Deda Elementi ZERO2DB User manual

ZERO2DB
ZERO2DB
USeR’S MAnUAL
Ver. 2 - September 2019 ©Deda Elementi
ZERO2DB
CLINCHER DISC BRAKE WHEELSET

Congratulations on your new Deda Elementi wheels. Please read these instructions
carefully and follow them for correct use. An improper installation or wrong
application of the instructions could damage the product, that will be no more
covered under warranty, damage the bicycle or cause an accident resulting in injury
or death. Since specific tools and experience are necessary for proper installation,
it is recommended that the product be installed by an official Deda Elementi dealer
or a qualified bicycle technician.

GENERAL SAFETY INFORMATION ____________________________________________ pag. 4
WARRANTY _______________________________________________________________ pag. 5
PACKAGING ______________________________________________________________ pag. 6
TECHNICAL SPECIFICATIONS ________________________________________________ pag. 6
TIRES _____________________________________________________________________ pag. 7
SPROCKETS INSTALLATION _________________________________________________ pag. 8
DISC BRAKE ROTOR _______________________________________________________ pag. 9
FITTING THE WHEELS ON THE FRAME ________________________________________ pag. 10
CLEANING, MAINTENANCE AND REPLACEMENT PARTS ________________________ pag. 13
eng
CONTENTS

4
eng
GENERAL SAFETY INFORMATION
It is under user’s responsibility to check regularly the product to determine the
need of maintenance or replacement. Wheels and their components are products
wearing during the standard use of the bike, for that reason we recommend users
to regularly inspect their bicycle and parts in order to find any damage. If any
doubts or problems occur, stop riding the wheels and have them inspected by an
official Deda Elementi dealer or a qualified bicycle technician.
These wheels have been designed and intended to be used on normal paved
surfaces. In case of use on not paved surfaces or off-road, wheels can be
subjected to damages, loose their functioning and cause serious accidents
and injury for the user.
Regularly check the wheels to make certain that they are installed correctly to
the bicycle and fastened securely to the frame and fork.
If any bicycle fall or accident occur, stop riding the wheels and have them
inspected carefully by an official Deda Elementi dealer or a qualified bicycle
technician.
Frequently check the status of the wheels parts subjected to wear and if
necessary make the maintenance and/or parts replacement through the
official Deda Elementi dealers.
It is recommended to make an inspection after each riding season or every
time in case of problems related to bearing, wheel out of center or damages
to single parts
Install only bicycle tires compatible with rims technical specifications included
in this user’s manual. The installation of tires not compatible can damage
the rim wheels, invalidate the Deda Elementi Warranty and cause serious
accidents and injury for the user.
Follow the minimum inflation pressure recommended by the tire manufacturer.
Never exceed the maximum inflation pressure permitted for this Deda
Elementi rim of 7 bar / 100 psi. The use of inflation pressures out of this
range can damage the rim, invalidate the Deda Elementi Warranty and cause
serious accidents and injury for the user.
Read the whole User’s Manual carefully and keep it in a safe place for later
reference.

5
WARRANTY
Deda Elementi warrants that all Deda Elementi products are free from defects in
materials or workmanship for a period of two years after original purchase unless
otherwise stated on the Warranty policy.
The Warranty is valid for the purchase of an original Deda Elementi product only.
2.1 LIMITS OF WARRANTY
In case of sale or product cession, the Warranty will be considered valid for a two
years period only from the original purchase.
The Warranty doesn’t cover damages caused by modifications, even small; any
kind of adaptations or alteration; maintenance performed by an unauthorized
people; use of the product outside the normal riding conditions on paved
road surfaces. The Warranty doesn’t cover even damages caused by impacts,
collisions, falls that may occur for accidental reasons.
The Warranty doesn’t cover aesthetic defects like: matting, chap, fading or other
phenomenons that may occur to the wheels during the use and after the bicycle
cleaning using water in pressure, solvents or similar products, petrol.
In case of imperfections, defects or damages found on the product, the user is
asked to contact the dealer within 10 (ten) days; after the ending of this period,
the Warranty will be no more considered due.
Deda Elementi reserves the right to modify partially or completely the products,
instructions and warranty without any notice to the customer.

