Decon wheel e-move User manual

E-MOVE
Service Manual

Contents
1. Product Overview ……………………………………………………………………… 1
1.1 Product Features …………………………………………………………………… 1
1.2 Variations …………………………………………………………………………… 2
2. Installation Requirements ………………………………………………………… 3
2.1 Strength Requirements ……………………………………………………………… 3
2.2 Structural Requirements …………………………………………………………… 3
2.3 Functional Requirements …………………………………………………………… 5
3. Unit Installation and Removal …………………………………………………… 6
3.1 JWX-2 Components …………………………………………………………………… 7
3.2 Installing the JWX-2 ……………………………………………………………… 8
3.3 Installing and Removing the Wheel Drive Unit Assembly ………………… 12
4. Component Adjustment ……………………………………………………………… 14
4.1 Adjusting the Battery Seat Angle …………………………………………… 14
4.2 Adjusting the Power Switch Location and Angle,
Fitting and Adjusting the Mode Switch, Changing
the Switch Location (Left/Right) and Connecting
the Wiring ………………………………………………………………………… 16
4.3 Adjusting the Position of the Coupler Box
(Coupler for the Left-hand Wheel Drive Unit Assembly) ………………… 30
4.4 Adjusting the Warning Lamp (LED) Direction ……………………………… 31
4.5 Using Offset Washers …………………………………………………………… 32
5. Component Installation, Removal, Disassembly,
Assembly and Adjustment ………………………………………………………… 33
5.1 Removing and Re-installing the Handrim …………………………………… 33
5.2 Removing and Re-installing the Wheel Assembly …………………………… 36
5.3 Removing and Re-installing the Circuit Board …………………………… 38
5.4 Removing and Re-installing the Coupler Box ……………………………… 41
5.5 Removing and Re-installing the L/R Connecting Cable …………………… 45
5.6 Adding and Removing the Springs ……………………………………………… 47
5.7 Copying Setting Data …………………………………………………………… 49
5.8 Calibrating the Handrim Sensor Neutral Position ………………………… 51
6. JW Smart Tune ………………………………………………………………………… 53
7. Warnings ………………………………………………………………………………… 54
7.1 Warnings List ……………………………………………………………………… 54
8. Self-diagnosis ……………………………………………………………………… 56
8.1 Self-diagnosis (Self-diagnosis Function) …………………………………… 56
8.2 Fault Detection Chart …………………………………………………………… 56
9. Inspections and Maintenance …………………………………………………… 59
9.1 Inspection Checklist …………………………………………………………… 59
10. Speci󲥬cations and Other Information ……………………………………… 60
10.1 Speci󲥬cations …………………………………………………………………… 60
10.2 Dimensions and Diagrams ……………………………………………………… 61
10.3 Wiring Diagram …………………………………………………………………… 62

1
Product Overview
1
1.1 Product Features
1. Product Overview
Sample E-Move Installa-
① Wheel drive unit assembly with AC servo 󲥭at motor
② Power switch
③ Dedicated battery with built-in microprocessor
Choice of nickel-metal hydride or lithium-ion battery
④ Mode switch (option)
④
③
①
②

1
Product Overview
2
1.2 Variations
Model E-Move
Product Tire size Note
JWX2-B24E2 24 inch
JWX2-C22E2 22 inch
JWX2-C24E2 24 inch
JWX2-D24E2 24 inch without mounting bracket
JWX2-E24E2 24 inch without mounting bracket
JWX2-F24E2 24 inch
Selectable Part
Hand rims: Stainless steel / Plastic coated
Battery: Nickel-metal hydride / Lithium-ion
Optional Part
Mode switch (Driving mode changing system)

