DeLonghi Pinguino PACL90 User manual

PACL90MODEL
PACL90MODEL
Instructions for use
Keep these instructions
Mode d'emploi
Conservez cette notice
Instrucciones para el uso
Repase y guarde estas instrucciones
Istruzioni per l’uso
Leggere e conservare queste istruzioni
ELECTRICAL SPECIFICATIONS 115V ~ 60Hz
DONNEES ELECTRIQUES 115V~60Hz
CARACTERISTICAS ELECTRICAS 115V ~ 60Hz
CARATTERISTICHE ELETTRICHE 115V~60Hz
Register this product on-line and receive a free trial issue of Cook's Illustrated.
Visit www.prodregister.com/delonghi.
Visit www.delonghi.com for a list of service centers near you. (U.S. Only)
Enregistrez ce produit en ligne et recevez un numéro gratuit de Cook's Illustrated.
Visitez www.prodregister.com/delonghi.
Visitez www.delonghi.com pour y voir une liste des centres de réparation proches de chez vous.
(É.-U. uniquement)
Registre este producto en línea y reciba un ejemplar gratis de Cook's Illustrated.
Visite www.prodregister.com/delonghi.
Visite www.delonghi.com para ver la lista de centros de servicios cercanos a usted. (Solamente
en los Estados Unidos)
Registra questo prodotto "on-line" per ricevere una copia omaggio della rivista.
Visita www.prodregister.com/delonghi.
Visita www.delonghi.com per una lista dei centri di servizio a te piu vicini. (Solo negli Stati Uniti)
PORTABLE AIR-CONDITIONER

2
PARTS AND ACCESSORIES
10 12 13
11
14
15
6
7
4
8
3
SWING SPEED
BOOST
15
9
2
16
18
17
19
• See description at page 3 for english • Voir déscription à la page 19 pour le Français
• Véase descripción a la pág 35 para español • Vedi descrizione a pagina 51 per l’italiano

3
IMPORTANT SAFEGUARDS
•Use this appliance only as described in this instruction manual.
As with any electrical appliance, the instructions aim to cover as many eventualities as possi-
ble. Caution and common sense should be used when operating and installing this air condi-
tioner.
•This appliance has been manufactured to cool and dehumidify domestic environments and
should not be used for other purposes.
•It is dangerous to alter or modify the unit's characteristics in any way.
•The appliance must be installed in line with the relevant national legislation.
•Should repairs be necessary, contact the nearest authorized De’Longhi Repair Service Center.
Unauthorized Delonghi servicing can be dangerous.
•This appliance is to be used by adults only; keep away from children.
•In the case that the power cord becomes damaged, this must be substituted only by specialized
personnel authorized by the manufacturer.
•Always ensure the appliance is grounded. If you have any doubts check with a qualified elec-
trician.
•We strongly discourage the use of an extension cord due to potential safety hazards. For tem-
porary situations, use only CSA certified and UL Listed 3-wire grounded extension cord, rated
15 A, 125 V.
•Before cleaning or maintenance operations, always unplug the unit from the outlet.
•Do not pull on or place strain on the power cord when moving the appliance.
•The appliance should not be installed where the atmosphere may contain combustible gases,
oil or sulphur, or near heat sources.
•Do not rest hot or heavy objects on the appliance.
•Clean the filters at least once a week.
•Avoid using heaters near the unit.
•The unit should be transported in a vertical position. If this is not possible secure the unit at
an angle, do not lie it horizontally.
•Before transporting the unit, drain the unit. After transportation, wait at least 1 hour before swit-
ching the unit on.
•The packaging materials can be recycled. You are therefore recommended to place them in
the special containers for differentiated waste collection.
SAVE THESE INSTRUCTIONS
DESCRIPTION
1air outlet grille
2control panel
3 castors
4 handles
5 evaporator air intake grille
6air exhaust hose housing
7condenser air inlet grille/hose housing
8 drain hose cover
9 power cord
10 2 flange caps
11 air exhaust hose
12 2 window outlets
13 suction pads
14 castor locks
15 remote control
16 single holes window bracket
17 double hose window bracket
18 air inlet hose
19 3M® electrostatic filter

