Dakota Digital VLC-40F User manual

Manual 650409A
VLC/VLK-40F
Dakota Digital VLK Instrument Installation
For 1940 Ford car
Your new VLC/VLK-40F kit includes:
Installation
(4) Mounting
screws
CAT5 Cable
Installation Manuals
VLK Display
1. Remove the four screws holding the clock to the glove box on the back side.
OR
VLC Display
Power Harness
(VLC ONLY)

Manual 650409A
2. Remove the clock assembly and rear housing.
3. Carefully position the new clock from the backside to avoid scratching the chrome. With
the four screws provided, secure the new clock to your original glove box.

Manual 650409A
WARNING: This product can expose you to chemicals including lead, which is known to the State of
California to cause cancer and birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov
4. Connect the CAT5 cable to the new clock;
with the VLC, connect the power harness
as well. Take care when routing this cable
to the control box.
5. Refer to the Operating Manual to complete the clock setup.
VLK shown
