Diamond SNE/RN-B7-R2 User manual

12/2021
Mod: SNE/RN-B7-R2
Production code: RD 60 TN_

NOTICE D’UTILISATION
VITRINE VERTICALE REFRIGEREE 60 80 FIXE ET 60
TOURNANTE
INSTRUCTIONS FOR INSTALLATION AND USE
FIXED 60 80 AND ROTATING 60 VERTICAL COOLING
DISPLAY

10
FIXED 60 80 AND ROTATING 60 VERTICAL COOLING
DISPLAY
Congratulations for purchasing this top end professional equipment! You have chosen
equipment that combines optimum technical properties with extreme user comfort.
We want you to get the greatest possible satisfaction out of this equipment.
1. SAFETY INSTRUCTIONS
Please respect these instructions scrupulously to avoid any risk of fire,electric
shock, scald or other wounds and damage. During the use of this appliance,
fundamental circumspection of security must always be noticed, such as :
- Take into account the instructions to be systematically kept with the
appliance.
- Install the appliance always in instructions respect.A 10 cmdistance
minimum with the partition or the wall is necessary.
- Protect the appliance from direct light of the sun, frost and humidity.
- Never leave the appliance within the reach of children or disabled
persons without surveillance.
- The machine has to be used only by qualified person.
- Never move the appliance when it is working.
- Check that the appliance is definitely off before connecting it up or
disconnecting it.
- Do not touch the hot surfaces of the appliance. The temperature of
the hot surfaces can be very important when the appliance is working.
Always use handles and control knobs.
- Do not use the appliance for other functions than determined use.
- Do not leave the electrical cord in contact of hot surfaces.
- The appliance should not be used close to combustible materials.
- During use, look after not to obstruct hearings of aeration of the
appliance
- To avoid any electric shock, never plunge the cord or plug in water
or quite other liquid.
- If the cord is harmed, it must be replaced by the producer, its after
sale service or persons of similar skills to avoid any risk.
- Entrust repairs only to a skilled person.
- Use only spare parts of origin.
- Before cleaning the appliance, do not forget to disconnect it.

11
2. CONTENTS OF CARDBOARD PACKAGING
Device : -Cooling Display 4 faces
-2 wooden ramps
Accessories : -5 grids (60 fixed display)
-5 glasses (80 fixed display)
-4 glasses and 1 mirror glass (60 rotating display)
-Technical documentation of the thermostat
-The present note
3. CONFORMITY OF USE
The device allows you to keep the temperature of your products between 2°C to 10°C
(desserts, cakes, pies, cocktails, etc…)
To take shelter from light is very important for hygiene and it lasts the storage of
foodstuff. The light generates a photochemical reaction on the food, which causes
discoloration, loss of flavour and alimentary characteristics.
In order to soften this phenomenon, don’t expose the machine at the sun.
4. WAY OF FUNCTIONING
The cooling display keeps food at a constant temperature of 2°C pre-adjusted in the
factory.
Press on the switch (n°3 on picture), the machine is on. The preset electronic
thermostat (n°2 on picture) flashes and displays the temperature. Press on the switch
(n°1 on picture) to turn on light and active and activate rotating shelves if rotating
display.
1
2
3
1
2
3
LED Lighting Switch
On / Off Switch
Electronic Thermostat

12
5. FUNCTIONING / MANIPULATION
a) Installation / Assembly :
-Place the equipment on a stable surface.
-Position the accessories
-A distance of 10 cm from the partition or the wall is considered enough.
- Never place the device near a wall or near a partition made of combustible
materials even if it is very well isolated.
- Caution : the display cooling must not be exposed at the sun.
b) First starting :
First cleaning
Clean the device before the first use. (See 6. Cleaning)
Connection of the device
-Make sure that the voltage and frequency of the electrical system comply with
the values indicated on the nameplate.
-Always check that the electric power supply cable or plug are free of damage.
-Make sure that every control knob is positioned on 0.
-Remove the flange at the bottom left (when facing the display) to pay out the
entire length of the cord and feed it through the square hole then close it before
inserting the plug into the socket.
-Connect the electric power supply cable to a socket with a protection wire.
-The display is now connected.
NB: To connect the display to a socket without any protection wire, or to connect
directly to the electrical system, ask for a qualified electrician to make the
connection.
c) Use of device :
Elements of command and display
Command/Display Function
Electronic thermostat (n°1 on picture) Temperature setting
Switch 0/I (n°2 on picture) Light On/Off + turning plate (rotating model)
Switch 0/I (n°3 on picture) On/Off