4
What are the Pinguino
portable air conditioners?
During the summer, you feel comfortable at a temperature of between 75 and 81°F (24 and
27°C) with a relative humidity of about 50%.
An air conditioning unit removes excess moisture and heat from the room where it is located.
Compared with installed models, portable air conditioning units have the advantage that they
can be moved from one room to another in the home or be transported from one building to
another.
Hot air from the room is passed through a
coil cooled by refrigerant gas.
Excess heat and moisture are
removed before the air
is re-emitted into the room.
In single unit models (Pinguino),
a small part of this air is used to
cool the refrigerant gas and
then, when hot and damp,
is discharged outside.

5
The instructions below will enable you to prepare your air conditioning unit for operation as effi-
ciently as possible.
Before use, make sure the air intake and outlet grilles are unobstructed.
NON PERMANENT INSTALLATION
Just a few simple steps and your comfort is
ensured with Pinguino:
•Fit the air exhaust hose in the housing
at the back of the appliance. Insert it as
shown in figure A.
In order to improve the performance of the
appliance in air conditioning and boost
(super-conditioning) modes, you can also fit
the intake hose accessory in its housing in
the back of the appliance as shown in figure
A1. This step is optional.
18
6
11
•Fit the window outlets to the end of
the hose / .
•Place the air conditioning unit near a win-
dow or French window.
•Make sure the air exhaust hose is unob-
structed.
1811
12
Installing your portable
air-conditioner
C
Keep air hoses as short and free of cur-
ves as possible to avoid constrictions.
ELECTRICAL CONNECTIONS
Before plugging the appliance into the electrical socket, check that:
•the power supply corresponds to the value indicated on the rating plate on the back of the appliance;
•the socket and electrical circuit are adequate for the appliance;
•the socket matches the plug. If this is not the case, have the plug replaced;
•the socket is adequately grounded. Failure to follow these important safety instructions absolves the manu-
facturer of all liability.
The power cord must be replaced by a qualified professional only.
1
2
AA1
C1
French window
Sash window
For optimum results:
•If you have a sash window, place the
bracket or according to your
needs, on the window sill, extend the
bracket fully within the window frame, fix the
bracket by using the pin then lower the win-
dow onto the bracket. Insert the window
outlet of the exhaust hose into the
slot, then connect the hose to the air condi-
tioner (fig. B and B1).
Thanks to the locking pins, it’s possible to use
the window bracket also for sliding windows.
Position the hole of the bracket so to allow a
correct installation of the exhaust hose.
11
12
1716
B1
B

6
Installing your portable
air-conditioner
SEMI-PERMANENT INSTALLATION
If required, the Pinguino can also be installed
semi-permanently (Fig. E and E1).
•Fit the flange accessory provided in
the hole
•Fit the hose / in the housing at the
back of the appliance (fig. A/ A1 page 5).
•Fit the end of the hose / to the flan-
ge as shown in fig. G.
10
1811
1811
10
Proceed as follows:
•Drill a hole in an outside wall or through a
window pane.
Respect the height and dimensions of the
hole given in figure F.
30 cm
11.8 inches
30 cm
11,8 inches
MAX100 cm
MIN 35 cm
MAX 39.37 inches
MIN 13.77 inches
When the hose /is not fitted, the dril-
led hole can be closed with the flange cap
.
NOTE.
When installing the air conditioning unit semi-
permanently, you should leave a door slightly
open (as little as 1/2 inches (1 cm) ) to gua-
rantee correct ventilation.
10
1811
G
Keep the air hoses as short and free of
curves as possible to avoid constrictions.
4.17 inches (106 mm)
in the window
pane
in the wall: you are
recommended to
insulate the sec-
tion of wall using
suitable insulation.
in the woo-
den kick-
board of a
French win-
dow
F
30 cm
11.8 inches
30 cm
11,8 inches
E1
E
•Open the French window slightly and
position the outlet as shown in figure C
and C1.
•Use the suction pads provided to hold
the two parts of the window together (fig.
D and D1).
13
12
DD1