2
Installation Requirements
3
（1）Thewheelchairframemustnothaveacamberangle.
（2）Thewheelchairframemustbesufficientlystrong.(Notethatthestrengthofawheelchairframemayde-
clinewithprolongeduse.)
Example:
 ・Playordeformationincomponentssuchasrivets,boltfasteningsorcasters.
 ・Componentswithvisiblewearorcorrosion.
2.1 StrengthRequirements
ToinstalltheE-Move,thewheelchairframemustmeetthestrengthrequirementslistedbelow.
Warning
・DonotinstalltheE-Moveonawheelchairframethatdoesnotmeetthestrengthrequirements.
2.2 StructuralRequirements
ToinstalltheE-Move,thewheelchairframemustmeetthestructuralrequirementslistedbelow.
Warning
・DonotinstalltheE-Moveonawheelchairframethatdoesnotmeetthestructuralrequirements.Even
whereitcanbesuccessfullyinstalled,problemsmayariseduringusethatcouldcauseinjuryorac-
cident.
2.2.1 Wheelchairframe
（1）Thediameteroftheaxleholeis18mmor20mm.
（2）Thecontactsurfacesforthenutsaroundtheaxleholemustbe󲥭atandhaveamplesurfacearea.
（3）WhentheE-Moveisinstalled,theremustbenointerference betweentheE-Moveand thewheel-
chairframe.
nImportant
・Ifyouareusingoffsetwasherstoavoidsuchinterference,checkthetwoitemsbelowandinstalluptothree
washersoneachside.
− Thenutseatsarecompletelysecure.
− Thewheelchairbrakeseatsarecompletelysecure.
2.InstallationRequirements

2
Installation Requirements
4
2.2.2 Casters
Seven-inchorlargercastersarerecommendedforthefrontcasters.
Withsmall-diametercasters,itisdifficulttogetoverlargebumps.Theshockexperiencedgoingoverbumps
isalsogreaterifthecastersaresmall.
Largediameter
(easytogetoverbumps)
Smalldiameter
(difficulttogetoverbumps)

2
Installation Requirements
5
2.3 FunctionalRequirements
Warning
・DonotinstalltheE-Moveonawheelchairframethatdoesnotmeetthefunctionalrequirements.Even
whereitcanbesuccessfullyinstalled,problemsmayariseduringusethatcouldcauseinjuryorac-
cident.
ToinstalltheE-Move,thewheelchairframemustmeetthefunctionalrequirementslistedbelow.
（1）Theframemustbeconstructedtoallow22-or24-inchwheelstobeattached.
（2）Thewheelchairisequippedwithaparkingbrakethatcanberelocatedandadjustedtothecor-
rectpositiononthetires.Whenapplied,thebrakemustbecapableofstoppingthewheelchair
withtheE-Moveinstalledona7°forwardorbackwardincline.
（3）WiththeE-Moveinstalled,itmustbepossibletotipthewheelchairforwardandbackbyatleast
20°andtothesidebyatleast15°.
 (Abackwardtippingangleofatleast25°isrecommended.)
Forwardtippingangle Backwardtippingangle Sidetippingangle
Minimum
20°
Minimum
20°
Minimum
15°
（4）Takecaretoensurethatthefunctioningofthewheelchairframeisnotimpairedbytheinstal-
lationoftheE-Move.
 Example:
 ・Movementofmoveablearmsupports,foldingmechanism,parkingbrakeeffectiveness,etc.

3
Unit Installation and Removal
6
3. Unit Installation and Removal
Warning
・When cutting cable ties, do not cut on an angle. Always cut off the
surplus as close as possible to the fastener. Cable ties cut to a
pointcouldcauseinjurytothecustomer.
Note
・In locations where the tightening torque is specified, always tighten to the specified torque.
Insufficient tightening torque will cause looseness, while excessive torque could cause dam-
age.
・Installtheunitwiththebatteryremoved.

