DG-WM2001SI User Manual
1
DG-WM2001SI
DIGISOL802.11N 300MBPS CEILING AP, 1 X FE 802.3AF POE
User Manual
V1.0
2015-09-26
As our products undergocontinuous development the specifications are subject to changewithout prior notice

DG-WM2001SI User Manual
2
COPYRIGHT
Copyright 2015 by Smartlink Network Systems Ltd.All rights reserved. No part of this
publication may be reproduced, transmitted, transcribed, stored in a retrieval system,
or translated into any language or computer language, in any form or by any means,
electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the
prior written permission of this company.
This company makes no representations or warranties, either expressed or implied,
with respect to the contents hereof and specifically disclaims any warranties,
merchantability or fitness for any particular purpose. Any software described in this
manual is sold or licensed "as is". Should the programs prove defective following their
purchase, the buyer (and not this company, its distributor, or its dealer) assumes the
entire cost of all necessary servicing, repair, and any incidental or consequential
damages resulting from any defect in the software. Further, this company reserves
the right to revise this publication and to make changes from time to time in the
contents thereof without obligation to notify any person of such revision or changes.
Trademarks:
DIGISOL™ is a trademark of Smartlink Network Systems Ltd. All other trademarks
are the property of the respective manufacturers.
Safety
This equipment is designed with the utmost care for the safety of those who install
and use it. However, special attention must be paid to the dangers of electric shock
and static electricity when working with electrical equipment.All guidelines of this and
of the computer manufacturer must therefore be allowed at all times to ensure the
safe use of the equipment.

DG-WM2001SI User Manual
3
Content
Chapter 1 Introduction...............................................................6
1.1 Overview........................................................................................................6
1.2 Get Familiar with your new indoor Access Point ...............................6
1.3 Installation Precautions.............................................................................7
1.4 Installation Environment Requirements................................................7
1.5 Equipment Accessories.............................................................................7
1.6 Installation Tools .........................................................................................8
1.7 Login Web Network Management...........................................................9
1.8 Quit Web Network Management........................................................... 10
1.9 Introduction to Page Layout of Web Network Management..........11
1.10 Introduction to Web Network Management Function................... 12
1.11 Introduction to Common Controls of Web Page............................13
1.12 Usage Restriction of Web Network Management..........................13
Chapter 2 Basic Configuration................................................15
2.1 Detailed Explanation of settings ..........................................................16
2.1.1 Description of this Access Point .........................................................16
2.1.2 Device Information ...............................................................................16
2.1.3 Administrator Password.......................................................................17
2.1.4 Serial Settings.......................................................................................17
2.1.5 System Settings....................................................................................17
Chapter 3 Current Status .........................................................18
3.1 Network Information................................................................................18
3.1.1 Wired Settings ......................................................................................18
3.1.2 Wireless Settings..................................................................................20
3.1.3 Explanation...........................................................................................20
3.2 Statistic for Transmitting and Receiving IP Traffic.......................... 20

DG-WM2001SI User Manual
4
3.2.1 Device Information Status....................................................................20
3.2.2 Transmit/Receive Packets....................................................................22
3.3 Client Associations.................................................................................. 23
Chapter 4 Advance Configuration..........................................25
4.1 Ethernet Settings...................................................................................... 25
4.2 Wireless Settings...................................................................................... 27
4.3 RF Parameters........................................................................................... 28
4.4 Virtual AP....................................................................................................30
4.4.1 None Security Configuration ...............................................................31
4.4.2 Static WEP Security Configuration......................................................32
4.4.3 WPAPersonal Security Configuration.................................................33
4.4.4 WPAEnterprise Security Configuration..............................................34
4.4.5 WDS.......................................................................................................35
4.5 AP Modes....................................................................................................36
Chapter 5 System Maintenance..............................................37
5.1 Configuration Management ...................................................................37
5.2 Firmware Upgrading................................................................................ 39
Chapter 6 Configuration Examples........................................42
6.1 Laws Wireless Access ............................................................................ 42
6.1.1 Networking Requirements....................................................................42
6.1.2 Configuration Steps..............................................................................42
6.1.3 Test the Configuration Results............................................................44
6.2 Cipher Wireless Access of Static-WEP (Open-System)................. 44
6.2.1 Networking Requirements....................................................................44
6.2.2 Configuration Steps..............................................................................44
6.2.3 Test the Configuration Results............................................................46
6.3 WPA2-PSK Wireless Access.................................................................. 46

DG-WM2001SI User Manual
5
6.3.1 Networking Requirements....................................................................46
6.3.2 Configuration Steps..............................................................................47
6.3.3 Test the Configuration Results............................................................48
6.4 WPA2-Enterprise Wireless Access...................................................... 48
6.4.1 Networking Requirements....................................................................48
6.4.2 Configuration Steps..............................................................................49
6.4.3 Test the Configuration Results............................................................51

