Deif Multi-line 2 User manual

DEIF
A/S
Option C1
Generator add-on protection package
Multi-line 2 – version 2
4189340267E
SW version 2.42.X
Description of options
•
Description of options
•Functional description
•Parameter list
DEIF A/S, Frisenborgvej 33 Tel.: [phone], Fax: [phone]
DK-7800 Skive, Denmark E-mail: [email protected], URL: www.deif.com

GPU, GPC, PPU Option C1, Generator add-on protection package
DEIF A/S Page 2 of 10
Table of contents
1. WARNINGS AND LEGAL INFORMATION........................................................................3
LEGAL INFORMATION AND RESPONSIBILITY ....................................................................................3
ELECTROSTATIC DISCHARGE AWARENESS.....................................................................................3
SAFETY ISSUES............................................................................................................................3
DEFINITIONS ................................................................................................................................3
2. DESCRIPTION OF OPTION ..............................................................................................4
C1 OPTION...................................................................................................................................4
3. FUNCTIONAL DESCRIPTIONS ........................................................................................5
VOLTAGE AND FREQUENCY...........................................................................................................5
ALARM INHIBIT..............................................................................................................................5
4. PARAMETER LIST ............................................................................................................6
PARAMETER TABLE DESCRIPTION..................................................................................................6
FAST OVERCURRENT PROTECTION ................................................................................................6
VOLTAGE PROTECTIONS ...............................................................................................................7
FREQUENCY PROTECTIONS...........................................................................................................8
OVERLOAD PROTECTION...............................................................................................................9
CURRENT UNBALANCE PROTECTION..............................................................................................9
VOLTAGE ASYMMETRY PROTECTION............................................................................................10
VAR IMPORT (LOSS OF EXCITATION)PROTECTION ........................................................................10
VAR EXPORT (OVEREXCITATION)PROTECTION.............................................................................10
This paper relates to multi-line 2 ver. 2 PPU/GPU/GPC units with application software
version 2.42.1 or later.

GPU, GPC, PPU Option C1, Generator add-on protection package
DEIF A/S Page 3 of 10
1. Warnings and legal information
Legal information and responsibility
DEIF takes no responsibility for installation or operation of the generator set. If there is any doubt
about how to install or operate the generator set controlled by the unit, the company responsible
for the installation or the operation of the set must be contacted.
Electrostatic discharge awareness
Sufficient care must be taken to protect the terminals against static discharges during the
installation. Once the unit is installed and connected, these precautions are no longer necessary.
Safety issues
Installing the unit implies work with dangerous currents and voltages. Therefore, the installation
should only be carried out by authorised personnel who understand the risks involved in working
with live electrical equipment.
Definitions
Throughout this document a number of notes and warnings will be presented. To ensure that these
are noticed, they will be highlighted in order to separate them from the general text.
Notes
Warning
The notes provide general information which will be helpful for the reader to
bear in mind.
The warnings indicate a potentially dangerous situation which could result in
death, personal injury or damaged equipment, if certain guidelines are not
followed.
Be aware of the hazardous live currents and voltages. Do not touch any AC
measurement inputs as this could lead to injury or death.
The units are not to be opened by unauthorised personnel. If opened anyway, the
warranty will be lost.

GPU, GPC, PPU Option C1, Generator add-on protection package
DEIF A/S Page 4 of 10
2. Description of option
C1 option
Option C1 is a software option and therefore not related to any hardware apart from the
standard-installed hardware. Option C1 is a mix of frequency, voltage, overload, overcurrent,
unbalance alarms and reactive power import/export protections as follows:
Protection ANSI no.
Overvoltage 59
Undervoltage 27
Overfrequency 81
Underfrequency 81
Overload 32
Fast overcurrent 50/51
Current unbalance 60
Voltage asymmetry 60
Loss of excitation (reactive power import) 40
Overexcitation (reactive power export) 40

GPU, GPC, PPU Option C1, Generator add-on protection package
DEIF A/S Page 5 of 10
3. Functional descriptions
Voltage and frequency
Voltage and frequency is set in % of nominal generator value. The delay settings are all of the
definite time type, meaning that a set point and time is selected.
If the function is e.g. overvoltage, then the timer will be activated, if the set point is exceeded. If
the voltage value goes below the set point value before the timer runs out, then the timer will be
stopped and reset.
Set point
Time
Timer
start
Timer
reset
Timer
start
Alarm
Timer setting
Measured
value
When the timer runs out, the output is activated. The total delay will be the delay setting + the
reaction time.
Alarm inhibit
Some of the alarms included in the option C1 can be inhibited in order to avoid nuisance alarms
during controlled conditions such as start/stop of the gen-set and breaker operations.
For general information about the inhibit function, please refer to the Designer’s
Reference Handbook.