7
Control panel
DESCRIPTION OF THE CONTROL PANEL
AON/OFF button
BMode selection button
Conditioning, Boost, Fan mode with air filtration, Smart
CAir conditioning mode indicator light
DBoost mode indicator light
E Fan mode with air filtration indicator light
FSleep function indicator light
GSmart function (indicator lights C/D/E)
HIncrease temperature/programmed operating time button
ITimer in operation indicator light
L Display Displays the temperature values set and the programmed operating time
MReduce temperature/programmed operating time button
N/O/P/Q Fan speed and AUTO mode indicator lights
RFan speed selection button
STimer button
TRemote control receiver
A
C
THE CONTROL PANEL
B
D
EF
S
HI
L
TMN
O P Q R
G

8
Operation
TURNING THE APPLIANCE ON
Plug the appliance into the socket.
Two lines appear on the display indicating that the appliance is
in standby.
You can control the appliance with the remote control (see page 10)
or with the control panel.
OPERATION WITH CONTROL PANEL
Press the ON/OFF button (A) (when turned on, the air conditioning unit
starts operating in the same mode as when it was turned off).
Press the MODE (B) button until the indicator light corresponding
to the required mode lights up:
Indicator light (C): air-conditioning mode
Indicator light (D): boost mode
Indicator light (E) : fan mode with air filtration
Indicator light (C-D-E) together: smart mode
AIR-CONDITIONING MODE
Ideal for hot humid weather when you need to cool and dehu-
midify the room.
To set the operation of the appliance correctly, press the +(H) or
- (M) buttons until the desired temperature is displayed.
Then select the fan speed by pressing the SPEED button (R) until
the indicator light corresponding to the required fan speed lights
up
MAX: the air conditioning unit operates at maximum to reach
the required temperature as rapidly as possible
MED: reduces noise levels but still maintains a good level of
comfort
MIN: for silent operation
AUTO: the appliance automatically selects the most suitable
fan speed in relation to the temperature set on the digi-
tal display.
The most suitable temperature for the room during the summer
varies from 75° - 81° F (24 to 27°C).
You are recommended, however, not to set a temperature
excessively lower than the outside temperature.
78

9
Operation
BOOST MODE
The BOOST mode is used to obtain rapid cooling. The fan is set to high speed and the tempera-
ture is automatically set to 64°F (18°C). The boost light (D) on the control panel comes on and the
display will show .
FAN MODE WITH AIR FILTRATION
Adjust fan speed by pressing the SPEED button (R) as described for the air-conditioning mode.
Remember that the higher the speed, the more air is filtered. If you select "Min" speed, less air is
filtered but the appliance is also less noisy.
In this mode, Auto cannot be selected.
The fan speed selected will be displayed.
SMART MODE
In SMART mode the air conditioner unit decides the best way to operate, to guarantee maximum
comfort. In SMART mode the operating mode (air-conditioning or fan), the temperature and the
fan speed are automatically controlled and the display will show .
SETTING THE TIMER
The timer can be used to delay appliance start up or shut down. This avoids wasting electricity by
optimizing operating periods
How to program delayed start up
•Plug the appliance into a socket and press the ON/OFF (A) button, then select the required
operating mode and other settings (temperature, fan speed, etc).
•Press the ON/OFF (A) button again to place the appliance in standby mode.
•Press the timer button (S). The two centre segments flash on the display.
•Use the “+” (H) o “-” (M) buttons to set the number of hours delay before the appliance comes
on. The setting is increased or decreased by an hour at a time; however, when the buttons are
held down for more than two seconds, the time runs rapidly up to a maximum of 24 hours. Wait
a few seconds for the data to be acquired.
The indicator light (I) flashes until the appliance starts up.
You can set the appliance to come on with a delay of up to 24 hours.
To cancel the timer setting, press the timer button (S), and use the “-” button (M) to set the time
to “00”. The indicator light (I) will stop flashing.
How to program delayed shut down
•Delayed shut down can be programmed in any operating mode.
•Press the timer button (S). The two centre segments flash on the display.
•Use the “+” (H) o “-” (M) button to set the number of hours delay before the appliance goes
off.
The setting is increased or decreased by an hour at a time; however, when the buttons are
held down for more than two seconds, the time runs rapidly up to a maximum of 24 hours. Wait
a few seconds for the data to be acquired.
The indicator light (I) flashes until the appliance shuts down.
To cancel the timer setting, press the timer button (S), and use the “-” button (M) to set the time
to zero. The indicator light (I) will stop flashing.