DG-WM2001SI User Manual
6
Chapter 1 Introduction
1.1 Overview
For the network administrator to configure and maintain to devices, this device provides
WEB network management function. The administrator can use WEB interface to manage
and maintain the network devices visually.
The running environment of Web network management is shown in fig 1-1.
Fig 1-1 Web The running environment of Web network management
1.2 Get Familiar with your new indoor Access Point

DG-WM2001SI User Manual
7
1.3 Installation Precautions
Only allow the professionals installing and disassembling the device and its annex. Before
the installation and configuration, please read the related security introduction carefully.
Adopt the appropriate security measures to avoid the personal injury and
equipment damage.
Please put the device on the dry and flat place and ensure the anti-skid
measures.
Keep the device clean without dirt.
Do not place the device on a wet place and avoid the device touching anyliquids.
Do not put the device and the installation tools in the walking area.
1.4 Installation Environment Requirements
Before the installation, please check the installation conditions of the device to make sure
that the device is in good operating environment for a long time. Check this with the
following aspects:
The temperature and humidity environment requirements of the device are as below:
Table 1-1 The temperature and humidity index
Items
Range
Standard working environment temperature (indoor)
-10℃～55℃
Storage temperature
-40℃～70℃
Working humidity (non-condensing)
5%～95%
1.5 Equipment Accessories
Please refer to the packing list.

DG-WM2001SI User Manual
8
Package Contents
Before you start using this AC, please check if there’s anything missing in the package,
and contact your dealer of purchase to claim for missing items:
DG-WM2001SI (1 No.)
M3.5 Plastic stopper (4 Nos.)
Wall mounting bracket (1 No.)
T-Keel Mounting Kit (1 No.)
M3 fixing screws (3 Nos.)
M3 bolt (2 Nos.)
1.6 Installation Tools
When installing the indoorAP, the following tools may be used (user-owned).
Horizontal
ruler
Permanent
marker
Knife
Wire
stripper
Network pliers
Impact drill (1)
and some
supporting drills
Rubber
hammer
Phillips
screwdriver
Ladder

DG-WM2001SI User Manual
9
1.7 Login Web Network Management
User can use the default information directly to login the web interface of the device.
The default Web login information includes:
User name: admin
Password:
IP address of the device: 192.168.1.10
The steps of web login:
(1) Connect the device to PC.
Use the cable to connect PC to the Ethernet interface of the device.
(2) Configure the IP address for PC and ensure that it can communicate with the device.
For example: Modify the IP address to 192.168.1.0/24.
(3) Launch the browser and input the login information.
Launch the browser on PC, and input “http://192.168.1.10” in the address bar and then
enter it. Enter into the web login page as shown in fig 1-2. Input the user name as admin
and password as blank, click “login”to login.

DG-WM2001SI User Manual
10
Fig 1-7 Web network management login page
1.8 Quit Web Network Management
Click the “log off”button on the upper right corner on the Web network management page
to quit.

DG-WM2001SI User Manual
11
1.9 Introduction to Page Layout of Web Network
Management
Web network management page includes: navigation bar, configuration area and help
area as shown in fig 1-8.
Fig 1-8 Initial page of Web network management
Navigation bar: Organize the Web network management menu by using the navigation
tree. User can choose the function menu in the navigation bar and the result will be shown
in the configuration area.
Configuration area: User can configure and check.
Help area: It provides the basic help information. The “more”button can check more help
information. And it provides the “log off”button to quit.

DG-WM2001SI User Manual
12
1.10 Introduction to Web Network Management
Function
The Web network management function explanation is given below in table 1-1:
Table 1-10 Web network management function explanation
Menu/label
Function explanation
Basic settings
Shows the AP address (IP address and MAC address),
version (firmware version) and device information. The
administrator password, serial ports configuration and
system settings can be configured.
Status
Network interface
Shows the real-time wired and wireless configuration of AP.
Transmit/Receive
Shows the virtual AP, enabling situation and the statistic of
transmitting and receiving packets of AP.
Client
association
Shows the information of transmitting and receiving packets
of the client which has been associated with AP.
Advance
Configuration
Ethernet settings
Configure the related wired configuration of AP including
host name, management vlan, untagged vlan, DHCP, static
IP and DNS server.
Wireless settings
Configure the related wireless configuration of AP including
country code, radio interface, physical mode and channel.
RF parameters
Configure the detailed RF parameters including radio
interface, physical mode, channel, channel bandwidth,
primary channel, supporting short protection interval or not,
STBC mode, protection, beacon frame interval, DTIM
interval, fragment threshold, RTS threshold, maximum
stations, transmission power, multicast rate and supported
rate.
Virtual AP
Configure the authentication mode of virtual AP and the