GPU, GPC, PPU Option C1, Generator add-on protection package
DEIF A/S Page 6 of 10
4. Parameter list
Parameter table description
The table consists of the following possible adjustments:
Set point: The alarm set point is adjusted in the set point menu. The setting is in
Hz/sec.
Timer: The timer setting indicates the duration of the period between the alarm
situation and the alarm occurrence.
Relay output A: A relay can be activated by the output A.
Relay output B: A relay can be activated by the output B.
Enable: The alarm can be activated or deactivated. ON means always activated,
RUN means that the alarm has run status. This means it is activated when
the running signal is present.
Fast overcurrent protection
1070 Generator fast overcurrent 1 protection
No. Setting Min. setting Max. setting Factory
setting
1071 Fast overcurr. 1 Set point 150.0% 350.0% 150.0%
1072 Fast overcurr. 1 Delay 0.0 s 100.0 s 0.0 s
1073 Fast overcurr. 1 Relay output A R0 (none) R1 (relay 1)
1074 Fast overcurr. 1 Relay output B R0 (none) Option
dependent R0 (none)
1075 Fast overcurr. 1 Enable OFF ON ON
1080 Generator fast overcurrent 2 protection
No. Setting Min. setting Max. setting Factory
setting
1081 Fast overcurr. 2 Set point 150.0% 350.0% 150.0%
1082 Fast overcurr. 2 Delay 0.0 s 100.0 s 1.0 s
1083 Fast overcurr. 2 Relay output A R0 (none) R1 (relay 1)
1084 Fast overcurr. 2 Relay output B R0 (none) Option
dependent R0 (none)
1085 Fast overcurr. 2 Enable OFF ON ON
For further information about the structure of the parameter descriptions,
please see the Designer’s Reference Handbook.
Alarm settings relate to the nominal current setting (menu 4013).

GPU, GPC, PPU Option C1, Generator add-on protection package
DEIF A/S Page 7 of 10
Voltage protections
1100 Generator high voltage 1 protection
No. Setting Min. setting Max. setting Factory
setting
1101 Gen. high volt. 1 Set point 90.0% 120.0% 103.0%
1102 Gen. high volt. 1 Delay 0.1 s 100.0 s 10.0 s
1103 Gen. high volt. 1 Relay output A R0 (none) R0 (none)
1104 Gen. high volt. 1 Relay output B R0 (none) Option
dependent R0 (none)
1105 Gen. high volt. 1 Enable OFF ON OFF
1110 Generator high voltage 2 protection
No. Setting Min. setting Max. setting Factory
setting
1111 Gen. high volt. 2 Set point 90.0% 120.0% 105.0%
1112 Gen. high volt. 2 Delay 0.1 s 100.0 s 5.0 s
1113 Gen. high volt. 2 Relay output A R0 (none) R0 (none)
1114 Gen. high volt. 2 Relay output B R0 (none) Option
dependent R0 (none)
1115 Gen. high volt. 2 Enable OFF ON OFF
1120 Generator low voltage 1 protection
No. Setting Min. setting Max. setting Factory
setting
1121 Gen. low volt. 1 Set point 80.0% 100.0% 97.0%
1122 Gen. low volt. 1 Delay 0.1 s 100.0 s 10.0 s
1123 Gen. low volt. 1 Relay output A R0 (none) R0 (none)
1124 Gen. low volt. 1 Relay output B R0 (none) Option
dependent R0 (none)
1125 Gen. low volt. 1 Enable OFF ON OFF
1130 Generator high voltage 2 protection
No. Setting Min. setting Max. setting Factory
setting
1131 Gen. low volt. 2 Set point 50.0% 100.0% 95.0%
1132 Gen. low volt. 2 Delay 0.1 s 100.0 s 5.0 s
1133 Gen. low volt. 2 Relay output A R0 (none) R0 (none)
1134 Gen. low volt. 2 Relay output B R0 (none) Option
dependent R0 (none)
1135 Gen. low volt. 2 Enable OFF ON OFF
Alarm settings relate to the nominal voltage setting (menu 4014), phase-phase
measurements.

GPU, GPC, PPU Option C1, Generator add-on protection package
DEIF A/S Page 8 of 10
Frequency protections
1140 Generator high frequency 1 protection
No. Setting Min. setting Max. setting Factory
setting
1141 Gen. high freq. 1 Set point 90.0% 120.0% 103.0%
1142 Gen. high freq. 1 Delay 0.2 s 100.0 s 10.0 s
1143 Gen. high freq. 1 Relay output A R0 (none) R0 (none)
1144 Gen. high freq. 1 Relay output B R0 (none) Option
dependent R0 (none)
1145 Gen. high freq. 1 Enable OFF ON OFF
1150 Generator high frequency 2 protection
No. Setting Min. setting Max. setting Factory
setting
1151 Gen. high freq. 2 Set point 90.0% 120.0% 105.0%
1152 Gen. high freq. 2 Delay 0.2 s 100.0 s 5.0 s
1153 Gen. high freq. 2 Relay output A R0 (none) R0 (none)
1154 Gen. high freq. 2 Relay output B R0 (none) Option
dependent R0 (none)
1155 Gen. high freq. 2 Enable OFF ON OFF
1160 Generator low frequency 1 protection
No. Setting Min. setting Max. setting Factory
setting
1161 Gen. low freq. 1 Set point 80.0% 100.0% 97.0%
1162 Gen. low freq. 1 Delay 0.2 s 100.0 s 10.0 s
1163 Gen. low freq. 1 Relay output A R0 (none) R0 (none)
1164 Gen. low freq. 1 Relay output B R0 (none) Option
dependent R0 (none)
1165 Gen. low freq. 1 Enable OFF ON OFF
1170 Generator low frequency 2 protection
No. Setting Min. setting Max. setting Factory
setting
1171 Gen. low freq. 2 Set point 80.0% 100.0% 95.0%
1172 Gen. low freq. 2 Delay 0.2 s 100.0 s 5.0 s
1173 Gen. low freq. 2 Relay output A R0 (none) R0 (none)
1174 Gen. low freq. 2 Relay output B R0 (none) Option
dependent R0 (none)
1175 Gen. low freq. 2 Enable OFF ON OFF
Alarm settings relate to the nominal frequency setting (menu 4011).