6
eng
TECHNICAL SPECIFICATIONS:
* Sram XDR freehub body version
** Campagnolo freehub body version
*** Tubeless conversion kit not included into the wheels package
****Disc brake rotor not included into the wheel package
The Wheels package you have just purchased contains the following items:
The wheels
User’s Manual
Rim Tapes
PACKAGING
Wheels Model ZERO2DB
Compatibility cassettes
10s Shimano / Sram (with 1.80 mm spacer)
11s Shimano / Sram
*12s Sram
**10-11-12s Campagnolo
Rim
Size 622x19C
Width 24.0mm
Height 30.0mm
Rim tape 622x18mm
Tire Compatibility Clincher o Tubeless (***)
Recommended tire sizes min 700x25 - max 700x32
Hubs Front 100mm
Rear 142mm
Spokes
Front 293 mm; flat; straight pull
Rear Non Drive side 293 mm; flat; straight pull
Rear Drive side 292 mm; flat; straight pull
Nipples 15 mm ABS, aluminum
Disc brake rotor compatibility Shimano® Center Lock (****)
Frames
compatibility
Thru-Axle Front 12x100 mm, Rear 12x142 mm (standard)
Traditional system
QR
Front 100 mm,
Rear 135 mm
(kit available as spare part)
15 mm
Front Thru-Axle
Front TA 15 mm
(kit available as spare part)

7
Deda ZERO2DB wheels are designed to use clincher tires with inner tubes or Tubeless
tire. The Tubeless conversion kit is not included into the wheels box. Check tires and
inner tubes dimensions according to the rim technical specifications included in this
user’s manual.
WARNING: Do not use tubular or tubeless tires with this wheel. The use of no-
compatible tires with this wheel can cause sudden and unexpected loss of pressure,
loss of control and tire failure causing serious accident and injury for the user.
Before the tire installation check that rim tape is already installed in the right
position inside the rim; if not please install first the rim tape.
Make sure the rim tape cover all the rim bed holes along the entire circumference
of the wheel.
The valve hole on the rim tape has to be placed at the same position of the valve
hole of the rim wheel (Fig. 1).
Install the tire on the wheel and proceed with tire inflation as tire manufacturer
recommendations. Never exceed the maximum inflation pressure permitted for
this Deda Elementi rim of 7 bar / 100 psi.
TIRES
Fig 1
Valve hole
Rim tape

8
eng
WARNING: for Tubeless tire installation carefully read the instructions of the tire and
tubeless conversion kit manufacturer.
WARNING: Never exceed the maximum inflation pressure recommended by the
wheels manufacturer as indicated in this user’s manual. Excessive tire pressures
could damage the rim structure causing serious accident and injury for the user.
WARNING: Tire installation requires a specific experience of the product, in case
of doubts please contact an official Deda Elementi dealer or a qualified bicycle
technician. During tire installation don’t use tools or tire lever that can fold, damage or
make the rim edge fragile. An incorrect tire installation can cause serious accidents
and injury for the user.
Deda Elementi wheels are available with Shimano® 10-11 speed, Sram® 10-11-12
speed and Campagnolo® 10-11-12 speed cassette. Read and carefully follow the
installation instructions of the sprockets. The rear wheel with Shimano® freehub
body is supplied with a 1.80mm aluminum spacer that is intended to be used with
Shimano® /Sram® 10 speed cassette only . Please don’t use 1.80mm spacer with
11 speed cassette.
Sram 12 speed groupset requires the use of the XD-R freehub body compatible,
available as spare part (part. No. WD17XDRSL).
*with XD-R compatible freehub body
SPROCKETS INSTALLATION
Wheel Type Freehub Cassette Compatibility
Shimano/Sram Sram 12s* Shimano/Sram 11s Shimano/Sram 10s +
dist. 1.80mm
Campagnolo Campagnolo 12s Campagnolo 11s Campagnolo 10s

9
WARNING: Since specific tools and experience are necessary for proper
sprockets installation, in case of doubts it is recommended that the product will
be installed by an official Deda Elementi dealer or a qualified bicycle technician.
An incorrect sprockets installation can cause serious accidents and injury for the
user.
WARNING: Please make sure that wheel freehub body will be compatible with
your sprockets cassette before proceed with the assembly. The ensure missing of
the compatibility between wheel and sprockets cassette can cause malfunction
of the bicycle drive train causing serious accident and injury for the user.
Deda ZERO2DB Disc Brake wheels are compatible with Shimano® Center Lock
locking systems.
The disc brake rotors are not included into the wheels box.
For Rotors installation with Shimano® Center Lock locking systems read and
carefully follow the instructions of the disc brake manufacturer.
WARNING: Disc brake rotor installation requires a specific experience of the
product.
In case of doubts please contact an official Deda Elementi dealer or a qualified
bicycle technician.
An incorrect rotor installation can cause serious accidents and injury for the user.
DISC BRAKE ROTOR

