Defiant IS09a4505BRBKTH User manual

THANK YOU
We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of
USE AND CARE GUIDE
MOTION SECURITY LIGHT
Questions, problems, missing parts?
8 a.m.-7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-866-308-3976
HOMEDEPOT.COM
SKU: 1008 992 390
MODEL: IS09a4505BRBKTH

2
Table of Contents
Table of Contents......................................2
Safety Information....................................2
Warranty ...................................................3
3-Year Limited Warranty ........................2
Pre-Installation.........................................3
Planning Installation ..............................3
........................................3
Tools Required .......................................3
Hardware Included.................................4
Package Contents ..................................4
Installation................................................5
Care and Cleaning ................................... 8
Troubleshooting ....................................... 8
Safety Information
PRECAUTIONS
□Please read and understand this entire manual before attempting to assemble, install, or operate this light xture.
This light xture requires 4x1.5V D cell batteries power source.
Some codes require installation by a qualied electrician.
This light xture should be installed outdoors to a wall or eave.
The light xture should be mounted approximately 8 ft. (2.4 m) above the ground. If the light xture is mounted
higher than recommended, aiming the sensor down will reduce the coverage area. .
□
□
□
□
□This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC compliance information is listed as below:
Responsible party: Leedarson America, Inc.
Responsible party address: 300 Technology Court SE Suite 100, Smyrna, GA 30082
Telephone number: [phone]
WARNING: Turn the power off at the circuit breaker or fuse. Place tape over the circuit breaker switch and verify power is off at the light xture.
WARNING: Risk of re. Keep the lamp heads at least 2 in. (51 mm) from combustible materials.
CAUTION: Burn hazard. Allow the light xture to cool before touching.
NOTICE: Do not connect this light xture to a dimmer switch or timer.
NOTICE: Any changes or modications to this unit not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.

3 HOMEDEPOT.COM
Please contact 1-866-308-3976 for further assistance.
Pre-Installation
PLANNING INSTALLATION
Hardware Included and
Package Contents sections. If any part is missing or damaged, do not attempt to assemble, install, or operate this
SPECIFICATIONS
Range Up to 26 ft. (8m) (Varies with surrounding temperature)
Sensing angle Up to 120°
Lumens 450lm
TOOLS REQUIRED
Phillips
screwdriver
Wire strippers/
cutters
Work gloves Ladder
Safety goggles
Warranty
3-YEAR LIMITED WARRANTY
WHAT IS COVERED
This product is guaranteed to be free of factory defective parts and workmanship for a period of 3 years from date
of purchase. Purchase receipt is required for all warranty claims.
WHAT IS NOT COVERED
This guarantee does not include repair service, adjustment and calibration due to misuse, abuse or negligence, or
its entirety. This warranty does not include reimbursement for inconvenience, installation, setup time, loss of use,
unauthorized service, or return shipping charges. This warranty is not extended to other equipment and components
that a customer uses in conjunction with this product.
No service parts available for this product.
Contact the Customer Service Team at 1-866-308-3976 or visit www.homedepot.com.
Power Drill Drill Bit

4
Pre-Installation (continued)
HARDWARE INCLUDED
NOTE: Hardware shown to actual size.
Part Description Quantity
AA Anchor 2
BB Mounting bracket screw 2
PACKAGE CONTENTS
AA BB
A
B
C
Installation
1Determining the mounting
location
NOTE:
mounted higher than recommended, aiming the sensor
down will reduce the coverage area.
□Determine the mounting location – wall or eave
mount.
□Position the lamp heads (A) in the general
direction of the desired light coverage.
Wall Mount
Eave Mount
A
Part Description Quantity
A Lamp head
Motion sensor
1
B 1
C Mounting base 1

5 HOMEDEPOT.COM
Please contact 1-866-308-3976 for further assistance.
2BATTERY INSTALLATION
Step 1.Remove the front cover of the lamp head (A) by rotating the face counterclockwise. Pull the face out from
the housing to reveal the battery holder.
Step 2. A) To release the battery door, rmly press down on the door tabs simultaneously.
B) Insert 4 D-cell batteries (not included) into the light. Ensure the batteries are inserted so that the at ends are
making contact with the springs.
C) Attach the battery (not include) door by matching the tabs to the rectangular holes and then push down on the
door until it clicks into place.
Step 3. Line up arrows then turn the face of the light clockwise. Make sure the unit is closed by twisting until the
arrow symbol is pointing past the lock symbol to ensure weatherproof seal is tight.
Step1
Step2 A
Step2 B Step2 CStep3
Battery Door
NOTE:
• Do not mix old and new batteries. If batteries are not new, it may cause the light to malfunction.
• Install batteries with polarity in correct position.
• Light may activate when batteries are inserted. Simply take light into a dark room. Allow batteries to settle, then test activation.
• If your light will not turn off, it means that it is time to replace the batteries.
Use only new alkaline D-Cell batteries with 1.5V rating.
Installation

6
Installation (continued)
3Mounting the light fixture
Step 1. Remove the mounting base (C) by turning the thumbscrew counterclockwise. Lift the lamp head (A) out
of the mounting base (C) and set aside.
Step 2. A) Determine the mounting location and mark the pilot holes. Use a drill bit to create the pilot holes (if
mounting to drywall, use the drywall anchors included with the screws). Use a hammer to tap the anchors(AA)
into the pilot holes, before screwing in the mounting base(C).
B)Drill the screws(BB) through the holes on mounting base(C). Insert the stem of the light back into mounting
base(C) and tighten the thumbscrew.
Step 3. Loosen the knuckle screw located on the stem of the light to point the light in desired direction. Then
tighten the screw to secure position.
AA
BB
Step1
Step2 A
Step2 B Step2 C
Step2 DStep3
Thumb
Screw
Mounting Base
Knuckle Screw
Thumb Screw

Installation (continued)
4Adjusting the lamp head
If needed, gently grasp the lamp head (A) and tilt it up or down or side to side to adjust the light coverage area.
WARNING: Risk of re. Keep the lamp head at least 2 in. from combustible materials.
7 HOMEDEPOT.COM
Please contact 1-866-308-3976 for further assistance.

8
Care and Cleaning
□
□
□
Troubleshooting
Problem Possible Cause Solution
The light will not come on. □Daylight turn-off (photocell) is in effect. □Recheck after dark.
□The motion sensor is aimed in the
wrong direction.
□Re-aim the motion sensor
to cover the desired area.
The lights stay on continuously. □The motion sensor may be picking up a
heat source, such as an air vent, dryer
surface.
□Decrease the “SENSITIVITY”
setting or reposition the
motion sensor.
□Heat or light from the bulbs may be
turning the motion sensor on and off.
□Reposition the lamp heads
away from the motion
sensor.

Questions, problems, missing parts?
8 a.m.-7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-866-308-3976
HOMEDEPOT.COM
Retain this manual for future use.
208986-01A
