DeLonghi AN Series User manual

www.delonghi.com 5715112451_00/11.16 _ Printed in China

AN Series
PORTABLE AIR CONDITIONER
Instructions for use. Keep these instructions
Visit www.delonghi.com for a list of service
centers near you.
ELECTRIC CHARACTERISTICS
115 V~ 60 Hz
CONDITIONNEUR D’AIR PORTATIF
Mode d’emploi . Conservez cette notice
Visitez www.delonghi.com pour y voir une liste
des centres de réparation proches de chez vous.
CARACTÉRISTIQUES ÉLECTRIQUES
115 V~ 60 Hz
SISTEMA DE AIRE
ACONDICIONADO PORTÁTIL
Repase y guarde estas instrucciones.
Lea cuidadosamente este instructivo
antes de usar su aparato.
Visite www.delonghi.com para ver la lista
de centros de servicios cercanos a usted.
CARACTERISTICAS ELECTRICAS:
115 V~ 60 Hz

2
EN FR ES
page pagina 4 page pagina 14 pág. pagina 24

3
13
1
2
3
4
6 5
7
8
9
10
12 14 15
11
16
17 18 19

4
en
IMPORTANT SAFEGUARD
• Use this appliance only as described in this
instruction manual.
As with any electrical appliance, the
instructions aim to cover as many situations as
possible. Caution and common sense should
be used when operating and installing this air
conditioner.
• This appliance has been manufactured to cool
and dehumidify domestic environments and
must not be used for other purposes.
• It is dangerous to alter or modify the unit's
characteristics in any way.
• The appliance must be installed in accordance
with the relevant national legislation.
• Shouldrepairs be necessary, contact thenearest
authorized Repair Service Center. Unauthorized
servicing can be dangerous.
• The appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that
they do not play with the appliance.
• If the power cable is damaged, it must be
replaced by the manufacturer or an authorized
technical service centre in order to avoid all risk.
• Always ensure the appliance is plugged into
a grounded 3-prong outlet. If you have any
doubts check with a qualied electrician.
• Do not use extension cables.
• Before cleaning or maintenance operations,
always unplug the unit from the outlet.
• Do not pull on or place strain on the power cord
when moving the appliance.
• Theappliance should notbeinstalledwherethe
atmosphere may contain combustible gases, oil
or sulphur, or near heat sources.
• Do not rest hot or heavy objects on the
appliance.
• Clean the lters at least once a week.
• Avoid using heaters near the unit.
• The unit should be transported in a vertical
position. If this is not possible secure the unit at
an angle, do not lie it horizontally.
• Before transporting the unit, drain the unit.
After transportation, wait at least 6 hours
before switching the unit on.
• The packaging materials can be recycled. You
are therefore recommended to place them in
the special containers for dierentiated waste
collection.
• This appliance is tted with a special safety
device. When the compressor switches o, this
device prevents it from switching on again for
at least 3 minutes.
• WARNING: Changes or modications not
expressly approved by the party responsible for
compliance could void the user's authority to
operate the equipment.
Specic warnings for appliances with R410A
refrigerant gas
R410A is a refrigerant that complies with
European ecological standards; nevertheless, it is
recommended not to pierce the cooling circuit of
the machine. At the end of its useful life, deliver the
appliance to a special waste collection centre for
disposal.
Thishermeticallysealedsystemcontainsuorinated
greenhouse gases.
ENVIRONMENTAL INFORMATION:
This unit contains uorinated greenhouse gases
covered by the Kyoto Protocol.
Maintenance and disposal must be carried out by
qualied personnel only (R410A, GWP=2088).
Save these instructions
This product is for household only

