DeWalt XR DCH614X2 User manual

DCH614
Final page size: A5 (148mm x 210mm)

B
ENGLISH
English (original instructions) 3
Pусский (перевод соригинала инструкции) 14
Türkçe (orijinal talimatlardan çevrilmiştir) 29
Англійська (оригінальні інструкції) 42
Copyright
DeWALT

1
Fig. A
Fig. B
8
9
9
8
16
2
1
5
8
4
6 7
3
9
10
13
XXXX XX XX
14
11
12

2
Fig. E
Fig. C Fig. D
3
2
15 67
2
5

ENGLISH
3
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.
EC-Declaration of Conformity
Machinery Directive
Heavy-Duty Cordless SDSMAX
CombinationHammer
DCH614
DeWALT
declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN60745-1:2009+A11:2010, EN60745-2-6:2010.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact
DeWALT
at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of
DeWALT
.
Markus Rompel
Vice-President Engineering, PTE-Europe
DeWALT
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
01.10.2019
the job. This may significantly reduce the exposure level
over the total workingperiod.
Identify additional safety measures to protect the operator
from the effects of vibration and/or noise such as: maintain
the tool and the accessories, keep the hands warm
(relevant for vibration), organisation of workpatterns.
The vibration and/or noise emission level given in this
information sheet has been measured in accordance with
a standardised test given in EN60745 and may be used to
compare one tool with another. It may be used for a preliminary
assessment ofexposure.
WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/or
noise should also take into account the times when the tool
is switched off or when it is running but not actually doing
DCH614
Voltage VDC 54
Type 1
Battery type Li-Ion
No-load speed min-1 190–380
No-load beats per minute bpm 1450–2900
Single impact energy (EPTA 05/2009) J10.5
Optimum drilling range into concrete mm 16–32
Maximum drilling range in concrete mm 45
Maximum core drilling range in concrete mm 40–125
Tool Holder SDS MAX
Chisel positions 18
Collar diameter mm 66
Weight (without battery pack) kg 6.8
Noise values and vibration values (triax vector sum) according to EN60745-2-6:
LPA (emission sound pressure level) dB(A) 93
LWA (sound power level) dB(A) 104
K (uncertainty for the given sound level) dB(A) 3
Drilling
Vibration emission value a
h, HD
= m/s28.8*
Uncertainty K = m/s21.5
Chiselling
Vibration emission value a
h
, Cheq
= m/s28.1*
Uncertainty K = m/s21.5
*Measured at the side handle. Side handle vibration is higher than vibration at
the main handle.
English (original instructions)
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough
product development and innovation make
DeWALT
one of the
most reliable partners for professional power toolusers.
Technical Data
HEAVYDUTY CORDLESS SDSMAX COMBINATION HAMMER
DCH614

4
ENGLISH
GENERAL POWER TOOL SAFETY WARNINGS
WARNING: Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
powertool.
1) Work Area Safety
a ) Keep work area clean and well lit. Cluttered or dark
areas inviteaccidents.
b ) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust orfumes.
c ) Keep children and bystanders away while operating
a power tool. Distractions can cause you to losecontrol.
2) Electrical Safety
a ) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of
electricshock.
b ) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if
your body is earthed orgrounded.
c ) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electricshock.
d ) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
Denotes risk of electricshock.
Denotes risk offire.
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electricshock.
e ) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electricshock.
f ) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electricshock.
3) Personal Safety
a ) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personalinjury.
b ) Use personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask,
non-skid safety shoes, hard hat or hearing protection used
for appropriate conditions will reduce personalinjuries.
c ) Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invitesaccidents.
d ) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in
personalinjury.
e ) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpectedsituations.
f ) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can be
caught in movingparts.
Batteries Chargers/Charge Times (Minutes)
Cat # VDC Ah Weight (kg) DCB104 DCB107 DCB112 DCB113 DCB115 DCB118 DCB132 DCB119
DCB546 18/54 6.0/2.0 1.05 60 270 170 140 90 60 90 X
DCB547 18/54 9.0/3.0 1.46 75* 420 270 220 135* 75* 135* X
DCB548 18/54 12.0/4.0 1.44 120 540 350 300 180 120 180 X
DCB181 18 1.5 0.35 22 70 45 35 22 22 22 45
DCB182 18 4.0 0.61 60/40** 185 120 100 60 60/40** 60 120
DCB183/B 18 2.0 0.40 30 90 60 50 30 30 30 60
DCB184/B 18 5.0 0.62 75/50** 240 150 120 75 75/50** 75 150
DCB185 18 1.3 0.35 22 60 40 30 22 22 22 X
DCB187 18 3.0 0.54 45 140 90 70 45 45 45 90
DCB189 18 4.0 0.54 60 185 120 100 60 60 60 120
*Date code 201811475B or later
**Date code 201536 or later
Batteries
Chargers/Charge Times (Minutes)
Cat #
DC
Weight
*Date code 201811475B or later
**Date code 201536 or later

5
ENGLISH
Additional Safety Instructions for Rotary
Hammers
• Wear ear protectors. Exposure to noise can cause
hearingloss.
• Use auxiliary handles supplied with the tool. Loss of
control can cause personalinjury.
• Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring or its own cord. Cutting
accessory contacting a "live" wire may make exposed metal
parts of the power tool "live" and could give the operator an
electricshock.
• Be certain that the material being drilled does not
conceal electric or gas service and that their locations
have been verified with the utilitycompanies.
• Use clamps or other practical way to secure and support
the workpiece to a stable platform. Holding the work by
hand or against your body is unstable and may lead to loss
ofcontrol.
• Wear safety goggles or other eye protection. Hammering
operations cause chips to fly. Flying particles can cause
permanent eye damage. Wear a dust mask or respirator
for applications that generate dust. Ear protection may be
required for mostapplications.
• Keep a firm grip on the tool at all times. Do not attempt
to operate this tool without holding it with both hands.
It is recommended that the side handle be used at all times.
Operating this tool with one hand will result in loss of control.
Breaking through or encountering hard materials such as
Shorting the battery terminals together may cause burns
or afire.
d ) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation orburns.
e ) Do not use a battery pack or tool that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion or risk
of injury.
f ) Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to fire or temperature
above 130 °C may causeexplosion.
g ) Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specified in the instructions. Charging
improperly or at temperatures outside the specified range
may damage the battery and increase the risk of fire.
6) Service
a ) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
b ) Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
g ) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-relatedhazards.
h ) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause severe
injury within a fraction of asecond.
4) Power Tool Use and Care
a ) Do not force the power tool. Use the correct power
tool for your application. The correct power tool
will do the job better and safer at the rate for which it
wasdesigned.
b ) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must berepaired.
c ) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the
power toolaccidentally.
d ) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrainedusers.
e ) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by
poorly maintained powertools.
f ) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier tocontrol.
g ) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardoussituation.
h ) Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpectedsituations.
5) Battery Tool Use and Care
a ) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another batterypack.
b ) Use power tools only with specifically designated
battery packs. Use of any other battery packs may create
a risk of injury andfire.
c ) When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.