GPU, GPC, PPU Option C1, Generator add-on protection package
DEIF A/S Page 9 of 10
Overload protection
1260 Generator overload 1 protection
No. Setting Min. setting Max. setting Factory
setting
1261 Overload 1 Set point 10.0% 200.0% 100.0%
1262 Overload 1 Delay 0.1 s 100.0 s 10.0 s
1263 Overload 1 Relay output A R0 (none) R2 (relay 2)
1264 Overload 1 Relay output B R0 (none) Option
dependent R0 (none)
1265 Overload 1 Enable OFF ON OFF
1270 Generator overload 2 protection
No. Setting Min. setting Max. setting Factory
setting
1271 Overload 2 Set point 10.0% 200.0% 110.0%
1272 Overload 2 Delay 0.1 s 100.0 s 5.0 s
1273 Overload 2 Relay output A R0 (none) R2 (relay 2)
1274 Overload 2 Relay output B R0 (none) Option
dependent R0 (none)
1275 Overload 2 Enable OFF ON OFF
1390 Generator overload 3 protection
No. Setting Min. setting Max. setting Factory
setting
1391 Overload 3 Set point 10.0% 200.0% 120.0%
1392 Overload 3 Delay 0.1 s 100.0 s 5.0 s
1393 Overload 3 Relay output A R0 (none) R2 (relay 2)
1394 Overload 3 Relay output B R0 (none) Option
dependent R0 (none)
1395 Overload 3 Enable OFF ON OFF
Current unbalance protection
1280 Generator current unbalance protection
No. Setting Min. setting Max. setting Factory
setting
1281 Current unbalance Set point 0.0% 100.0% 30.0%
1282 Current unbalance Delay 0.1 s 100.0 s 10.0 s
1283 Current unbalance Relay output A R0 (none) R2 (relay 2)
1284 Current unbalance Relay output B R0 (none) Option
dependent R0 (none)
1285 Current unbalance Enable OFF ON OFF
Alarm settings relate to the nominal power setting (menu 4012).
Alarm settings relate to the nominal current setting (menu 4013).
Overload 3 is not included in the parameter shift function. (Please refer to the
Designers Reference Handbook.)

GPU, GPC, PPU Option C1, Generator add-on protection package
DEIF A/S Page 10 of 10
Voltage asymmetry protection
1290 Generator voltage unbalance protection
No. Setting Min. setting Max. setting Factory
setting
1291 Voltage unbalance Set point 0.0% 50.0% 10.0%
1292 Voltage unbalance Delay 0.1 s 100.0 s 10.0 s
1293 Voltage unbalance Relay output A R0 (none) R2 (relay 2)
1294 Voltage unbalance Relay output B R0 (none) Option
dependent R0 (none)
1295 Voltage unbalance Enable OFF ON OFF
VAr import (loss of excitation) protection
1300 Generator VAr import protection
No. Setting Min. setting Max. setting Factory
setting
1301 VAr import Set point 0.0% 150.0% 10.0%
1302 VAr import Delay 0.1 s 100.0 s 10.0 s
1303 VAr import Relay output A R0 (none) R1 (relay 1)
1304 VAr import Relay output B R0 (none) Option
dependent R0 (none)
1305 VAr import Enable OFF ON OFF
VAr export (overexcitation) protection
1310 Generator VAr export protection
No. Setting Min. setting Max. setting Factory
setting
1311 VAr export Set point 0.0% 100.0% 75.0%
1312 VAr export Delay 0.1 s 100.0 s 10.0 s
1313 VAr export Relay output A R0 (none) R2 (relay 2)
1314 VAr export Relay output B R0 (none) Option
dependent R0 (none)
1315 VAr export Enable OFF ON OFF
DEIF A/S reserves the right to change any of the above
Alarm settings relate to the nominal voltage setting (menu 4014).
Alarm settings relate to the nominal power setting in kW (menu 4012).
Alarm settings relate to the nominal power setting in kW (menu 4012).
