DBI SALA 3400800 Operator's manual

© Copyright 2008, DB Industries, Inc.
This supplement includes additional information for the following sections:
Descriptions, 3.6 Retrieval System Operation, 3.7 Retrieval Overload Feature, 5.6
Inspection Steps f or Retrieval Components, 7 Specications, and 9 Labels.
DESCRIPTIONS
3400800 - SEALED SELF RETRACTING LIFELINE:
30 feet of 3/16 inch galvanized wire rope, self-locking
plated steel swiveling snap hook with indicator.
3400801 - SEALED SELF RETRACTING LIFELINE:
30 feet of 3/16 inch stainless wire rope, self-locking
plated steel swiveling snap hook with indicator.
3400802 - SEALED SELF RETRACTING LIFELINE:
30 feet of 3/16 inch stainless wire rope, self-locking
stainless steel swiveling snap hook with indicator.
3400825 - SEALED SELF RETRACTING LIFELINE:
15 feet of 3/16 inch galvanized wire rope, self-locking
plated steel swiveling snap hook with indicator.
3400826 – SEALED SELF RETRACTING LIFELINE:
15 feet of 3/16 inch stainless wire rope, self-locking
plated steel swiveling snap hook with indicator.
3400827 – SEALED SELF RETRACTING LIFELINE:
15 feet of 3/16 inch stainless wire rope, self locking
stainless steel swiveling snap hook with indicator.
3400850 - SEALED SELF RETRACTING LIFELINE
WITH RETRIEVAL: 30 feet of 3/16 inch galvanized
wire rope, self-locking plated steel swiveling snap hook
with indicator.
3400851 - SEALED SELF RETRACTING LIFELINE
WITH RETRIEVAL: 30 feet of 3/16 inch stainless steel
wire rope, self-locking plated steel swiveling snap hook
with indicator.
3400852 - SEALED SELF RETRACTING LIFELINE WITH RETRIEVAL: 30 ft. of 3/16
inch stainless wire rope, self-locking stainless steel swiveling snap hook with indicator.
3400853 - SEALED SELF RETRACTING LIFELINE WITH RETRIEVAL: 30 feet of 3/16
inch stainless steel wire rope, self-locking plated steel swiveling snap hook with indicator,
mounting bracket included.
SuPPlEmENTal INSTRuCTION
uSER INSTRuCTION maNual
SEalED SElf RETRaCTINg lIfElINE
Use this Supplemental Instruction with
Sealed Self Retracting Lifeline User Instruction Manual 5902122.
Supplemental Instruction to:
Sealed Self Retracting Lifeline
(See back page for specic model numbers.)
Form: 5902408
Rev: B

3
Figure 1 - Self Retracting Lifeline Parts Identication
ID Label
Lifeline
Cable
Guide
Self-Locking
Snap Hook
Anchorage
Handle
Instruction
Label
Housing
Bumper
Figure 2 - Retrieval Parts Identication
Shift Knob
Winch
Operating
Label
Retrieval
Label
Retrieval Handle
Locking Screw
Retrieval Arm
(Crank arm)
RFID Label

4
3.0 OPERaTION aND uSE
3.6 RETRIEVAL SYSTEM OPERATION: Figure 2 identies key
components of the retrieval system. To activate retrieval mode,
rotate the locking screw down completely to free the crank arm.
Rotate the handle out from the stowed position. To engage the
winch, pull and hold the shift knob in the unlocked position. Push
the crank arm in to the engaged position and release the shift
knob. If needed, rotate the crank arm clockwise (lowering) to aid
in gear engagement.
A. TO RAISE: Rotate the crank arm counterclockwise.
B. TO LOWER: First crank the crank arm counterclockwise to
release the fall arrest brake, then crank clockwise.
NOTE: A minimum load of 75 lbs (33.9 kg) is required for lowering
or to pay out line. A force of up to 30 lbs is required to operate winch
when loaded to capacity.
CauTION: Stop cranking when line is fully extended or retracted.
Continued cranking can damage components.
C. DISENGAGEMENT OF RETRIEVAL MODE: Remove any load
from the lifeline. Pull and hold the shift knob in the unlocked
position. Pull the crank arm out to the disengaged position and
release the shift knob. Secure the crank arm with the locking
screw. Pull out on the retrieval handle and rotate the handle to
the stowed position.
3.7 RETRIEVAL OVERLOAD FEATURE: Winches on the SRL models
covered in this supplementary instruction do not incorporate an
overload clutch to limit the force applied to the drive components
and the person being raised. Care must be taken to avoid line
slack while in rescue mode. Also, the individual must be monitored
during retrieval to ensure they do not become stuck and subjected
to excessive force from continued lifting.
5.0 INSPECTION
5.6 INSPECTION STEPS FOR RETRIEVAL COMPONENTS:
Step 13. Inspect the retrieval arm for distortion or other damage.
Ensure that the retrieval handle can be rotated out and
secured in the cranking position.
Step 14. Ensure the locking screw can be tightened completely.
Step 15. Ensure the shift knob can be pulled out to the unlocked
position and then released, locking the crank arm in both
the engaged and disengaged positions.