6
ENGLISH
Chargers
DeWALT
chargers require no adjustment and are designed to be
as easy as possible tooperate.
Electrical Safety
The electric motor has been designed for one voltage only.
Always check that the battery pack voltage corresponds to the
voltage on the rating plate. Also make sure that the voltage of
your charger corresponds to that of yourmains.
Your
DeWALT
charger is double insulated in
accordance with EN60335; therefore no earth wire
isrequired.
If the supply cord is damaged, it must be replaced by a
specially prepared cord available through the
DeWALT
serviceorganisation.
re-bar may be hazardous as well. Tighten the side handle
securely beforeuse.
• Do not operate this tool for long periods of time.
Vibration caused by hammer action may be harmful to your
hands and arms. Use gloves to provide extra cushion and limit
exposure by taking frequent restperiods.
• Do not recondition bits yourself. Chisel reconditioning
should be done by an authorized specialist. Improperly
reconditioned chisels could causeinjury.
• Wear gloves when operating tool or changing bits.
Accessible metal parts on the tool and bits may get extremely
hot during operation. Small bits of broken material may
damage barehands.
• Never lay the tool down until the bit has come to a
complete stop. Moving bits could causeinjury.
• Do not strike jammed bits with a hammer to dislodge
them. Fragments of metal or material chips could dislodge
and causeinjury.
• Slightly worn chisels can be resharpened bygrinding.
• Do not overheat the bit (discoloration) while grinding
a new edge. Badly worn chisels require reforging. Do not
reharden and temper thechisel.
Residual Risks
The following risks are inherent to the use of rotary hammers:
• Injuries caused by touching the rotating parts or hot parts of
thetool.
In spite of the application of the relevant safety regulations
and the implementation of safety devices, certain residual risks
cannot be avoided. These are:
• Impairment ofhearing.
• Risk of squeezing fingers when changing theaccessory.
• Health hazards caused by breathing dust developed when
working in concrete and/ormasonry.
• Risk of personal injury due to flyingparticles.
• Risk of burns due to accessories becoming hot
duringoperation.
• Risk of personal injury due to prolongeduse.
SAVE THESE INSTRUCTIONS
Mains Plug Replacement
(U.K. & Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the oldplug.
• Connect the brown lead to the live terminal in theplug.
• Connect the blue lead to the neutralterminal.
WARNING: No connection is to be made to the
earthterminal.
Follow the fitting instructions supplied with good quality plugs.
Recommended fuse: 3A.
Using an Extension Cable
An extension cord should not be used unless absolutely
necessary. Use an approved extension cable suitable for
the power input of your charger (see Technical Data). The
minimum conductor size is 1mm2; the maximum length
is30m.
When using a cable reel, always unwind the cablecompletely.
Important Safety Instructions for All Battery
Chargers
SAVE THESE INSTRUCTIONS: This manual contains important
safety and operating instructions for compatible battery
chargers (refer to TechnicalData).
• Before using charger, read all instructions and cautionary
markings on charger, battery pack, and product using
batterypack.
WARNING: Shock hazard. Do not allow any liquid to get
inside charger. Electric shock mayresult.
WARNING: We recommend the use of a residual current
device with a residual current rating of 30mA orless.
CAUTION: Burn hazard. To reduce the risk of injury,
charge only
DeWALT
rechargeable batteries. Other types of
batteries may burst causing personal injury anddamage.
CAUTION: Children should be supervised to ensure that
they do not play with theappliance.
NOTICE: Under certain conditions, with the charger
plugged into the power supply, the exposed charging
contacts inside the charger can be shorted by foreign
material. Foreign materials of a conductive nature such
as, but not limited to, steel wool, aluminum foil or any
buildup of metallic particles should be kept away from
charger cavities. Always unplug the charger from the
power supply when there is no battery pack in the cavity.
Unplug charger before attempting to clean
• DO NOT attempt to charge the battery pack with any
chargers other than the ones in this manual. The charger
and battery pack are specifically designed to worktogether.
• These chargers are not intended for any uses other than
charging
DeWALT
rechargeable batteries. Any other uses
may result in risk of fire, electric shock orelectrocution.
• Do not expose charger to rain orsnow.
• Pull by plug rather than cord when disconnecting
charger. This will reduce risk ofdamage to electric plug
andcord.

7
ENGLISH
• Make sure that cord is located so that it will not be
stepped on, tripped over, or otherwise subjected to
damage orstress.
• Do not use an extension cord unless it is absolutely
necessary. Use of improper extension cord could result in risk
of fire,electric shock, orelectrocution.
• Do not place any object on top of charger or place
the charger on a soft surface that might block the
ventilation slots and result in excessive internal heat.
Place the charger in a position away from any heat source. The
charger is ventilated through slots in the top and the bottom
of thehousing.
• Do not operate charger with damaged cord or plug—
have them replacedimmediately.
• Do not operate charger if it has received a sharp blow,
been dropped, or otherwise damaged in any way. Take it
to an authorised servicecentre.
• Do not disassemble charger; take it to an authorised
service centre when service or repair is required. Incorrect
reassembly may result in a risk of electric shock, electrocution
orfire.
• In case of damaged power supply cord the supply cord must
be replaced immediately by the manufacturer, its service agent
or similar qualified person to prevent anyhazard.
• Disconnect the charger from the outlet before
attempting any cleaning. This will reduce the risk of
electric shock. Removing the battery pack will not reduce
thisrisk.
• NEVER attempt to connect two chargerstogether.
• The charger is designed to operate on standard
230V household electrical power. Do not attempt to
use it on any other voltage. This does not apply to the
vehicularcharger.
Charging a Battery (Fig. B)
1. Plug the charger into an appropriate outlet before inserting
battery pack.
2. Insert the battery pack 8 into the charger, making sure the
battery pack is fully seated in the charger. The red (charging)
light will blink repeatedly indicating that the charging
process has started.
3. The completion of charge will be indicated by the red
light remaining ON continuously. The battery pack is fully
charged and may be used at this time or left in the charger.
To remove the battery pack from the charger, push the
battery release button 9 on the battery pack.
NOTE: To ensure maximum performance and life of lithium-ion
battery packs, charge the battery pack fully before first use.
Charger Operation
Refer to the indicators below for the charge status of the
batterypack.
Charge Indicators
Charging
Fully Charged
Hot/Cold Pack Delay*
*The red light will continue to blink, but a yellow indicator light
will be illuminated during this operation. Once the battery pack
has reached an appropriate temperature, the yellow light will
turn off and the charger will resume the charging procedure.
The compatible charger(s) will not charge a faulty battery pack.
The charger will indicate faulty battery by refusing to light.
NOTE: This could also mean a problem with a charger.
If the charger indicates a problem, take the charger and battery
pack to be tested at an authorised service centre.
Hot/Cold Pack Delay
When the charger detects a battery pack that is too hot or too
cold, it automatically starts a Hot/Cold Pack Delay, suspending
charging until the battery pack has reached an appropriate
temperature. The charger then automatically switches to the
pack charging mode. This feature ensures maximum battery
pack life.
A cold battery pack will charge at a slower rate than a warm
battery pack. The battery pack will charge at that slower rate
throughout the entire charging cycle and will not return to
maximum charge rate even if the battery pack warms.
The DCB118 charger is equipped with an internal fan designed
to cool the battery pack. The fan will turn on automatically
when the battery pack needs to be cooled. Never operate the
charger if the fan does not operate properly or if ventilation slots
are blocked. Do not permit foreign objects to enter the interior
of the charger.
Electronic Protection System
XR Li-Ion tools are designed with an Electronic Protection
System that will protect the battery pack against overloading,
overheating or deep discharge.
The tool will automatically turn off if the Electronic Protection
System engages. If this occurs, place the lithium-ion battery
pack on the charger until it is fully charged.
Wall Mounting
These chargers are designed to be wall mountable or to sit
upright on a table or work surface. If wall mounting, locate the
charger within reach of an electrical outlet, and away from a
corner or other obstructions which may impede air flow. Use
the back of the charger as a template for the location of the
mounting screws on the wall. Mount the charger securely using
drywall screws (purchased separately) at least 25.4mm long
with a screw head diameter of 7–9mm, screwed into wood to
an optimal depth leaving approximately 5.5mm of the screw
exposed. Align the slots on the back of the charger with the
exposed screws and fully engage them in the slots.