3
Unit Installation and Removal
7
3.1 E-MoveComponents
OWNER’S MANUAL
①
⑦⑨ ⑩
⑪
⑫
⑬
⑭
⑮
⑯
⑰
⑧⑨
②③
⑱
⑲
⑤⑥
⑤⑥
④
No. Component Remarks Qty
① Leftwheeldriveunitassembly For22-inchor24-inch(selectable) 1
② Rightwheeldriveunitassembly For22-inchor24-inch(selectable) 1
③ Manualset Owner’sManual,Warranty,GuidelinesforSafeUse,
InstallationManual 1
④ Cableties 10
⑤ Battery Nickel-metalhydrideorlithium-ion(selectable) 1
⑥ Charger Nickel-metalhydrideorlithium-ion(selectable) 1
⑦ Stopperarm Left 1
⑧ Stopperarm Right 1
⑨O-rings Fittedontostopperarms 4
⑩Boss 2
⑪ Washers
Forstopperarmoffset(axlesleeve)
Foraxlesleeveinstallation–35/18.5mmdia.,
3.2mmthick
8
⑫ Washers Forstopperarmoffset(boss)
28/8.5mmdia.,3.2mmthick 6
⑬ Washers Forplateoffset-18/6.2mmdia.,1.6mmthick 12
⑭Bolts Forstopperarm–M8 2
⑮Bolts Forplatelock–M6 4
⑯ Platelock 2
⑰ Axlesleeve 2
⑱ Nuts Foraxlesleeveinstallation 2
⑲ Bushes Foradjustmentfrom18→20mmdia.axlesleeve 2
*ThecomponentsNo.⑦~No.⑲arenotincludedinthe“withoutmountingbarcket”models.
 See“1.2Variations”.

3
Unit Installation and Removal
8
3.2 InstallingtheE-Move
Withtheexceptionofthecabling,theprocedureforinstallingtheE-Moveinamodular-typewheel-
chairisthesame forbothleftandrightsides.Accordingly,themodeldescriptiongivenbelowis
forinstallationontheleftside.Usethesameproceduretoinstallontheright.
Requiredtools: 4mmand5mmhexagonalwrenches(Allenkeys),24mmsocket,socketwrench,torque
wrench,22mmand24mmspanners
1 Remove the axle sleeve (a) installed
onthewheelchair.
Removetheexistingwheelandaxlesleeve(a)
fromthesidebracket(b)onthewheelchair.
（a）
（b）
2 Installtheaxlesleeve(c).
（1）Installthestopperarm(d)andboss(e)on
thewheelchairsidebracket(b)andtem-
porarilytightenthebolt(f).
（e）
（f）
（d）
（b）

3
Unit Installation and Removal
9
（2）Fittheaxlesleeve(c)intothestopperarm
(d)andsidebracket(b).
nImportant
・Inserttheaxlesleeve(c)fromthestopperarmside.
・Theouterdiameterofthethreadedsectionofthe
axlesleeve(c)is18mm.Ifthediameteroftheaxle
holeinthewheelchairsidebracket(b)is20mm,
insertthebush(g)betweentheaxleholeandaxle
sleeve(c).
（3）Fitthe3.2mmthickwasher(h)ontothe
axlesleeveandtemporarilytightenthenut
(i).
（4）Fullytightenthenut(i)andbolt(f)inthe
sequencebelow.
1.Nut(i)
Tighteningtorque 40–50N･m
2.Bolt(f)
Tighteningtorque 8.5–12N･m
Note
・If the wheelchair frame interferes with the
stopper arm (d). insert a 3.2 mm thick offset
washer between the stopper arm (d) and the
wheelchair side bracket (b). For details, see
“4.5UsingOffsetWashers”.
・Use up to 3 offset washers on each side. For
details,see“4.5UsingOffsetWashers”.
（b）
（f）
（c） （d）
（h）
（g）
（i）
3 Install the plate lock (j) on the wheel
driveunitassembly(k).
Installtheplatelock(j)onthewheeldriveunit
assembly(k)andsecureitusingthebolts(l).
Tighteningtorque 8.5–12N･m
nImportant
・Installtheplatelock(j)sothatitfacesinthedirec-
tionindicatedinthe󲥬gure.
・Oncethewheeldriveunitassembly(k)isinstalled,
usewasherstoadjustthespacingsothatstopper
arm(d)engagescorrectlywiththeholeintheplate
lock(j).Fordetails,see“4.5UsingOffsetWash-
ers”.
・Useupto3washersoneachside.Fordetails,see
“4.5UsingOffsetWashers”.
（l）
（k）
（j）