5
A
INTRODUCTION
Thank you for choosing a De’Longhi product. Please take a few
moments to read the instructions to avoid risks or damage to
the appliance.
DESCRIPTION
Description of the appliance (see page 3 )
1Air outlet grille
2Control panel
3Handles
4Castors
5 Remote control housing
6Filter
7 Air intake grille
8Air exhaust hose housing
9Air intake grille
10 Power cable
11 Drainage hose with 2 caps
12 Wall ange with cap
13 Air exhaust hose
14 Hose adaptor
15 Accessory for wall mounting
16 Window bracket
17 Additional window bracket
18 Window outlet
19 Remote control
Electrical connection
Before plugging the appliance into the electrical receptacle,
check that:
• The outlet’s power supply corresponds to the value indi-
cated on the rating label on the back of the appliance;
• The outlet and electrical circuit are adequate for the appli-
ance;
• The outlet is a 3-hole grounded outlet . If this is not
the case, you must choose another outlet. Failure to follow
these important safety instructions absolves the manufac-
turer of all liability.
If it becomes necessary, the power cable must be re-
placed by a qualied professional only.
The instructions below will enable you to prepare your air condi-
tioner for operation as eciently as possible. Before use, make
sure the air intake and outlet grilles are unobstructed.
USE
Air conditioning with installation
For optimal results set-up your appliance in this way:
1) Screw the hose adaptor 13 to the hose’s end 12.
2) Fit the air exhaust hose in the housing at the back of the
appliance. Insert it as shown in gure A.
3) Drill a hole (ø134mm / 5.27 in.) in an outside wall or
through a window pane.
Respect the height and dimensions of the hole given in
gures Band C.
Note:
This appliance is provided with an auto-evaporation
feature for conensate removal during cooling and de-
humiding modes.
12 inches
30 cm
30 cm
12 inches
B
134
5.27 inches
C
in the window pane in the wooden
kickboard of a
French window
in the wall: you are
recommended to
insulate the section
of wall using suitable
insulation.

6
4) Fit the wall ange 12 into the hole.
5) Screw the hose adaptor 14 to the hose’s end 13 (g. A).
6) Fit the air exhaust hose in the housing at the back of the
appliance as shown in gure A.
7) Screw the wall mounting accessory 15 into the hose 13
(g. D) and t it into the wall ange 12 as shown in g. E.
When the hose 13 is not tted, the hole can be closed with the
ange cap 12.
Air conditioning without installation
You can also set-up in a double-hung window:
1) Place the bracket in the window sill, extend the bracket
fullywithinthewindowframe,x the bracketbyusing the
pin then lower the window onto the bracket. (Should the
window bracket be too large for the window. The plastic
can be cut with a saw by a qualied professional).
2) Fit the air exhaust hose in the housing at the back of the
appliance. Insert it as shown in g. A.
3) Screw the window outlet 17 to the other end of the
exhaust hose (see g. F).
4) Insert the window outlet end of the exhaust hose into the
slot of the window bracket (g. G).
Other set-up methods:
• Thanks to the locking pins, it’s possible to use the window
bracket also for sliding windows. Position the hole of the
bracket so to allow a correct installation of the exhaust
hose (see g. H).
• If you have a casement window f ollow steps 2 & 3 and
place the window outlet outside the window to exhaust
the hot air (g. I).
2
D
MAX100 cm
MAX 39 inches
MIN 35 cm
MIN 14 inches
E
Note:
• As special tools are required for installation, we
suggest you have the appliance installed by specialized
personnel.
• Keep the air hoses as short and free of curves as possible
to avoid constrictions.
G
H
I
2
1
2
F

7
en
CONTROL PANEL
For help with installation, operation, and for all
accessories and spare/replacement parts, please contact
our toll free customer service call center at:
1-800-322-3848 [US only]
1-888-335-6644 [Canada only]
01-800-711-8805 (Mexico only]
or log onto our website at www.delonghi.com
A ON /OFF button
B MODE selection button
Air conditioning, dehumidifying, fan
C Reduce temperature/programme mode time
button
D Timer button
E Fan speed button (MAX/MED/MIN)
F Increase temperature/programme mode time
button
G Air conditioning symbol
H Dehumidifying symbol
I Fan symbol
L Alarm symbol
M Fan speed indicator
N Temperature scale indicator
O Time indicator
P Set temperatures, room temperature and
programmed on/o time
Q Timer symbol
R Room temperature symbol
S Set temperature symbol
Note:
Never turn the air conditioner o by unplugging from the outlet.
Always press the button, then wait for a few minutes
before unplugging. This allows the appliance to perform a cycle
of checks to verify operation.
°C
°F
A D
B E
C F
G H I L
MNOPQRS

