Decon wheel MEM6423P User manual

2021-06-10
Assembly instructions for Berollka Slash (0–3˚)
MEM6423P and MEM6424P
1. Remove wheels and sleeves on both sides.
2.
3. Check the correct placement for the eMove, and that it is axle Ø12,7 x 51 with
Part Number: XOE-2530E-C0 without axle spacer and Stop pins are assembled
with Part Number: 320003.
7
5

2021-06-10
4. Assembly of the plate according to picture.
Parts for right side mounting:
Item No. Part Number Qty Description
1 310069 1 Clamp Slash
2 MC6SM8X25 1 Screw Socket M8 x 25
3 310068R 1 Bracket Right side
4 XSM6X12 1 Screw Rounded M6 x 12
5 320003 1 Bracket
Note! If you only order the mounting set, the axle is not included, for replacement see the
service manual.
5. Assemble the back placed battery bag.

2021-06-10
Åtdragningsmoment / Tightening torque
Metriska grovgängor, stål.
Metric coarse threads, steel.
Gänga / Thread
Åtdragningsmoment / Tightening torque
M3
1,2 Nm
M4
3 Nm
M5
6 Nm
M6
10 Nm
M8
25 Nm
M10
50 Nm
M12
85 Nm
Navhylsa.
Sleeve.
Gänga / Thread
Åtdragningsmoment / Tightening torque
M16x1
30 Nm
M18x1
40 Nm
