Diggs Evolv Modern Dog Crate Quick guide

Evolv
Modern Dog Crate
Additional Configuration
Instructions
Designed for Better Bonds
1.0 Installing Second Side Door
2.0 Installing Back Door
3.0 Converting to Playpen mode
4.0 Converting to Den mode

Video: Installing Second Side Door Instruction
Part/tools needed
Instructions
Assembled Evolv Crate
Extra Side Door Panel
Extra Edge Connectors
Philips Head Screwdriver (not included)
1.0 Installing Second Side Door
Designed for Better Bonds
Open the front door and remove the tray and anything else inside
the crate (eg. Bolstr pad, Crate Bowl with Clip, Groov, etc.).
If installed, also remove the puppy divider.
1
Close the front door and unlock and remove the four (4) corner
pieces that hold the ceiling in place. Set these pieces aside.
2

Remove the ceiling panel.
3
1.0 Installing Second Side Door
Designed for Better Bonds
4Flip your crate over so the open base panel is facing upward.
For the Intermediate and Large crate sizes we recommend 2
people flip the crate.

Unlock and remove the four (4) corner pieces that hold the open
base in place.
5
Remove the base panel and set aside.
6
1.0 Installing Second Side Door
Designed for Better Bonds

Remove the side panel without a door by sliding it out of the
edge connectors that connect it to the front and back panels.
7
On the new side door, remove the edge connectors using a
phillips head screwdriver. We recommend opening the door
to allow better access.
8
1.0 Installing Second Side Door
Designed for Better Bonds

1.0 Installing Second Side Door
Designed for Better Bonds
In the bag of extra edge connectors, find the connectors that match
the ones shown below. Please note you will need 2 of each for
Intermediate and Large sizes.
9
Screw these edge connectors into the new side door panel in the
orientation shown below. Be sure to pay extra attention to both the
orientation of the connectors and the orientation of the panel.
10

Install the new side door by sliding it into the edge connectors.
There is only one orientation where the edge connectors can be
properly aligned with the rest of the assembly.
11
Re-install the open base panel and its four (4) base corner connectors.
Make sure that the feet are oriented upwards.
12
1.0 Installing Second Side Door
Designed for Better Bonds

Flip your crate over. For Intermediate and Large size crates,
we recommend getting help from a second person.
13
Place the tray back into your crate along with any other accessories
you removed in step 1.
14
1.0 Installing Second Side Door
Designed for Better Bonds

Re-install the ceiling panel and its four (4) corner connectors.
15
1.0 Installing Second Side Door
Designed for Better Bonds

Part/tools needed
Instructions
Assembled Evolv Crate
Extra Front/Rear Door Panel
Extra Edge Connectors
Philips Head Screwdriver (not included)
2.0 Installing Back Door
Designed for Better Bonds
Open the front door and remove the tray and anything else inside
the crate (eg. Bolstr pad, Crate Bowl with Clip, Groov, etc.).
If installed, also remove the puppy divider.
1
Close the front door and unlock and remove the four (4) corner
pieces that hold the ceiling in place. Set these pieces aside.
2

Remove the ceiling panel.
3
2.0 Installing Back Door
Designed for Better Bonds
4Flip your crate over so the open base panel is facing upward.
For the Intermediate and Large crate sizes we recommend 2
people flip the crate.

Unlock and remove the four (4) corner pieces that hold the open
base in place.
5
Remove the base panel and set aside.
6
2.0 Installing Back Door
Designed for Better Bonds

Now remove the back panel by sliding it out of the edge
connectors that connect it to the two side panels.
7
On the new door, remove the edge connectors using a
phillips head screwdriver. We recommend opening the door
to allow better access.
8
2.0 Installing Back Door
Designed for Better Bonds

2.0 Installing Back Door
Designed for Better Bonds
In the bag of extra edge connectors, find the connectors that match
the ones shown below.
9
Screw these edge connectors into the new door panel in the
orientation shown below. Be sure to pay extra attention to both the
orientation of the connectors and the orientation of the panel.
10

Install the new door panel by sliding it into the edge connectors. There
is only one orientation where the edge connectors can be properly
aligned with the rest of the assembly.
11
Re-install the open base panel and its four (4) base corner connectors.
Make sure that the feet are oriented upwards.
12
2.0 Installing Back Door
Designed for Better Bonds

Flip your crate over. For Intermediate and Large size crates,
we recommend getting help from a second person.
13
Place the tray back into your crate along with any other accessories
you removed in step 1.
14
2.0 Installing Back Door
Designed for Better Bonds

Re-install the ceiling panel and its four (4) corner connectors.
15
2.0 Installing Back Door
Designed for Better Bonds

Video: Converting to Playpen mode
Part/tools needed
Instructions
Assembled Evolv crate
Playpen Ceiling Panel
3.0 Converting to Playpen mode
Designed for Better Bonds
Open the front door and remove the tray and anything else inside
the crate (eg. Bolstr pad, Crate Bowl with Clip, Groov, etc.).
If installed, also remove the puppy divider.
1
Close the front door and unlock and remove the four (4) corner
pieces that hold the ceiling in place. Set these pieces aside.
2

Remove the ceiling panel.
3
3.0 Converting to Playpen mode
Designed for Better Bonds
4Replace the mesh ceiling panel with the Playpen Ceiling Panel.

Reinstall the four (4) corner connectors.
5
3.0 Converting to Playpen mode
Designed for Better Bonds