10
THE REMOTE CONTROL
Inserting/replacing batteries (included)
•Remove the back cover (see figure).
•Insert two new batteries (not rechargea-
ble) making sure the (+) and (-) are in the
correct positions.
•Replace the back cover.
NB: Alkaline batteries should be used (LR03
AAA type).
When replacing or disposing of the remote
control, the batteries must be removed and
disposed of according to the legislation in
force, being harmful to the environment.
Warning:
Do not mix old and new batteries. Do not mix
alkaline, standard (carbon-zinc) or rechar-
geable (nickel-cadmium) batteries.
Do not dispose of batteries in fire. batteries
may explode or leak.
If the remote control is not be used for a cer-
tain length of time, remove the batteries.
CORRECT USE
•Aim the remote control at the signal recei-
ver on the air-conditioner.
•Maximum distance: around 23 ft. (7
metres) (without obstacles between the
remote control and the receiver).
•The remote control should be handled
with extreme care: without dropping it,
without exposing it to direct sunlight or
near sources of heat.
1
2
The remote control

11
Description of the remote control
THE REMOTE CONTROL
A
E D C
B
B
I
H
G
F
SWING SPEED
BOOST
THE DISPLAY
Signal transmission
Air-conditioning indicator
Air filtration indicator
BOOST indicator
SMART indicator
SLEEP indicator
Automatic fan speed
High fan speed
Medium fan speed
Low fan speed
Used to set the temperature in SMART
mode (see page 13 for further informa-
tion)
A. MODE button
Selects the operating mode (air conditio-
ning, boost, air filtration, smart).
B. Buttons for SETTING THE ROOM TEMPERATU-
RE
Set room temperature or program the
timer.
C. SPEED button
Sets fan speed to automatic, high,
medium or low in sequence.
D. SWING button
(available only on some models)
Activates the motorized lowers.
E. TIMER button
Sets or cancels the timer.
F. SLEEP button ( )
Sets or cancels the automatic SLEEP func-
tion.
G. SMART button ( )
When this button is pressed, the appliance
automatically establishes the most suita-
ble operating mode for maximum
comfort.
H. BOOST button ( )
Starts or stops rapid cooling (in the rapid
cooling mode, the fan operates at high
speed with the temperature automatical-
ly set to 64°F (18°C).
I. ON/OFF button
Press this button to turn the appliance on
and off. NB: the settings are displayed
even when the air conditioner is off.

