EVM User's Guide: TPS1213Q1EVM TPS1213-Q1
TPS1213-Q1 Evaluation Module for Smart High-Side
Driver
Description
The TPS1213Q1EVM allows reference circuit
evaluation of TI's TPS1213-Q1 smart high-side driver.
The TPS1213-Q1 device has operating range of
3.5V-40V and has main path gate drive with 1.69-A
strength to enable switching parallel MOSFETs in high
current designs. The TPS12130-Q1 has low-power
mode to support always ON loads while consuming
28 µA (typ). In low power mode, only the low power
path FET is kept ON and the main FETs are turned
OFF to save IQ. The device provides adjustable
short circuit protection with configurable auto-retry
and latch-off fault behavior.
Features
• 3.5-V to 40-V operating voltage range
• 15-A to 50-A adjustable short circuit protection
using onboard jumpers
• Programmable short-circuit protection delay
• Programmable load wakeup threshold
• Programmable auto-retry and latch options
• LED status indication for fault and Active mode
Applications
•Automotive 12 V BMS
•Power distribution box
www.ti.com Description
SLUUCV7 – DECEMBER 2023
Submit Document Feedback
TPS1213-Q1 Evaluation Module for Smart High-Side Driver 1
Copyright © 2023 Texas Instruments Incorporated

1 Evaluation Module Overview
1.1 Introduction
This user’s guide describes the TPS1213-Q1 evaluation module (EVM). This guide provides configuration
information, test setup details and contains the EVM schematics, bill of materials, assembly drawings, and top
and bottom board layouts.
CAUTION
Hot surface. Contact can cause burns. Do not touch.
1.2 Kit Contents
Table 1-1. TPS1213Q1EVM Kit Contents
Item Description Quantity
TPS1213Q1EVM PCB 1
1.3 Specification
• 6-V to 36-V (typ) operation
• Current sensing using MOSFET VDS
• Programmable load wakeup threshold
1.4 Device Information
The TPS1213-Q1 is a 45-V low IQ smart high side driver with protection and diagnostics. With wide operating
voltage range of 3.5 V–40 V, the device is an excellent choice for 12-V system designs. The device can
withstand and protect the loads from negative supply voltages down to –40 V. The device has integrated two
gate drives with 1.69-A src/2-A sink capacity to drive MOSFETs in the main path and 150-μA src/2-A sink
capacity for the low power path.
In the low power mode with LPM = Low, the low power path FET is kept ON and the main FETs are turned OFF.
The device consumes low IQ of 35- μA (typ) in this mode. Auto Load wakeup threshold to enter into active state
can be adjusted using ISCP/LWU pin. IQ reduces to 1-μA (typ) with EN/ UVLO low.
The device provides adjustable short circuit protection using MOSFET VDS sensing or by using an external
RSNS resistor. Auto-retry and latch-off fault behavior can be configured. The device also features diagnosis of
the internal short circuit comparator using external control on SCP_TEST input.
Evaluation Module Overview www.ti.com
2TPS1213-Q1 Evaluation Module for Smart High-Side Driver SLUUCV7 – DECEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

2 Hardware
The TPS1213Q1EVM evaluation board enables evaluation of TPS12130-Q1 driver. The input power is applied
between connectors T1 and T3 while T2 and T4 provide an output connection to the load, Refer to the schematic
in Figure 4-1 and EVM test setup in Figure 3-1.
D3 provides the fault indication output for under-voltage fault, short-circuit fault and during SCP comparator
diagnosis whereas D4 provides the device is in active mode.
Table 2-1. TPS1213Q1EVM Evaluation Board Options and Setting
Part Number EVM Function Vin Range Vin UVLO ENABLE
(EN/UVLO)
Short circuit
protection Features
Low Setting Hi Setting
TPS1213Q1EVM
Low IQ High Side
Switch Controller with
Low Power Mode
and Adjustable Load
Wakeup Trigger
6 V–36 V 6 V Active high 15 A 50 A
MOSFET VDS
sensing
Short-circuit
protection with Auto-
retry/ latch response
www.ti.com Hardware
SLUUCV7 – DECEMBER 2023
Submit Document Feedback
TPS1213-Q1 Evaluation Module for Smart High-Side Driver 3
Copyright © 2023 Texas Instruments Incorporated

