dallmeier DF5 Series Installation and operation manual

005309 / 1.0.7 / 2018-12-14
DF5(X)00HD-DN
Commissioning
English

2www.dallmeier.com
DF5(X)00HD-DN Commissioning
Informaon about Copyright, Trademarks, Design Patents
© 2018 Dallmeier electronic
The reproducon, distribuon and ulizaon of this document as well as the communicaon of its contents to
others without express authorizaon is prohibited. Oenders will be held liable for the payment of damages.
All rights reserved in the event of the grant of a patent, ulity model or design.
We reserve the right to make technical modicaons.
The manufacturer accepts no liability for damage to property or pecuniary damages arising due to minor de-
fects of the product or documentaon, e.g. print or spelling errors, and for those not caused by intenon or
gross negligence of the manufacturer.
All trademarks idened by ® are registered trademarks of Dallmeier electronic.
All trademarks idened by *) are trademarks or registered trademarks of the following owners:
Google and Google Chrome of Google Inc. headquartered in Mountain View, California, USA;
HDMI of HDMI Licensing, LLC headquartered in Sunnyvale, California, USA;
JavaScript of Oracle Corporaon (and/or its aliates) headquartered in Redwood Shores, California, USA;
microSDXC of SD-3C, LLC headquartered in North Hollywood, California, USA;
Microso, Internet Explorer, Microso Edge and Windows of Microso Corporaon headquartered in Red-
mond, Washington, USA;
Mozilla and Firefox of Mozilla Foundaon headquartered in Mountain View, California, USA.
Third-party trademarks are named for informaon purposes only.
Dallmeier electronic respects the intellectual property of third pares and always aempts to ensure the com-
plete idencaon of third-party trademarks and indicaon of the respecve holder of rights.
In case that protected rights are not indicated separately, this circumstance is no reason to assume that the
respecve trademark is unprotected.
This product includes soware developed by the OpenSSL Project for use in the OpenSSL Toolkit
(hp://www.openssl.org) and cryptographic soware wrien by Eric Young (eay@cryptso.com).

www.dallmeier.com 3
Commissioning DF5(X)00HD-DN
Contents
1 Validity 4
2 Documents 4
This Document 5
Other Applicable Documents 5
3 Typographical Convenons 6
4 Safety Instrucons 8
5 General Notes 12
Scope of Delivery 12
Transportaon and Packaging 12
Warranty 13
Approvals/Cercaons 13
Appropriate Use 14
Operaon 15
6 Requirements 16
Ambient Condions 16
Power Supply 17
7 Maintenance 18
8 Installaon 19
9 Pin Assignment 30
10 Connecon and Login 34
Connecon 35
Login 36
11 Technical Specicaons 38
12 Dimensions 40

4www.dallmeier.com
DF5(X)00HD-DN Commissioning
1 Validity
This document applies to the following devices:
• DF5200HD-DN
• DF5300HD-DN
Figures in this document may dier from the actual product.
2 Documents
The product documentaon contains several documents which are included in the
scope of delivery in a printed form and/or on a digital medium.
Read all documents included in the scope of delivery carefully and thoroughly
before using the device.
Always follow the instrucons, notes and warnings and observe the technical
specicaons in the product data sheet.
Keep all documents in legible condion and in a suitable locaon for future refer-
ence.
Regularly check the website www.dallmeier.com for the latest updates on product
documentaon.

www.dallmeier.com 5
Commissioning DF5(X)00HD-DN
This Document
Commissioning
The document “Commissioning” (this document) contains detailed descripons on
installaon, connecon and commissioning of the device as well as safety instruc-
ons and general notes.
The target audience of this document is trained system integrators.
Other Applicable Documents
Data Sheet
The document “Data Sheet” contains detailed technical specicaons, features
and characteriscs of the device.
The target audience of the document is trained system integrators.
Conguraon
The document “Conguraon” contains detailed descripons on the conguraon
of the device.
The target audience of the document is trained system integrators.

6www.dallmeier.com
DF5(X)00HD-DN Commissioning
3 Typographical Convenons
This document may contain various warning words and symbols that indicate
potenal sources of danger:
DANGER
DANGER indicates a hazardous situaon which, if not avoided, will
result in death or serious injury.
WARNING
WARNING indicates a hazardous situaon which, if not avoided,
could result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situaon which, if not avoided,
could result in minor or moderate injury.
NOTICE
NOTICE is used to address pracces not related to physical injury.

www.dallmeier.com 7
Commissioning DF5(X)00HD-DN
For reasons of clarity and readability, various text formang elements and types
of emphasis are used in this documentaon:
Instrucons are indicated by arrows (➡).
➡Always carry out instrucons one aer the other in the sequence described.
“Expressions” in quotaon marks generally indicate a control element on the
device (switches or labels) or on its user interface (buons, menu items).
Paragraphs in italics provide informaon on basic principles, special features
and ecient procedure as well as general recommendaons.

