Daikin 669529101 Instruction Manual

Installation & Maintenance Data
MicroTech™ III Water Source Heat Pump Wall-Mounted
Room Temperature Sensors
Sensor Kit P/N 669529101, 669529201 & 669529001
Group: WSHP
Part Number: 910144730
Date: October 2013
IM 955-3
Sensor 669529101 Sensor 669529201 Sensor 669529001
©2013 Daikin Applied • www.DaikinAP.com • 800.432.1342

Page 2 of 6 / IM 955-3
Sensor Specications
• Thermistorresistance(10kΩ)
 (ConformstoAdvanceThermalProductscurve2)
• AmbientTemperatureLimits:
• ShippingandStorage:40°Fto160°F(–40°Cto71°C)
• Operating:40°Fto140°F(4°Cto60°C)
• Humidity:5to95%RH,noncondensing
• Locations:NEMAType1,Indooronly
• Connections:ColorCodedLeads
Introduction
MicrotechIIIWallMountedRoomTemperatureSensors
provideelectronicsensingofroomtemperaturesatwall
locations.Allsensormodelsfeatureathermistor(10kΩ),a
greenLEDforunitstatusandtenantoverridebutton.Setpoint
adjustmentpotentiometer,heatandfanmodeswitchesare
optionalfeatures(seeTable1).
Thismanualincludesinstallationinstructionsandgeneral
informationforaMicrotechIIIWallMountedRoomTem-
peratureSensor.
Forinstallationandcommissioninginstructionsandgeneral
informationonaparticularunit,refertoitsmodel-specic
installationmanual.
Table 1: MicroTech III Sensor Kits – Water Source Heat Pump (10 kW)
Sensor Kit P/N Tenant Override Button SPT Adj. Pot Status LED Fan and Mode Switches
669529001 Yes No Yes No
669529101 Yes Yes Yes Yes 55ºto 95ºF (12ºto 35ºC)
669529201 Yes Yes Yes Yes -3ºto +3ºF (-1.5º to +1.5ºC)
Contents
Introduction ..........................................................................2
Sensor Specications .........................................................2
Pre-Installation.....................................................................3
Inspection .........................................................................3
Required Installation Items: ..............................................3
Wiring ................................................................................3
Mounting Location ............................................................3
Installation ............................................................................3
Utility Box Mounting of Sensor 669529001.......................4
Wiring ...................................................................................4
Temperature Sensors 669529101 & 669529201 .............4
Temperature Sensor 669529001 ......................................4
Testing ..................................................................................4
Temperature Sensors 669529101 & 669529201 ..............4
Temperature Sensor – 669529001 ...................................5
Operating Modes .................................................................5
Temperature Sensors 669529101 & 669529201 ..............5
All Temperature Sensors .................................................5
Troubleshooting ..................................................................6