2.1 General Configurations
2.1.1 Physical Access
Table 2-2 lists the TPS1213Q1EVM Evaluation Board input and output connector functionality. Table 2-3 and
Table 2-4 describe the test point availability and the jumper functionality.
Table 2-2. Input and Output Connector Functionality
Connector Label Description
T1 VIN Power input connector to the positive rail of the input power supply
T3 PGND Ground connection for the power supply
T2 VOUT Power output connector to the positive side of the load
T4 PGND Ground connection for the load
Table 2-3. Test Points Description
Test Points Label Description
TP1 G2 GATE of the low power path MOSFET
TP2 VIN Input power supply to the EVM
TP3 VOUT Output from the EVM
TP4 EN/UVLO Enable control (active high) and undervoltage input
TP5 GATE GATE of the external main MOSFET
TP6 TMR Fault timer voltage
TP7 VAUX Auxiliary supply to bias the LEDs
TP8 INP Control input of main MOSFET
TP9 LPMb Low power mode control input
TP10 INP/ Inversion of control input for main MOSFET
TP11 LPM Inversion of control input for the low power mode
TP12 FLTb Fault output
TP13 WAKE Output to indicate active mode
TP14, TP15 PGND Power ground
TP16 GND Ground
TP17, TP18 CAP_INS Connector to insert output capacitor
TP19 SCP_TEST Internal short circuit comparator (SCP) diagnosis input
Table 2-4. Jumper and LED Descriptions
Jumper Label Description
J1 SCP_TEST Internal short circuit comparator (SCP) diagnosis input.
1-2 Position disables the diagnosis function.
J2 LPM 1-2 position forces the device to lower power mode.
J3 TMR
Short-circuit protection delay setting.
1-2 Position sets 1 ms delay.
3-4 Position sets 10 ms delay.
5-6 Position sets the controller in Latch-off mode.
J4 ISCP/LWU
Short-circuit protection threshold setting.
1-2 Position sets ISCP at 15 A and LWU at 11.5mA.
3-4 Position sets ISCP at 25 A and LWU at 17.5mA.
5-6 Position sets ISCP at 50 A and LWU at 35 mA.
J5 BST 1-2 position charges BST capacitor from the VIN.
D3
(RED – LED) D3 Fault indicator. LED turns ON for under-voltage fault, short-circuit fault and during SCP comparator diagnosis.
D4
(GREEN – LED) D4 LED turns ON when device enters into active mode.
Hardware www.ti.com
4TPS1213-Q1 Evaluation Module for Smart High-Side Driver SLUUCV7 – DECEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

2.1.2 Test Equipment and Setup
2.1.2.1 Power Supplies
One adjustable power supply with 0-V to 40V- output and 0-A to 50-A output current limit.
2.1.2.2 Meters
One DMM minimum needed.
2.1.2.3 Oscilloscope
A DPO2024 or equivalent, three 10 times voltage probes, and a DC current probe.
2.1.2.4 Loads
One resistive load or equivalent that can tolerate up to 50-A DC load at 40 V and capable of the output short.
www.ti.com Hardware
SLUUCV7 – DECEMBER 2023
Submit Document Feedback
TPS1213-Q1 Evaluation Module for Smart High-Side Driver 5
Copyright © 2023 Texas Instruments Incorporated

3 Implementation Results
3.1 Test Setup and Procedures
Make sure the evaluation board has default jumper settings as shown in Table 3-1.
Table 3-1. Default Jumper Setting for TPS1213Q1EVM Evaluation Board
J1 J2 J3 J4 J5
Install Install 5-6 5-6 OPEN
Positive
Negative
Positive
Load
Negative
Voltmeter
PRINT
HELP
ALPHA
SHIFT
ENTER
RUN
D
GE RF I
A
JB KC L
7
M8 N9 O
D
GD GD G
D
G T 3 U
0
V. WXYZ
TAB
% UTILIZATION
HUB/MAU NIC
2
BNC
4Mb/s
Oscilloscope
Power
Supply
Figure 3-1. TPS1213Q1EVM Setup with Test Equipment
Follow the below instructions before starting any test and repeat again before moving to next test.
• Set the power supply output (VIN) to zero volts.
• Turn ON the power supply and set the power supply output (VIN) to 12 V, current limit = 50 A.
• Turn OFF the power supply.
• Set the jumper setting on EVM to default position as shown in Table 3-1.
Implementation Results www.ti.com
6TPS1213-Q1 Evaluation Module for Smart High-Side Driver SLUUCV7 – DECEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