3
Unit Installation and Removal
10
4 Install the wheel drive unit assem-
bly(k).
（1）Liftupthehandleplate(m).
（2）Aligntheholesintheaxle(n)andplate
lock(j)withtheaxleholeintheaxle
sleeve(c)andthepinonthestopperarm
(d)andthen󲥬tthemtogether.
Note
・If there is interference between the wheel-
ch air  f ra m e a n d  c o m p o ne nt s  s u c h a s th e
power switch, insert 3.2 m m thick offset
washers between the axle sleeve (c) and the
stopper arm (d). For details, see“4.5 Using
OffsetWashers”.
・Use up to 3 offset washers on each side. For
details,see“4.5UsingOffsetWashers”.
（3）Setthehandleplate(m)backdownand
checkthatthewheelretainingball(o)is
locked.
（m）
（j）
（d）
（c）
（n）
（o）

3
Unit Installation and Removal
11
5 Connectthecable.
（1）Openthecap(p)onthecouplerboxcase
(q).
（2）Connect the cable so that the coupler
triangularmark(r)(yellowmark)isaligned
withthetriangularmark(s)onthecoupler
box.
（3）Rotatethering(t)onthecoupler(u)on
theendofthecabletolockitintoplace.
 Checkthatthecoupler(u)is󲥬rmlyse-
cured.
（s）
（r）
（p）
（q）
（u）
（t）

3
Unit Installation and Removal
12
3.3 InstallingandRemovingtheWheelDriveUnitAssembly
nImportant
・Thesameprocedureisusedforinstallingandremovingboththeleftandrightwheeldriveunitassemblies.
Accordingly,themodeldescriptionbelowisfortherightside.Usethesameprocedurefortheleftside.
Requiredtools: 17mmdeepsocket,socketwrench,torquewrench
3.3.1 RemovalMethodforReleasableWheels
1 Removethebattery(a).
（a）
Thefigureshowstheprocedure
foranickel-metalhydridebattery.
2 Disconnectthecable(b).
1.Turnthering(d)onthecoupler(c)onthe
endofthecable(b)toloosenit,andthen
pullitupwardstodisconnectthecable.
2.Fitthecap(f)ontothecoupler(e)forthe
leftwheel.
（c） （b）
（d）
（f）
（e）

3
Unit Installation and Removal
13
3 Remove the wheel drive unit assem-
bly(h).
Raisethehandleplate(g).Then,whilesup-
portingthebatteryhousingsothatthewheel
driveunitassembly(h)doesnotrotate,pullthe
handleplate(g)toremovethewheeldriveunit
assembly(h),takingcarenottodamagethe
cable.
Note
・Su pp ort the b atter y ho usin g s o  th at th e
wheel drive unit assembly (h) does not rotate
while you are removing the assembly. Other-
wise, the wheel drive unit assembly (h) could
rotate during removal and damage the switch
orbatteryhousing.
（g）
（h）
3.3.2 InstallationMethodforReleasableWheels
Theinstallationprocedureissimplytheremovalproce-
dureinreverse,butcareshouldbetakenwiththeitems
below.
Note
・Insert the axle (i) and the plate lock hole (j)
byaligningtheaxleholeintheaxlesleeve(k)
withthestopperarmpin(l).
Warning
・Check that the wheel retaining ball (m) is
locked and that the wheel drive unit assembly
cannotberemoved.
（j）
（l）
（k）
（i）
（m）