5
Step 16. Test the retrieval mode for proper operation by raising
and lowering a test weight (75 lb - 310 lb sand bag).
Retrieval operation should be smooth and even. When
the retrieval handle is released, the weight should not
move and the retrieval handle should remain in position
(no movement). A ‘clicking’ sound should be evident
when raising the load.
7.0 SPECIfICaTIONS
Model Size (LxWxH)/Weight Lifeline Type/Working Range
3400800 11.5” x 9.4” x 5.4”/19 lbs Galvanized Wire Rope / 30 ft
3400801 11.5” x 9.4” x 5.4”/19 lbs Stainless Steel Wire Rope / 30 ft
3400802 11.5” x 9.4” x 5.4”/19 lbs Stainless Steel Wire Rope / 30 ft
3400825 10.2” x 7.6” x 4.3”/12 lbs Galvanized Wire Rope / 15 ft
3400826 10.2” x 7.6” x 4.3”/12 lbs Stainless Steel Wire Rope / 15 ft
3400827 10.2” x 7.6” x 4.3”/12 lbs Stainless Steel Wire Rope / 15 ft
3400850 11.5”x9.4”x8.8”/23.6 lbs Galvanized Wire Rope / 30 ft
3400851 11.5”x9.4”x8.8”/23.6 lbs Stainless Steel Wire Rope / 30 ft
3400852 11.5”x9.4”x8.8”/23.6 lbs Stainless Steel Wire Rope / 30 ft
3400853 11.5”x10.4”x8.8”/25.4 lbs Stainless Steel Wire Rope / 30 ft
Working Range does not include an additional 2 ft of lifeline which may*
deploy in the event of a fall.
Figure 3 - Specications
"H" "W"
"L"
Working Range
(Lifeline Extended)
"W"
"L"
"H"

6
7.1 MATERIAL: Component material is the same as specied in
Sealed SRL User Instruction Manual 5902122 unless otherwise
listed below:
Cable Guide:• Nylon
Ratchet Ring:• Stainless Steel
Motor Spring:• Stainless Steel
Connecting Hook:• Forged Alloy Steel or Stainless Steel.
7.2 OPERATING CHARACTERISTICS, RETRIEVAL MODELS:
Model Gear Ratio Weight Lifted Cranking Force
3400850
3400851
3400852
3400853
6.2:1
200 lbs 8 lbs - 21 lbs
310 lbs 12 lbs - 30 lbs
9.0 labElINg
9.1 These labels must be securely attached to the self retracting
lifeline and must be fully legible. See Figures 1 and 2 for label
locations.
Identication Label
All Models
RFID Label
All Models
Instruction Label
30 Foot Models Only
Winch Operating Label
Retrieval Models Only

Instruction Label
15 Foot Models Only
Retrieval Label
Retrieval Models Only

WARRANTY
Equipment offered by DBI-SALA is warranted against factory defects in
workmanship and materials for a period of two years from date of installation
or use by the owner, provided that this period shall not exceed two years from
date of shipment. Upon notice in writing, DBI-SALA will promptly repair or
replace all defective items. DBI-SALA reserves the right to elect to have any
defective item returned to its plant for inspection before making a repair or
replacement. This warranty does not cover equipment damages resulting from
abuse, damage in transit, or other damage beyond the control of DBI-SALA.
This warranty applies only to the original purchaser and is the only one
applicable to our products, and is in lieu of all other warranties, expressed or
implied.
This supplemental instruction
applies to the following models.
3400800 3400825 3400850
3400801 3400826 3400851
3400802 3400827 3400852
3400853
Additional model numbers may appear on the next printing of this instruction.
USA Canada
3833 SALA Way 260 Export Boulevard
Red Wing, MN 55066-1837 Mississauga, Ontario L5S 1Y9
Toll Free: 800-328-6146 Toll Free: 800-387-7484
Phone: [phone] Phone: [phone]
Fax: [phone] Fax: [phone]
www.capitalsafety.com www.capitalsafety.com
This manual is available for download at www.capitalsafety.com.
A CAPITAL SAFETY COMPANY