3.1.1 Startup in Low Power Mode
Use the following instructions to verify the power up profile of TPS12130-Q1
1. Connect the EN/UVLO pin (TP4) to ground.
2. Now, enable the EN/UVLO to HIGH to verify the startup profile of BST, G2 and SRC.
Figure 3-2. Start-Up Profile of Low Power Path (LPMb = Low, VIN= 12 V, No-load, CBST = 470 nF)
www.ti.com Implementation Results
SLUUCV7 – DECEMBER 2023
Submit Document Feedback
TPS1213-Q1 Evaluation Module for Smart High-Side Driver 7
Copyright © 2023 Texas Instruments Incorporated

3.1.2 State Transition (LPM to Active Mode through Load Wakeup Trigger)
Use the following instructions to verify state transition of TPS12130-Q1 through load wakeup trigger
1. Apply 12 V at the input of the EVM at no-load.
2. Enable the EN/UVLO to HIGH.
3. Now, gradually increase the load current from 5 mA to 200 mA and observe the transition from low power
mode to Active mode at the pins of G1 (TP5), G2 (TP1), WAKE (TP13) and load current using oscilloscope.
Figure 3-3. State Transition from LPM to Active Mode (LPMb = Low, VIN= 12 V, EN/UVLO = High)
Figure 3-4. Zoom-in View of State Transition from LPM to Active Mode (LPMb = Low, VIN= 12 V, EN/UVLO
= High)
Implementation Results www.ti.com
8TPS1213-Q1 Evaluation Module for Smart High-Side Driver SLUUCV7 – DECEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

Figure 3-5. As LPMb = Low, INP Has No Control on G1 Even After WAKEUP
www.ti.com Implementation Results
SLUUCV7 – DECEMBER 2023
Submit Document Feedback
TPS1213-Q1 Evaluation Module for Smart High-Side Driver 9
Copyright © 2023 Texas Instruments Incorporated

3.1.3 State Transition (LPM to Active Mode with LPMb Trigger)
Use the following instructions to verify state transition of TPS12130-Q1 with LPMb trigger.
1. Apply 12 V at the input of the EVM at no-load.
2. Enable the EN/UVLO to HIGH.
3. Now, make LPMb from LOW to HIGH to see the state transition from LPM to active mode.
Figure 3-6. State Transition from LPM to Active Mode (LPMb = Low to High, VIN= 12 V, No-load)
Figure 3-7. With LPMb = Low to High, INP Gained Control on G1 (VIN= 12 V, No-load)
Implementation Results www.ti.com
10 TPS1213-Q1 Evaluation Module for Smart High-Side Driver SLUUCV7 – DECEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

3.1.4 Inrush Current Limit Test
Use the following instructions to measure the inrush current during startup in low power mode.
1. Populate R3 = 10 Ω and C1 = 15 nF on the EVM.
2. Connect 220 µF at the output terminals of the EVM.
3. Apply 12 V at the input of the EVM at no-load.
4. Enable the EN/UVLO to HIGH.
5. Observe the waveform at VOUT (TP3) with an oscilloscope to measure the slew rate and risetime with a
given input voltage of 12 V.
6. Repeat the same test with 0.5A load at the output to see the state transition from LPM to active mode.
Figure 3-8. Inrush Current Profile with 220 µF at the Output (LPMb = Low)
Figure 3-9. Inrush Current Profile with 220 µF at the Output and 0.5A Load (LPMb = Low)
www.ti.com Implementation Results
SLUUCV7 – DECEMBER 2023
Submit Document Feedback
TPS1213-Q1 Evaluation Module for Smart High-Side Driver 11
Copyright © 2023 Texas Instruments Incorporated

3.1.5 Overload and Short Circuit Protection Test
Use the following instructions to perform over current test on the TPS1213Q1EVM
1. Turn ON the power supply and set the power supply output VIN=12 V, current limit = 50 A.
2. Set the Short Circuit Protection (SCP) threshold at 50 A by installing jumper J4 in 5-6 position and install
jumper J3 in 1-2 position to set 1-ms delay.
3. Uninstall J2 to enable the Active mode of operation.
4. Now, load the output to 40 A with electronic load and apply a step of 15 A to observe the overload behavior
of TPS12130-Q1.
5. Disconnect the load.
6. To perform short-circuit test, uninstall J3 to set shortest SCP delay.
7. Now perform output short to capture the short-circuit behavior of TPS12130-Q1.
Figure 3-10. Overcurrent Response of TPS1213Q1EVM for 40-A to 55-A Load Step
Figure 3-11. Auto-Retry Response of TPS12130-Q1 for an Overcurrent Fault
Implementation Results www.ti.com
12 TPS1213-Q1 Evaluation Module for Smart High-Side Driver SLUUCV7 – DECEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

