SL20 Smartwatch User Manual
User Manual
Version1.1

Foreword
Welcome to use our SL20, this is a stylish watch which can help
you reach your sport goals.
The package includes:
• SL20 smart watch
• User Manual
• Charging cable
SL20 initial setting
First download & install the app SMART TIME to make sure the
watch can synchronize the data with the app.The app is where you
can set goals, analyze historical data and trends , and much more.
Setting up your smart watch with a mobile device
SL20 app supports IOS 8.0 and Android 4.4 above system,also
supports all Bluetooth3.0 and 4.0(more than 150 kinds mobile
devices).
Setting up your smart watch with a mobile device
SL20 app supports IOS 8.0 and Android 4.4 above system,also
supports all Bluetooth3.0 and 4.0(more than 150 kinds mobile
devices).

1. Turn on Bluetooth of the watch and mobile at the same time.
2. Find the “SMART-TIME” app in stores according the device:
• The Apple® App Store® iPhone® for iOS devices.
Android devices can be downloaded and installed in mainst as
Appbao,Pea Pod,Baidou Mobile Assistant.
Or scan the below QR-CODE to download “SMART-TIME”
App Store: SMART-TIME
Google Play: SMART-TIME
3. After installing the APP,start and log in according to the prompts.
4. Select the Bluetooth “ R2” with the strongest signal from the
list.Then the watch will show pairiag interface, click to confirm
pairing.Then you will see the Bluetooth icon on the left top of
the watch is blue.

5. IOS users need to open setting--Bluetooth,find R2,then click
on connection or open menu >>Bluetooth >>Search new device
>> From the list of Bluetooth devices,find and click the Bluetooth
6. When the phone gets a prompt of Bluetooth pairing request,click
PAIR.The color of the Bluetooth icon in the upper left corner of
the watch will turn orange, at this point the watch and phone are
successfully bound.
You should use device with Android 4.4 or
IOS 8.0 and above, the function they support
between Android and IOS device are differ-
ent. The watch can only pair with one mobile
each time. If you want to pair with another
mobile, you shall cancel the current pairing.

Changing the Wristband
SL20 smart watch contains two separate parts (watch body and
straps) and you can purchase different straps separately and change
it anytime.
Charging instructions
Charging
Turn the watch over, align and attach the charging pins to the
magnets four gold prongs.You will see the charging icon on the
watch screen after about 10s.
Charging fully can take around 2 hours. You will see the battery
icon is full if the watch have been fully charged. Before charging,
please wipe up the charging port to avoid the corrosion of metal
contacts or other risks.
Functions
Making phone calls
After the watch and mobile paired successfully, the contact of the
mobile can be synced to the watch.The user can dial out, receive or
reject calls on the watch directly.

Switching between phone calls:
If you make or answer phone calls with your watch, the call are
done on your watch by default.
If you make or answer phone calls with your phone, the calls are
done on your phone by default.
To switch between your watch and your phone during phone calls,
perform the following operations:
On the call scree of your phone, touch Bluetooth to use your watch
for the call, or choose Speaker or Headset earpiece to use your
phone for the call.
Quick entrance:
Slip down from watch face,then it enters quick switch page
(User can set BT3.0,Vibration,settings,manu style, language,
brightness,gesture,theme,alarm clock,time, flightmode,low battery
mode etc.)calendar--weather. slip up from home page,it enters
sports records-heart rate.

Sport mode:
Slip left on the dial interface of the watch, you can quickly enter
the sport mode or click dial interface-menu-sport mode. SL20
supports multi-sport mode, which includes indoor running, outdoor
running, cycling,fast walking, climbing and other sports modes.
Blood pressure:
After wearing our watch correctly, click menu blood pressure,you
can measure blood pressure manually.
Breathing training:
After wearing our watch collectly, click menu- breathing training.
Pedometer:
The sports data recorded by the watch, including steps, distance
and calories, which can be viewed on the watch or APP. nce and
calories, which can be viewed on the watch or APP. Slipping up on
the dial interface can enter the step mode quickly.
Heart rate:
Wear the watch in a right way, you can measure your heart rate
as below ways. Open heart rate on the watch, you can measure it
manually Set heart rate monitoring period and interval in app.