14
4
Component Adjustment
4.1 Adjusting the Battery Seat Angle
When adjusting the battery seat angle because interference with the seat back makes battery removal dif-
󲥬cult, adjust the angle so that the battery is roughly parallel with the wheelchair back pipe.
Required tools: Philips-head screwdriver, 12 mm socket, socket wrench, torque wrench
4. Component Adjustment
（c） （b）
（c）
（a）
1 Dismount the right-hand wheel drive
unit assembly (a).
Dismount the right-hand wheel drive unit as-
sembly (a) from the wheelchair frame.
2 Remove the cover (b).
Remove the 2 screws (c) and then remove the
cover (b) below the battery seat.

15
4
Component Adjustment
（e）
（d）
（e）
3 Adjust the angle of the battery seat
(d).
Remove the 3 bolts (e) and adjust the angle of
the battery seat (d).
nImportant
・ The battery seat (d) can be adjusted through 4
steps.
・ The seat angle shifts through roughly 15° for each
step.
4 Re-install the removed components.
（1） Tighten the 3 bolts (e).
Tightening torque 8.5 – 14 N･m
（2） Install the cover (b) below the battery seat
and secure it in place with the 2 screws
(c).
Tightening torque 2 – 3.5 N･m

16
4
Component Adjustment
4.2 Adjusting the Power Switch Location and A n gle,
Fitting and Adjusting the Mode Switch, Changing
the Switch Location (Left/Right) and Con necting
the Wiring
Required tools: Philips-head screwdriver, nippers, 4 mm hexagonal wrench (Allen key), 10 mm socket,
socket wrench, torque wrench, 26 mm spanner
4.2.1 Adjusting the Power Switch Position
（c） （b）
（c）
（a）
1 Dismount the right-hand wheel drive
unit assembly (a).
If the right-hand wheel drive unit assembly (a)
is installed in the wheelchair frame, dismount
it.
2 Remove the cover (b).
Remove the 2 screws (c) and then remove the
cover (b) below the battery seat.

17
4
Component Adjustment
（k）
（i）
4 Adju s t th e p o sitio n of th e p o wer
switch (i).
（1） Remove the 2 bolts (k) and adjust the po-
sition of the power switch (i).
nImportant
・ The switch can be set to any of 4 positions.
・ Moving the switch one position changes the angle
by roughly 40°.
（2） Tighten the 2 bolts (k) to lock the position
of the power switch (i).
Tightening torque 10 – 16 N･m
（d）（i）
（a）
（h）
（f）
（d） （g）
（e）
（3） Cut the cable tie (h) and pull the cable (d)
for the power switch (i) out of the channel
in the unit back plate (a).
Note
・ When cutting the cable tie (h), take care not
to cut the cable (d).
3 Free the cables (d).
（1） Remove the 4 bolts (e) and remove the
battery seat (f).
（2） Cut the cable ties (g).
Note
・ When cutting the cable ties (g), take care not
to cut the cables (d).
（j）
（4）Loosen and remove the cable tie (j) under
the battery seat.

18
4
Component Adjustment
（d）
（l）
（l） （a）
（i） （m）
5 Secure the cable (d).
（1） Starting from the power switch (i), fit the
cable (d) into the channel in the unit back
plate (a) and secure it with the cable tie (l).
Note
・ Avoid excessive looseness or tautness in the
cable (d).
・ Fasten the cable tie (l) as shown in the 󲥬gure
so that it does not touch the wheel (m).
（4） Bundle the cables (d) together with the
cable tie (j) under the battery seat.
（2） Install the battery seat (f) secure it in
place with the 4 bolts (e).
Tightening torque 8 – 13 N･m
（3） Secure the cables (d) with the cable ties
(n).
（f）
（d） （n）
（e）
（j）
（d）
6 Re-install the cover (b).
Install the cover (b) below the battery seat and
secure it in place with the 2 screws (c).
Tightening torque 2 – 3.5 N･m