Figure 3-12. Latch-off Response of TPS12130-Q1 for an Overcurrent Fault
Figure 3-13. Output Short-Circuit Response of TPS12130-Q1
www.ti.com Implementation Results
SLUUCV7 – DECEMBER 2023
Submit Document Feedback
TPS1213-Q1 Evaluation Module for Smart High-Side Driver 13
Copyright © 2023 Texas Instruments Incorporated

4 Hardware Design Files
4.1 Schematic
Figure 4-1 illustrates the EVM schematic.
GND
TP4
EN/UVLO
R5
470k
GND
VIN
VIN
TP2
470nF
25V
C10
LPMb
WAKE
FLTb
ISCP
CS_SEL
SCP_TEST
Aux Power Supply and Fault Indicators
1
23 Q4
GND
VIN
TP7
VAUX
TP12
FLTb
5V
Red
12
D3
5.6V
D5
VAUX
R21
3.16k
R17
10.0k
R18
10.0k
FLTb
PGNDPGND
VOUT
PGND
G2
PGND GND
1NT2 2
1NT1 2
SRC
TP13
WAKE
R22
3.16k
WAKE
1 2
3 4 5 6
J3
TP6
TMR
Circuit Breaker Timer Setting
TMR
GND
100k
R23
68nF
C13
1ms 10ms
C14
680nF
TMR
0
R14
GND
ISCP
GND
Short Circuit Protection Setting
15A 25A 50A
1 2
3 4 5 6
J4
1
2
J1
TP5
GATE
VOUT
TP3
GND
INP
INP
TP8
VAUX
1
2 3
Q5
GND
R15
INP
3.16k
INP/
TP10
TP9
LPMb
VAUX
1
2 3
Q6
GND
R16
3.16k
LPMb
LPM
TP11
R19
9.53k
R20
9.53k
CS+ 18
17
CS-
FLT 5
4
WAKE
12
BST
10
SCP_TEST
1EN/UVLO
7CS_SEL
3INP
NC 19
8ISCP/LWU
G2
11
2LPM
14
G1PD
15
G1PU
13
SRC
TMR
9
20 VS
6
GND
U1
GND
TPS12130QDGXRQ1
R12 10.0
R13 0
0
R8
0
R10 SRC
1
2
J2
T1
CB70-14-CY
PGND
T3
CB70-14-CY
T2
CB70-14-CY
T4
GND CB70-14-CY
100
R4
100nF
50V
C7
50V
C5
1µF
50V
C4
1µF50V
10uF
C350V
C2
0.01µF
100
R6
50V
C9
0.01µF
105k
R11
Green
D4
470nF
25V
C11
10.0
R3
R7
2.21
R9
2.21
50V
0.01µF
C8
22nF
C1
50V
GND
G2
TP1
G2
GND
TP14
GND
TP15
GND
TP16
GND
1 2
D1
SMBJ36CA-13-F
1
R1
1 2
D2
SMBJ36CA-13-F
C15
0.01µF
GND
C16
0.01µF
GND
SCP_TEST
TP19
SCP_TEST R28
3.16k
VAUX
R27
2.21
750
R24
TP17
TP18
PGND PGND
4
25
1
3
Q7
4
25
1
3
Q1
4
25
1
3
Q2
3
41
2
5
7
6
8
Q3
R29
2.21
G2
R26
12.4k
R25
3.74k
D6
1
2
J5
VIN
50V
C12
1µF
50V
10uF
C17
50V
1µF
C18
50V
C6
1µF
PGND
0
R2
Figure 4-1. TPS1213Q1EVM: Evaluation Module Schematic
Hardware Design Files www.ti.com
14 TPS1213-Q1 Evaluation Module for Smart High-Side Driver SLUUCV7 – DECEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

