IDENTIFICATION AND NOMENCLATURE OF PARTS
POS. NOMENCLATURE POS. NOMENCLATURE
1PUMP CASING 8AIR EXHAUST SILENCER
2BALL SEAT DELIVERY VALVES 9SUCTION BALL VALVE SEAT
3BALL 10 CAP
4OUTER DIAPHRAGM (product side) 11 DISTRIBUTOR CENTRAL BODY
5SHAFT 12 PNEUMATIC EXCHANGER
6DELIVERY MANIFOLD 13 SUCTION MANIFOLD
7INNER DIAPHRAGM (air side)