8
ENGLISH
Battery Packs
Important Safety Instructions for All Battery
Packs
When ordering replacement battery packs, be sure to include
catalogue number and voltage.
The battery pack is not fully charged out of the carton. Before
using the battery pack and charger, read the safety instructions
below. Then follow charging procedures outlined.
READ ALL INSTRUCTIONS
• Do not charge or use battery in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust. Inserting or removing the battery from the charger may
ignite the dust or fumes.
• Never force battery pack into charger. Do not modify
battery pack in any way to fit into a non-compatible
charger as battery pack may rupture causing serious
personal injury.
• Charge the battery packs only in
DeWALT
chargers.
• DO NOT splash or immerse in water or other liquids.
• Do not store or use the tool and battery pack in
locations where the temperature may reach or exceed
40 ˚C (104 ˚F) (such as outside sheds or metal buildings
in summer).
• Do not incinerate the battery pack even if it is severely
damaged or is completely worn out. The battery pack can
explode in a fire. Toxic fumes and materials are created when
lithium-ion battery packs are burned.
• If battery contents come into contact with the skin,
immediately wash area with mild soap and water. If
battery liquid gets into the eye, rinse water over the open eye
for 15 minutes or until irritation ceases. If medical attention
is needed, the battery electrolyte is composed of a mixture of
liquid organic carbonates and lithium salts.
• Contents of opened battery cells may cause respiratory
irritation. Provide fresh air. If symptoms persists, seek
medicalattention.
WARNING: Burn hazard. Battery liquid may be flammable
if exposed to spark or flame.
WARNING: Never attempt to open the battery pack for
any reason. If battery pack case is cracked or damaged,
do not insert into charger. Do not crush, drop or damage
battery pack. Do not use a battery pack or charger that
has received a sharp blow, been dropped, run over or
damaged in any way (i.e., pierced with a nail, hit with
a hammer, stepped on). Electric shock or electrocution
may result. Damaged battery packs should be returned to
service centre for recycling.
Charger Cleaning Instructions
WARNING: Shock hazard. Disconnect the charger
from the AC outlet before cleaning. Dirt and grease
may be removed from the exterior of the charger using a
cloth or soft non-metallic brush. Do not use water or any
cleaning solutions. Never let any liquid get inside the tool;
never immerse any part of the tool into a liquid.
WARNING: Fire hazard. Do not store or carry the
battery pack so that metal objects can contact
exposed battery terminals. For example, do not place
the battery pack in aprons, pockets, tool boxes, product kit
boxes, drawers, etc., with loose nails, screws, keys, etc.
CAUTION: When not in use, place tool on its side on
a stable surface where it will not cause a tripping
or falling hazard. Some tools with large battery packs
will stand upright on the battery pack but may be easily
knocked over.
Transportation
WARNING: Fire hazard. Transporting batteries can
possibly cause fire if the battery terminals inadvertently
come in contact with conductive materials. When
transporting batteries, make sure that the battery
terminals are protected and well insulated from
materials that could contact them and cause a short
circuit. NOTE: Lithium-ion batteries should not be put in
checkedbaggage.
DeWALT
batteries comply with all applicable shipping
regulations as prescribed by industry and legal standards which
include UN Recommendations on the Transport of Dangerous
Goods; International Air Transport Association (IATA) Dangerous
Goods Regulations, International Maritime Dangerous Goods
(IMDG) Regulations, and the European Agreement Concerning
The International Carriage of Dangerous Goods by Road (ADR).
Lithium-ion cells and batteries have been tested to section 38.3
of the UN Recommendations on the Transport of Dangerous
Goods Manual of Tests and Criteria.
In most instances, shipping a
DeWALT
battery pack will be
excepted from being classified as a fully regulated Class 9
Hazardous Material. In general, only shipments containing a
lithium-ion battery with an energy rating greater than 100 Watt
Hours (Wh) will require being shipped as fully regulated Class 9.
All lithium-ion batteries have the Watt Hour rating marked on
the pack. Furthermore, due to regulation complexities,
DeWALT
does not recommend air shipping lithium-ion battery packs
alone regardless of Watt Hour rating. Shipments of tools with
batteries (combo kits) can be air shipped as excepted if the Watt
Hour rating of the battery pack is no greater than 100 Whr.
Regardless of whether a shipment is considered excepted
or fully regulated, it is the shipper's responsibility to consult
the latest regulations for packaging, labeling/marking and
documentation requirements.
The information provided in this section of the manual is
provided in good faith and believed to be accurate at the time
the document was created. However, no warranty, expressed or
implied, is given. It is the buyer’s responsibility to ensure that its
activities comply with the applicable regulations.
Transporting the FLEXVOLTTM Battery
The
DeWALT
FLEXVOLTTM battery has two modes: Use
andTransport.
Use Mode: When the FLEXVOLTTM battery stands alone or is in
a
DeWALT
18V product, it will operate as an 18V battery. When
the FLEXVOLTTM battery is in a 54V or a 108V (two 54V batteries)
product, it will operate as a 54V battery.