4.2 PCB Layout
Figure 4-2 and Figure 4-3 shows component placement of the EVAL Board, and Figure 4-4 through Figure 4-7
show PCB layout images.
Figure 4-2. TPS1213Q1EVM Board Top Overlay Figure 4-3. TPS1213Q1EVM Board Bottom Overlay
Figure 4-4. TPS1213Q1EVM Board Top Layer Figure 4-5. TPS1213Q1EVM Board Bottom Layer
www.ti.com Hardware Design Files
SLUUCV7 – DECEMBER 2023
Submit Document Feedback
TPS1213-Q1 Evaluation Module for Smart High-Side Driver 15
Copyright © 2023 Texas Instruments Incorporated

Figure 4-6. TPS1213Q1EVM Board Inner Signal
Layer
Figure 4-7. TPS1213Q1EVM Board Inner Routing
Layer
Hardware Design Files www.ti.com
16 TPS1213-Q1 Evaluation Module for Smart High-Side Driver SLUUCV7 – DECEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

4.3 Bill Of Materials (BoM)
Table 4-1 lists the EVM bill of materials.
Table 4-1. TPS1213Q1EVM Bill Of Materials
Designator Quantity Description Part Number Manufacturer
!PCB1 1 Printed Circuit Board LP102 Any
C3, C17 2 CAP, CERM, 10 uF, 50 V, +/- 20%, X7R, 1210 GRM32ER71H106MA12 MuRata
C4, C5, C6, C12, C18 5 CAP, CERM, 1 uF, 50 V, +/- 10%, X7R, AEC-Q200
Grade 1, 0805 CGA4J3X7R1H105K125AB TDK
C7 1 CAP, CERM, 0.1 uF, 50 V, +/- 10%, X7R, AEC-Q200
Grade 1, 0603 CGA3E2X7R1H104K080AA TDK
C10 1 CAP, CERM, 0.47 uF, 25 V, +/- 10%, X7R, AEC-
Q200 Grade 1, 0603 CGA3E3X7R1E474K080AB TDK
C13 1 CAP, CERM, 0.068 uF, 100 V, +/- 10%, X7R, 0805 C0805C683K1RACTU Kemet
C14 1 CAP, CERM, 0.68 uF, 50 V, +/- 10%, X7R, 0805 C0805C684K5RACTU Kemet
D1, D2 2 58.1V Clamp 10.3A Ipp Tvs Diode Surface Mount
SMB SMBJ36CA-13-F Diodes Inc
D3 1 LED, Red, SMD LTST-C170KRKT Lite-On
D4 1 LED, Green, SMD LTST-C170KGKT Lite-On
D5 1 Diode, Zener, 5.6 V, 300 mW, AEC-Q101, SOD-323 SZMM3Z5V6ST1G ON Semiconductor
D6 1 Diode, Schottky, 100 V, 0.25 A, SOD-123F BAT46WH,115 Nexperia
H1, H2, H3, H4 4 Machine Screw, Round, #4-40 x 1/4, Nylon, Philips
panhead NY PMS 440 0025 PH B&F Fastener Supply
H5, H6, H7, H8 4 1902C Keystone
J1, J2, J5 3 Header, 100mil, 2x1, Gold, TH PBC02SAAN Sullins Connector Solutions
J3, J4 2 Header, 100mil, 3x2, Tin, TH PEC03DAAN Sullins Connector Solutions
Q1, Q2 2 Trans MOSFET N-CH 40 V 190 A Automotive 5-
Pin(4+Tab) LFPAK T/R BUK7J1R4-40HX Nexperia
Q4 1 Transistor, NPN, 160 V, 0.3 A, SOT-23 PMBT5551,215 Nexperia
Q5, Q6 2 MOSFET, N-CH, 60 V, 0.115 A, SOT-323 2N7002W-7-F Diodes Inc
Q7 1 Trans MOSFET N-CH 40 V 25 A Automotive 5-
Pin(4+Tab) LFPAK T/R BUK9Y29-40E,115 Nexperia
R1 1 RES Thick Film, 1 Ω, 1%, 1.5W, 100 ppm/°C, 1218 CRCW12181R00FKEKHP Vishay
www.ti.com Hardware Design Files
SLUUCV7 – DECEMBER 2023
Submit Document Feedback
TPS1213-Q1 Evaluation Module for Smart High-Side Driver 17
Copyright © 2023 Texas Instruments Incorporated