8
en
OPERATING FROM THE CONTROL
PANEL
Turning the appliance ON/OFF
Before plugging the appliance check the caps on the
back of the unit are correctly inserted and screwed on
the drainage hose 11.
Plug into the electrical receptacle. Two lines appear on the
display indicating that the appliance is in stand-by.
°C
°F
PresstheON/OFFbutton(A).Whenturnedon,the airconditioner
starts operating in the same mode as when it was turned o.
Press the MODE button (B) until the light corresponding to the
desired mode lights up:
: Air conditioning symbol (G)
: Dehumidifying symbol (H)
:Fan symbol (I)
Air conditioning mode
Ideal for hot muggy weather when you need to cool and
dehumidify the room.
To set this function correctly:
• Press the MODE button a number of times until the air
conditioning symbol appears. Room temperature is
displayed.
°F
°F °F
• Select the target temperature by pressing the button
(F) or button (C) until the required value is displayed.
During selection, the temperature ashes.
°F
After 10 seconds, room temperature is displayed again.
• Select the required fan speed by pressing the button.
There are 3 speeds available:
High speed: to achieve the target temperature as
rapidly as possible
Medium speed: reduces noise levels but still
maintains a good level of comfort
Low speed: for silent operation
NOTE:
• The most suitable indoor temperature for the room during
the summer varies from 75°F to 81°F (24 to 27°C). You are
recommended, however, not to set a temperature much
below the outdoor temperature.
• Wheninstalling the air conditioner,you should leaveadoor
slightly open little as 1/2“ (1 cm) to guarantee correct ven-
tilation and room pressure.
Dehumidifying mode
Ideal to reduce room humidity (spring and autumn, damp
rooms, rainy periods, etc). For this mode, the appliance should
be prepared in the same way as for air conditioning, with the air
exhaust hose attached to enable the moisture to be discharged
outside.
To set this function correctly:
• Press the MODE button a number of times until the
dehumidifying symbol appears.
°F
°F
°F
PLEASE NOTE: In this mode, with room temperature above
77 degree F, the fan speed is adjustable. If the temperature is
below, fan speed is selected automatically by the appliance and
cannot be set manually.
Fan mode
When using the appliance in this mode, the air exhaust hose
does not need to be attached.
To set this function correctly:
• Press the MODE button a number of times until the fan
symbol appears.
• Select the required fan speed by pressing the button.
High speed: for maximum fan power;

9
°F °F
°F
Medium speed: reduces noise levels but still
maintains a good level of comfort;
°F
°F
°F
Low speed: for silent operation.
°F
°F
°F
PLEASE NOTE: To change the unit of measurement for the
displayed temperature, press the and buttons together
for 3 seconds.
Setting the timer
The timer can be used to delay appliance start up or shut down.
This avoids wasting electricity by optimising operating periods.
How to programme delayed start up
• Plug the appliance into the mains socket. It will be in
STAND-BY.
• Press the timer button (D). The timer symbol (R) comes
on.
• Press the timer button (D).The timer light“H”ashes.
• Use the (F) or (C) buttons to set the number of hours
delay before the appliance comes on. They increase or
decrease the time in steps of an hour.
PLEASE NOTE: after setting, the operating mode and fan speed
can be modied.
To cancel the timer programme, press the timer button (D)
again. Pressing the ON/OFF button (A) cancels the timer
programme and the air conditioner comes on immediately in
the selected mode.
How to programme delay OFF
• Delay OFF can be programmed in any operating mode - air
conditioning/fan/dehumidifying.
• Press the timer button (D).The timer on symbol (R) comes
on.
• Use the (F) or (C) buttons to set the number of hours
delay before the appliance goes o.
They increase or decrease the time in steps of an hour.
The appliance can be set to go o within the next 24 hours.
Five seconds after the timer has been set, the operating mode is
displayed and the timer symbol remains on.
At the set time, the air conditioner goes o and remains in
stand-by.
To cancel the timer programme, press the timer button (D)
again.The timer symbol goes o.
PLEASE NOTE: after setting, the operating mode and fan speed
can be modied.
OPERATING FROM THE REMOTE
CONTROL
Using the remote control
• Point the remote control at the receiver on the air
conditioner. The remote control must be no more than
16,4ft (5 meters) away from the appliance (without
obstacles between the remote control and the receiver).
• The remote control must be handled with extreme care.
Do not drop it or expose it to direct sunlight or sources of
heat.
PLEASE NOTE: The remote control can be safely stored in the
appropiate compartment (S) (see gure).
5715111481/11.13
Description of the remote control
20) “ON/OFF”button
21) Temperature decrease/increase and
programme mode button
22) “MODE”button
23) “TIMER”button
24) °F/°C switching button
25) Fan speed button (MAX/MED/MIN)
MAX 16 ft
MAX 5 meters
