press the
“SWING button ” once more.
• The louvers will stop moving.
• “ ” disappears from the LCD.
1, 2
3, 4
01_EN_3P207037-1.fm Page 12 Monday, September 10, 2007 5:16 PM

13
■To start 3-D Airflow
1. 3. Press the “SWING button ” and the “SWING button ”:
the “ ” and “ ” display will light up and the flap and louvers will
move in turn.
■To cancel 3-D Airflow
2. 4. Press either the “SWING button ” or the “SWING button ”.
■COMFORT AIRFLOW operation
• Check COMFORT AIRFLOW operation in the section of “COMFORT AIRFLOW Operation”
and “INTELLIGENT EYE Operation”. (page 14.)
Notes on flaps and louvers angles
• When “SWING button” is selected, the flaps
swinging range depends on the operation
mode. (See the figure.)
Three-Dimensional (3-D) Airflow
• Using three-dimensional airflow circulates
cold air, which tends to collected at the bottom
of the room, and hot air, which tends to collect
near the ceiling, throughout the room,
preventing areas of cold and hot developing.
■
ATTENTION
• Always use a remote controller to adjust the
angles of the flaps and louvers. If you
attempt to move it forcibly with hand when it
is swinging, the mechanism may be broken.
• Always use a remote controller to adjust the
louvers angles. In side the air outlet, a fan is
rotating at a high speed.
5˚
80˚
5˚
15˚
50˚
80˚
30˚
70˚
In DRY mode or
COOL mode
Upper limit
COMFORT AIRFLOW
(page 14.)
COMFORT AIRFLOW (page 14.)
Lower limit
Stop operation
Upper limit
Lower limit
Upper limit
Lower limit
In HEAT mode
In FAN mode
Stop operation
Stop operation
01_EN_3P207037-1.fm Page 13 Monday, September 10, 2007 5:16 PM

14
COMFORT AIRFLOW and
INTELLIGENT EYE Operation
The INTELLIGENT EYE incorporates infrared
sensors to detect the presence of people in the
conditioned room.
When these sensors detect people, the louvers
will adjust the airflow direction to an area where
people are not present. When there are no people
in the sensing areas, the air conditioner will go
into energy-saving mode.
■To start operation
1. Press “COMFORT/SENSOR
button” and select an
operation mode.
• Choose the desired operation mode
out of the following sequence.
• Each time the “COMFORT/SENSOR
button” is pressed a different setting
option is displayed on the LCD.
■To cancel operation
2. Press “COMFORT/SENSOR
button”.
• Press the button to select “Blank”.
Display Operation mode Explanation
COMFORT AIRFLOW
The flaps will adjust the airflow direction upward
while cooling, and adjust the airflow direction
downward while heating. (page 15.)
INTELLIGENT EYE
The sensors will detect the movement of people
in the sensing areas and the louvers will adjust
the airflow direction to an area where people are
not present. When there are no people in the
sensing areas, the air conditioner will go into
energy-saving mode. (page 15.)
COMFORT AIRFLOW and
INTELLIGENT EYE
The air conditioner will be in COMFORT
AIRFLOW operation combined with
INTELLIGENT EYE operation. (page 16.)
Blank No function –
1, 2
Blank
01_EN_3P207037-1.fm Page 14 Monday, September 10, 2007 5:16 PM

15
Notes on “COMFORT AIRFLOW Operation”
Notes on “INTELLIGENT EYE Operation”
•
The flap position will change, preventing air from blowing directly on the occupants of the room.
•
POWERFUL operation and COMFORT AIRFLOW operation cannot be used at the same time.
• The volume of air will be set to AUTO. If the upward and downward airflow direction is
selected, the COMFORT AIRFLOW function will be canceled.
• Priority is given to the function of whichever button is pressed last.
• The COMFORT AIRFLOW function makes the following airflow direction adjustments.
The flaps will move upward while cooling so that the airflow will be directed upward.
The flaps will move downward while heating so that the airflow will be directed downward.
• The INTELLIGENT EYE sensor according to the following situations.
Cooling operation Heating operation
90˚
55˚ 55˚
Horizontal angle 110˚
(Top View)
Vertical angle 90˚
(Side View)
5m
5m
A person is detected in
area 1.
A person is detected in
area 2.
No people are detected in
any areas.
People are detected in
any areas.
* The wind direction may differ from the
illustrated direction depending on the actions
and movements of the people in the areas.
(Use the INTELLIGENT EYE
Operation in combination with the
COMFORT AIRFLOW Operation.)
The air conditioner will go into
energy-saving mode after 20 minutes.
Area 1 Area 2
Area 1 Area 2
Area 1 Area 2
01_EN_3P207037-1.fm Page 15 Monday, September 10, 2007 5:16 PM