9
ENGLISH
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual beforeuse.
Wear earprotection.
Wear eyeprotection.
Package Contents
The package contains:
1 Rotary Hammer
1 Side handle
1 Charger
1 Li-Ion battery pack (C1, D1, L1, M1, P1, S1, T1, X1, Y1 models)
2 Li-Ion battery packs (C2, D2, L2, M2, P2, S2, T2, X2, Y2 models)
3 Li-Ion battery packs (C3, D3, L3, M3, P3, S3, T3, X3, Y3 models)
1 Instruction manual
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® battery packs.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by
DeWALT
is under license. Other trademarks and
trade names are those of their respective owners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Battery Type
The DCH614 operate on a 54 volt battery pack.
These battery packs may be used: DCB546, DCB547, DCB548.
Refer to Technical Data for moreinformation.
Transport Mode: When the cap is attached to the FLEXVOLTTM
battery, the battery is in Transport mode. Keep the cap
forshipping.
When in Transport mode, strings
of cells are electrically
disconnected within the pack
resulting in 3 batteries with a
lower Watt hour (Wh) rating as compared to 1 battery with a
higher Watt hour rating. This increased quantity of 3 batteries
with the lower Watt hour rating can exempt the pack from
certain shipping regulations that are imposed upon the higher
Watt hour batteries.
For example, the Transport
Wh rating might indicate
3x36 Wh, meaning 3
batteries of 36 Wh each.
The Use Wh rating might
indicate 108Wh (1battery implied).
Storage Recommendations
1. The best storage place is one that is cool and dry away
from direct sunlight and excess heat or cold. For optimum
battery performance and life, store battery packs at room
temperature when not in use.
2. For long storage, it is recommended to store a fully charged
battery pack in a cool, dry place out of the charger for
optimal results.
NOTE: Battery packs should not be stored completely
depleted of charge. The battery pack will need to be recharged
beforeuse.
Labels on Charger and Battery Pack
In addition to the pictographs used in this manual, the labels
on the charger and the battery pack may show the following
pictographs:
Read instruction manual before use.
See Technical Data for charging time.
Do not probe with conductive objects.
Do not charge damaged battery packs.
Do not expose to water.
Have defective cords replaced immediately.
Charge only between 4 ˚C and 40 ˚C.
Example of Use and Transport Label Marking
Only for indoor use.
Discard the battery pack with due care for the
environment.
Charge
DeWALT
battery packs only with designated
DeWALT
chargers. Charging battery packs other
than the designated
DeWALT
batteries with a
DeWALT
charger may make them burst or lead to
other dangerous situations.
Do not incinerate the battery pack.
USE (without transport cap). Example: Wh rating
indicates 108 Wh (1 battery with 108 Wh).
TRANSPORT (with built-in transport cap). Example:
Wh rating indicates 3 x 36 Wh (3batteries of 36 Wh).

10
ENGLISH
Soft Start Feature
The soft start feature allows the tool to accelerate slowly, thus
preventing the drill bit from walking off the intended hole
position whenstarting.
The soft start feature also reduces the immediate torque
reaction transmitted to the gearing and the operator if the
hammer is started with the drill bit in an existinghole.
Active Vibration Control (AVC) System
For best vibration control, hold the tool as described in Proper
Hand Position and apply just enough pressure so the damping
device on the main handle is approximately midstroke.
The active vibration control neutralises rebound vibration from
the hammer mechanism. Lowering hand and arm vibration,
it allows more comfortable use for longer periods of time and
extends the life of theunit.
The hammer only needs enough pressure to engage the active
vibraton control. Applying too much pressure will not make
Description (Fig. A)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1 Trigger switch
2 Side handle
3 Front Barrel (Collar)
4 Mode selector dial
5 Main handle
6 Bit holder
7 Sleeve
8 Battery pack
9 Battery release button
10 Electronic speed and
impact control dial
11 Red anti-rotation system
indicator LED
12 Yellow service
indicatorLED
Intended Use
Your rotary hammer has been designed for professional
rotary masonry and concrete drilling, chiselling and
chippingapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
Your rotary hammer is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Date Code Position (Fig. A)
The date code 13, which also includes the year of manufacture,
is printed into thehousing.
Example:
2019 XX XX
Year of Manufacture
the tool drill or chip faster and active vibration control will
notengage.
DeWALT
Tool Tag Ready (Fig. A)
Optional Accessory
Your hammer comes with mounting holes 14 and fasteners
for installing a
DeWALT
Tool Tag. You will need a T15 bit tip to
install the tag. The
DeWALT
Tool Tag is designed for tracking and
locating professional power tools, equipment, and machines
using the
DeWALT
Tool Connect™ app. For proper installation of
the
DeWALT
Tool Tag refer to the
DeWALT
Tool Tagmanual.
Electronic Speed and Impact Control (Fig.A)
The electronic speed and impact control allows the use of
smaller drill bits without the risk of bit breakage, hammerdrilling
into light and brittle materials without shattering and optimal
tool control for precisechiseling.
To set the electronic speed and impact control dial10, turn
the dial to the desired level. The higher the number, the greater
the speed and impact energy. Dial settings make the tool
extremely flexible and adaptable for many different applications.
The required setting depends on the bit size and hardness of
material beingdrilled.
• When chiselling or drilling in soft, brittle materials or when
minimum break-out is required, set the dial to a low setting;
• When breaking or drilling in harder materials, set the dial to
a highsetting.
Overload Clutch
In case of jamming of a drill bit, the drive to the drill spindle
is interrupted by the overload clutch. Due to the resulting
forces, always hold the tool with both hands and take a
firmstance. After the overload, release and depress the trigger
to re-engagedrive.
WARNING: Drill may stall if overloaded causing a sudden
twist. Always expect the stall. Grip the drill firmly to control
the twisting action and avoidinjury.
Anti-Rotation System
In addition to the clutch, an anti-rotation system offers increased
user comfort through an on-board, anti-rotation technology
capable of detecting if the user loses control of the hammer.
When a jam is detected, the torque and speed are stopped
instantly. This feature prevents self rotation of the tool.
The red anti-rotation system indicator 11 will illuminate to
indicatestatus.
Anti-Rotation System and Service Indicator LED
(Fig. A)
Your rotary hammer has two LEDs, indicating the anti-rotation
system and a service indicator. Refer to the table for more
information on LEDfunctionality.