Sleep monitor:
The watch will track your sleep when you’re wearing it to sleep.
And you can check your sle
Remote capture:
This feature can remote control the mobile camera to take pictures.
Please click device in the app and choose smart photo-open camera.
Music player:
This function can play cellphone music, also switch songs and
adjust volume on the watch.
Sedentary reminder
Sitting to long is not good for health. You can set the time on the
watch or app to remind you to move.
Alarm:
You can set the alarm on the watch or app, maximum 8 alarms.
Find your mobile and watch:
Click “Find mobile” on your watch when it connected with your
mobile, you will hear the voice from your mobile; Click “Fine
device”, you will hear the voice from the watch.

- Gesture: - Auxiliary tool:
1. Flip to mute alarm -Timer
2. Wake-up gesture - Stopwatch
3. Shaking switch main menu - Calculator
4. Shake to answer the call
Replaceable dial interface and theme :
Press a while of the dial, slip left and right to view different styles
of dials, click OK to replace it.Open menu-theme, choose your
favorite theme, click Ok
Specicaiton
Waterproof level IP67 (To prevent splash water
intrusion, not soaked in water
and not support showerand
swimming.)
Wristband width 260mm
Wristband width 22mm
Battery 300mAh Poly-Li
Display Touch
Waterproof level Bluetooth 3.0 & 4.0

Troubleshooting
Heart rate signal loss
The SL20 smart watch keeps paying attention to your heart rate
data during your exercise and your daily life. Sometime the watch
may not get a suitable heart rate signal.At this time,the missing
heart rate data will appear at the dotted line.
If you can’t get the heart rate signal,first you should confirm that
you wear the watch correctly,adjust it to avoid being too high or too
low, neither too tight or too loose on your wrist.
After adjustment,turn on real-time heart rate monitoring to get
the data
If there is still no heart rate data,check if the heart rate monitoring
function is turned on at SMART TIME App Other problems
If your mobile cannot pair the watch, click Settings-Bluetooth in
your mobile and check if there is signal of R2.If yes,it means there
is no problem with the Bluetooth signal.Please check if the watch is
paired with other phones,please unbind it.IOS device users should
click Setting - Bluetooth - ignore this device and then pair it.
Exemption Clause
1.The Hear Rate and Blood Pressure data output by SL20 are not
intended to be a medical or diagnostic basis.
2.Self-diagnosis and self-treatment are dangerous. Only qualified
physicians are allowed to diagnose and treat high blood pressure
or any other heart diseases. Please contact your physician for more
professional diagnostic opinions.

3.The data and information of heart rate and blood pressure
provided by SL20 may not be completely accurateand may
exceed the tolerance as per the specification stated in the
document due to diuerent factors, such as interference with signal
from external sources, incorrect wearing position and changes in
weather condi-tions or user’s body condition.
4.DO NOT adjust any of your medication or therapeutic schedule
based on the results output by SL20. Please follow the doctor’s
instructions before taking any treatment or medication.
WE DISCLAIM ALL LIABILITY ARISING FROM SUCH
INACCURACY AND ASSUMES NO RESPONSIBILITY FOR
THE CONSEQUENCES OF USE OF SUCH DATA AND
INFORMATION.
Warranty Clause
Our company always pursues the service concept of “creating
value for customers”Warranty Clause
We offer 1year warranty period for SL20 smart watch. If there
is any damage or malfunction during normal use, the warranty
service will be provided to the customer for free after
confirmation by our technician.
The following conditions are not covered by the warranty:
A. Accident or human damage
B. Testing, repairing or disassembling without authorization
C. Contamination due to human reasons
D. Damage caused by connection with equipment which is not
compatible
E. Natural aging of the product
F. Damage caused by force majeure
