Danfoss MBC 5000 User manual

Installation guide
Pressure control
Type MBC 5000
© Danfoss A/S (AC-MCI / jmn), 2013-06 IC.PI.P10.B2.22 / 520B5758 1
061R9314 061R9314
Electrical connection
Attention:
Use only the accompanying plug,
also when replacing.
Caution:
Disconnect power supply before wiring connenctions
are made to avoid possible electrical shock
or damage to equipment. All wiring should conform
to the National Electrical Code and local regulations.
Contact load
2.9 FLA/17.4 LRA 240AC/60Hz
Pilot duty 278VA 240VAC/60Hz
Adjustment
Mechanical dierential. One full turn (360°) of the MBC
setting-screw is approx. equal to 7% of the full setting range.
Type Range Permissible
operating pressure Code no
High pressure
diaphragm 73 – 580 psi 1088 psi 061B301666
High pressure
piston 232 – 2320 psi 4350 psi 061B503266
Operation
temperature
Piston version: -40 – 140 °F
Diaphragm version: 14 – 140 °F
Maximum media
temperature
185 °F

Danfoss 93Z100
3.66
1.00
G1/4
0.59
1.18
2.87
3.30
0.59
0.59
0.78
1.18
ø0.21
2 IC.PI.P10.B2.22 / 520B5758 © Danfoss A/S (AC-MCI / jmn), 2013-06
Mounting and pressure connection
Note
Caution:
MBC 5000 pressure switches should
be installed in the way that will ensure that
the unit will be not subjected to impact.
Dimensions [in]