11
ENGLISH
Side Handle (Fig.A, C)
WARNING: To reduce the risk of personal injury, ALWAYS
operate the tool with the side handle properly installed.
Failure to do so may result in the side handle slipping
during tool operation and subsequent loss of control. Hold
tool with both hands to maximisecontrol.
The side handle2 clamps to the front of the gear case and may
be rotated 360˚ to permit right- or left-hand use.
Mounting the Straight Side Handle (Fig.C)
1. Widen the ring opening of the side handle2 by rotating it
counterclockwise.
2. Slide the assembly onto the nose of the tool, through the
steel ring15 and onto the collar3, past the chisel holder
andsleeve.
3. Rotate the side handle assembly to the desired position. For
hammerdrilling horizontally with a heavy drill bit, place the
side handle assembly at an angle of approximately 20° to
the tool for optimumcontrol.
4. Lock the side handle mounting assembly in place by
securely tightening the handle2 rotating it clockwise so
that the assembly will notrotate.
Bit and Bit Holder
WARNING: Burn Hazard. ALWAYS wear gloves when
changing bits. Accessible metal parts on the tool and bits
may get extremely hot during operation. Small bits of
broken material may damage barehands.
The rotary hammer can be fitted with various chisel bits
depending on the desired application. Use sharp drill
bitsonly.
Inserting and Removing SDSMAX Accessories
(Fig.D)
This machine uses SDSMAX bits and chisels (refer to the inset in
FigureD for a cross-section of an SDSMAX bitshank).
1. Clean the bitshank.
2. Pull back the locking sleeve7 and insert the bitshank.
3. Turn the bit slightly until the sleeve snaps intoposition.
4. Pull on the bit to check if it is properly locked. The
hammering function requires the bit to be able to move
axially several centimetres when locked in the toolholder.
5. To remove a bit pull back the tool holder locking sleeve/
collar7 and pull the bit out of the tool holder6.
Inserting and Removing the Battery Pack
from the Tool (Fig. B)
NOTE: Make sure your battery pack 8 is fullycharged.
To Install the Battery Pack into the Tool Handle
1. Align the battery pack 8 with the rails inside the tool’s
handle (Fig. B).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
1. Press the release button 9 and firmly pull the battery pack
out of the toolhandle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig. B)
Some
DeWALT
battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button 16. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
WARNING: Use only
DeWALT
battery packs andchargers.
subject to variation based on product components, temperature
and end-userapplication.
LED Function Description
Red
(permanently on)
Anti-rotation system
The red anti-rotation system
indicator LED 11 lights up
when anti-rotation isengaged.
Yellow
(permanently on)
Service required
The yellow service indicator
LED 12 lights up to indicate
the tool needs servicing within
the next 10 hours of use (new
lubrication and hammer
mechanismsealing).
Yellow
(flashing)
Service exceeded
With the service indicator lit,
after a further 10 hours use
the service indicator flashes to
indicate the tool has exceeded
the required serviceinterval.

12
ENGLISH
Proper hand position requires one hand on the mounted side
handle2, with the other hand on the mainhandle5.
Operation Modes (Fig.A)
WARNING: Do not select the operating mode when the
tool isrunning.
CAUTION: Never use in Rotary Drilling or Rotary
Hammering mode with a chisel bit in the bit holder.
Personal injury and damage to the the tool mayresult.
Your tool is equipped with a mode selector dial 4 to selectthe
mode appropriate to desiredoperation.
Symbol Mode Application
Rotary
Hammering
Drilling into concrete
andmasonry
Hammering only Lightchipping
Bit Adjustment Chisel bit position adjustment
To Select an Operating Mode
• Rotate the mode selector dial so that the arrow points to the
symbol corresponding for the desiredmode.
NOTE: The arrow on the mode selector dial4 must be pointing
at a mode symbol at all times. There are no operable positions
inbetween. It may be necessary to briefly run the motor after
having changed from 'Hammering Only' to 'Rotary Hammering'
modes in order to align thegears.
Indexing the Chisel Position (Fig.A)
The chisel can be indexed and locked into 18 differentpositions.
1. Rotate the mode selector switch4 until it points towards
the position.
2. Rotate the chisel in the desiredposition.
3. Set the mode selector switch4 to the hammering
onlyposition.
4. Twist the chisel until it locks inposition.
Proper Hand Position (Fig. E)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Performing an Application (Fig. A)
WARNING: TO REDUCE THE RISK OF PERSONAL
INJURY, ALWAYS ensure workpiece is anchored or
clamped firmly. If drilling thin material, use a wood
“backup” block to prevent damage to thematerial.
WARNING: Always wait until the motor has come to
a complete standstill before changing the direction
ofrotation.
Switching On and Off (Fig.A)
To turn the tool on, depress the trigger switch1.
To stop the tool, release the triggerswitch.
Drilling with a Solid Bit (Fig.A)
1. Insert the appropriate drillbit.
2. Set the mode selector switch4 to the 'rotary
hammering'position.
3. Set the electronic speed and impact control dial10.
4. Fit and adjust the side handle2.
5. Mark the spot where the hole is to bedrilled.
6. Place the drill bit on the spot and switch on thetool.
7. Always switch off the tool when work is finished and
beforeunplugging.
Drilling with a Core Bit (Fig.A)
1. Insert the appropriate corebit.
2. Assemble the centerdrill into the corebit.
3. Set the mode selector switch4 to the 'rotary
hammering'position.
4. Turn the electronic speed and impact control dial10 to a
medium or high speedsetting.
5. Fit and adjust the side handle2.
6. Place the centerdrill on the spot and switch on the tool. Drill
until the core penetrates into the concrete approximately
1cm.
7. Stop the tool and remove the centerdrill. Place the core bit
back into the hole and continuedrilling.
8. When drilling through a structure thicker than the depth of
the core bit, break away the round cylinder of concrete or
core inside the bit at regularintervals.
To avoid unwanted breaking away of concrete around
the hole, first drill a hole the diameter of the centerdrill
completely through the structure. Then drill the cored hole
halfway from eachside.
9. Always turn the tool off when work is finished and
beforeunplugging.
Chipping and Chiselling (Fig.A)
1. Insert the appropriate chisel and rotate it by hand to lock it
into one of 18positions.
2. Set the mode selector switch4 to the 'hammering
only'position.
3. Set the electronic speed and impact control dial10.
4. Fit and adjust the side handle2.
5. Turn the tool on and startworking.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.

13
ENGLISH
Optional Accessories
WARNING: Since accessories, other than those offered
by
DeWALT
, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only
DeWALT
recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
Cleaning
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Lubrication
Your power tool requires no additionallubrication.
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regularcleaning.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
The charger and battery pack are notserviceable.
Protecting the Environment
Separate collection. Products and batteries marked
with this symbol must not be disposed of with normal
householdwaste.
Products and batteries contain materials that can
be recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and batteries
according to local provisions. Further information is available at
www.2helpU.com.
Rechargeable Battery Pack
This long life battery pack must be recharged when it fails
to produce sufficient power on jobs which were easily done
before. At the end of its technical life, discard it with due care for
our environment:
• Run the battery pack down completely, then remove it from
the tool.
• Li-Ion cells are recyclable. Take them to your dealer or a
local recycling station. The collected battery packs will be
recycled or disposed of properly.
6. Always turn the tool off when work is finished and
beforeunplugging.
Recommendations for Tool Operation
• When drilling, always apply pressure in a straight line with
the bit, but do not push hard enough to stall the motor or
deflect thebit. A smooth even flow of material indicates the
proper drillingrate.
• If drilling thin material or material that is prone to splinter,
use a wood “back-up” block to prevent damage to
theworkpiece.
WARNING:
• Do not use this tool to mix or pump easily combustible
or explosive fluids (benzine, alcohol,etc.).
• Do not mix or stir inflammable liquids
labelledaccordingly.