Functions
75 F
AIR-CONDITIONING MODE
•Press the button to turn the appliance on.
•Abeep indicates that the air-conditioning unit is on and the
symbol flashes on the display.
•Press the MODE button a number of times until the air-conditio-
ning symbol appears on the display.
•Now set the temperature using the buttons.
•To select fan speed, press the “SPEED” button repeatedly until
the required fan speed is selected (automatic, high, medium,
low).
NB: in air-conditioning mode, the appliance automatically removes
excess moisture from the atmosphere.
FAN MODE WITH AIR FILTRATION
In humid but not particularly hot days, the fan function alone may
be adequate.
•Press the button. A beep indicates that the air-conditioning
unit is on and the symbol flashes on the display.
•Press the MODE button a number of times until the fan symbol
appears on the display.
•Once purifying mode has been selected, press the SPEED button
until the required speed is reached (low, medium, high).
PROGRAMMING THE TIMER
The timer can be used to delay appliance start up or shut down.
This avoids wasting electricity by optimising operating periods.
Programming shut-down
•With the air-conditioning unit on, press the TIMER button. The time
is displayed and the “h” symbol flashes. Set the time when you
want the appliance to go off using the buttons (from 30
minutes to 24 hours).
•Press the TIMER button again to confirm the selection. A count-
down of the time left is displayed.
•At the end of the set time the appliance switches off automatical-
ly. During the first ten hours, you can select half hour intervals. For
times greater than ten hours, one hour intervals can be selected.
•To cancel the set time, press the TIMER button again. You will
hear a beep.
Programming start-up
•With the air-conditioning unit off, press the TIMER button. The time
is displayed and the “h” symbol flashes. Set the time when you
want the appliance to come on using the buttons (from 30
minutes to 24 hours). During the first ten hours, you can select half
hour intervals. For times greater than ten hours, one hour intervals
can be selected.
•Press the TIMER button again to confirm the selection.
•At the end of the set time the appliance switches on automati-
cally.
•To cancel the set time, press the TIMER button again. You will
hear a beep.
18
12

13
Functions
BOOST FUNCTION
BOOST function is used to obtain rapid cooling. The fan is set to high
speed and the temperature is automatically set to 64°F (18°C).
To select BOOST function, proceed as follows:
•Press the button to turn the appliance on. A beep indica-
tes that the air-conditioning unit is on and the symbol fla-
shes on the display.
•Press the BOOST button to set the function. The symbol is
displayed.
•To go back to the previous mode, press the BOOST button
again. With the BOOST function activated, the display on the
control panel shows 6600.
SMART FUNCTION
In SMART function, the air-conditioning unit decides the best way to
operate to guarantee maximum comfort.
•Press the button to turn the appliance on. A beep indicates
that the air-conditioning unit is on and the symbol flashes on
the display.
•Press the SMART function. The appliance functions automatically
and the symbol appears on the display.
NB: in SMART function, the temperature is controlled automatically.
However, if the required temperature has not yet been reached, it
can be reduced or increased by a maximum of 4°F (approx. 2°C) by
pressing the buttons.
The appliance automatically establishes the operating mode (air-
conditioning, fan, heating) and the optimum fan speed.
Whit the SMART function activated the display on the control panel
shows .
SLEEP FUNCTION
The automatic SLEEP function is ideal for the night-time as it enables
operation of the air-conditioning unit in the air-conditioning mode
to be gradually reduced until it shuts down completely (after eight
hours).
To select SLEEP mode, proceed as follows:
•Press the button to turn the appliance on.
•Abeep indicates that the air-conditioning unit is on and the
symbol flashes on the display.
•Press the MODE button a number of times until the symbol of
the function required appears on the display.
•Then select the required temperature by pressing the but-
tons.
•Now press the SLEEP button to set the night function. The sym-
bol is displayed. Press the SLEEP button again to go back to the
previous mode. In this mode, the fan operates at low speed.
The SLEEP function maintains the room temperature at the optimum level, avoiding
excessive increases or drops in the temperature, with silent operation.
The flow of air decreases, while the room temperature varies gradually according
to the comfort requirements: increases of approx. 2°F (approx.1°C) after 60 minutes
and approx. 4°F (approx.2°C) after 2 hours (it switches off altogether after eight
hours). With the SLEEP function activated the sleep indicator light on the control
panel is on.
79 F