13
Starting
- Press on the on/off switch (n°3 on picture) to start the unit. The electronic
thermostat turns on.
- Wait for the unit to be at the right temperature (stop of the compressor).
- Press on the light switch (n°2 on picture) to start the light and activate rotating
plate (rotating model)
Temperature setting
The electronic thermostat is preset in factory. It can be adjusted if necessary.
To modify the temperature, refer to the technical documentation of the
thermostat.
Regulation of defrost
The defrost is an important operation for ventilated refrigerating displays.
A homogeneous temperature is ensured thanks to the air circulation through the
evaporator. This evaporator has a negative temperature when the compressor is
working. In this way, its blades “trap” the humidity as frost, and the air of the
chamber dries. If there is too much frost, the air cannot circulate through the
evaporator and the internal temperature rises.
In order to avoid this phenomenon, the defrost programmed in the factory stops the
compressor 10 min every 2 hours.
These values canbe adjusted by your technician. It depends onthe type of products
presented in the refrigerating display, on the use and the environment.
Stopping the machine at night or on closing days is recommended for total defrost
§10.
Stopping the appliance
Set each switch (n°2 and 3 on picture) on 0: the appliance is no longer
functioning.
Disconnect the power supply cable.
Clean the appliance. (See 6. Cleaning)

14
d) Breakdown / repair :
In case of breakdown or of damaged part, please call your after-sales service and
confide any technical operation to a qualified person.
When you contact the after-sales service of your distributor or your store, provide
him with the complete reference of your device (commercial name, type and serial
number). This information appears on the visible descriptive plate on the side of the
device.
6. CLEANING AND MAINTENANCE
- Disconnect the device
Every week:
- remove the dust from the condenser using a vacuum cleaner. To access,
remove the front grid from the cooling display.
- Clean the condensate evaporation pan using sponge. To access, remove the
side grill.
- Clean regularly the metallic parts after each use by using only use non-abrasive
products, warm water and wash liquid: avoid the abrasive toweling. Rinse your
device with a wet sponge and dry it with a soft cloth.
- Dry the device with a clean soft cloth.
- Never clean the device under a water jet, the infiltrations would risk to damage it in
an irreparable way.
- Never immerse the cord or the plug in the water or quite other liquid to avoid any
electric shock.
CAUTION : In places with a high rate of humidity (>60%), it is obligatory to
proceed to a total defrost every week.
7. TECHNICAL SPECIFICATIONS
Model FIXED COOLING DISPLAY
60
ROTATING
COOLING
DISPLAY 60
FIXED COOLING
DISPLAY
80
Effective Volume 360 l 360 l 480 l
Dimensions 600x630x1850 mm 600x630x1850 mm 800x630x1850 mm
Weight 130 Kg 135 Kg 190 Kg
Power 430 W 460 W 430 W
Gas R 290 R 290 R 290
Temperature 2° à 10° C 2° à 10° C 2° à 10° C
Voltage 220-240 V ~ 220-240 V ~ 220-240 V ~
Frequency 50-60 Hz 50-60 Hz 50-60 Hz
Shelfs 435 x 495 (x5) 470 (x5) 465 x 620 (x5)
Climatic Level about
compressor and
condensor Tropicalised Tropicalised Tropicalised
Maximum weight/grid 10 kg 10 kg 10 kg

15
8. GUARANTEE
Conditions of guarantee
The guarantee applicable to any device is the commercial guarantee of the
distributor or the retailer. Please contact the store where you bought your device to
know the precise conditions.
The guarantee grants no right for damages.
The dispositions which follow are not exclusive of the profit of the legal guarantee
planned by articles 1641 and following ones of the Civil code relative to the defects
and the latent defects.
Exclusion clauses of the guarantee
The equipment travels at the risk of the user; in the case of delivery by carrier,
the consignee must make reservations vis-à-vis the carrier before any delivery
of the device. Without reserve no recourse will be possible.
Shocks transport.
Incorrect installation of the device.
Incorrect use of the device.
Non-compliance with the instructions in this user manual.
False maneuvers.
Inappropriate uses.
Improper maintenance of the device.
Electric shock. (Thunderstorm, Lightning, Overvoltage, Under Power)
Overloading the device.
The warranty terminates in case of intervention, repair, modification by
unqualified persons, or use for improper purposes.

16
9. MAINTENANCE GUIDE
ANOMALIE CAUSE REMEDE
The display does not start Thermostat stopped Switch on position « on»
plug not plugged Check the plug
The display does not stop No refrigerating power Clean the condenser
The display does not
regulate Helicoïd ventilator is blocked Remove foreign or Eventually replace the ventilator
The temperature rises up Presence of ice Make a total defrost §10
Presence of water droplets
on the top Appearance of ice Make a total defrost §10
Presence humidity marks on
the display High level of humidity in the air
It is a normal atmospheric
phenomenon.
The phenomenon will disappear
on its own.
Presence of condensation
on the display Display in defrost phase Normal The phenomenon will disappear on its own.
Presence of water under the
display Container for condensation particles is full, total defrost too late
Empty and clean the container
and reposition the holds
10. REALIZING A TOTAL DEFROSTING
- Empty the window.
- Stop the showcase.
- Open the door of the window.
- Leave it out of operation for 24 hours.
- Wipe off water marks.
- Empty the evaporation water tank located behind the front grill.
- Clean the condenser.