14
PУССКИЙ
Значение шумовой эмиссии и/или эмиссии вибрации,
указанное в данном справочном листке, было получено
в соответствии со стандартным тестом, приведенным
в EN60745, и может использоваться для сравнения
инструментов. Кроме того, оно может использоваться для
предварительной оценки воздействиявибрации.
DCH614
Напряжение Впост. тока 54
Тип 1
Тип батареи Ионно-литиевая
Скорость без нагрузки мин.-1 190–380
Ударов в минуту без нагрузки уд/мин. 1450-2900
Энергия одного удара (EPTA 05/2009) Дж 10,5
Оптимальный диаметр сверления в бетоне мм 16-32
Максимальный диаметр сверления в бетоне мм 45
Максимальный диаметр сверления полой
коронкой в бетоне
мм 40-125
Патрон SDS MAX
Положения долота 18
Диаметр муфты мм 66
Вес (без аккумуляторной батареи) кг 6,8
Значения шума и вибрации (сумма векторов в трех плоскостях) в
соответствии с EN60745-2-6:
LPA (уровень звукового давления) дБ(A) 93
LWA (уровень акустической мощности) дБ(A) 104
K (погрешность для заданного уровня
мощности)
дБ(A) 3
Сверление
Значения вибрационного воздействия a
h,
HD
=
м/с28,8*
Погрешность K = м/с21,5
Долбление
Значения вибрационного воздействия
a
h
, Cheq
=
м/с28,1*
Погрешность K = м/с21,5
*Измеряется от боковой рукоятки. Вибрации на боковой рукоятки выше
вибраций на основной рукоятке.
!
Вы приобрели инструмент
DeWALT
. Многолетний опыт,
тщательная разработка изделий иинновации делают
компанию
DeWALT
одним из самых надёжных партнеров для
пользователей профессионального электроинструмента.
 
ОСТОРОЖНО! Заявленное значение шумовой
эмиссии и/или эмиссии вибрации относится к
основным областям применения инструмента.
Однако, если инструмент используется для
различных целей, с различными дополнительными
принадлежностями или при ненадлежащем уходе, то
уровень шума и/или вибрации может измениться.
Это может привести к значительному увеличению
уровня воздействия вибрации в течение всего
рабочегопериода.
При расчете приблизительного значения уровня
воздействия шума и/или вибрации также
необходимо учитывать время, когда инструмент
выключен или то время, когда он работает
на холостом ходу. Это может привести к
значительному снижению уровня воздействия
вибрации в течение всего рабочегопериода.
Определите дополнительные меры техники
безопасности для защиты оператора от
воздействия шума и/или вибрации, а именно:
поддержание инструмента и дополнительных
принадлежностей в рабочем состоянии, создание
комфортных условий работы (соответствующих
вибрации), хорошая организация рабочегоместа.
   
Директива по механическому оборудованию
Аккумуляторный перфоратор SDSMAX
DCH614
DeWALT
заявляет, что продукция, описанная вТехнические
характеристики, соответствует:
2006/42/EC, EN60745-1:2009+A11:2010, EN60745-2-6:2010.
Эти продукты также соответствуют Директиве 2014/30/EU
и2011/65/EU. За дополнительной информацией
обращайтесь вкомпанию
DeWALT
по адресу,
указанному ниже или приведенному на задней стороне
обложкируководства.
Нижеподписавшийся несет ответственность за составление
технической документации исоставил данную декларацию
по поручению компании
DeWALT
.
Маркус Ромпель
Вице-президент отдела по разработке ипроизводству,
PTE-Europe
DeWALT
, Richard-Klinger-Straße 11,
Pусский (перевод соригинала инструкции)
АККУМУЛЯТОРНЫЙ ПЕРФОРАТОР SDSMAX
DCH614

15
PУССКИЙ
ВНИМАНИЕ: Во избежание риска получения травм
ознакомьтесь синструкцией.
:  

Ниже описывается уровень опасности, обозначаемый
каждым из предупреждений. Прочитайте руководство
иобратите внимание на данныесимволы.
ОПАСНО: Обозначает опасную ситуацию, которая
неизбежно приведет ксерьезной травме или
смертельному исходу, вслучае несоблюдения
соответствующих мербезопасности.
ВНИМАНИЕ: Указывает на потенциально опасную
ситуацию, которая, вслучае несоблюдения
соответствующих мер безопасности,
может привести ксерьезной травме или
смертельномуисходу.
ПРЕДУПРЕЖДЕНИЕ: Указывает на потенциально
опасную ситуацию, которая, вслучае несоблюдения
соответствующих мер безопасности может
стать причиной травм средней или легкой
степенитяжести.
ПОЯСНЕНИЕ: Указывает на практики,
использование которых не связано
сполучением травмы, но если ими пренебречь,
могут привести кпорчеимущества.
Указывает на риск поражения электрическимтоком.
Указывает на рисквозгорания.
D-65510, Idstein, Германия
01.10.2019   
  

ВНИМАНИЕ: Прочитайте ипросмотрите
все предупреждения, инструкции,
иллюстрации испецификации по данному
электроинструменту. Несоблюдение всех
приведенных ниже инструкций может стать
причиной поражения электрическим током,
возгорания и/или тяжелойтравмы.
СОХРАНИТЕ ВСЕ ИНСТРУКЦИИ ДЛЯ
ПОСЛЕДУЮЩЕГОИСПОЛЬЗОВАНИЯ
Термин «электроинструмент» впредупреждениях
относится кработающим от сети
(проводным) электроинструментам или
работающим от аккумуляторной батареи
(беспроводным)электроинструментам.
1) Безопасность на рабочем месте
a ) Следите за чистотой ихорошим освещением
на рабочем месте. Захламленное или плохо
освещенное рабочее место может стать причиной
несчастногослучая.
b ) Запрещается работать
сэлектроинструментами во
взрывоопасных местах, например, вблизи
легковоспламеняющихся жидкостей, газов
ипыли. Искры, которые появляются при
работе электроинструментов могут привести
квоспламенению пыли илипаров.
c ) Следите за тем, чтобы во время работы
сэлектроинструментом взоне работы
не было посторонних идетей. Отвлекаясь
от работы вы можете потерять контроль
надинструментом.
2) Электробезопасность
a ) Штепсельная вилка электроинструмента
должна соответствовать розетке. Никогда
не меняйте вилку инструмента. Запрещается
Батареи
Зарядные устройства/время зарядки (мин)
Кат. №
пост.тока
Вес
*Код даты 201811475B или новее
**Код даты 201536 или новее
Батареи Зарядные устройства/время зарядки (мин)
Кат. № Vпост. тока Ah Вес (kg) DCB104 DCB107 DCB112 DCB113 DCB115 DCB118 DCB132 DCB119
DCB546 18/54 6.0/2.0 1.05 60 270 170 140 90 60 90 X
DCB547 18/54 9.0/3.0 1.46 75* 420 270 220 135* 75* 135* X
DCB548 18/54 12.0/4.0 1.44 120 540 350 300 180 120 180 X
DCB181 18 1.5 0.35 22 70 45 35 22 22 22 45
DCB182 18 4.0 0.61 60/40** 185 120 100 60 60/40** 60 120
DCB183/B 18 2.0 0.40 30 90 60 50 30 30 30 60
DCB184/B 18 5.0 0.62 75/50** 240 150 120 75 75/50** 75 150
DCB185 18 1.3 0.35 22 60 40 30 22 22 22 X
DCB187 18 3.0 0.54 45 140 90 70 45 45 45 90
DCB189 18 4.0 0.54 60 185 120 100 60 60 60 120
*Код даты 201811475B или новее
**Код даты 201536 или новее