DG-WM2001SI User Manual
13
related configuration.
Modes of AP
Configure the modes and IP address of AP.
System
maintenance
Configuration
management
Configure to restart AP and restore it to the factory
configuration. Import and export the files.
Firmware
upgrading
Configure the firmware upgradation of AP.
1.11 Introduction to Common Controls of Web Page
1. <Update> button
Click < Update> button to submit the input information.
2. <Refresh> button
Click <Refresh> button to refresh the information of the current page.
1.12 Usage Restriction of Web Network Management
(1) The operating systems supported by Web network management include: Windows XP,
Windows 2000, Windows Server 2003 Enterprise Edition, Windows Server 2003 Standard
Edition, Windows Vista, Windows 7, Linux and MAC OS.
(2) The browsers supported by Web network management include: Microsoft Internet
Explorer 6.0 SP2 and the versions above, Mozilla Firefox3.0 and the versions above,
Google chrome and Safari.
(3) Web network management does not support the “previous”, “next”and “refresh”
buttons from the browser. Using these buttons may cause the unusual page showing.
(4) Because the firewall of the Windows operating system will limit the number of
connected TCP, there will be the situation that the page cannot be opened when using
web network management occasionally. For avoiding this situation, we suggest to close
the firewall of the Windows.
(5) After the software version of the device has changed, we suggest to clear the cache

DG-WM2001SI User Manual
14
data of the browser first during login the device through web network management.
Otherwise, the content of web network management may not be shown normally.

DG-WM2001SI User Manual
15
Chapter 2 Basic Configuration
Shows the basic configuration of the device and it includes the following content:
Review description of this access point, Device information; Administrator password;
Serial settings and System settings.

DG-WM2001SI User Manual
16
2.1 Detailed Explanation of settings
2.1.1 Description of this Access Point
Field
Description
IP Address
Shows the IP address of the current device.
IPv6 Address
Shows the IPv6 address of the current device.
IPv6 Autoconfigured Global Addresses
Shows the IPv6 auto configuredglobal address of
the current device.
IPv6 Link Local Address
Shows the IPv6 link local address of the current
device.
MAC Address
Shows the MAC address of the current device.
Firmware Version
Shows the firmware version of the current device.
2.1.2 Device Information
Field
Description
Product identifier
Shows the product ID of the current device.
Hardware version
Shows the hardware version of the current
device.
Serial number
Shows the serial number of the current
device.
Device name
Shows the device name of the current
device.
Device description
Shows the device description of the current
device.

DG-WM2001SI User Manual
17
2.1.3 Administrator Password
Field
Description
Current password
Input the current administrator password.
Newpassword
Input the new password.
Confirm new password
Input the new password again and it must
be same as the above new password.
2.1.4 Serial Settings
Field
Description
Baud Rate
Configure the baud rate of the serial ports.
2.1.5 System Settings
Field
Description
System name
Configure the system name.
System contact
Configure the contact.
System location
Configure the device location.

DG-WM2001SI User Manual
18
Chapter 3 Current Status
The current status includes network information, statistic of transmitting and receiving
packets and the client association.
3.1 Network Information
3.1.1 Wired Settings
Field
Description
MAC address
Shows the MAC address of the current
device.
Management VLAN ID
Shows the vlan ID of the current device.
IP address
Shows the IP address of the current device.

DG-WM2001SI User Manual
19
Subnet mask
Shows the subnet mask of the current
device.
IPv6 Address
Shows the IPv6 address of the current
device.
Static IPv6 Address Prefix Length
Shows the prefix length of static IPv6
address.
IPv6 Auto configured Global Addresses
Shows the IPv6 auto configured global
addresses of the current device.
IPv6 Link Local Address
Shows the IPv6 link local address of the
current device.
IPv6 DNS Server-1
Shows the IPv6 DNS server-1 of the current
device.
IPv6 DNS Server-2
Shows the IPv6 DNS server-2 of the current
device.
Default IPv6 Gateway
Shows the default IPv6 gateway of the
current device.
DNS-1
Shows the IP address of DNS-1 server of
the current device.
DNS-2
Shows the IP address of DNS-2 server of
the current device.
Default gateway
Shows the default gateway of the current
device.

DG-WM2001SI User Manual
20
3.1.2 Wireless Settings
Field
Description
MAC address
Shows the MAC address information of
RF1 or 2.
Mode
Shows the wireless mode information of
RF1 or 2.
Channel
Shows the channel information of RF1 or 2.
3.1.3 Explanation
Click the “Edit”link in the wired and wireless configuration to link to the wired and wireless
configuration page directly.
3.2 Statistic for Transmitting and Receiving IP Traffic
3.2.1 Device Information Status
Shows all the physical ports and the status of virtual AP.