8www.dallmeier.com
DF5(X)00HD-DN Commissioning
4 Safety Instrucons
Only use the device if it is technically in proper working condion and for the
intended purpose while keeping safety and potenal dangers in mind.
• Qualied Personnel
The installaon, mounng, connecon, commissioning and conguraon of the
device may only be carried out by qualied personnel.
This also applies to the maintenance, tesng and repair, whereat the regula-
ons of the DIN VDE 0701 series of standards (repair, modicaon and inspec-
on of electrical appliances) must be followed.
• Regulaons
The use of video and audio surveillance systems is, in general, strictly regulated.
Inform yourself about the currently valid laws and regulaons regarding data,
worker and environmental protecon before using the device and ensure
compliance with them.
• System Components
Only use internal components that have been tested and approved by Dallmeier.
Inappropriate internal components may cause malfuncons, damages and data
loss and may result in the loss of warranty.
• Modicaons
Do not make any modicaons to the hardware or soware that have not been
tested and approved by Dallmeier.
Inappropriate modicaons may cause malfuncons, damages and data loss
and may result in the loss of warranty.

www.dallmeier.com 9
Commissioning DF5(X)00HD-DN
• Documentaon
Read the documents included in the delivery carefully and thoroughly.
Always observe the contained instrucons, notes and warnings.
The product documentaon contains several documents which are included in
the scope of delivery in a printed form and/or on a digital medium.
Keep all documents in legible condion and in a suitable locaon for future
reference.
• Condensaon Water
If the device is brought from a cold to a warm environment, resulng conden-
saon water may cause malfuncons and damages.
In this case, wait (up to 8 hours) unl the device has reached room tempera-
ture before commissioning.
• Earthing & Equipotenal Bonding
For the safety of persons (protecon against dangerous contact voltages) and
devices (protecon against over-voltages) as well as for the immunity of infor-
maon and communicaon technology equipment to electromagnec interfer-
ences (EMI), all protecve measures, which are specied by the currently valid
DIN, VDE and ISO standards and which provide for a standard-compliant earth-
ing and a correct equipotenal bonding of electrical and electronic devices, are
mandatory and must be fullled by all means.
• Lightning Storms
To avoid damage to the device by electrical surge during lightning storms, all
protecve measures, which are specied by the currently valid DIN, VDE and
ISO standards and which provide for a standard-compliant lightning protecon
equipotenal bonding, are mandatory and must be fullled by all means.

10 www.dallmeier.com
DF5(X)00HD-DN Commissioning
• Operang Condions
Unfavorable operang condions may shorten the life of the device and may
cause malfuncons, damages and data loss and may result in the loss of war-
ranty.
Observe the specicaons given in the technical data, the operang condion
requirements and the maintenance instrucons.
• Foreign Bodies
If objects or liquids get into the device, immediately disconnect it from the
power supply (pull out the power plug).
Contact the sales partner responsible for your area.
• Burnt Smell
If you noce burnt smell or a formaon of smoke coming from the device, im-
mediately disconnect it from the power supply (pull out the power plug).
Contact the sales partner responsible for your area.
• Opening
The device may only be opened by qualied personnel for inspecon, mainte-
nance and repair.
• Disposal
Do not dispose waste electrical and electronic equipment into the household
trash.
Disconnect the device from the power supply.
Remove all connected devices.
Return the device to your respecve sales partner.

12 www.dallmeier.com
DF5(X)00HD-DN Commissioning
5 General Notes
Scope of Delivery
Included in the standard scope of delivery is:
• Documentaons (published in print and on DVD-ROM)
The scope of delivery may dier depending on the ordered equipment, device
variant or country of desnaon.
The funconal range of the device depends on the ordered equipment or
device variant and may dier from this document’s content.
Certain funcons and features may require the purchase of an addional
license.
Transportaon and Packaging
Store the original packaging for later transportaon.
Dallmeier is not responsible for any damage resulng from unprofessional/im-
proper transportaon.
The device should only be shipped in the original packaging.
If the original packaging is no longer available, ensure that the used packaging suf-
ciently protects the device against damage, moisture, heat and cold.

www.dallmeier.com 13
Commissioning DF5(X)00HD-DN
Warranty
The terms and condions valid at me the contract was signed shall apply.
Approvals/Cercaons
The following approvals/cercaons were valid for the device at the me of this
document’s compilaon:
• CE, FCC, RCM, UL, DIN 50130-4 compliant
Visit www.dallmeier.com for possible updates.
Note (USA)
This equipment has been tested and found to comply with the limits for a Class A digital device, pur-
suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protecon against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instrucon manual, may cause harmful interference to radio communicaons. Operaon of
this equipment in a residenal area is likely to cause harmful interference in which case the user will
be required to correct the interference at his own expense.