16
PУССКИЙ
электроинструмента он подключен ксети, ипри
этом ваш палец находится на выключателе, это
может стать причиной несчастныхслучаев.
d ) Уберите все регулировочные или гаечные ключи
перед включением электроинструмента.
Ключ, оставленный на вращающейся части
электроинструмента, может привести ктравме.
e ) Не пытайтесь дотянуться до слишком
удаленных поверхностей. Обувь должна быть
удобной, чтобы вы всегда могли сохранять
равновесие. Это позволит лучше контролировать
электроинструмент внепредвиденныхситуациях.
f ) Одевайтесь соответствующим образом.
Избегайте носить свободную одежду
иювелирные украшения. Следите за тем,
чтобы волосы иодежда не попадали под
движущиеся детали. Возможно наматывание
свободной одежды, ювелирных изделий идлинных
волос на движущиесядетали.
g ) При наличии устройств для подключения
оборудования для удаления исбора пыли
необходимо обеспечить правильность их
подключения иэксплуатации. Использование
устройства для пылеудаления сокращает риски,
связанные спылью.
h ) Не позволяйте хорошему знанию от частого
использования инструментов стать причиной
самонадеянности иигнорирования правил
техники безопасности. Небрежное действие
может повлечь серьезные травмы за долюсекунды.
4) Эксплуатация электроинструмента иуход
за ним
a ) Избегайте чрезмерной нагрузки
электроинструмента. Используйте
электроинструмент всоответствии
сназначением. Правильно подобранный
электроинструмент выполнит работу более
эффективно ибезопасно при стандартнойнагрузке.
b ) Не пользуйтесь инструментом, если
не работает выключатель. Любой
инструмент, управлять выключением
ивключением которого невозможно, опасен, иего
необходимоотремонтировать.
c ) Перед выполнением любых настроек,
сменой аксессуаров или прежде чем убрать
инструмент на хранение, отключите его от
сети и/или снимите снего аккумуляторную
батарею, если ее можно снять. Такие
превентивные меры безопасности сокращают риск
случайного включенияэлектроинструмента.
d ) Храните электроинструмент внедоступном
для детей месте ине позволяйте работать
синструментом людям, не имеющим
соответствующих навыков работы стакого
рода инструментами. Электроинструмент
представляет опасность вруках
неопытныхпользователей.
использовать переходники квилкам для
электроинструментов сзаземлением.
Использование оригинальных штепсельных вилок,
соответствующих типу сетевой розетки снижает
риск поражения электрическимтоком.
b ) Избегайте контакта сзаземленными
поверхностями, такими как трубы,
радиаторы ихолодильники. Если вы будете
заземлены, увеличивается риск поражения
электрическимтоком.
c ) Запрещается оставлять электроинструмент
под дождем ивместах повышенной влажности.
При попадании воды вэлектроинструмент риск
поражения электротокомвозрастает.
d ) Берегите кабель от повреждений. Никогда
не используйте кабель для переноски
инструмента, не тяните за него, пытаясь
отключить инструмент от сети. Держите
кабель подальше от источников тепла, масла,
острых углов или движущихся предметов.
Поврежденный или запутанный кабель питания
повышает риск поражения электрическимтоком.
e ) При работе сэлектроинструментом на
открытом воздухе используйте удлинитель,
подходящий для использования на улице.
Использования кабеля питания, предназначенного
для использования вне помещения, снижает риск
поражения электрическимтоком.
f ) Если использование электроинструмента
вусловиях повышенной влажности неизбежно,
используйте устройства защитного
отключения (УЗО) для защиты сети.
Использование УЗО сокращает риск поражения
электрическимтоком.
3) Обеспечение индивидуальной
безопасности
a ) Будьте внимательны, смотрите, что делаете
ине забывайте оздравом смысле при работе
сэлектроинструментом. Запрещается
работать сэлектроинструментом
всостоянии усталости, наркотического,
алкогольного опьянения или под воздействием
лекарственных препаратов. Невнимательность
при работе сэлектроинструментом может
привести ксерьезным телеснымповреждениям.
b ) Используйте индивидуальные средства
защиты. Всегда используйте защитные очки.
Средства защиты, такие как пылезащитная маска,
обувь снескользящей подошвой, каска изащитные
наушники, используемые при работе, уменьшают
риск получениятравм.
c ) Примите меры для предотвращения
случайного включения. Перед тем как
подключить электроинструмент ксети и/или
аккумуляторной батарее, взять инструмент
или перенести его на другое место, убедитесь
втом, что выключатель находится
вположении «Выкл.». Если при переноске

17
PУССКИЙ
  
   