16
COMFORT AIRFLOW and
INTELLIGENT EYE Operation
Notes on “INTELLIGENT EYE Operation”
“INTELLIGENT EYE” is useful for Energy Saving
■To combine “COMFORT AIRFLOW Operation” and
“INTELLIGENT EYE Operation”
CAUTION
• While the air conditioner is in INTELLIGENT EYE operation, the louvers will adjust the
airflow direction if there are people in the sensing areas of the INTELLIGENT EYE so that
the leftward or rightward airflow will not be directed to the people.
If no people are detected in either area 1 or 2 in 20 minutes, the air conditioner will go into
energy-saving mode with the set temperature shifted by 2°C.
The air conditioner may go into energy-saving operation though there are people in the
areas. This may occur depending on the clothes of the people or if there are no movements
of the people in the areas.
•
The airflow direction from the louvers will be leftward if there are people in both areas 1 and 2 or if there
is a person right in front of the sensors because the sensors on the both sides will detect the person.
•
Due to the position of the sensor, people will be exposed to the wind of the indoor unit if they
are close to the front side of the indoor unit.
If there are people close to the front side of the indoor unit or in both areas, it is recommended
to use the COMFORT AIRFLOW and INTELLIGENT EYE functions simultaneously. When
both of them are in use, the air conditioner will not direct the airflow towards the people.
• Sensor may not detect moving objects further than 5m away. (Check the application range)
• Sensor detection sensitivity changes according to indoor unit location, the speed of
passersby, temperature range, etc.
• The sensor also mistakenly detects pets, sunlight, fluttering curtains and light reflected off of
mirrors as passersby.
• NIGHT SET MODE (page 20.) will not go on during use of INTELLIGENT EYE operation.
■
Energy saving operation
• Change the temperature –2°C in heating / +2°C in cooling / +2°C in dry mode from set temperature.
• Decrease the airflow rate slightly in FAN mode only. If no presence detected in the room for
20 minutes.
• The air conditioner can go into operation with the COMFORT AIRFLOW and INTELLIGENT
EYE functions combined.
The flaps adjust the airflow direction upward (while in cooling operation) and downward
(while in heating operation), during which the sensors of the INTELLIGENT EYE are working
to detect the movement of people. When the sensors detect people, the louvers will direct
the airflow such it will not be blown directly on them. If there are no people, the air
conditioner will go into energy-saving operation in 20 minutes.
• Do not place large objects near the sensor.
Also keep heating units or humidifiers outside the sensor’s detection area. This sensor can
detect undesirable objects.
•
Do not hit or violently push the INTELLIGENT EYE sensor. This can lead to damage and malfunction.
01_EN_3P207037-1.fm Page 16 Monday, September 10, 2007 5:16 PM

17
POWERFUL Operation
POWERFUL operation quickly maximizes the
cooling (heating) effect in any operation mode.
You can get the maximum capacity.
■To start POWERFUL
operation
1. Press “POWERFUL button”.
• POWERFUL operation ends in
20minutes. Then the system
automatically operates again with the
previous settings which were used
before POWERFUL operation.
• “ ” is displayed on the LCD.
• When using POWERFUL operation,
there are some functions which are
not available.
■To cancel POWERFUL
operation
2. Press “POWERFUL button”
again.
• “ ” disappears from the LCD.
NOTE
■
Notes on POWERFUL operation
• POWERFUL Operation cannot be used together with ECONO, QUIET, or COMFORT
Operation.
Priority is given to the function of whichever button is pressed last.
• POWERFUL Operation can only be set when the unit is running. Pressing the operation
stop button causes the settings to be canceled, and the “ ” disappears from the LCD.
• In COOL and HEAT mode
To maximize the cooling (heating) effect, the capacity of outdoor unit must be increased
and the airflow rate be fixed to the maximum setting.
The temperature and airflow settings are not variable.
• In DRY mode
The temperature setting is lowered by 2.5°C and the airflow rate is slightly increased.
• In FAN mode
The airflow rate is fixed to the maximum setting.
• When using priority-room setting
See “Note for Multi System”. (page 27.)
1, 2
01_EN_3P207037-1.fm Page 17 Monday, September 10, 2007 5:16 PM

18
OUTDOOR UNIT QUIET Operation
OUTDOOR UNIT QUIET operation lowers the
noise level of the outdoor unit by changing the
frequency and fan speed on the outdoor unit.
This function is convenient during night.
■To start OUTDOOR
UNIT QUIET operation
1. Press “QUIET button”.
• “ ” is displayed on the LCD.
■To cancel OUTDOOR
UNIT QUIET operation
2. Press “QUIET button” again.
• “ ” disappears from the LCD.
NOTE
■
Note on OUTDOOR UNIT QUIET operation
• If using a multi system, this function will work only when the OUTDOOR UNIT QUIET
operation is set on all operated indoor units.
However, if using priority-room setting, see “Note for Multi System”. (page 27.)
• This function is available in COOL, HEAT, and AUTO modes.
(This is not available in FAN and DRY mode.)
• POWERFUL operation and OUTDOOR UNIT QUIET operation cannot be used at the
same time.
Priority is given to the function of whichever button is pressed last.
1, 2
01_EN_3P207037-1.fm Page 18 Monday, September 10, 2007 5:16 PM

19
ECONO Operation
ECONO operation is a function which enables
efficient operation by limiting the maximum power
consumption value.
This function is useful for cases in which attention
should be paid to ensure a circuit breaker will not
trip when the product runs alongside other
appliances.
■To start ECONO
operation
1. Press “ECONO button”.
• “ ” is displayed on the LCD.
■To cancel ECONO
operation
2. Press “ECONO button” again.
• “ ” disappears from the LCD.
• This diagram is a representation for illustrative purposes only.
* The maximum running current and power consumption of the air conditioner in ECONO
mode vary with the connecting outdoor unit.
NOTE
• ECONO Operation can only be set when the unit is running. Pressing the OFF button
causes the setting to be canceled, and the “ ” disappears from the LCD.
• ECONO operation is a function which enables efficient operation by limiting the power
consumption of the outdoor unit (operating frequency).
• ECONO operation functions in AUTO, COOL, DRY and HEAT modes.
• POWERFUL and ECONO operation cannot be used at the same time.
Priority is given to the function of whichever button is pressed last.
• Power consumption may not drop even if ECONO operation is used of the level of power
consumption is already low.
1, 2
Running current and
power consumption
From start up until set
temperature is reached
Time
Maximum during
normal operation
Maximum during
ECONO Mode
Normal
operation
ECONO
Mode
01_EN_3P207037-1.fm Page 19 Monday, September 10, 2007 5:16 PM
