Deda Elementi Jet Clip-On User manual

JET Clip-on
JET Clip-on
JET CLIP-ON
USeR’S MAnUAL
Ver. 00 – February 2021 ©Deda Elementi
JET Clip-on
JET Clip-on

Congratulations for your new Deda Elementi product. Please read these
instructions carefully and follow them for correct use. An improper installation or
wrong application of the instructions could damage the product, that will be no
more covered under warranty, damage the bicycle or cause an accident resulting
in injury or death. Since specific tools and experience are necessary for proper
installation, it is recommended that the product be installed by an official Deda
Elementi dealer or a qualified bicycle technician.

GENERAL SAFETY INFORMATION ____________________________________________ pag. 4
WARRANTY _______________________________________________________________ pag. 5
PACKAGING ______________________________________________________________ pag. 6
ASSEMBLY INSTRUCTIONS__________________________________________________ pag. 10
COMPUTER MOUNT________________________________________________________ pag. 15
eng
CONTENTS

4
eng
GENERAL SAFETY INFORMATION
It is under user’s responsibility to examine the product on a regular basis
to determine the need for service or replacement. Carbon parts and their
components are products that wear from normal use of the bicycle, for that
reason we recommend cyclists to regularly inspect their bicycle and parts in order
to detect any damage. If any doubts or problems occur, discontinue riding and
have them inspected by an official Deda Elementi dealer or a qualified bicycle
technician.
This product has been designed and intended to be used on normal paved
surfaces. In case of use on not paved surfaces or off-road, the product can
be subjected to damages, loose its functioning and cause serious accidents
and injury for the user.
If any bicycle fall or accident occurs, discontinue riding the bicycle and have
it inspected carefully by an official Deda Elementi dealer or a qualified bicycle
technician. The use of any damaged bicycle part can cause serious accidents
and injury for the user.
Read the whole User’s Manual carefully and keep it in a safe place for later
reference.

5
WARRANTY
Deda Elementi warrants that all products are free from defects in materials or
workmanship for a period of two years after original purchase unless otherwise
stated on the Warranty policy. The Warranty is valid with the purchase of an
original Deda Elementi products only.
2.1 LIMITS OF WARRANTY
In case of sale or product cession, the Warranty will be considered valid for
two years period only from the original purchase.
The Warranty doesn’t cover damages caused by modifications, even
small; any kind of adaptions or alterations; maintenance performed by an
unauthorized people; use of the product outside the normal riding conditions
on paved road surfaces. The Warranty does not cover even damages caused
by impacts, collisions, falls that may occur for accidental reasons.
The Warranty does not cover aesthetic defects like: matting, chap, fading
or other phenomenon that may occur during the use and after the bicycle
cleaning using water in pressure, solvents or similar products, petrol.
In case of imperfections, defects or damages found on the product, the user
is asked to contact the dealer within 10 (ten) days; after this period ends the
Warranty and it will be no more considered eligible.
Deda Elementi reserves the right to modify partially or completely the products,
instructions and warranty without any notice to the customer.

6
eng
PACKAGING
The JET extensions are available in two versions:
JET ONE, to be assembled on Ø31.75 mm handlebar. Spacers and other
parts are included for mounting on Deda Elementi handlebars or any other
handlebar with a diameter of Ø31.75 mm.
JET TWO, for direct mounting on original bicycle brands TT handlebar. JET
TWO clip-on includes an aluminum plate to fit the original handlebar spacers.
Check the compatibility of JET TWO clip-on with TT handlebars on the market
at www.dedaelementi.com
3.1 JET ONE
JET ONE clip-on includes the following parts:
1) Carbon extensions, 1 set
2a) Fixing plate, 2 pcs
3a) Support plates, 1 set
4a) Extension fixing screw M5x12 mm, 4 pcs
5) Adjustable computer mount for Garmin® & Wahoo® or for Bryton®
6) Computer holder fixing screw M4x12 mm, 2 pcs
7) Armrest pads and cable cover sticker, 1 set
8) 30 mm spacer, 2 pcs
9) 15 mm spacer, 2pcs
10) Clamp, 2 pcs
11) Screw M5x25 mm, 4 pcs
12) Screw M5x40 mm, 4 pcs
13) Screw M5x55 mm, 4 pcs
14) Screw M5x70 mm, 4 pcs
PACKAGING

7
3
2
6
1
4
4b
3b
6
5
2b
4b
7
11-12-13-14
10
9
8
4a
3a
6
5
2a
7
1
GARMIN - BRYTONWAHOO
16
1
5

8
eng
3.2 JET TWO
JET TWO clip-on includes the following parts:
1) Carbon extensions, 1 set
2b) Fixing plate, 2 pcs.
3b) Support plates, 1 set
4b) Extension fixing screw M5x12 mm and nut, 4 pcs
5) Adjustable computer mount for Garmin® & Wahoo® or for Bryton®
6) Computer holder fixing screw M4x12 mm, 2 pcs
7) Armrest pad and cable cover sticker, 1 set

9
3
2
6
1
4
4b
3b
6
5
2b
4b
7
11-12-13-14
10
9
8
4a
3a
6
5
2a
7
1
GARMIN - BRYTONWAHOO
16
1
5