10
eng
FITTING THE WHEELS ON THE FRAME
WARNING: Since specific experience is necessary for proper wheels installation, in
case of doubts it is recommended that the product be installed by an official Deda
Elementi dealer or a qualified bicycle technician. An incorrect wheels installation
can cause serious accidents and injury for the user.
Deda ZERO2DB wheels are pre-assembled from the factory with Thru- axle locking
system (Front 12x100, Rear 12x142). The Thru-axles are not included into the
wheels package.
For thru-axle installation and wheels locking to the frame and fork, read and carefully
follow the installation instructions provided by the bicycle and fork manufacturer.
WARNING: An incorrect installation of the through axle can cause the wheel
separation from the fork and cause serious accidents and injury for the user.
Conversion kit for Quick Release (100 mm Front/ 135 mm Rear) and Thru-axle (TA
15 mm Front) are available as spare parts.

11
(1) (3) (3) (2)
(4) (4)
(1) (2)(3)(3)
(4) (4)
8.1 CONVERSION END CAPS KIT MOUNTING
Front hub
Remove the pressure end caps installed on the front hub (standard TA
12x100 mm) and replace them with those you need (QR 100 mm, TA 15 mm)
Install the end cap with the smaller flange diameter (1) on the disc brake rotor
side and the one with the bigger flange diameter (2) on the opposite side
Make sure the washer (3) is correctly placed in its seat on the end cap (4)
before inserting caps into the hub
Rear hub
Unscrew the end caps fastened to the rear hub axle (standard TA 12x142 mm)
with appropriate wrenches and replace them with those you need (QR 135
mm)
Install the longer end cap (1) on the disc brake rotor side and the shorter one
(2) on the opposite side (drive side)
Make sure the washer (3) is correctly placed in its seat on the end cap (4)
before inserting the caps into the hub

12
eng
8.2 HUBS SPARE PARTS SPECIFICATIONS

13
The wheels you have just purchased are high technology products that require
specific care and maintenance to fully obtain the maximum performance
advantages and to preserve them over time. So we recommend to follow simple
rules of use to avoid any kind of problem.
WARNING: Never clean the wheels and parts using high pressure and high
temperature water. The water pressure can overcome seals and bearings
protections systems causing damages irreparably or malfunction of internal parts
of the hub. Never use solvents, chemical products, petrol or similar substances,
over the hubs that can damage seals and rubber gaskets or remove the grease
from the bearings completely.
After the bicycle washing, dry every parts and components avoiding to store
water into the hollow points of the wheel (for instance inside the rim and hub).
Frequently check the wear status of the wheels parts and if necessary make
the maintenance and/or parts replacement through the official Deda Elementi
dealers.
The recommended maintenance intervals depend on the use and using condition
of the wheels. It is recommended to make an inspection after each riding season
or every time in case of problems related to bearing, wheel out of center or
damages to single parts.
Since specific tools and experience are necessary for hub maintenance, wheel
truing or parts replacement it is recommended that the service should be done
by official Deda Elementi dealer.
For any intervention or replacement parts, only original Deda Elementi spare
parts have to be used in order to guarantee the product quality and the warranty
maintaining.
CONTACTS
For any question or technical information please contact Deda Elementi by
visiting the website at www.dedaelementi.com and through the email address
[email protected].
Dedaindustrie S.r.l reserves the right to modify without notice the content of
this manual always guaranteeing the availability of the updated versions on the
website download area.
CLEANING, MAINTENANCE AND REPLACEMENT PARTS

www.dedaelementi.com
Dedaindustrie S.r.l.
Via Leonardo Da Vinci 19/21/23
26010 Campagnola Cremasca (CR) - Italia
Phone [phone]
Fax [phone]
www.dedaos.com.tw
Deda OS
No.8, Lane 150-30, Sec. 3, Xitun Rd.,
Xitun Dist.
Taichung City 407, Taiwan (R.O.C.)
tel: [phone]
fax: [phone]
Deda Elementi USA
[email protected]
#ridededa