IM 955-3 / Page 3 of 6
Pre-Installation
Inspection
Visuallyinspectthecartonfordamages.Ifitisdamaged,
notifytheappropriatecarrierimmediately.
Openthecartonandvisuallyinspectthedeviceforobvious
defects.Returndamagedordefectiveproducts.
Required Installation Items:
• WiringdiagramforMicroTechIIIUnitController
Tools
 ■ Appropriatescrewdriver(s)forcover,terminals,and
mountingscrews
 ■ Wirestripper/cutter
The following only if wallboard mounting:
 ■ Appropriatedrillanddrillbits
 ■ Appropriatemountingscrewsandplasticanchors
Wiring
3-leadNECClassIIlowvoltagewiringfortemperaturesen-
sor669529001,5-leadforsensor669529101and669529201.
Notes: 1.Do not install the wire cables in the same conduit
with power wiring.
2.Never apply external voltage of any type to any
terminal or damage will result.
3.Do not exceed ratings of the device. This is a low
voltage device:
4.Always use 22-gauge wire and never locate the
room temperature sensor more than 250' from the
unit:
WiringmustbeinstalledinaccordancewiththeNational
ElectricalCodeandalllocalcodesandordinances,whichcan
requiretheuseofplenumratedcableorconduit.
Mounting Location
Locatethesensoronawallwhereexposuretounrestrictedair
circulationrepresentstheaveragetemperatureofthespace.A
commonmistakeistomountthesensortooclosetothesup-
plyairdiffuserinaroom.Thiscausesshortcyclingoftheair
conditioningunitandlargeroomtemperatureswings.
Installation
DANGER
Hazardous Voltage!
This equipment presents hazards of electricity.
Failure to read and follow these instructions can re-
sult in property damage, severe personal injury or
death.
1. Turnoffpoweratthemainservicepanelbyremovingthe
fuseorswitchingtheappropriatecircuitbreakertothe
OFFposition.
2. Removethesensorcoverbyinsertingascrewdriverand
gentlytwistingitintheslotsonthesidesofthewall
temperaturesensor(669529101&669529201only).
Toremovethecoveronsensor669529001,loosentwo
allen-wrenchsetscrewslocatedontheundersideofthe
cover.
Note: Mountthesensorvefeetabovetheoor.Donot
mount the sensor on an outside wall, in direct sunlight,
behind a door, or in an area affected by a vent or duct.
3. Placethewallsensormountingbaseagainstthewall
wherethesensorwherebelocated.Usingthebaseasa
templatetracethemountingholesontothewall.
4. Drilla3/16"holeateachmountingholemark.
5. Insertwallanchorsintomountingholesandtapintothe
wallsurface.
6. Feedwiresthroughthebackofthesensormountingbase
andalignsensormountingholeswithwallanchors.
7. Usesuppliedscrewstosecuresensorbasetowall.
CAUTION
Be certain that exposed portions of wires do not come in contact
with each other.
8. Connectstripped,labeledwirestomatchingterminalson
thetemperaturesensor.RefertoeitherFigure1orFigure
2onpage4forwiringdetails.
9. Tightenscrewsonterminalconnections.Gentlytugwire
tocheckforsecureconnections.Conrmthateachwire
isconnectedtotheproperterminal.
10. Sealtheholewherethewireentersthroughthewall
behindthetemperaturesensor,withnon-ammable
insulationorputty.
11. Replacecoveronwalltemperaturesensorbysnappingit
inplace.
12. Turnonpowertothesystematthemainservicepanel
13. Testwalltemperaturesensoroperationasdescribedin
"Testing"onpage4.
Note: Sensor 669529001 has two allen wrench set-screws
on the underside of the sensor cover to secure it in
place. Do not overtighten.

Page 4 of 6 / IM 955-3
Utility Box Mounting of Sensor 669529001
1. Feedthecablefromtheutilitybox.
2. Strip1/4–inchofinsulationfromtheendofthewires.
3. Connectstripped,labeledwirestomatchingterminalson
thetemperaturesensorbase.SeeFigure2.
4. Tightenscrewsonterminalconnections.Gentlytugwire
tocheckforsecureconnections.Conrmthateachwire
isconnectedtotheproperterminal.
5. Neatlystoreexcesswirebackinsidetheutilitybox.
6. Mountthesensorbasetotheutilityboxusingtwo6-32×
5/8–inchatheadsheetmetalscrews
providedwiththesensor.
7. Replacecoveronwalltemperaturesensorbyattaching
thecatchesatthetopofthecovertothetoptabsonthe
sensorbase.Securethecovertothebasebytightening
thetwoallenwrenchset-screwsonthebottomofthe
sensorcover.Donotovertighten.
Wiring
Temperature Sensors 669529101 &
669529201
Note: All sensors have black (common), white (thermistor),
and red (LED) wires. With the tenant override and/or
set point adjustment option, a green wire is provided.
The optional thermometer does not affect wiring.
Figure 1: Temperature Sensor Wiring to MicroTech III Unit
Controller
Temperature
Sensor Terminals
MicroTech III Unit Con-
troller TB1 Terminals
Temperature Sensor 669529001
Figure 2: Temperature Sensor Wiring to MicroTech III Unit
Controller
MicroTech III Unit Con-
troller TB1 Terminals
Temperature
Sensor Terminals
Testing
Temperature Sensors 669529101 &
669529201
Cool Test
1. SlideModeswitchtoCoolmode.
2. Adjustsettemperaturesoitis5degreesbelowroom
temperature.
3. Airconditioningshouldcomeonwithinve(5)minutes.
Statusindicatormaycomeon.
4. Adjustthesettemperature2degreesabovetheroom
temperatureandtheA/Cshouldturnoff.Theremaybea
fandelayonyoursystem.
Heat Test
1. SlideModeswitchtoHeatmode.
2. Adjustthesettemperaturesoitis5degreesabovethe
roomtemperature.
3. Heatshouldcomeonwithinve(5)minutes.Status
indicatormaycomeon.
4. Adjustthesettemperaturesoitis2degreesbelowthe
roomtemperatureandtheheatshouldturnoff.There
maybeafandelayonyoursystem.
Fan Test
1. Setroomtemperaturesothatunitisnolongerheatingor
coolingthespace.Waitforunittocycleoff.
2. SlideFanswitchtoOnposition.
3. Indoorfanturnson.
4. SlideFanswitchtoAutoposition.
5. Indoorfanturnsoff.