10
eng
WARNING
Always use a calibrated dynamometric key to tighten all screws when assembling
and adjust the extensions.
A tightening torque higher than recommended can lead to parts failure without
notice.
WARNING
For the shifter levers assembly follow the recommendations from the manufacturer.
The maximum tightening torque of the shifter lever must not exceed 4Nm.
4.1 JET ONE
1. Assembly the fixing plates (3a) on the handlebar and use the spacers (8
e 9) to adjust according to the desired height. According to the selected
spacers, use the appropriate length screws (11, 12, 13 or 14) to ensure the
correct assembly (see Fig. 1).
ASSEMBLY INSTRUCTIONS
Fig. 1
Spacers Bolt type
15 mm 30 mm
0 0 M5x25 mm
1 0 M5x40 mm
0 1 M5x55 mm
1 1 M5x70 mm

11
Tighten both clamp screws alternately, turning half turn at a time, until a minimum
torque of 4Nm is reached. If the clamp is not tight enough on the handlebar,
increase the torque up to a maximum of 5 Nm.
2. Position the extensions (1) on the support plates (3a) and use the fixing
plates (2a) and relative screws (4a) to ensure them. The fixing plates have two
different positions to adjust the extensions set-up (see Fig. 2).
Furthermore, the fixing plates have a double couple of holes that allows to
increase the width adjustment range.
Once the desired position of extensions has been fixed (width and angle of
convergence), tighten the screws to 6 Nm.
3. the carbon extension can be cut to length, never exceed the cut limit as
indicated on the product (see Fig. 2).
WARNING
The cutting of the carbon extension required specific tools and must be done by
an official Deda Elementi dealer or a qualified bicycle technician.

12
eng
152 mm
Cut limit /
Limite di taglio
15.0°
MAX 77 mm
3.0°
A
BB
A
1415
16 46
30
76 mm
From 70 to 110 mm
From 110 to 150 mm
183 mm
MAX 64 mm
60
100mm
Armrest setback / Arretramento poggiagomiti ( ± 15 mm )
LENGTH / LUNGHEZZA :
S = 340 mm
M = 370 mm
Fig. 2
4. Install the pads and the cable cover stickers (8).

13
Fig. 3
4.2 JET TWO
1. Ensure the support plate (3b) to the spacers of the compatible handlebar
(see Fig. 3).
2. Position the extensions (1) on the support plates (3b) and use the fixing
plates (2b), relative screws and nuts (4b) to ensure them. The fixing plates
have double holes positions that allows to increase the width adjustment
range. Once the desired position of the extension (width and convergence)
has been established, tighten the screws to 6 Nm.
3. the carbon extension can be cut to length, never exceed the cut limit as
indicated on the product (see Fig. 4).
WARNING
The cutting of the carbon extension required specific tools and must be done by
an official Deda Elementi dealer or a qualified bicycle technician.

14
eng
From 70 to 110 mm
76 mm
3.0°
100mm
15.0°
Armrest setback / Arretramento poggiagomiti ( ± 20 mm )
LENGTH / LUNGHEZZA :
S = 340 mm
M = 370 mm
Cutlimit/
Limiteditaglio
Fig. 4
4. Install the pads and the cable cover stickers (8)

15
The computer mount is made up to the following parts:
1) Bottom support
2) Top support
3) Upper support adjustment screws M3x8 mm, 2 pcs
4) Computer holder insert for Garmin®/Wahoo® or for Bryton®
5) Insert fixing screw M3x4 mm
6) Computer holder fixing screw M4x12 mm, 2 pcs
COMPUTER MOUNT
3
2
6
1
4
4b
3b
6
5
2b
4b
7
11-12-13-14
10
9
8
4a
3a
6
5
2a
7
1
GARMIN - BRYTONWAHOO
16
1
5

16
eng
5.1 COMPUTER MOUNT ASSEMBLY AND ADJUSTMENT
Ensure the computer mount with the screws (6) on the extension.
Computer alignment:
1. Completely unscrew the insert fixing screw (5).
2. Remove the insert (4).
3. Slightly unscrew the adjustment screws (3).
4. Center the top support.
5. Tighten the adjustment screws (3).
6. Install the insert as the following schema according to the type of computer:
3
2
6
1
4
4b
3b
6
5
2b
4b
7
11-12-13-14
10
9
8
4a
3a
6
5
2a
7
1
GARMIN - BRYTONWAHOO
16
1
5
7. Add and tighten the insert fixing screw (5).
WAHOO
BRYTONGARMIN

17
CONTACTS
For any question or technical information please contact Deda Elementi by
visiting the website at www.dedaelementi.com and through the email address
[email protected].
Dedaindustrie s.r.l. owner of Deda Elementi brand, reserves the right to modify
without notice the content of this manual always guaranteeing the availability of
the updated versions on the website download area.

www.dedaelementi.com
Dedaindustrie S.r.l.
Via Leonardo Da Vinci 19/21/23
26010 Campagnola Cremasca (CR) - Italia
Phone [phone]
Fax [phone]
www.dedaos.com.tw
Deda OS
No.8, Lane 150-30, Sec. 3, Xitun Rd.,
Xitun Dist.
Taichung City 407, Taiwan (R.O.C.)
tel: [phone]
fax: [phone]
