HSDPA 7.2/HSUPA 2Mega & ADSL2+ Router
3G BACK-UP - Code 8D5632
lConnect your LAN to the Internet via UMTS
lDownload speed up to 7.2M and Upload up to 2M
lYour ADSL always online with the 3.5G Backup function
lBuilt-in 54 Mbps Wi-Fi module
lWeb based conguration
DESCRIPTION
3G Back-Up is a latest generation HSDPA router totally integrated. It is
equipped with a 3G module that integrates the maximum performances
of the mobile UMTS network.
In particular, thanks to the HSDPA and HSUPA technologies the
download speed can reach the 7.2 Mbps, while the upload speed is up
to 2 Mbps.
3G Back-up is ideal in all those applications that require performing
transmissions (for example when sending large size mail attachments)
and mainly in video applications or for the back-up of ADSL o SHDSL
lines.
3G Back-up is also an ADSL 2/2+ router with speed up to 24Mbps.
With a sole device it is possible to carry out Back-up applications of
the ADSL line with an integrated device, making easier the coexistence
of 2 gateways on the same network and no need to recongure the LAN
PCs.
With 3G Back-Up you will perform 3 different connection types: ADSL,
3.5G or ADSL with backup over HSDPA.
You can also add a rechargeable backup battery for a continuous operation of your Gateway even if the power line
falls down.
The implementation of the Remote Activation function offers the possibility to remote enable the connection.
When a specic SMS is received or a phone number is detected (CLI), 3G Back-up will connect for a time set by the
user.
Furthermore 3G Back-up can be set to intercept E-mails received in LAN enabling the 3G connection and it can send
an SMS.

For further information
visit our website
http://www.digicom.it
TECHNICAL FEATURES
Wireless WAN
l3G Gateway for Back Up and/or 3G Router applications
lUMTS technology with HSDPA Category 8 (7.2 Donwnlink)
lHSUPA Category 5 (2.0 Uplink upgradable uo to 5.76 Mbps)
lEDGE/GPSR Class 12
lBands: UMTS 2100MHz
lBands: EDGE/GPRS/GSM 850/900/1800/1900MHz
Hardware
lWeb based local and remote configuration
lLAN: 1 10/100 Ethernet port
lSize: 230 x 133 x 65 mm (exclusive of antennas)
lReset to Factory Default button
l12VDC/1.2A external power supply (range 10-14.5V)
lStandby consumption: 672mA - 770mA
Maximum consumption 840mA
l1 SIM holder
lOperating temperature 0-40 ºC
lNon-condensig humidity: 20-95%
lBattery Back-up (optional) Li-ion
lCE Mark
Network Functionalities
lFull Routing IP (static and dynamic, NAT, Dynamic DNS (DDNS)
lFirewall (SPI) and protection from DoS attackes, Packet
Filtering, URL content
lDMZ, Virtual Server, VPN Pass-through
lVPN IPSec (1 tunnel), DES, 3DES, AES, MD5, SHA1
lDHCP Server/Client support
Wireless LAN
lWireless up to 54Mbps (IEEE802.11g, b)
l64/128 bit WEP , WPA-PSK/WPA2-PSK encryption
Management
lWEB based local/remote configuration and management
lWEB based Firmware upgrade
ADSL
lBuilt-in ADSL 2/2+ router
lStandards: ADSL2+, G.dmt bisplus (ITU G.992.5); ADSL 2
G.dmt.bis (ITU G.992.3), Full.rate ANS T1.413 Issue 2, G.dmt
(ITU G.992.1), G.Lite (ITU G.992.2) G.hs (ITU G.994.1), ATM
Adaptation Layer Type 5 (AAL5)
lMultiple Protocol over AAL5 (RFC 2684 Formely RFC 1483);
Bridge or Routed Ethernet encapsulation, VC and LLC based
mux PPP over Ethernet (PPPoE) and PPP over ATM (PPPoA)
MANAGEMENT AND CONFIGURATION
3G Back-Up can be setup and managed via WEB
interface, apart from the operating system.
INTERNET
ADSL
Firewall
3G Backup
Computer
Wireless
Camera
UMTS
