DeLonghi PACT 40 User manual

14
Warnings
•This appliance is designed for home air conditioning and must not be used for other purposes.
•It is dangerous to modify or alter the characteristics of the appliance in any way.
•The appliance must be installed in conformity with legislation in force in the country concerned.
•If the appliance requires repair, contact a Service Centre authorised by the manufacturer only.
Repairs carried out by unauthorised personnel may be dangerous.
•If the power cable is damaged, it must be replaced by a qualified professional authorised by the
manufacturer only.
•The appliance is not intended for use by young children or infirm persons without supervision.
Young children should be supervised to ensure that they do not play with the appliance.
•The appliance must be connected to an efficient earth system. Have your electrical circuit checked
by a qualified electrician.
•Do not use extension cables.
•Before cleaning or maintenance operations, always unplug the appliance from the mains socket.
•Do not move the appliance by pulling the power cable.
•Do not install the appliance in rooms containing gas, oil or sulphur. Do not install near sources of heat.
•Do not rest heavy or hot objects on top of the appliance.
•Clean the anti-microbial filters at least once a week.
•Avoid using heating appliances near the air conditioning unit.
•Always transport the appliance upright or resting on one side.
Before transporting the appliance, completely empty the internal circuit of water by turning the
function selector to the PUMP position until you hear the gurgling of the pump.
•Use the appliance as described in this instruction manual only. As with all electrical equipment, whil-
st the instructions aim to cover as many eventualities as possible, caution and common sense
should be applied when operating and installing this appliance.
•At the end of its working life, take the appliance to a special collection centre.
•The materials used for packaging can be recycled. You are therefore recommended to dispose of
them in special differentiated waste collection containers.
•When putting the appliance away, do not cover with plastic bags.
•R407 is a refrigerant gas conforming to EC environmental regulations. Avoid perforating the refrige-
rant circuit of the appliance.
•Keep the appliance at least 50 cm away from flammable substances (alcohol etc) or pressurised
containers (e.g. aerosol cans).
•If the appliance is used in rooms without adequate ventilation, take the necessary precautions to
avoid possible leaks of refrigerant gas stagnating in the atmosphere, creating a fire risk.
•This appliance must be used and kept in rooms with a volume of more than 21 m2.
•If an appliance containing flammable refrigerant is used in an unventilated room, make sure the
room is suitable and that there is no danger of gas leaks reaching a concentration which could
cause fire or explosion in the presence of other heat sources (electrical heating appliances, heaters
or similar).
DESCRIPTION
1Control panel
2Air outlet grille
3Evaporator air intake grill
4Housing for air exhaust hose
5Condenser air intake grill
6Continuous condensate drain connection
7Condensate tank
8Power cable
9Castors
10 Handles
11 Air conditioning light
12 Dehumidification light
13 Fan light
14 Function selector
15 Thermostat dial
16 Timer
17 Tank full/tank absent light
18 Alarm light
19 Power on light
20 Flange cap
21 Air exhaust hose
22 Window outlet
23 Suckers
24 Castor locks
25 Continuous drain hose with coupling
GB-5751013500 27-07-2006 18:10 Pagina 14

15
ENGLISH
During the summer, you feel comfortable at a tem-
perature of between 24 and 27° C with a relative
humidity of about 50%.
An air conditioning unit removes excess moistu-
re and heat from the room where it is loca-
ted.
Compared with installed models, porta-
ble air conditioning units have the
advantage that they can be moved
from one room to another in the home
or transported from one building to
another.
Hot air from the room is passed throu-
gh a coil cooled by refrigerant gas.
Excess heat and moisture are remo-
ved before the air is re-emitted into
the room.
In single unit models (Pinguino), a
small part of this air is used to cool the
refrigerant gas and then once hot
and moist, is discharged outside.
In models with case (SuperPinguino),
the circuit is cooled using air from outsi-
de.
All Pinguino and SuperPinguino models
can also be used in fan-only mode.
What are the Pinguino and SuperPinguino?
GB-5751013500 27-07-2006 18:10 Pagina 15