Self diagnosis/ Troubleshooting
SELF DIAGNOSIS
The appliance has a self diagnosis system to identify a number of malfunctions.
LOW TEMPERATURE
(frost prevention)
ppffPROBE FAILURE
(The probe is damaged)
FULL TANK
(The tank is full)
When the appliance is operating in air conditioning mode, this device pre-
vents the formation of ice.
The appliance starts up again automatically when the defrosting process is
completed.
If this alarm appears, contact the service centre.
Empty the internal safety tank, through the drain hoses.
(see page 16 “end of season operations”).
IF THE DISPLAY SHOWS … …WHAT SHOULD YOU DO?
PROBLEM CAUSE REMEDY
The air conditioning
unit does not start
•no electricity
•it is not plugged into the socket
•the safety device has tripped
•restore electricity
•plug into the socket
•reset the safaty plug ( see pag. 17)
The air conditioning
unit works for a
short time only
•the air exhaust hose has a constriction
•the air exhaust hose is blocked
•there are tight bends in the air exhaust hose
•position the exhaust hose cor-
rectly
•check there are no obstacles
obstructing air discharge
•eliminate the tight bends
The air conditioning
unit works, but does
not cool the room
•window open
•there are heat sources in the room (burner,
lamp, etc)
•the exhaust hose is detached
•air filters clogged
•Inadequate size of the room (too large)
•close the window
•eliminate the heat source
•connect the exhaust hose
•clean or replace the filters
•clean or replace the filter
Particular odour in
the room
•air filter clogged
The air conditioning
unit does not ope-
rate for about three
minutes after turning
it on.
•it is normal for the compressor to start after
three minutes
•wait for three minutes
//PPFF//appears
on the display
•See "self-diagnosis" section
TROUBLESHOOTING
14

15
To get the best from your air conditioning unit,
follow these recommendations:
•close the windows and doors in the room to
be air conditioned.
The only exception is when the appliance is
installed through a hole in the wall.
In this case, you are recommended to
leave a slight draught through a door or
window to guarantee correct ventilation.
•Protect the room from direct exposure to
the sun by partially closing curtains and/or
blinds to make the appliance much more
economical to run;
•Never rest objects of any kind on the air
conditioning unit;
•Never obstruct the air intake or outlet
grilles;
•Make sure there are no heat sources in the
room.
1
5
•Never use the appliance in very damp
rooms (laundries for example).
•Never use the appliance outdoors.
Tips
close doors and windows
close blinds or curtains
do not
cover the
appliance
•Make sure the air conditioning unit is on a
level floor. If necessary, place the two
castor locks under the front wheels
.
3M® ELECTROSTATIC FILTER
To use the 3M® electrostatic filter, remove it
from the packaging and attach it to the dust
filter by inserting the two plastic profiles on the
3M® filter onto the tabs on the dust filter (see
figure).
Reposition the assembled filters in the grill and
replace in the appliance.
When removing the evaporator air intake
grille (5), do not touch the evaporator’s
metallic wings because they are very sharp
and they could be dangerous.
19
3
14

16
Before cleaning or maintaining, turn the
appliance off by pressing the ON/OFF button
(A) or button (I) on the remote control and
always unplug the appliance from the socket.
CLEANING THE CABINET
You should clean the appliance with a slightly
damp cloth then dry with a dry cloth.
For safety reasons, never wash the air condi-
tioning unit with water.
Precautions
Never use petrol, alcohol or solvents to clean
the appliance.
Never spray insecticide liquids or similar.
CLEANING THE FILTERS
To keep your air conditioning unit working effi-
ciently, you should:
Clean the dust filter every week of operation.
The filter is housed in the intake grille.
When removing the evaporator air intake
grille (5), do not touch the evaporator’s
metallic wings because they are very sharp
and they could be dangerous.
To clean the filters, proceed as follows
1. Remove the intake grille by rotating
outwards (Fig. 1).
Use a vacuum cleaner to remove the dust
collected on the filter.
If the dust filter is very dirty, immerse in warm
water and rinse a number of times.
The water should never be hotter than 105 °F
(40°C).
After washing, leave the filter to dry.
To replace, put the filters back in the intake
grille then attach the intake grille to the
appliance.
Do not wash the 3M® ectrostatic filter when it
is worn-out change it with a new filter.
START OF SEASON CHECKS
Make sure the power cord and plug are
undamaged and the properly grounded.
Follow the installation instructions precisely.
END OF SEASON OPERATIONS
To empty the internal circuit completely of
water, open the cover (8) on the rear of the
appliance.
Pull out the 2 drain hoses, take off the caps
and let all the residual water flow out (fig. 3).
2. Remove the dust filter by detaching it from the
grille (Fig. 2). Remove 3M® electrostatic filter if
it is mounted.
1
Cleaning and Maintenance
2
3
intake
grille
3M® electrostatic
filter
dust filter
When all the water has been drained, place
the caps back on the hoses and put the
hoses back inside.
Clean the filters and dry thoroughly before
putting them back.