14 www.dallmeier.com
DF5(X)00HD-DN Commissioning
Appropriate Use
The DF5(X)00HD-DN is a HD network camera built into a compact and lightweight
box housing.
Equipped with a 1/4" tripod socket located on the top and boom side, the cam-
era ts all standard brackets with UNC threaded screws.
The camera is designed for indoor installaons on ceiling/wall brackets and can be
powered via PoE (Power over Ethernet, Class 0, IEEE 802.3af) or supplied with a
separate power supply unit.
NOTICE
For an outdoor use, the camera must be installed in a proper
weather-proof housing.
However, note that direct sunlight can cause extremely high tem-
peratures inside the housing.
In this case, it is absolutely necessary to use a venlated, temper-
ature-controlled weather-proof metal housing and a sunshield,
where required.
In addion, a metal slide should be used if the camera is installed
in a (weather-proof) housing to ensure opmal heat dissipaon.

www.dallmeier.com 15
Commissioning DF5(X)00HD-DN
Operaon
• When using a separate power supply unit, interference caused by a ground
loop may occur in the analog video preview signal. In this case, use a video
signal transformer (balun) for galvanic (ground) isolaon between the signal
source (camera) and the RG-59 cable.
• In order to prevent damage to the device, a galvanic isolator (balun) must be
installed if the BNC interface is permanently in use.
• If the device or the cables connected to the device are located near sources
with strong radiaon, the video image may be distorted.
• The device is equipped with automac gain control (AGC). In low-light condi-
ons the image may be altered (e.g. noise). However, this is not a malfuncon.
• The quality of the video image depends on the lighng condions and the used
monitor.
• The accuracy of the automac white balance (AWB) algorithm depends on the
used lighng. Mixed light (consisng of arcial light and daylight) may cause
color distorons (inaccurate color reproducon).
• Poor lighng can lead to an incorrect white balance.

16 www.dallmeier.com
DF5(X)00HD-DN Commissioning
6 Requirements
Ambient Condions
Unfavorable local condions may shorten the lifeme of the product and may
cause malfuncons or damages.
➡Do not install/operate the device in places
• with a large amount of dust and dirt,
• with steam or oil vapors (e.g. kitchen),
• with direct sunlight,
• with strong heat emissions (e.g. radiator),
• with improper ambient temperatures,
• near sources with strong radiaon (e.g. radio transmiers, magnec elds),
• with corrosive surroundings (e.g. gases, salt water),
• with insucient air venlaon (e.g. closed cabinet).

www.dallmeier.com 17
Commissioning DF5(X)00HD-DN
Power Supply
The device can be powered via PoE (Power over Ethernet, Class 0, IEEE 802.3af) or
supplied with a separate power supply unit.
WARNING
Electric shock hazard
Danger of death or serious injury
➡Always disconnect the separate power supply unit from the
mains socket (pull out the power plug) before connecng or
disconnecng the device.
Over-voltage (electrical surge)
Danger of death or serious injury as well as damage to the device
➡To ensure the safety of persons (protecon against dangerous
contact voltages) and to prevent damage to the device caused
by electrical surge, a standard-compliant earthing of the device
is mandatory.
NOTICE
Damage to the device resulng from improper power supply
➡Always ensure the correct polarity when using a separate power
supply unit.
➡Do not use PoE (Power over Ethernet) and a separate power
supply unit simultaneously.

18 www.dallmeier.com
DF5(X)00HD-DN Commissioning
7 Maintenance
The device may only be opened by qualied personnel for inspecon, mainte-
nance and repair.
Cleaning
If it is necessary to clean the device, observe the following notes:
NOTICE
Damage to the surface of the device
➡Clean the housing with a so, dry and anstac cloth.
• Do not use detergents.
➡If necessary, remove dust from the lens element with a suitable
bulb blower.
• Always beware not to touch the lens element in order to
avoid damages due to scratching or loss of image quality due
to ngerprints.
• Do not use canned air.
• Do not use organic solvents (alcohol, benzine) or coon buds
for cleaning.

www.dallmeier.com 19
Commissioning DF5(X)00HD-DN
8 Installaon
The installaon of the device may only be carried out by qualied personnel.
CAUTION
Falling device
Danger of injury
➡Observe the manufacturer’s instrucons about the maximum
adequate carrying capacity of the supporng structure.
➡For the installaon of ceiling/wall brackets, always use screws
and anchors suitable for your ceiling/wall type:
• Plasc screw anchors for solid wall material (concrete/brick)
• Toggle-bolt-style anchors for drywall/hollow wall type
(plaster)
You need:
• Ceiling/wall bracket with tripod screw (1/4"-20 UNC)

20 www.dallmeier.com
DF5(X)00HD-DN Commissioning
❶
ⓐ
ⓐTripod socket UNC 1/4"-20 for brackets with standard tripod screws