16
AIR-CONDITIONING WITHOUT INSTALLATION
Just a few simple steps and your comfort is
ensured with Pinguino:
•Fix the air discharge hose in the housing
at the back of the appliance. Insert it as
shown in figure A.
4
21
•If you have a double window, use the
suckers provided to hold the two parts of
the window together (fig. C).
23
•Fit the window outlet to the end of the
hose .
•Place the air conditioning unit near a win-
dow or French window.
•Make sure the air exhaust hose is unob-
structed.
•Open the window or French window sligh-
tly and position the outlet as shown in
figure B.
21
22
21
A
Preparing for use
B
C
ELECTRICAL CONNECTIONS
Before plugging the appliance into the mains socket, check that:
•the mains power supply corresponds to the value indicated on the rating plate on the back of
the appliance;
•the mains socket and electrical circuit are adequate for the appliance;
•the mains socket matches the plug. If this is not the case, have the plug replaced;
•the mains socket is adequately earthed. Failure to follow these important safety instructions
absolves the manufacturer of all liability.
The power cable must be replaced by a qualified professional only.
The instructions below will enable you to prepare your air conditioning unit for operation as effi-
ciently as possible.
Before use, make sure the air intake and outlet grilles are unobstructed.
Keep air hoses as short and free of curves as
possible to avoid constrictions.
GB-5751013500 27-07-2006 18:10 Pagina 16

17
ENGLISH
Preparing for use
AIR-CONDITIONING WITH INSTALLATION
If required, the Pinguino can also be installed
semi-permanently.
Proceed as follows:
•Drill a hole in an outside wall or through a
window pane. Respect the height and
dimensions of the hole given in figure E-F.
30 cm
30 cm
106
MAX100 cm
MIN 35 cm
Whenever the hose is not fitted, the hole
can be closed with the flange cap .
Note:
When installing the air conditioning unit semi-
permanently, you should leave a door slightly
open (as little as 1 cm) to guarantee correct
ventilation.
DEHUMIDIFYING
Place the appliance in the room without fit-
ting the hose. The dehumidified air will thus be
released directly into the atmosphere.
Cold air will come out of the front grill and hot
air from the back grill (fig. G), thus guaran-
teeing efficient dehumidifying.
In addition to the air exhaust hose , a
second hose is available as an accessory to
take air from outside rather than inside the
room.
21
20
21
in the window
pane
in the wall: you are
recommended to
insulate the sec-
tion of wall using
suitable insulation.
in the woo-
den socle of
a French win-
dow
E
F
Keep air hoses as short and free of curves as
possible to avoid constrictions.
•Fit the flange accessory provided in
the hole
20
G
hot air
cold air
D
•Attach the hose to the special housing
in the back of the appliance (fig. Apage
16).
•Fit the end of the hose to the flange
as shown in fig. F.
20
21
21
GB-5751013500 27-07-2006 18:10 Pagina 17

18
Turning on and selecting the functions
HOW TO USE AS AN AIR CONDITIONER
When the air conditioning unit is off, the func-
tion selector is in the “●●” position. To use the
unit in air conditioning mode, proceed as fol-
lows:
1. Turn the function selector knob clockwise:
•When the large crystal symbol is lined
up with the reference mark on the
appliance, the unit will operate in air con-
ditioning mode at maximum fan speed.
•When the small crystal symbol is lined
up with the reference mark on the
appliance, the unit will operate in air con-
ditioning mode at minimum fan speed
2. Choose the required temperature by tur-
ning the room thermostat dial.
Note
The temperature is not indicated in degrees.
We therefore suggest you turn the room ther-
mostat dial to the maximum cold position.
When the temperature in the room is comfor-
table, turn the thermostat slowly anticlockwi-
se until the thermostat trips and turns the air
conditioning off.
This will programme the appliance to the
exact level of comfort which will then be
automatically maintained by the thermostat,
at the same time guaranteeing considerable
energy savings. Whenever the air conditioner
reaches the required temperature, it conti-
nues to operate in fan only mode.
THIS APPLIANCE USES AN EXCLUSIVE CON-
DENSATE RECYCLING SYSTEM TO ELIMINA-
TE EXCESS MOISTURE.
IN NORMAL CONDITIONS, CONDENSATE IS
ELIMINATED AUTOMATICALLY.
WHEN HUMIDITY IS HIGH, THERE MAY BE
EXCESS CONDENSATE IN THE TANK. INDI-
CATOR LIGHT COMES ON AND YOU
SHOULD EMPTY THE TANK.
MAKE SURE YOU PUT THE TANK BACK COR-
RECTLY OR INDICATOR LIGHT WILL
REMAIN ON.
17
17
HOW TO USE AS A FAN
If you want to use the appliance as a fan
only, turn the function selector anti-
clockwise to the symbol.
HOW TO USE AS A DEHUMIDIFIER
When the appliance is operating in air condi-
tioning mode, it automatically reduces excess
moisture in the air, while at the same time lowe-
ring room temperature.
If you want to remove excess moisture without
lowering the temperature, remove the air
exhaust hose and turn the function selector
anticlockwise to the symbol.
Note
In dehumidifying mode, the air coming out of
the air discharge grill is colder than the air in
the room while the air coming out of the hose
housing at the back of the appliance is
hotter.
4
14
GB-5751013500 27-07-2006 18:10 Pagina 18