• Используйте защитные наушники. Шум может
стать причиной сниженияслуха.
• Пользуйтесь дополнительными рукоятками,
входящими в комплект поставки инструмента.
Потеря контроля может привести ктравме.
• При выполнении работ, когда есть вероятность
того, что режущий инструмент может
коснуться скрытой проводки или собственного
сетевого кабеля, держите силовой инструмент
за изолированные поверхности. Если вы держитесь
за металлические детали инструмента, то в случае
перерезания находящегося под напряжением провода,
возможно поражение оператора электрическимтоком.
• Убедитесь в том, что под поверхностью
материала не проходят газовые трубы или
электропроводка; уточните их местонахождение
в соответствующихслужбах.
• Используйте зажимы или другие уместные
средства фиксации заготовки на устойчивой
опоре. Удерживание заготовки рукой или прижимание
ее к телу не обеспечивает устойчивости и может
привести к потереконтроля.
e ) Поддерживайте электроинструмент
ипринадлежности висправном состоянии.
Проверьте, не нарушена ли центровка или
не заклинены ли движущиеся детали, нет
ли повреждений или иных неисправностей,
которые могли бы повлиять на работу
электроинструмента. Вслучае обнаружения
повреждений, прежде чем приступить
кэксплуатации электроинструмента, его
нужно отремонтировать. Большинство
несчастных случаев происходит из-за
электроинструментов, которые не обслуживаются
должнымобразом.
f ) Содержите режущий инструмент востро
заточенном ичистом состоянии. Вероятность
заклинивания инструмента, за которым следят
должным образом икоторый хорошо заточен,
значительно меньше, аработать снимлегче.
g ) Используйте электроинструменты,
принадлежности инасадки всоответствии
сданными инструкциями, принимая во
внимание условия работы ихарактер
выполняемой работы. Использование
электроинструмента для выполнения операций,
для которых он не предназначен, может привести
ксозданию опасныхситуаций.
h ) Все рукоятки иповерхности захватывания
должны быть сухими ибез следов смазки.
Скользкие рукоятки иповерхности захватывания
не позволяют обеспечить безопасность
работы иуправления инструментом
внепредвиденныхситуациях.
5) Использование аккумуляторных
электроинструментов иуход за ними
a ) Используйте для зарядки аккумуляторной
батареи только указанное производителем
зарядное устройство. Использование зарядного
устройства определенного типа для зарядки других
батарей может привести квозгоранию.
b ) Используйте для электроинструмента только
батареи указанного типа. Использование других
аккумуляторных батарей может стать причиной
травмы ипожара.
c ) Оберегайте батарею от попадания внее
скрепок, монет, ключей, гвоздей, болтов или
других мелких металлических предметов,
которые могут вызывать замыкание
контактов. Короткое замыкание контактов
аккумуляторной батареи может привести кпожару
или получениюожогов.
d ) При повреждении батареи, из нее может
вытечь электролит. Не прикасайтесь кнему.
При случайном контакте сэлектролитом
смойте его водой. При попадании электролита
вглаза обратитесь за медицинской помощью.
Жидкость, находящаяся внутри батареи, может
вызвать раздражение илиожоги.
e ) Не используйте поврежденные или измененные
аккумуляторные батареи или инструменты.
Поврежденные или измененные аккумуляторные
батареи могут работать непредсказуемо, что
может привести квозгоранию, взрыву или риску
получениятравм.
f ) Не подвергайте аккумуляторные батареи
или инструмент воздействию огня или
повышенной температуры. Открытый огонь
или воздействие высокой температуры выше 130°C
может привести квзрыву.
g ) Следуйте всем инструкциям по зарядке ине
заряжайте аккумуляторную батарею или
инструмент вне температурного диапазона,
указанного винструкции. Неправильная зарядка
или зарядка вне указанного температурного
диапазона может привести кповреждению батареи
иувеличить риск возгорания.
6) Обслуживание
a ) Обслуживание электроинструмента
должен проводить квалифицированный
специалист сиспользованием только
оригинальных запасных частей. Это позволит
обеспечить безопасность обслуживаемого
электрифицированногоинструмента.
b ) Не выполняйте обслуживание поврежденных
аккумуляторных батарей. Обслуживание
аккумуляторных батарей должно выполняться
только производителем или авторизованными
поставщикамиуслуг.

18
PУССКИЙ
 
Зарядные устройства
DeWALT
не требуют регулировки
имаксимально просты виспользовании.
Электробезопасность
Электродвигатель рассчитан на работу только при одном
напряжении сети. Необходимо обязательно убедиться
втом, что напряжение источника питания соответствует
указанному на шильдике устройства. Необходимо также
убедиться втом, что напряжение работы зарядного
устройства соответствует напряжению всети.
Зарядное устройство
DeWALT
оснащено двойной
изоляцией всоответствии стребованиями
EN60335; поэтому провод заземления нетребуется.
Вслучае повреждения кабеля питания его необходимо
заменить специально подготовленным кабелем, который
можно приобрести всервисных центрах
DeWALT
.
Использование удлинительного кабеля
Используйте удлинитель только вслучаях крайней
необходимости. Используйте только утвержденные
удлинители промышленного изготовления, рассчитанные
на мощность не меньшую, чем потребляемая мощность
зарядного устройства (см. Технические характеристики).
Минимальное поперечное сечение провода электрического
кабеля должно составлять 1мм2; максимальная длина 30м.
При использовании кабельного барабана всегда полностью
разматывайтекабель.
Важные инструкции по технике безопасности
для всех зарядных устройств
СОХРАНИТЕ НАСТОЯЩЕЕ РУКОВОДСТВО. Вданном
руководстве содержатся важные инструкции по технике
безопасности для совместимых зарядных устройств (см.
Техническиехарактеристики).
• Перед тем как использовать зарядное устройство,
внимательно изучите все инструкции
ипредупреждающие этикетки на зарядном
устройстве, батарее иинструменте, для которого
используетсябатарея.
ВНИМАНИЕ: Опасность поражения электрическим
током. Не допускайте попадания жидкости
взарядное устройство. Это может привести
кпоражению электрическимтоком.
• Всегда надевайте защитные очки или другое
устройство защиты для глаз. Во время сверления
могут разлетаться кусочки стружки и частицы
материала. Разлетающиеся осколки могут серьезно
повредить глаза. Если во время работы образуется
пыль, надевайте пылезащитную маску или респиратор.
При выполнении многих работ нужно использовать
защитныенаушники.
• Крепко держите инструмент во время работы.
Не пытайтесь работать данным инструментом,
удерживая его одной рукой. При работе
рекомендуется всегда использовать боковую рукоятку.
В противном случае, это может привести к потере
управления. Просверливание или касание таких твердых
материалов, как арматурные стержни, также может
представлять опасность. Перед использованием
надежно затяните боковуюрукоятку.
• Не используйте данный инструмент в течение
длительных промежутков времени. Вибрация,
вызываемая инструментом, может оказывать
вредное воздействие на руки. Используйте перчатки,
для обеспечения дополнительной амортизации и
старайтесь ограничивать вредное воздействие за счет
частых перерывов вработе.
• Не меняйте самостоятельно форму насадок.
Менять форму долота может только авторизованный
специалист. Ошибки в изменении формы могут
привести ктравме.
• Работая с инструментом или меняя насадки,
надевайте перчатки. Выступающие металлические
части инструмента и насадки могут очень
сильно нагреваться во время работы. Частицы
обрабатываемого материала могут стать причиной
травмы незащищенныхрук.
• Никогда не кладите электроинструмент до тех
пор, пока насадка полностью не остановится.
Движущаяся насадка может привести ктравмам.
• Не пытайтесь выбить застрявшую насадку
молотком. Таким образом можно получить травму от
отколовшихся кусочков метала илиматериала.
• Слегка изношенное долото можнозаточить.
• Не доводите насадку до перегрева
(обесцвечивания) при заточке. Сильно изношенные
долота нуждаются в заправке. Не подвергайте долото
повторной закалке илиотпуску.
 
Следующие риски являются характерными при
использовании перфораторов:
• Травмы в результате контакта с вращающимися или
горячими деталямиинструмента.
Несмотря на соблюдение соответствующих инструкций по
технике безопасности и использование предохранительных
устройств, некоторые остаточные риски невозможно
полностью исключить. А именно:
• Ухудшениеслуха.
• Риск защемления пальцев при смененасадок.
• Угроза здоровью вследствие вдыхания пыли,
которая образуется при работе с бетоном и/или
кирпичнойкладкой.
• Риск травм от разлетающихсячастиц.
• Риск получения ожогов в результате нагревания
инструмента в процессеработы.
• Риск получения травмы в результате
продолжительнойработы.
СОХРАНИТЕ НАСТОЯЩЕЕ РУКОВОДСТВО
