Dell OptiPlex 7090 User manual

OptiPlex 7090 Tower Cable Cover
Install Guide
May 2021
Rev. A00

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid
the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2021 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other
trademarks may be trademarks of their respective owners.

Chapter 1: Before you begin ......................................................................................................... 4
Chapter 2: Dell OptiPlex Tower Cable Cover..................................................................................5
Chapter 3: After installing the accessory...................................................................................... 9
Chapter 4: Getting help and contacting Dell.................................................................................10
Contents
Contents 3

Before you begin
Steps
1. Save and close all open files and exit all open applications.
2. Shut down your system: Click Start > Power > Shut down .
NOTE: If you are using a Linux operating system, see the documentation of your operating system for shut-down
instructions.
3. Disconnect your system and all attached devices from their electrical outlets.
4. Disconnect all attached network devices and peripherals, such as keyboard, mouse, and monitor from your system.
CAUTION: To disconnect a network cable, first unplug the cable from your system and then unplug the cable
from the network device.
5. If the system unit or the adapter is being installed on the monitor:
a. Disconnect the power and all the display cables from the monitor.
b. Remove the stand from the monitor and place the monitor on a clean and soft surface.
1
4 Before you begin

Dell OptiPlex Tower Cable Cover
The cable cover for the OptiPlex 7090 Tower system protects the ports and organize cables that are connected to the system
unit.
Steps
1. Follow the instructions in before you begin.
2. NOTE: Images that are shown below may vary depending on your system configuration.
Route the cables through the slot on the cable cover and connect the cables to their respective ports.
2
Dell OptiPlex Tower Cable Cover 5

3. Align the cable cover retaining hooks into the slots on the OptiPlex 7090 Tower chassis.
CAUTION: Take care not to bend or break the delicate plastic hooks.
6 Dell OptiPlex Tower Cable Cover

4. Gently press down on the cable cover until it clicks into place.
5. Slide the latch to lock the cable cover in place.
Dell OptiPlex Tower Cable Cover 7

NOTE: For added security, use the Kensington cable lock to secure the system unit.
8 Dell OptiPlex Tower Cable Cover

After installing the accessory
Steps
1. Replace all screws and ensure that no stray screws remain.
2. Connect any external devices, peripherals, or cables you removed before working on your system.
3. Connect your system and all attached devices to their electrical outlets.
4. Turn on your system.
3
After installing the accessory 9

Getting help and contacting Dell
Self-help resources
You can get information and help on Dell products and services using these self-help resources:
Table 1. Self-help resources
Self-help resources Resource location
Information about Dell products and services www.dell.com
My Dell app
Tips
Contact Support In Windows search, type Contact Support, and press
Enter.
Online help for operating system www.dell.com/support/windows
www.dell.com/support/linux
Access top solutions, diagnostics, drivers and downloads, and
learn more about your computer through videos, manuals and
documents.
Your Dell computer is uniquely identified by a Service Tag or
Express Service Code. To view relevant support resources for
your Dell computer, enter the Service Tag or Express Service
Code at www.dell.com/support.
For more information on how to find the Service Tag for your
computer, see Locate the Service Tag on your computer.
Dell knowledge base articles for a variety of computer
concerns
1. Go to www.dell.com/support.
2. On the menu bar at the top of the Support page, select
Support > Knowledge Base.
3. In the Search field on the Knowledge Base page, type the
keyword, topic, or model number, and then click or tap the
search icon to view the related articles.
Contacting Dell
To contact Dell for sales, technical support, or customer service issues, see www.dell.com/contactdell.
NOTE: Availability varies by country/region and product, and some services may not be available in your country/region.
NOTE: If you do not have an active Internet connection, you can find contact information about your purchase invoice,
packing slip, bill, or Dell product catalog.
4
10 Getting help and contacting Dell