19
ENGLISH
Mode selection/indicator lights
TURNING THE APPLIANCE OFF
TO TURN THE APPLIANCE OFF COMPLETELY, TURN THE FUNCTION SELECTOR TO THE "O" POSITION
AND UNPLUG FROM THE MAINS.
THERE MAY BE A SLIGHT DELAY BETWEEN TURNING THE SELECTOR AND START-UP OF THE MODE SELEC-
TED.
OPERATING INDICATOR LIGHTS
The lights indicate operation of the unit.
*The light comes on three minutes after the appliance has been turned on (when the com-
pressor starts operating). It goes off when the temperature set by the thermostat has been rea-
ched.
** The light comes on three minutes after the appliance has been turned on (when the com-
pressor starts operating).
In air conditioning mode, the appliance operates continuously. If the temperature is too low,
the frost prevention thermostat trips and turns off operation.
MODE INDICATOR
LIGHT 11
INDICATOR
LIGHT 13
OFF --
AIR CONDITIONING on* off
DEHUMIDIFYING off off
FAN -on
INDICATOR
LIGHT 12
-
off
on**
-
GB-5751013500 27-07-2006 18:10 Pagina 19

20
To get the best from your air conditioning unit,
follow these recommendations:
•close the windows and doors in the room to
be air conditioned. The only exception is
when the appliance is installed through a
hole in the wall.
In this case, you are recommended to
leave a slight draught through a door or
window to guarantee correct ventilation.
•Protect the room from direct exposure to
the sun by partially closing curtains and/or
blinds. This makes the appliance more
economical to run;
•Never rest objects of any kind on the air
conditioning unit;
•Never obstruct the air intake or outlet
grilles;
•Make sure there are no heat sources in the
room.
2
3
•Never use the appliance in very damp
rooms (laundries for example).
•Never use the appliance outdoors.
Tips
close doors and windows
close blinds or curtains
do not cover
•Make sure the air conditioning unit is on a
level floor. If necessary, place the two
castor locks under the front wheels
.
9
24
GB-5751013500 27-07-2006 18:10 Pagina 20

ENGLISH
Before cleaning or maintenance, always turn
the appliance off and unplug from the mains
socket.
CLEANING THE CABINET
You should clean the appliance with a slightly
damp cloth then dry with a dry cloth. For
safety reasons, never wash the air conditio-
ning unit with water.
Precautions
Never use petrol, alcohol or solvents to clean
the appliance. Never spray insecticide liquids
or similar.
CLEANING THE AIR FILTERS
To keep your air conditioning unit working effi-
ciently, you should:
Clean the dust filter every week of operation
The filter is housed in the intake grille.
To clean the filter, proceed as follows:
1. Remove the intake grille by rotating
outwards (fig. L).
Use a vacuum cleaner to remove dust accu-
mulations from the filter. If it is very dirty,
immerse in warm water and rinse a number of
times. The water should never be hotter than
40°C.
After washing, leave the filter to dry.
To replace, put the filters back in the intake
grille then attach the intake grille to the
appliance.
START OF SEASON CHECKS
Make sure the power cable and plug are
undamaged and the earth system is efficient.
Follow the installation instructions precisely.
END OF SEASON OPERATIONS
To empty the internal circuit completely of
water, turn the function selector to the PUMP
position until you hear the gurgling of the
pump. Do not remove the tank.
The water in the internal circuit will drain into
the tank or through the continuous drain
hose if connected.
Make sure the other end of the hose leads to
a drain.
When completely drained, disconnect the
continuous drain hose.
Clean the filters and dry thoroughly before
putting back.
6
7
2. Remove the dust filter by detaching it from
the grille (figure M).
intake grille
L
M
Cleaning
dust filter
21
GB-5751013500 27-07-2006 18:10 Pagina 21