IM 955-3 / Page 5 of 6
Timed Override Button Test
1. UsingtheBMS,changetheroomsettingssotheunitisin
Unoccupiedmode.
2. Presstheroomsensormountedoverridepushbuttonfor
morethan3secondsandlessthan10seconds.
3. UnitwillresumeOccupiedoperationuntiltheoverride
timeexpires(asprogrammedinBMS).
4. UsingtheBMS,returntheunittoregularschedule.
Figure 3: MicroTech III Wall Sensor 669529101 (669529201
- Similar)
Fan Control
Slide Switch
Mode Control
Slide Switch
Status LED
(Green)
0 to 1.5 K ohm
Potentiometer
Tenant Override
Momentary Push Button Switch
4.59"
3.75"
Temperature Sensor – 669529001
Cool Test
1. Usingthebuildingautomationsystem(BMS),adjust
roomcoolingsetpointto5degreesbelowroom
temperature.
2. Airconditioningshouldcomeonwithinve(5)minutes.
Statusindicatormaycomeon.
3. UsingtheBMS,adjustthesettemperature2degrees
abovetheroomtemperatureandtheA/Cshouldturnoff.
Theremaybeafandelayonyoursystem.
Heat Test
1. Usingthebuildingautomationsystem(BMS),adjust
roomheatingsetpointto5degreesaboveroom
temperature.
2. Heatingshouldcomeonwithinve(5)minutes.Status
indicatormaycomeon.
3. UsingtheBMS,adjustthesettemperature2degrees
abovetheroomtemperatureandtheA/Cshouldturnoff.
Theremaybeafandelayonyoursystem.
Table 2: WSHP Unit Status LED Denitions
Status LED Unit Status Unit Operation
ON OFF
0.5 seconds 0.5 seconds
Controller Off
(or Network “Wink”
operation active)
“Alarm”
0.0 seconds Continuous
Unit running in Night
Setback Override
Mode or no power to
the sensor
“Override”
0.5 seconds 5.5 seconds Unoccupied Mode “Unoccupied”
5.5 seconds 0.5 seconds Standby Mode
“Energy Save” or
“Load Shed” com-
mand from Energy
Management System
Continuous 0.0 seconds Occupied Mode “Occupied”
Figure 4: MicroTech III Wall Sensor
3.28"
4.5"
Operating Modes
Temperature Sensors 669529101 & 669529201
Cool Mode
■ IncoolmodetheMicroTechIIIwall-mounted
temperaturesensorcontrolsthecoolingsystem
Heat Mode
■ Inheatmode,theMicrotechIIIwall-mountedRoom
TemperatureSensorscontrolstheheatingsystem.
Auto-changeover Mode
■ InthismodetheMicrotechIIIwall-mountedRoom
TemperatureSensorswillautomaticallychangefromheat
modetocoolmode,orviceversa.
All Temperature Sensors
Timed Override
■ PressOverridebuttonformorethan3butlessthan10
secondsandUnitwillreturntoOccupiedoperationuntil
theoverridetimeexpires(asprogrammedinBMS).

Troubleshooting
Symptom Remedy
No LED illuminated Check for 5 VDC at sensor, LED is
dark when 5 VDC is not present
Unit turns on and off too frequently
Sensor must be located as de-
scribed in "Mounting Location" on
page 3.
For Sensors 669529101 and 669529201 Only
System fan does not come on
properly
Verify wiring is correct. See "Fan
Test" on page 4.
Fan runs continuously Check fan On/Off switch, ON posi-
tion runs indoor fan continuously.
Daikin Training and Development
Now that you have made an investment in modern, efficient Daikin equipment, its care should
be a high priority. For training information on all Daikin HVAC products, please visit us at
www.DaikinAP.com and click on Training, or call 540-248-9646 and ask for the Training Department.
Warranty
All Daikin equipment is sold pursuant to its standard terms and conditions of sale, including
Limited Product Warranty. Consult your local Daikin Representative for warranty details. Refer to Form
933-430285Y. To find your local Daikin Representative, go to www.DaikinAP.com .
Aftermarket Services
To find your local parts office, visit www.DaikinAP.com or call 800-37PARTS (800-377-2787).
To find your local service office, visit www.DaikinAP.com or call 800-432-1342.
This document contains the most current product information as of this printing. For the most up-to-date
product information, please go to www.DaikinAP.com .
Products manufactured in an ISO certified facility.
©2013 Daikin Applied • www.DaikinAP.com • 800.432.1342 IM 955-3 / Page 6 of 6