17
Technical specification
LIMIT CONDITIONS
Room temperature range of the air-condi-
tioned space 64-95°F (18 - 35°C)
TECHNICAL SPECIFICATION
Power supply
voltage see rating plate
Max. power input
during air conditioning “
Refrigerant “
Cooling capacity “
Appliance dimensions:
•width 19.9 inc. 505 mm
•height 31,4 inc. 800 mm
•depth 17,3 inc. 440 mm
•weight 75 Lbs 34 kg
Transport, filling, cleaning, recovery and disposal of refrigerant should be performed by a
technical service centre appointed by the manufacturer only.
The appliance should be disposed of by a specialist centre appointed by the manufacturer only.
SAFETY PLUG
The appliance is fitted with a safety plug to protect the power cable.
If power is cut off, unplug from the mains and make sure the power cable is undamaged.
If the cable is damaged, call the service center immediately.
If power cuts off frequently and the power cable is undamaged, contact a qualified elec-
trician.
OPERATION OF THE SAFETY PLUG
If the safety device incorporated in the plug trips and cuts off the power supply, check
that the power cable and plug are not damaged.
If the power cable is undamaged, to restore operation press the "RESET" button.
To verify correct operation of the plug, press the "TEST" button periodically and make sure
the appliance disconnects. If this is not the case, contact the service center.
To restore operation, press the "RESET" button.
NEVER TURN THE APPLAIANCE UPSIDE DOWN OR ON ITS SIDE.
IF THIS OCCURS, WAIT AT LEAST 1 HOURS BEFORE TURNING THE
APPLIANCE ON

18
Limited Warranty
De’Longhi is the distributor of Kenwood home appliances.
This warranty applies to all home appliances with De’Longhi or Kenwood brand names.
FOR CONTIGUOUS UNITED STATES ONLY
Limited Warranty
We warrant each De’Longhi AIR CONDITIONER to be free from defects in material and workman-
ship. From the purchase date, our obligation under this warranty is to provide one (1) year free
parts and labor on the entire AIR CONDITIONER, with an additional four (4) years free on any part
of the sealed system consisting of the compressor, evaporator, condenser and factory connected
refrigerant tubing. Labor and all other parts during the additional four (4) year warranty are to be
paid by the owner. All AIR CONDITIONERS in need of repair are to be shipped to an authorized
De’Longhi service center at the owner’s expense, and De’Longhi will then incur the return ship-
ping costs. After the first five (5) years of ownership, all expenses (all parts, labor and shipping) are
to be paid by the owner of the unit. This warranty shall apply only if the AIR CONDITIONER is used
in accordance with the factory directions that accompany it, and on an Alternating Current (AC)
circuit. This warranty is in lieu of all other warranties and representations, expressed or implied, and
all other obligations or liabilities on our part. We do not authorize any other person or company
to assume for us any liability in connection with the sale or use of our AIR CONDITIONER. This war-
ranty shall not apply to any AIR CONDITIONER that has been repaired or altered outside our fac-
tory nor shall it apply to any AIR CONDITIONER that has been subjected to misuse, negligence or
accidents.
If repairs become necessary, see contact information below:
U.S. Residents:
Please contact our toll free hotline at 1-800-322-3848 or log onto our website at
www.delonghi.com.
For all accessories, spare parts or replacement parts, please contact our parts division at 1-800-
865-6330.
CANADA Residents:
Please contact our toll free hotline at 1-888-335-6644 or log onto our website at
www.delonghi.com.
Other countries:
Please visit: www.delonghi.com.