22
Troubleshooting…
PROBLEM CAUSE RIMEDY
The air conditioning
unit is off
•no electricity
•it is not plugged into the mains
•the safety device has tripped
•wait
•plug into the mains
•contact your service centre
The air conditioning
unit works for a
short time only
•the exhaust hose has a constriction
•the exhaust hose is blocked
•there are bends in the exhaust hose
•position the exhaust hose cor-
rectly
•check there are no obstacles
obstructing air discharge
•eliminate the bends
The air conditioning
unit works, but does
not cool the room
•window open
•there are heat sources in the room (radiators,
lamp, etc)
•the exhaust hose is detached
•air filters clogged
•the air conditioning unit is not powerful enou-
gh for the conditions or size of the room
•close the window
•eliminate the heat source
•connect the exhaust hose
•clean or replace the filters
•clean or replace the filters
Particular odour in
the room
•air filters clogged
The air conditioning
unit does not ope-
rate for about three
minutes after turning
it on
•the safety device has tripped • wait for three minutes
The tank full light
is on
17
•The condensate tank is full or positioned
incorrectly
•empty the tank or position it
correctly. If the light remains
on, contact a service centre
The alarm light
flashes
18 •temperature sensor fault •Contact a Service Centre.
The alarm light
is on
18 •pump fault •Contact a Service Centre.
GB-5751013500 27-07-2006 18:10 Pagina 22

23
ENGLISH
Guarantee/technical specification
GUARANTEE AND TECHNICAL ASSISTANCE
The conditions of the guarantee and techni-
cal assistance are given on the certificate
supplied with your appliance.
LIMIT CONDITIONS
Room temperature 21 ÷ 35°C
Transport, filling, cleaning, recovery and disposal of refrigerant should be performed by a tech-
nical service centre appointed by the manufacturer only.
The appliance should be disposed of by a specialist centre appointed by the manufacturer only.
TECHNICAL SPECIFICATION
Power supply voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .see rating plate
Max. absorbed power during air conditioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .“
Max. absorbed power during dehumidifying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .“
Refrigerant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .“
Cooling capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .“
Dimensions internal unit:
width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .495 mm
height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .940 mm
depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .410 mm
weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34 kg
ELECTRICAL CONNECTION (U.K. ONLY)
A) If your appliance comes fitted with a plug, it will incorporate a 13 Amp fuse. If it does not fit your socket, the plug should
be cut off from the mains lead, and on appropriate plug fitted, as below. warning: Very carefully dispose of the cut off
plug after removing the fuse: do not insert in a 13 Amp socket elsewhere in the house as this could cause a shock hazard.
With alternative plugs not incorporating a fuse, the circuit must be protected by a 15 Amp fuse. If the plug is a moulded-
on type, the fuse cover must be re-fitted when changing the fuse using a 13 Amp Asta approved fuse to BS 1362. In the
event of losing the fuse cover, the plug must NOT be used until a replacement fuse cover can be obtained from your nea-
rest electrical dealer. The colour of the correct replacement fuse cover is that as marked on the base of the plug.
B) If your appliance is not fitted with a plug, please follow the instructins provided below:
WARNING - THIS APPLIANCE MUST BE EARTHED
IMPORTANT
The wires in the mains lead are coloured in accordance with
the following code:
Green and yellow Earth
Blue Neutral
Brown Live
As the colours of the wires in the mains lead may not corre-
spond with the coloured markings identifying the terminals
in your plug, proceed as follows:
The green and yellow wire must be connected to the termi-
nal in the plug marked with the letter E or the earth symbol
or coloured green or green and yellow.
The blue wire must be connected to the terminal marked with
the letter N or coloured black.
The brown wire must be connected to the terminal marked
with the letter L or coloured red.
GB-5751013500 27-07-2006 18:10 Pagina 23