Table 4-1. TPS1213Q1EVM Bill Of Materials (continued)
Designator Quantity Description Part Number Manufacturer
R2 1 RES, 0, 0.75 W, AEC-Q200 Grade 0, 1206 CRCW12060000Z0EAHP Vishay-Dale
R4 1 RES, 100, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 ERJ-3EKF1000V Panasonic
R5 1 RES, 470 k, 1%, 0.1 W, 0603 RC0603FR-07470KL Yageo
R7, R9, R29 3 RES, 2.21, 1%, 0.1 W, 0603 RC0603FR-072R21L Yageo
R8, R10, R13, R14 4 RES, 0, 5%, 0.1 W, AEC-Q200 Grade 0, 0603 CRCW06030000Z0EA Vishay-Dale
R11 1 RES, 105 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 CRCW0603105KFKEA Vishay-Dale
R12 1 RES, 10.0, 1%, 0.25 W, AEC-Q200 Grade 0, 0603 CRCW060310R0FKEAHP Vishay-Dale
R15, R16, R21, R22, R28 5 RES, 3.16 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 CRCW06033K16FKEA Vishay-Dale
R17, R18 2 RES, 10.0 k, 1%, 0.125 W, AEC-Q200 Grade 0, 0805 ERJ-6ENF1002V Panasonic
R19, R20 2 RES, 9.53 k, 1%, 0.1 W, 0603 RC0603FR-079K53L Yageo
R23 1 RES, 100 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 CRCW0603100KFKEA Vishay-Dale
R24 1 RES, 750, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 CRCW0603750RFKEA Vishay-Dale
R25 1 RES, 3.74 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 CRCW06033K74FKEA Vishay-Dale
R26 1 RES, 12.4 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 CRCW060312K4FKEA Vishay-Dale
SH-J1, SH-J2, SH-J3,
SH-J4 4 Shunt, 100mil, Flash Gold, Black SPC02SYAN Sullins Connector Solutions
T1, T2, T3, T4 4 Terminal 90 A Lug CB70-14-CY Panduit
TP1, TP4, TP5, TP6,
TP8, TP9, TP12, TP13,
TP19
9 Test Point, Multipurpose, White, TH 5012 Keystone
TP2, TP3, TP7 3 Test Point, Multipurpose, Red, TH 5010 Keystone
TP10, TP11 2 Test Point, Multipurpose, Orange, TH 5013 Keystone
TP14, TP15, TP16 3 Test Point, Multipurpose, Black, TH 5011 Keystone
TP17, TP18 2 Connector, Receptacle, Pin, TH 0300-2-15-01-47-01-10-0 Mill-Max
U1 1 Low IQ Smart High Side gate driver with SCP and
Diagnostics TPS12130QDGXRQ1 Texas Instruments
C1 0 CAP, CERM, 0.022 uF, 50 V, +/- 10%, X7R, 0603 C0603C223K5RACTU Kemet
C2, C8, C9, C15, C16 0 CAP, CERM, 0.01 uF, 50 V, +/- 10%, X7R, AEC-
Q200 Grade 1, 0603 GCM188R71H103KA37D MuRata
Hardware Design Files www.ti.com
18 TPS1213-Q1 Evaluation Module for Smart High-Side Driver SLUUCV7 – DECEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

Table 4-1. TPS1213Q1EVM Bill Of Materials (continued)
Designator Quantity Description Part Number Manufacturer
C11 0 CAP, CERM, 0.47 uF, 25 V, +/- 10%, X7R, AEC-
Q200 Grade 1, 0603 CGA3E3X7R1E474K080AB TDK
FID1, FID2, FID3, FID4,
FID5, FID6 0 Fiducial mark. N/A N/A
Q3 0 N-Channel 40 V 2.9A (Ta), 5.7A (Tc) 2W (Ta), 7.5W
(Tc) Surface Mount DFN2020MD-6 BUK6D120-40EX Nexperia
R3 0 RES, 10.0, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 CRCW060310R0FKEA Vishay-Dale
R6 0 RES, 100, 1%, 0.5 W, AEC-Q200 Grade 0, 1206 CRCW1206100RFKEAHP Vishay-Dale
R27 0 RES, 2.21, 1%, 0.1 W, 0603 RC0603FR-072R21L Yageo
www.ti.com Hardware Design Files
SLUUCV7 – DECEMBER 2023
Submit Document Feedback
TPS1213-Q1 Evaluation Module for Smart High-Side Driver 19
Copyright © 2023 Texas Instruments Incorporated

5 Additional Information
Trademarks
All trademarks are the property of their respective owners.
Additional Information www.ti.com
20 TPS1213-Q1 Evaluation Module for Smart High-Side Driver SLUUCV7 – DECEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated
